- Page 1 4-Port HDMI 2.0 Splitter User's Guide P/N: Splitter4P-HD20 G4-0086A...
- Page 2 Thank you for purchasing from gofanco. Our products aim to meet all your connectivity needs wherever you go. For optimum performance and safety, please read the instructions carefully and keep this User’s Guide for future reference. If you need more information about our products, please visit www.gofanco.com.
- Page 3 • Shut off power and make sure environment is safe before installation • Do not plug the HDMI cables in/out when the device is in use to avoid cable damage. Make sure they are plugged into the correct ports • Use the included DC5V power adapter only.
- Page 4 Introduction The 4-Port HDMI 2.0 Splitter splits HDMI signals from an HDMI source to 4 HDMI outputs. Features • Supports up to 4K @60Hz YUV 4:4:4, HDR10 and Dolby Vision • HDMI 2.0 and up to HDCP 2.3 • 18Gbps bandwidth •...
- Page 5 Installation Requirements • HDMI source device (computer, DVD player, XBOX, PS3, etc) • HDMI display device (SDTV/Monitor, HDTV/Monitor, projector, etc.) • HDMI cables Product Layout Figure 1: Product Layout Power LED LED is solid red when powered on LED blinks blue when HDMI source signal is Input LED detected HDMI In...
-
Page 6: Hardware Installation
Hardware Installation Power off all devices including your HDMI source and HDMI display(s). Connect your HDMI source device to the Splitter's HDMI In connector with an HDMI cable (HDMI cable not included). Connect your HDMI display(s) to the HDMI Out connector(s) with an HDMI cable (HDMI cable not included). - Page 7 Application HDMI Out HDMI In HDMI Out HDMI Out Resolution Downscaling The 4K signal can be automatically down-scaled to 1080p resolution for compatibility with 1080p displays, see the table below for more information.
- Page 8 Firmware Update Follow the steps below to upgrade the firmware. Connect the Splitter to the PC using a Micro USB to Type-A cable (cable not included). The PC will automatically detect a "USB drive". Double click the USB drive to open the drive, a file named "Ready.txt"...
- Page 9 FAQ & Solutions There is no video output or audio and video display is not normal: 1) Check the HDMI cables for proper connection. 2) Use higher quality HDMI cables. The Splitter is not working properly: 1) Please check the cable lengths below: - HDMI cables: 4K@60Hz: up to 5m, 1080p: up to 15m 2) Use HDMI 2.0 cables.
-
Page 10: Specifications
Specifications... - Page 11 Disclaimer The product name and brand name may be registered trademarks of related manufacturers. TM and ® may be omitted on the user’s guide. The pictures on the user’s guide are just for reference, and there may be some slight differences with the actual products.
- Page 12 Thank you for choosing gofanco www.gofanco.com...
