Handbook
Audi R8 LMS
MODIFIED TO COVER 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R8 LMS 2018 and is the answer not in the manual?

Questions and answers

Related Manuals for Audi R8 LMS 2018

Summary of Contents for Audi R8 LMS 2018

  • Page 1 Handbook Audi R8 LMS MODIFIED TO COVER 2018...

  • Page 2: Table Of Contents

    Contents Contents List of Images ..................4 List of Abbreviations ................6 Miscellaneous ..................7 Car Views ....................8 000 – Air Jack and Fire Extinguisher ............11 000 - 1 Air Jack System ................11 000 - 2 Fire Extinguisher System 596 ............14 100 –...
  • Page 3 Contents 700- Pneumatic Gearshift and Pedals ............. 65 700 - 1 Pedals ..................65 700 - 1.1 Longitudinal Adjustment Pedal Unit ........65 700 - 1.2 Throttle Pedal ................ 69 700 - 1.3 Brake Pedal ................74 800- Bodywork, Chassis Parts, Seat and Air Conditioning ......77 800 - 1 Seat ....................

  • Page 4: List Of Images

    List of Images List of Images Image 1: Adding Engine Oil during Endurance Races ........22 Image 2: Scheme of Cooling System ............24 Image 3: Expansion Reservoir ..............28 Image 4: Refuelling Coupling, Service Tool and Molykote 1292 Grease ... 30 Image 5: Using Service Tool, Refuelling Coupling in Service Position ....
  • Page 5 Image 32: Brake Pedal Plate Height Adjustment ........... 76 Image 33: Brake Pedal Plate Angle Adjustment ..........76 Image 34: Audi Safety Seat PS1 ..............77 Image 35: Shoulder Strap Mounting Below Roll-Cage Tube......82 Image 36: Shoulder Strap Mounting Above Roll-Cage Tube ......82 Image 37: Rear Wing Adjustment Range ............

  • Page 6: List Of Abbreviations

    List of Abbreviations List of Abbreviations ARB anti-roll bar Throttle pedal butterfly cam Camshaft DDU Digital Display Unit Electronic Control Unit Fédération Internationale de l’Automobile Design Position PDM Product Detail Assembly Instructions POM Polyoxymethylene Reference Page Traction Control Variant Option Work page 6 / 113 Version 1 2016-01-01...

  • Page 7: Miscellaneous

    Miscellaneous Miscellaneous The Audi R8 LMS race car was designed and built in accordance with the FIA technical regulations for GT3 category cars and in accordance with the FIA homologation. Homologation number: GT3-038 Homologation date: 01.05.2015 The specification corresponds with the current version of the regulations at the time of delivery.

  • Page 8: Car Views

    Car Views Car Views 8 / 113 Version 1 2016-01-01...
  • Page 9 Car Views 9 / 113 Version 1 2016-01-01...
  • Page 10 Car Views 10 / 113 Version 1 2016-01-01...

  • Page 11: Air Jack And Fire Extinguisher

    000 – Air Jack and Fire Extinguisher 000 – Air Jack and Fire Extinguisher 000 - 1 Air Jack System When driving, the bleed valve must be open (pulled out) in order to ensure the air jack piston is fully retracted. Working under the car supported only by the air jacks without the chocks (safeties) is forbidden.
  • Page 12 000 – Air Jack and Fire Extinguisher If a new pressure line is fitted to the car, the insertion depth of the tube must be marked before tightening the union nut. Recommended air jack service interval: see PDM 4SA 011 001 Contact Krontec for service and maintenance (see chapter 902 –...
  • Page 13 000 – Air Jack and Fire Extinguisher Lifting the car It is recommended to lift the car to the desired level for working using ONLY a Car lift System. Only in exceptional circumstances such as during a race should the car be lifted on the flat bottom.

