Manage Client Certificates - Softing dataFEED Series User Manual

dataFEED Gateway - User Manual

4.2.4 Manage Client Certificates

The Manage Client Certificates view supports the the management of existing certificates, the upload of new
certificates and the display of certificate properties in a table.
For a certificate of an OPC UA Client to become trusted (from view of the OPC UA Server in the dataFEED
Gateway) the following conditions need to be fulfilled:
1. The certificate is digitally signed and the whole chain of certificates used for signing is available to the
dataFEED Gateway. It is either stored in the CA (Certificate Authority) folder or in the Trusted certificates
folder (see below).
2. The certificate is stored in the dataFEED Gateway. Self-signed certificates need to be stored in the Trusted
certificates folder to become trusted. This classification stays valid unless a certificate is declared not
trusted.
3. In addition, it is checked for user authentication that the certificate is not stored in the Rejected certificates
folder in the dataFEED Gateway.
Upload new certificate
To ease certificate management, the OPC UA Server in the dataFEED Gateway stores each new client certificate
in the New certificates folder using the binary DER format. Additional DER format certificates can be uploaded in
the dataFEED Gateway using the Browse... button.
Declare a certificate trusted
To declare a certificate trusted, move it into the Trusted certificates folder. To do so, select the certificate and
click the Move to trusted folder (
Note
Check the certificate's fingerprint to make sure you declare the correct certificate trusted.
Declare a certificate not trusted
To exclude a certificate from being trusted, remove it from the Trusted certificates folder. To do so, select the
certificate and delete it by clicking the Delete certificate ( ) button or move it to the Rejected folder by clicking
the Move to rejected folder (
Note
If the certificate is deleted, it may reappear in the New certificates folder, if the certificate owner
tries to re-connect.
Manage certificate authorities certificates
The certificates of certificate authorities (CA) are certificates that are required to verify that (not self-signed)
certificates in the Trusted Certificates folder are valid. These certificates are uploaded in the dataFEED
Gateway as follows:
1. Upload the DER format certificate into the New certificates folder (see above).
2. Select the uploaded certificate and click the Move to certificate authority (CA) (
CA folder.
14
) button.
) button.
) button to move it to the
© Softing Industrial Automation GmbH
