dataFEED Gateway - User Manual

2.6 Powering up the Device

Turn on the power supply. The boot process takes a few seconds.
For an indication of proper operation of the dataFEED Gateway refer to

2.7 Resetting the Device

If the dataFEED Gateway cannot be reached e.g. due to an error in the configuration, use the reset button at the
lower front side of the device. This will reset the dataFEED Gateway to the factory settings.
Reset the configuration to factory defaults
1. Disconnect the dataFEED Gateway from the power supply.
2. Re-connect it to the power supply and hold down the reset button until the LEDs SYS, RUN and ERR light up
red for about one second.
Hint
To prevent the device from accidental configuration reset, the reset button is only active for a short
period during reboot.
8
40
LED Status Indicators