  • Page 14: Fire Extinguisher System 596

    000 – Air Jack and Fire Extinguisher 000 - 2 Fire Extinguisher System 596 The car is equipped with an FIA homologated fire extinguisher system. The extinguishant is Aerosol. The fine particulate powder used is extremely efficient and thanks to a special nozzle system is distributed evenly in the car. The extinguishant is discharged via three nozzles –...
  • Page 15 000 – Air Jack and Fire Extinguisher Technical Data Extinguishant: Aerosol KD-A96 Filling pressure: 36.5 bar / 20 °C Operating pressure: Min. 32.5 bar Max. 41.5 bar Net extinguishant weight: 0.5 kg Operating temperature range: - 10 to + 60 °C Discharge time: Approx.
  • Page 16 000 – Air Jack and Fire Extinguisher Activating Extinguishing System When the toggle switch on the control unit is set to ‘ON’, the extinguishing system is operational. Only the system active LED glows. The fire extinguisher is activated and extinguishant is discharged from the nozzles by pressing the ‘FIRE’...
  • Page 17 000 – Air Jack and Fire Extinguisher Service Interval Extinguisher System Extinguishant reservoir: The next date for servicing the extinguishant reservoir is printed on the service sticker (see inspection sticker). The date indicates the latest date for servicing the extinguishant reservoir. The service interval is 2 years. See chapter 902 –...

  • Page 18: Engine Ancillaries, Oil Tank And Water Cooler

    100 – Engine Ancillaries, Oil Tank and Water Cooler 100 – Engine Ancillaries, Oil Tank and Water Cooler 100 - 1 Drivetrain 100 - 1.1 Engine a) Technical Data Type V10 FSI – 90 ° Displacement 5,204 cc Power Up to 585 hp. Adjustable using air restrictor Direction of rotation Anticlockwise when looking at the clutch...
  • Page 19 100 – Engine Ancillaries, Oil Tank and Water Cooler c) Service & Maintenance Please refer to PDM 4SA 100 021 for 902 – Service and Maintenance Contacts 10,000 km Minor service - description 20,000 km Major service – description The engine must be delivered in a transport box (flight case) with the following ancillary components: ...

  • Page 20: 1.2 Engine Lubrication

    100 – Engine Ancillaries, Oil Tank and Water Cooler 100 – 1.2 Engine Lubrication The R8 LMS engine is equipped with a dry sump lubrication system. The oil tank is located in the engine bay. Engine cooling is made via an oil-water heat exchanger and an additional oil cooler mounted in the sill on the left hand side of the car.
  • Page 21 100 – Engine Ancillaries, Oil Tank and Water Cooler The difference between the minimum ‘Fill’ mark and maximum ‘Do not fill’ mark is 2 litres. If the level is too high, oil can enter the air intake system. Do not fill higher than the maximum ‘Do not fill’...

  • Page 22: Image 1: Adding Engine Oil During Endurance Races

    100 – Engine Ancillaries, Oil Tank and Water Cooler Quick release coupling Oil fill bottle O-Ring 27x1.5 Quick fill dipstick Image 1: Adding Engine Oil during Endurance Races After filling the oil fill bottle with engine oil (maximum 1.8 litres), pressurise the bottle to 6 bar.
  • Page 23 100 – Engine Ancillaries, Oil Tank and Water Cooler Attention The oil filler cap with quick release coupling is part of the endurance homologation VO (VO -Variant Option). When using a system, which is homologated together with other systems in a single VO, the full extent of the homologated components must be used.

  • Page 24: 1.3 Engine Cooling System

    100 – Engine Ancillaries, Oil Tank and Water Cooler 100 – 1.3 Engine Cooling System The R8 LMS GT3 cooling system is specially optimised for use in a racecar. The maximum cooler performance is only achieved when the cooler is cleaned and the cooling fins (lamella) are realigned.
  • Page 25 The mixture ratio is 35 % coolant additive to 65 % water. For all events in hot countries, Audi Sport customer racing recommends that the additive ratio is reduced from the ex-works value to the ratio of 10 % additive and 90 % water.
  • Page 26 100 – Engine Ancillaries, Oil Tank and Water Cooler Special Tools Required Cooling system filling device - VAS 6096 Adapter for cooling system tester - V.A.G 1274/8 Fill the VAS 6096 coolant reservoir with approx. 20 litres of premixed coolant in the desired ratio. Screw the adapter for the V.A.G 1274/8 cooling system tester onto the coolant reservoir.
  • Page 27 100 – Engine Ancillaries, Oil Tank and Water Cooler Close valves A and B by turning the levers perpendicular to the flow direction. Connect hose (3) to the pressurised air.  Pressure: 6 – 10 bar Open valve B by turning the level in the flow direction. ...

  • Page 28: Image 3: Expansion Reservoir

    100 – Engine Ancillaries, Oil Tank and Water Cooler Tighten the expansion reservoir cap  The cap must click audibly and noticeably into position when closing. Only check the coolant level when the engine is cold.  When the engine is cold, the coolant must be level with the ‘MAX’ mark.

