Technical specifications
50-60Hz data
Tandem and trios
Model
DSH482
DSH535
DSH590
DSH620
DSH675
DSH725
DSH760
DSH780
DSH865
50Hz DSH970
DSH420
DSH483
DSH552
DSH720
DSH885
DSH1140
DSH1245
DSH1350
DSH1455
DSH482
DSH535
DSH590
DSH620
DSH675
DSH725
DSH760
DSH780
DSH865
60Hz DSH970
DSH420
DSH483
DSH552
DSH720
DSH885
DSH1140
DSH1245
DSH1350
DSH1455
 Displacement at nominal speed: 2900rpm at 50Hz, 3500rpm at 60Hz
 Net weight with oil charge
TR: Ton of Refrigeration, Standard rating conditions
EER: Energy Efficiency Ratio Refrigerant: R410A
COP: Coefficient Of Performance
Subject to modification without prior notification.
Data given for motor code 4 compressor with above condition, for full data details and capacity tables refer to Coolselector®2
www.coolselector.danfoss.com
Nominal
tons 60Hz
Composition
TR
2xDSH240 40.0
DSH240 + DSH295 45.0
2xDSH295 50.0
DSH240 + DSH381 50.0
DSH295 + DSH381 55.0
DSH240 + DSH485 60.0
2xDSH381 60.0
DSH295 + DSH485 65.0
DSH381 + DSH485 70.0
2xDSH485 80.0
3xDSH140 35.0
3xDSH161 39.0
3xDSH184 44.0
3xDSH240 60.0
3xDSH295 75.0
3xDSH381 90.0
2xDSH381 + DSH485 100.0
DSH381 + 2xDSH485 110.0
3xDSH485 120.0
2xDSH240 40.0
DSH240 + DSH295 45.0
2xDSH295 50.0
DSH240 + DSH381 50.0
DSH295 + DSH381 55.0
DSH240 + DSH485 60.0
2xDSH381 60.0
DSH295 + DSH485 65.0
DSH381 + DSH485 70.0
2xDSH485 80.0
3xDSH140 35.0
3xDSH161 39.0
3xDSH184 44.0
3xDSH240 60.0
3xDSH295 75.0
3xDSH381 90.0
2xDSH381 + DSH485 100.0
DSH381 + 2xDSH485 110.0
3xDSH485 120.0
For 50Hz: Evaporating temperature: 5°C (41°F), Condensing temperature: 50°C (122°F), Superheat: 10K (18°F), Subcooling: 0K (0°F)
For 60Hz: Evaporating temperature: 7.2°C (45°F), Condensing temperature: 54.4°C (130°F), Superheat: 11.1K (20°F), Subcooling: 8.3K (15°F)
Nominal cooling Power
capacity input
W Btu/h kW
104511 356602 34.1
116195 396468 37.4
127879 436335 40.7
133012 453850 43.3
144696 493717 46.6
154824 528275 49.8
161513 551099 52.4
166508 568141 53.1
183325 625524 58.9
205137 699948 65.4
89106 304028 29.1
102367 349277 33.1
114543 390822 37.1
154710 527885 51.1
189302 645916 61.1
239092 815805 78.6
260617 889253 85.1
282143 962701 91.7
303669 1036149 98.2
142228 485297 44.9
157936 538892 49.4
173643 592487 53.9
180421 615616 57.0
196129 669211 61.5
211737 722468 66.1
218615 745935 69.0
227444 776063 70.6
249930 852787 78.2
281246 959639 87.3
121790 415549 38.3
138543 472710 44.1
155971 532175 49.1
210544 718397 67.4
257048 877073 80.9
323620 1104224 103.6
354525 1209675 112.7
385430 1315125 121.8
416335 1420575 131.0
Displacement
COP E.E.R.

W/W Btu/h/W m 3 /h cu.ft/h
3.07 10.46 79.2 2797
3.11 10.60 87.7 3097
3.14 10.72 96.2 3397
3.08 10.49 99.6 3517
3.11 10.60 108.1 3818
3.11 10.62 116.6 4118
3.08 10.51 120 4238
3.14 10.71 125.1 4418
3.11 10.61 137 4838
3.13 10.70 154 5438
3.07 10.46 69.3 2447
3.09 10.56 79.2 2797
3.09 10.54 88.8 3136
3.03 10.33 118.8 4195
3.10 10.58 144.3 5096
3.04 10.38 180 6357
3.06 10.44 197 6957
3.08 10.50 214 7557
3.09 10.56 231 8158
3.17 10.80 95.6 3376
3.20 10.90 105.8 3736
3.22 10.99 116 4097
3.17 10.80 120.1 4241
3.19 10.89 130.3 4602
3.20 10.93 140.7 4969
3.17 10.80 144.6 5107
3.22 10.99 150.9 5329
3.20 10.91 165.2 5834
3.22 10.99 185.8 6561
3.18 10.86 83.7 2956
3.14 10.72 95.7 3380
3.18 10.84 107.4 3793
3.12 10.66 143.4 5064
3.18 10.84 174 6145
3.12 10.66 216.9 7660
3.15 10.73 237.5 8387
3.16 10.79 258.1 9115
3.18 10.85 278.7 9842
