- Page 1 NO Monteringsanvisning Installation- and user manual Installations- och bruksanvisning Käyttöohje Lisboa Art.no: FP-LIS00-0X0 Test report No: 40 15 3968 Last updated: 14.08.2019...
- Page 2 IMPORTANT SAFETY PRECAUTIONS! INDEX 1. General information 1. Please follow the installation manual when Weight Adjustment Floor plate pipe to the surrounding materials. Acrylic glue Minor damage 2. Before use, please carefully read the user manual and follow the instructions. Painting Chimney Draught never be reduced or partially obstructed.
- Page 3 Installation of the insert must comply with the rules and regulations of the country where installed. Nordpeis AS is not responsible for wrongly assembled inserts. system. In case of simultaneous operation with other We accept no liability for typographical errors and changes.
- Page 4 The insert is delivered with two assembled front legs. Before you start assembling the surrounding you need All products Nordpeis have secondary combustion and to assemble bracket leg to the insert - see FIG5. The are clean burning. The combustion takes place in two bracket leg is longer than front legs, it’s advisable to...
- Page 5 Fresh air supply can be connected through the base FIG 13-14 If product is going to utilize rear chimney connection, prepare the next element before assembling. Use imple- Ignition air vent control ments to cut out a hole for the chimney connector on As an integrated part of the air vent control, insert the back along the prefabricated groove.
- Page 6 The wear time will depend on the individual use of your product. Nordpeis wood logs can be inserted when there is a glowing layer of ember . Pull the hot ember to the front of the replacements can be purchased.
- Page 7 Note that the air supply for the combustion also can quickly heat up the whole combustion chamber to an the combustion chamber completely with wood.
- Page 8 Error Solution The chimney is blocked. Contact a chimney sweeper / dealer for more information or clean the No draught Downdraught in the room caused by no draught, that the house is too “air tight”. be installed in the room. Downdraught in the room –...
- Page 9 Du trenger følgende verktøy GB You need the following tools Du behöver föjande verktyg Tarvitset seuraavat työkalut 10 mm 13 mm 5 mm 4 mm 16 mm...
- Page 10 FIG 1...
- Page 12 FIG 2 =Brennbart materiale/Brændbart materiale/ Brännbart material/ Tulenarka materiaali/ Combustible material >550 >1100...
- Page 13 S-18U insert FIG 4 FIG 3 A = ignition FIG 5 016197 - 2x 016487 - 2x 16 mm 696310 - 1x...
- Page 14 FIG 6 5 mm <9 mm <9 mm FIG 7 4 mm 5 mm...
- Page 15 FIG 8 FIG 9...
- Page 16 FIG 10 FIG 11...
- Page 17 FIG 11a FIG 12 90 0 90 0 FIG 2...
- Page 18 FIG 13 FIG 14 CO-STO00-004 FIG 16 FIG 15 90 0 90 0 CO-STO00-004...
- Page 19 FIG 17 FIG 18 21-50001-018 x8 22-3004-016 x8 FIG 19...
- Page 20 FIG 20 13 mm FIG 20a 5 mm <9 mm <9 mm...
- Page 21 FIG 21 FIG 22 21-50001-018 x6 22-3004-016 x6...
- Page 22 FIG 23 10 mm 0 mm 0 mm FIG 24 5 mm...
- Page 23 FIG 25 FIG 26 FIG Z...
- Page 24 FIG 27 FIG 28 FIG 27a FIG 29 FIG 30...
- Page 25 FIG 30a FIG 31...
- Page 26 FIG 32 FIG 33 FIG 34 90 0...
- Page 27 FIG 35 FIG 36 FIG 37...
- Page 29 FIG 38 FIG 39 FIG 40...
- Page 30 FIG 41 PLASSERING AV SERIENUMMER / POSITION OF THE SERIAL NUMBER PLACERING AV SERIENUMMER / SARJANUMERON SIJAINTI...
- Page 31 Nordpeis AS Gjellebekkstubben 11 3420 Lierskogen, Norway EN 13240:2001 / A2:2004 Lisboa Heating of living accomodation / Kamin zum Heizen mit festen Brennstoffen Year of Approval / 2015 Zulassungjahr Fire safety: Feuersicherheit : Reaction to fire: A1 WT Brandverhalten: Distance to combustible:...
- Page 32 Permanent pilot flame power requirement Pilot flame power requirement (if applicable) Contact details Name and address of the supplier: Nordpeis AS, Gjellebekkstubben 11, N-3420 LIERSKOGEN, Norway...
- Page 33 Nordpeis AS. Nordpeis S18 ENERGIA · ЕНЕРГИЯ · ΕΝΕΡΓΕΙΑ · ENERGIJA · ENERGY · ENERGIE 2015/1186 www.nordpeis.no...