  • Page 29: 1.3 Clutch - Flywheel

    100 – Engine Ancillaries, Oil Tank and Water Cooler 100 - 1.3 Clutch - Flywheel a) Service and Maintenance Please refer to PDM 4SA 141 000 for 902 – Service and Maintenance Contacts. b) Bleeding Attach an empty bleed bottle hose to the clutch bleed nipple Fill the reservoir on the clutch actuator half-full with brake fluid (spec DOT 3, DOT 4, DOT 4+ (plus), super DOT 4+ (plus), DOT 5.1) Minimum ½...

  • Page 30: Fuel Cell And Exhaust System

    200 – Fuel Cell and Exhaust System 200 – Fuel Cell and Exhaust System 200 - 1 Fuel Cell 200 – 1.1 Refuelling Valve Service Instructions RFC-88-K-SL and RFC-88-K-FL We recommend that the coupling O-rings are coated with “Molykote 1292” grease after every event.

  • Page 31: Image 5: Using Service Tool, Refuelling Coupling In Service Position

    200 – Fuel Cell and Exhaust System Instructions Image 5: Using Service Tool, Refuelling Coupling in Service Position When the service tool is fitted, the valve is pushed downwards. The O-rings are now accessible and can be lubricated / changed. Image 6: Using Service Tool, Lubricating O-rings 31 / 113 Version 1 2016-01-01...
  • Page 32 200 – Fuel Cell and Exhaust System Order Number Service tool: RFC-88-K Service Tool Service kit: RFC-88-K Service KIT Complete refuelling coupling service (after 10,000 km or 1 x per season): RFC-88-K-FL service (dump churn version) RFC-88-K-SL service (refuelling rig version) Please return the refuelling coupling to Krontec for a complete rebuild.

  • Page 33: Service Instructions Refuelling Coupling

    200 – Fuel Cell and Exhaust System 200 – 1-2 Service Instructions Refuelling Coupling RFC-88-TN and RFC-88-N We recommend that the coupling O-rings are coated with “Molykote 1292” grease after every event. Use the RFC-88-TN service tool to depress the inner piston down until the 2 O-rings in the housing are visible.

  • Page 34: Image 8: Service Tool Decoupled And Unlocked

    200 – Fuel Cell and Exhaust System Instructions Image 8: Service Tool Decoupled and Unlocked Image 9: Service Tool Fitted, Locked and Open After fitting the locking ring, rotate clockwise to lock the service tool. Afterwards, the valve can be depressed. The O-rings are now accessible and can be lubricated / changed.
  • Page 35 200 – Fuel Cell and Exhaust System Order Number Service tool: RFC-88-TN Service Tool Service kit: RFC-88-TN Service KIT Complete refuelling coupling service (after 10,000 km or 1 x per season): RFC-88-TN Service Please return the refuelling coupling to Krontec for a complete rebuild. 35 / 113 Version 1 2016-01-01...

  • Page 36: Gearbox, Drive Shafts And Ancillary Components

    SAF XJ) Part number V31 748 005 01L --> 1 litre bundle It is recommended that only gearbox oil approved by Audi Sport customer racing is used. Differences in the quality of gearbox oil influence significantly the wear of the idler and fixed gears as well as the crown wheel and pinion.
  • Page 37 300 – Gearbox, Drive Shafts and Ancillary Components c) Oil Quantities 3.2 litres when oil cooler and oil pipes empty (initial fill when new or after rebuild). 2.9 litres when oil cooler and oil pipes full (service and maintenance work). Changing the filter and oil is mandatory after 500 km with a new car and with a new gearbox.
  • Page 38 (special tools required) Rebuilds and training courses are implemented and coordinated in conjunction with Audi Sport customer racing. Please contact Kurt Gräfenstein Kurt1.graefenstein@audi.de +49 (0) 151 / 421 340 05...

  • Page 39: Image 12: Screw Plug, Adjustable Differential Preload

    300 – Gearbox, Drive Shafts and Ancillary Components Image 12: Screw Plug, Adjustable Differential Preload Image 13: Adjustable Preload Attention The preload is approx. 100 – 150 Nm at delivery and with new gearbox. It should be noted that the preload changes significantly before a certain distance is covered with new clutch discs.

