Retrospec Chippy Owner's Manual page 2

HANDLEBAR
T-BAR
COLLAR
CLAMP & COVER
REAR WHEELS
DECK
Carton Contents:
Scooter | Owner's Manual | 2 - 5mm hex wrenches | 1 – 10mm / 13mm double-end wrench
ASSEMBLY AND SET-UP
GRIPS
PAD
FRONT
FORK
Fig. 1
STEP 1: HANDLEBARS
Tools: 10mm wrench
1. Align the holes on the Handlebar with those on the T-Bar. Insert bolts into top of the
handlebar and through the T-Bar base (Fig. 2).
2. Install one lock washer and nut onto each of the two bolts. Tighten with 10mm wrench
(Fig. 3).
3. Install handlebar pad over handlebar and secure with Velcro cover (Fig. 4).
10mm
TIGHTEN
(CLOCKWISE)
Fig. 3
Fig. 2
Fig. 4
