- Page 1 SERENITY HOT TUBS OWNER’S MANUAL Hydropool Inc. 335 Superior Blvd Mississauga, ON, Canada L5T 2L6 Tel: 905.565.6810 Toll Free: 1.800.465.2933 Fax: 905.565.6820 Email: info@hydropoolhottubs.com www.hydropoolhottubs.com Contents subject to change without notice BJBA...
-
Page 2: Table Of Contents
Cartridge Filter – Removal / Cleaning Site Preparation 8-13 Above Ground Installations Changing your Hot Tub Water Serenity Filter Grill and Leaf Bag In-ground & Partial In-ground Installations Water Softeners Equipment Accessibility & Protection Each Time Before Filling the Hot Tub... -
Page 3: Letter Of Introduction
We are confident that as you become familiar with various safety and maintenance features of your new hot tub you will be satisfied that you made the right decision in purchasing a Hydropool hot tub. Happy hot tubbing…... -
Page 4: Important User Safety Instructions
SAVE THESE INSTRUCTIONS IMPORTANT SAVE THESE INSTRUCTION Your physiological response to hot water is subjective and depends on your age, health, and medical history. If you don’t know your tolerance to hot water, or if you get a headache, or become dizzy or nauseous when using your hot tub, get out and cool off immediately. -
Page 5: Hyperthermia
SAVE THESE INSTRUCTIONS IMPORTANT SAVE THESE INSTRUCTION Your physiological response to hot water is subjective and depends on your age, health, and medical history. If you don’t know your tolerance to hot water, or if you get a headache, or become dizzy or nauseous when using your hot tub, get out and cool off immediately. -
Page 6: Choosing The Right Location
CHOOSING THE RIGHT LOCATION Your Hydropool hot tub can be installed indoors or out, on the ground, in the ground or half-and-half. The following information will assist you in choosing the right location for your individual needs. When making your decision, always remember that hot tubs can be enjoyed year-round, indoors or out, regardless of the climate. -
Page 7: General Installation Considerations
2. Ensure that your HYDROPOOL hot tub is properly supported by either a level concrete pad, or a properly constructed deck capable of supporting 1220 kg/m2 (250 lbs/ft2). If there is a possibility that the pad could shift by freezing / thawing ground movement (such as in clay regions, and/or areas with high water tables) concrete footings extending below the frost line are recommended. -
Page 8: Special Considerations
The hot tub support equipment is designed for indoor (out of direct elements) use. When your HYDROPOOL hot tub is equipped with a factory-installed cabinet, and installed as per the guidelines of this manual, the equipment will be adequately protected. If the hot tub is shipped without a cabinet, your custom cabinet or other structure must be designed to supply protection for the hot tub support equipment from rain, snow, splash water, etc., bit still be designed in a manner to ensure adequate... -
Page 9: In-Ground & Partial In-Ground Installations
For units being installed fully or partially in the ground, the type of support will again vary based on whether or not the tub is being installed in an area with freeze/thaw conditions. Hydropool does not recommend back- filling full in-ground or partial in-ground installations. -
Page 10: Equipment Accessibility & Protection
Most Hydropool models require a clearance width of at least 100 cm (39 inches) to allow movement of the unit on its side through alley-ways, fence openings, etc. Where this is not possible, the use of a crane to lift the hot tub from the truck or trailer over the house to the patio or yard is often a simple and economical option. -
Page 11: Important Electrical Safety Instructions
This guide is for standard installations where the wire run is 15m (50 feet) or less. For longer runs, consult a qualified electrician. GFCI/RCD APPLICATION GUIDE FOR HYDROPOOL SERENITY SERIES NORTH AMERICA SE4L / SE5L models 4300 / 4500/ 6600 models... - Page 12 IMPORTANT NOTE: (FIGURE 1) The following dimensions can be used to determine the proper location of submerged conduits in concrete slab installations. The dimensions are made from the outside of the spa / hot tub frame with the access for panels removed.
-
Page 13: European Rcd Installation Diagrams
Canadian Electrical Code, and all Federal, State/Provincial and local codes and regulations in effect at the time of installation. Hydropool highly recommends the use of a new Siemens GFCI breaker for all of its products. Other GFCI’s and older Siemens GFCI’s may have tripping issues. - Page 14 EUROPE – RCD INSTALLATION NOTICE Important Note: Installation of the R.C.D. – Circuit Breaker, including ampere sizing and selection of conductor size and type, must be performed by a qualified electrician in accordance with National, Regional and Local Codes and Regulations in effect at the time of installation. 230 VOLT 50 HZ SINGLE PHASE RCD WIRING 230 VOLT 50 HZ DUAL PHASE RCD WIRING 230 VOLT 50 HZ THREE PHASE RCD WIRING...