  • Page 40: Front Axle, Anti-Roll Bar, Dampers And Steering

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 1 Filling / Bleeding Steering System Filling Procedure Fill initially with engine oil (Castrol Edge 5W-30, V31 748 012) to 3 mm above MAX 20°...
  • Page 41 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Attention To prevents pressure spikes in the system, do not steer hard against the steering stops when the steering is at full lock! Oil level at room temperature between ‘MAX 20° and MAX 20° -3 mm’. Oil level immediately after turning off engine at operating temperature between ‘MAX 80°...

  • Page 42: Miscellaneous

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2 Miscellaneous Comment Parameter Front Rear Wheelbase 2,700 mm Track width 1,667 mm 1,670 mm Michelin 30/ Michelin Standard tyres 68-18 S9L 31/71-18 S9L Wheel width / 12.5" x 18" 13.0"...
  • Page 43 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Anti-dive angle 11.8 ° 10.2° For 390 mm centre of gravity height Anti-dive percentage 87 % and 60 % front brake balance Anti-squat angle 0.5 ° Anti-squat percentage Steering wheel Steering rack ratio 6.747 °/ mm angle / rack bar displacement...

  • Page 44: 2.1 Suspension Geometry Curves

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.1 Suspension Geometry Curves Front axle: Heave 0,25 Heave in mm ( - rebound / + bump) 0,20 -30 -25 -20 -15 -10 -5 10 15 20 25 30 35 40 45 50 0,15 -0,5 0,10...
  • Page 45 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Rear axle: Heave 0,25 Heave in mm ( - rebound / + bump) 0,20 -30 -25 -20 -15 -10 -5 10 15 20 25 30 35 40 45 50 0,15 -0,5 0,10 -1,0 0,05...

  • Page 46: 2.2 Springs

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.2 Springs The following springs for the car are defined in the FIA homologation documentation. Front springs Spring Ratio Spring rate at Axle roll Spring free block Spring rate (spring / the wheel in stiffness in...

  • Page 47: 2.3 Anti-Roll Bars

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.3 Anti-roll Bars The following images show the correct lengths of the anti-roll bar drop links. Front Rear Anti-roll Bar Adjustment Front anti-roll bar Position 1 (soft) 2 (middle) 3 (hard) Alignment ARB rate at...
  • Page 48 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Rear anti-roll bar Position 1 (soft) 2 (middle) 3 (hard) Alignment ARB rate at 49 N/ mm 60 N/ mm 69 N/ mm the wheel Axle roll 2,385 Nm/ ° 2,920 Nm/ ° 3,360 Nm/ °...

  • Page 49: 2.4 Damper / Ride Height Adjustment

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.4 Damper / Ride Height Adjustment Bump Stops and Packers The following packers are available: Thickness Form 2 mm 3 mm slotted slotted full 5 mm 5 mm full To install bump stops and packers, the push rod (part with external hex) must be removed from the piston rod.
  • Page 50 400 – Front Axle, Anti-Roll Bar, Dampers and Steering The following images show the fully extended dampers. The lengths can be set using the push rods. Front Rear Listed in the following table are the maximum and minimum adjusted damper lengths as well as the default setting for the ride heights at design level.

  • Page 51: Image 14: Push Rod Thread With Groove Marking

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering Attention It must always be guaranteed that the ride-height is within the permitted range when measured at the FIA measurement points! The maximum adjustable extended damper length must not be exceeded! A groove on the push rod thread marks the maximum permitted position (see Image 14).
  • Page 52 400 – Front Axle, Anti-Roll Bar, Dampers and Steering The ride height can be set on the push rod. The thread pitch on the push rod is 1 Front axle pushrod Rear axle pushrod On damper On damper On wheel On damper On damper On wheel 1.00 turn...

  • Page 53: Image 16: Characteristic Curve Front Damper 4Sa 412 019 B

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering Damper Characteristic Curves Front Damper 4SA.412.019.B 3000 2500 2000 1500 1000 -500 -1000 -1500 -2000 -2500 -3000 Speed in mm/s Image 16: Characteristic Curve Front Damper 4SA 412 019 B Rear Damper 4SA.512.019.C 3000 2500 2000...

  • Page 54: 2.5 Camber Adjustment

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.5 Camber Adjustment Front Axle On the front axle, the static camber is adjusted by adding or removing camber shims between the upper wishbone mounting and the upright. A change in camber also influences the toe angle.
  • Page 55 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Thickness of Camber Camber Thickness of Adjustment adjustment change in change in adjustment shim shim colour shim on degrees minutes toe rod wishbone blank / 0.25 ° 1.3 mm 0.4 mm metallic 0.50 °...

