Retrospec Chippy Owner's Manual page 3

STEP 2: REAR WHEELS
Tools: 2, 5mm hex wrenches
1. Make sure both Frame Axle Covers are installed.
2. Remove the 5mm Bolt & Flat Washer from one side of the Axle.
a. Insert the Axle through one rear wheel, through the Frame Axle Cover,
and through the Frame.
b. Slide the other wheel onto the Axle, then the Flat Washer, insert 5mm
Bolt (Fig. 5). Wheels are interchangeable.
3. Tighten securely using the 2, 5mm hex wrenches (Fig. 6).
FRAME
Fig. 6
AXLE BOLT 5mm
WASHER
AXLE
WHEELS
FRAME
AXLE COVERS
Fig. 5
TIGHTEN
(CLOCKWISE)
STEP 3: FRONT FORK & WHEEL ASSEMBLY
1. Insert Front Fork Assembly into Frame Steering Tube from the bottom-up (Fig. 7).
2. Slide Collar Clamp onto Front Fork (Fig. 7).
COLLAR
CLAMP
FRAME
STEERING
TUBE
FORK
TUBE
FRONT
FORK
ASSEMBLY
Fig. 7