  • Page 56: 2.6 Toe Rods / Toe Adjustment

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.6 Toe Rods / Toe Adjustment Toe Rod Lengths The following images show the toe rod lengths for zero toe at design level (ride height and static camber). Front Rear Toe Adjustment Toe rod front axle...

  • Page 57: 2.7 Brake Discs

    400 – Front Axle, Anti-Roll Bar, Dampers and Steering 400 – 2.7 Brake discs It is highly recommended that the brake discs and pads are bedded according to the instructions issued by Brembo (see below). Bedding should prevent the creation of cracks in the discs and pads and increase the durability. It cannot be guaranteed that shorter versions of the bedding procedure will produce the same level of safety and service life of brake discs and pads.
  • Page 58 400 – Front Axle, Anti-Roll Bar, Dampers and Steering cleaner or similar) in order to avoid contamination during bedding. Normally, this operation can be avoided because the RB330, 340 & 350 friction material are initially very abrasive and able to clean up the disc surface automatically, though time-to-bed will likely increase.
  • Page 59 400 – Front Axle, Anti-Roll Bar, Dampers and Steering local overheating on the disc and subsequent distortion on it. The heat transferred into the disc becomes however higher (high gradient of temperature) toward the end of the bedding because the disc surface is now completely and uniformly settled up and the friction efficiency optimized, at this point no risk of uneven heat distribution and distortion should exist.
  • Page 60 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Temperature evolution** (sx) and friction profiles (COF vs. speed) during bedding. ** The time is only related to the brake application, it does not refer to the cooling. Typical appearance of a correctly bedded set of disc/pads (sx) compared to a new one. Blanking Attention Due to thermally induced mechanical stresses, cracks can develop despite...

  • Page 61: Image 18: Front Axle Brake Cooling Duct Without Blanking

    Brake disc temperature paint can provide information about the maximum temperatures of the brake discs. The Audi part number for a kit (AP Racing), containing three colours, is V03 862 443 E. The brake disc temperatures are in the correct operating window when: Green >...
  • Page 62 400 – Front Axle, Anti-Roll Bar, Dampers and Steering Crack on the edge Critical cracks (deep, long, straight and Uncritical cracks (thin, short continuous, cracks on the edges of the branched, distributed evenly over the brake discs) entire surface, no cracks on the edges of the brake discs) Attention Check the brake discs regularly for cracks and replace if necessary!

  • Page 63: 500- Rear Axle, Anti-Roll Bar And Dampers

    500- Rear Axle, Anti-roll Bar and Dampers 500- Rear Axle, Anti-roll Bar and Dampers For current information, see chapter 400 – Front Axle, Anti-Roll Bar, Dampers and Steering. 63 / 113 Version 1 2016-01-01...

  • Page 64: 600- Brake Pipes, Brake Cooling Ducts, Wheels And Tyres

    600- Brake Pipes, Brake Cooling Ducts, Wheels and Tyres 600- Brake Pipes, Brake Cooling Ducts, Wheels and Tyres No current information. 64 / 113 Version 1 2016-01-01...

  • Page 65: 700- Pneumatic Gearshift And Pedals

    700- Pneumatic Gearshift and Pedals 700- Pneumatic Gearshift and Pedals 700 - 1 Pedals The pedal box has a large adjustment range in order to achieve the best possible ergonomics for drivers of different stature. The individual possibilities are described below in details. 700 - 1.1 Longitudinal Adjustment Pedal Unit The seat is bolted firmly to the chassis.

  • Page 66: Image 21: Centre Console With Button To Disengage Pedal Unit And Main Switch To Activate Compressor

    700- Pneumatic Gearshift and Pedals Image 21: Centre Console with Button to Disengage Pedal Unit and Main Switch to Activate Compressor The compressed air is taken from the compressor for the gearshift. If the car is not used for a long time, the compressed air reservoir will be empty. In this case, the MAIN switch in the centre console must be switch on.

  • Page 67: Image 22: Push Surface On The Pedal Unit Cover

    700- Pneumatic Gearshift and Pedals Attention Only push the pedal unit forward using the area marked in the image below. Pushing in other positions (e.g. on the left footrest or the brake pedal) increase the force required and can cause the unit to jam! Image 22: Push Surface on the Pedal Unit Cover When the button is released, two independent springs push the lock into the detents.
  • Page 68 700- Pneumatic Gearshift and Pedals Procedure to Adjust the Longitudinal Position of the Sledge Ensure that the pneumatic reservoir is charged with sufficient pressure, or switch on the MAIN switch and wait until the compressor switches off Press the button valve in the centre console Move the sledge to the desired position by pushing below the throttle pedal plate with the heel of the right foot Release the button valve in the centre console...

  • Page 69: 1.2 Throttle Pedal

    700- Pneumatic Gearshift and Pedals 700 - 1.2 Throttle Pedal The following adjustments can be made to the throttle pedal: Lateral position of the pedal plate Spring preload Damping a) Lateral Position of Pedal Plate There are two positions. The pedal in the left hand image shows the standard position.

  • Page 70: Image 24: Nut To Adjust Spring Preload On Throttle Pedal

    700- Pneumatic Gearshift and Pedals Image 24: Nut to Adjust Spring Preload on Throttle Pedal By turning the nut (16 mm AF spanner), the threaded stud is moved and the spring preload changed. The basic setting is shown in the following image. The pin in the slot shows the actual setting.

  • Page 71: Image 26: Pedal Assembly - Throttle Pedal Damper

    700- Pneumatic Gearshift and Pedals c) Damping The damper of the throttle pedal is located below the cover on the left of the gas spring used for moving the sledge. Image 26: Pedal Assembly – Throttle Pedal Damper The damping is adjustable. The standard setting is completely soft. Changing the damping is made by rotating the cylinder relative to the piston rod.
  • Page 72 700- Pneumatic Gearshift and Pedals Swing the damper to the right (see Image 27) Rotate the damper clockwise --> stiffer damping Rotate the damper anticlockwise --> softer damping While rotating pull lightly on the cylinder so that the adjustment gears engage in the piston.

  • Page 73: Image 27: Adjusting The Throttle Pedal Damper

    700- Pneumatic Gearshift and Pedals Image 27: Adjusting the Throttle Pedal Damper 73 / 113 Version 1 2016-01-01...

  • Page 74: 1.3 Brake Pedal

    700- Pneumatic Gearshift and Pedals 700 - 1.3 Brake Pedal The following adjustments can be made to the brake pedal: X Position (longitudinal offset between brake and throttle pedals) Y Position (distance to throttle pedal and to left foot rest) Z Position and angle (height and angle of pedal plate) a) X Position In the standard position, the brake pedal plate is on the same plane as the left...

  • Page 75: Image 30: Brake Pedal Plate Long Side Left

    700- Pneumatic Gearshift and Pedals Attention The distance between the pedal plate and the driver should not be adjusted on the brake master cylinder, otherwise the bell crank geometry changes and the system can stick in the depressed position! b) Y Position To increase the distance to the left footrest or the throttle pedal plate to the right, the brake pedal plate can be turned through 180°.

  • Page 76: Image 32: Brake Pedal Plate Height Adjustment

    700- Pneumatic Gearshift and Pedals Image 32: Brake Pedal Plate Height Image 33: Brake Pedal Plate Angle Adjustment Adjustment 76 / 113 Version 1 2016-01-01...

  • Page 77: 800- Bodywork, Chassis Parts, Seat And Air Conditioning

    Audi PS1 Image 34: Audi Safety Seat PS1 800 - 1.1 Homologation The Audi PS1 is homologated under the number AS.031.13 (M) and AS.032.13 (L). This homologation is valid for 10 years from the date of manufacture. 77 / 113...
  • Page 78 800- Bodywork, Chassis Parts, Seat and Air Conditioning 78 / 113 Version 1 2016-01-01...

  • Page 79: 1.2 Seat Sizes

    800- Bodywork, Chassis Parts, Seat and Air Conditioning 800 - 1.2 Seat Sizes The Audi PS1 is available in two sizes: Audi PS1 M – 42A 881 023 D Audi PS1 L – 42A 881 023 E The width of the M and L seats differs by 35 mm.

  • Page 80: 1.3 Cushions

    800- Bodywork, Chassis Parts, Seat and Air Conditioning 800 - 1.3 Cushions The Audi PS1 is equipped with different thickness Confor CF45 cushions, which comply with the regulations. Attention The cushions are an integral component of the safety concept and are important to absorb energy during accidents.

  • Page 81: 1.4 Additional Inserts

    800- Bodywork, Chassis Parts, Seat and Air Conditioning 800 - 1.4 Additional Inserts If additional seat inserts must be made to fit the driver, one of the following FIA homologated foams must be used. FIA Technical List No. 50 81 / 113 Version 1 2016-01-01...

  • Page 82: 1.5 Shoulder Strap Mounting

    800- Bodywork, Chassis Parts, Seat and Air Conditioning 800 - 1.5 Shoulder Strap Mounting Adjustment Options The angle of the shoulder straps must comply with FIA guidelines. To fulfil these guidelines, the shoulder strap mounting must be adapted to suit the size of the driver.

  • Page 83: 801- Aerodynamics

    801- Aerodynamics 801- Aerodynamics 801 - 1 Aero Set-Up Sheet Rear Wing Adjustment Range Marking Pos. see Fehler! Ungültiger Eigenverweis 1 – flat Textmarke. Image 37: Rear Wing Adjustment Range 6 - steep ISO Balance – Table Ride height Measured Configuration Balance Total...
  • Page 84 801- Aerodynamics Balance – Ride Height Table Ride height Ride height set- Measured under Balance Total Total the axles @ front front rear wing downforce drag axle [mm] [mm] [Pos.] Standard downforce Increased FRH - 1.8 - 1.8 Increased RRH - 0.2 Balance –...
  • Page 85 801- Aerodynamics Minimum ride height (see chapter 800 - 1.1 Homologation) Front Rear 54 mm 54 mm Measured on the floor beneath the axles: 65.5 mm 128 mm Measure on the FIA reference points on the chassis: Rear wing position (see chapter 800 - 1.1 Homologation) Ensure that the Gurney flap –...
  • Page 86 801- Aerodynamics 86 / 113 Version 1 2016-01-01...

  • Page 87: 900- Electric And Data Acquisition

    If changes are desired and teams are still unfamiliar with RaceCon, please do not hesitate to contact customer support at Audi Sport customer racing. a) Going online with the system To make changes in the RaceCon project a connection with the car must be created.
  • Page 88 900- Electric and Data Acquisition The following changes can only be made online: Every calibration or adjustment Adapting the pit speed (after changing the value always copy the WP, work page, to the RP, reference page) After connecting to the car, a status LED (green, yellow or red) is displayed for every component listed in the system tree.
  • Page 89 900- Electric and Data Acquisition After making changes to the project, which are made online, the configuration must be downloaded to the car in order to ensure that the computer and car configurations match. If the MS6.4-ECU status message is yellow after connecting to the car, this indicates that changes were made offline, whereby the parameters between computer and ECU differ.
  • Page 90 900- Electric and Data Acquisition b) Adapting the lap trigger c) Resetting the outing and lap counters 90 / 113 Version 1 2016-01-01...
  • Page 91 900- Electric and Data Acquisition d) Calibration and adjustment Various elementary functions can or must be adjusted and/or calibrated. For example, the following variables must be recalibrated after every engine or ECU change: Throttle pedal (aps) via CWAPSADJ  (also if throttle pedal changed) Butterflies (ath) via CWTHRADJ ...
  • Page 92 900- Electric and Data Acquisition Important: When calibrating or adjusting, every calibration and adjustment can only be made if the ECU is connected (status green). After calibration, the calibration conditions must always be reset to FALSE and/or ‘0’. Overview of engine and gearbox temperatures and pressures Calibration camshaft Run the engine at idle speed;...
  • Page 93 900- Electric and Data Acquisition Calibration throttle pedal Press the throttle pedal to the mechanical stop (full throttle) – activate status ‘calibrate full pressed pedal’ Release throttle pedal and/or do not press – activate status ‘calibrate release pedal’ Reset status to ‘calibration inactive’ Calibration clutch pedal Pull right clutch paddle to mechanical stop –...
  • Page 94 900- Electric and Data Acquisition Rotate the steering by to the straight ahead positon – activate status ‘cal middle offset’ Reset status to ‘off’ Adjusting pit speed Change the pit speed to the desired value Copy work page (WP) to reference page (RP) Special case pit speed If the pit speed value is changed, the work page must be copied to the reference page afterwards.

  • Page 95: Diagnosis

    900- Electric and Data Acquisition 900 - 2 Diagnosis The R8 LMS on-board system architecture provides complete diagnostic capability of almost every actuator and sensor. As a result, there are several options available to detect and diagnose errors. One option is via the RaceCon interface when the ERROR page is selected. This page displays every monitored variable, which is controlled or received by the ECU.
  • Page 96 900- Electric and Data Acquisition The following page view includes every component that should be checked before the engine start. For example, calibrations can be checked if they were successful. To check every component, the following page view also allows every component to be checked that requires the engine to be running.
  • Page 97 900- Electric and Data Acquisition Monitoring values via the display during the engine start procedure is complemented by another page view in RaceCon. The engine’s actual status is indicated in the left field of the page. In contrast to the previous page views, the pressures and temperatures are listed separately, which provides improved performance when monitoring the most important values.

  • Page 98: 901- Engine Warm-Up Procedure / Engine Start

    901- Engine Warm-Up Procedure / Engine Start 901- Engine Warm-Up Procedure / Engine Start 901 - 1 Preparation before Engine Start 901 - 1.1 Checking / Adjusting Gearbox Potentiometer To avoid damaging the gearbox, the gearbox potentiometer setting must be checked before running the car on track or selecting gears with the engine running.

  • Page 99: Image 38: Shift Barrel In Neutral (N) Position

    901- Engine Warm-Up Procedure / Engine Start Image 38: Shift Barrel in Neutral (N) Position Adjustment Loosen the bolts Rotate the gearbox potentiometer until the value ‘gearbox’ in the display shows 1.2 V Retighten the bolts to 3 Nm Image 39: Adjusting the Gearbox Potentiometer 99 / 113 Version 1 2016-01-01...

  • Page 100: 1.2 Checking Engine Oil Level

    901- Engine Warm-Up Procedure / Engine Start 901 - 1.2 Checking Engine Oil Level See chapter 100 – 1.2 Engine Lubrication for information about engine oil quality and fill level. Checking engine oil level Position the car on a level, flat surface Run the engine until the engine oil temperature reaches 100 °C –...

  • Page 101: 1.3 Checking Gearbox Oil Level

    901- Engine Warm-Up Procedure / Engine Start 901 - 1.3 Checking Gearbox Oil Level See chapter 300 – Gearbox, Drive Shafts and Ancillary Components for information about gearbox oil quality and fill level. Checking gearbox oil level Position the car on a level, flat surface. To measure the oil level, remove the oil dipstick, wipe dry with a clean cloth.

  • Page 102: 1.4 Fuel, Coolant And Coolant Additive, Steering Oil And Brake Fluid

    901- Engine Warm-Up Procedure / Engine Start 901 - 1.4 Fuel, Coolant and Coolant Additive, Steering Oil and Brake Fluid Before starting the engine or running the car on track, all fluids must be checked to ensure the level is correct. a) Fuel See chapter 100 - 1.1 for information about fuel quality.
  • Page 103 901- Engine Warm-Up Procedure / Engine Start e) Checking steering oil level Unscrew filler cap Clean the oil dipstick with a dry cloth Screw in the filler cap hand and then remove again Check oil level Oil level at room temperature between ‘MAX 20° and MAX 20° - 3mm’.

  • Page 104: 1.5 Preparation Warm Up Procedure / 'Warm Up

    901- Engine Warm-Up Procedure / Engine Start 901 - 1.5 Preparation Warm Up Procedure / ‘Warm up’ The following preparation must be made before starting the engine for the warm up procedure: Ensure that the complete car is in a drivable condition and the car is on a level, flat surface Remove the engine cover Lift the car with the air jack system, fit the air jack chocks (safeties)

  • Page 105: Warming Up / Cooling Down The Engine And Gearbox

    901- Engine Warm-Up Procedure / Engine Start 901 - 2 Warming up / Cooling down the Engine and Gearbox 901 - 2.1 Warm up Procedure Ensure that the main switch and ignition are switched on Engine start --> pull the clutch paddle, press the brakes and push the start button Run the engine at idle speed for 2 minutes Pull the clutch paddle and from neutral select first gear...

  • Page 106: 2.2 Cooling Down Procedure

    901- Engine Warm-Up Procedure / Engine Start 901 - 2.2 Cooling Down Procedure Downshift from sixth to first gear, do not apply throttle during this procedure, with the engine at idle speed (do not activate the clutch) Select neutral using the clutch Check reverse gear engages.