-
Page 15: Filling, Checking And Starting Your Hot Tub
Follow the control instructions for your particular model hot tub to put the pump into low speed see section HYDROPOOL CONTROL SYSTEMS PUMP PRIMING / RELEASING AN AIR LOCK. On some systems a message will appear on the display indicating that the system is in PUMP PRIMING MODE (“RUN PMPS PURG AIR”). -
Page 16: Pump Priming / Releasing An Air Lock
O-RING / GASKET AT THE UNION STARTING (continued) The water should start circulating immediately. If the motor works but if you do not notice water circulating within the first 15 seconds, the pump may require priming due to trapped air (referred to as an ‘air lock’). If the pumps have not self-primed after 2 minutes and water is not flowing from the jets, DO NOT allow the pumps to continue to run. - Page 17 HYDROPOOL SERENITY SERIES CONTROL SYSTEMS NORTH AMERICA / EUROPE GECKO IN.YE3 INITIAL START UP TEMPERATURE CONTROL Before applying voltage to power up your hot tub, it is FUNCTIONALITY AND very important that you understand the sequence of ADJUSTMENT events that occur when the system is activated in order that the pump(s) can be primed efficiently and damage to the system can be avoided.
-
Page 18: North America / Europe
HYDROPOOL SERENITY SERIES CONTROL SYSTEMS NORTH AMERICA / EUROPE 4300, 4500, 6600, SE4L and SE5L MODELS KEYPAD FUNCTIONS AND DISPLAY ICONS JET KEY WHICH CONTROLS PUMP 1 ILLUM KEY WHICH CONTROLS THE LIGHTING AND THE PROGRAMMING FUNCTIONS TEMPERATURE UP KEY... -
Page 19: 5900 / 6800 & 6900 Controls
HYDROPOOL SERENITY SERIES CONTROL SYSTEMS NORTH AMERICA / EUROPE 5900, 6800 and 6900 MODELS KEYPAD FUNCTIONS AND DISPLAY ICONS JET KEY WHICH CONTROLS PUMP 1 JET KEY WHICH CONTROLS PUMP 2 ILLUM KEY WHICH CONTROLS THE LIGHTING AND THE PROGRAMMING... - Page 20 HYDROPOOL SERENITY SERIES CONTROL SYSTEMS NORTH AMERICA / EUROPE GECKO IN.YE3 PROGRAMMING THE FILTER / PURGE CYCLES The filter cycle menu consists of the following parameters: The start time (FS), the duration (Fd) and the frequency (FF) NOTE: A filter cycle consists of starting all the pumps and blower (if equipped) in high speed for 1 minute (purge step) then the pump associated with the filter cycle will run in low speed for the remaining duration of the filter cycle (clean up step).
- Page 21 HYDROPOOL SERENITY SERIES CONTROL SYSTEMS NORTH AMERICA / EUROPE GECKO IN.YE3 The display will show Edxx, with “xx” representing the duration in hours of the economy mode. Use the arrow keys to adjust the hour. Use the Light Key to jump to the next parameter, temperature units.
-
Page 22: Topside Control Panel Display Messages
LIGHT FUNCTION Press this key to activate the light press: rotating colours press: solid blue colour press: solid green colour press: solid red colour NOTE: Pressing the light key in intervals less than five seconds will scroll to the next colour. Once you have selected the colour another press will turn the light off. -
Page 23: Variable Air Therapy System Control
OPTIONAL VARIABLE AIR THERAPY SYSTEM CONTROL FUNCTIONS Press: Blower button on the main control to activate the system 1) ON/OFF Press: The blower starts at maximum speed. LED: ON Press: The blower stops. LED: OFF 2) TO CONTROL SPEED Press and hold: Speed goes up and down. LED: ON when pressing Release pressure at the desired speed 3) TO CONTROL PULSATION Press: Slow Pulsation Cycle. -
Page 24: Hydroclear Pure Water System
OPTIONAL HYDROCLEAR PUREWATER SYSTEM HOW IT WORKS This system combines the benefits of both Ozone and UV-C sanitization utilizing a patented UV Chamber to both inject ozone into the water, mix it and then expose it to powerful UV-C rays, all-in-one. This process not only kills and deactivates microorganisms in the water it passes, but also creates a powerful hydroxyl radical to burn off contaminants and dissolved solids within the water to significantly increase the clarity of the spa water. -
Page 25: Hot Tub Water Balance
For these reasons, it is very important to develop proper hot tub water maintenance habits and follow your Hydropool retailer’s recommended water maintenance procedures. Heater and other component failure due to improper water balance is not covered under warranty. -
Page 26: Initial Fill
4) Add sanitizing tablets (Bromine or Chlorine) to the dispenser: Built in dispenser: if your Hydropool hot tub was ordered with the optional built in bromine/chlorine dispenser, (located under the basket of the cartridge filter housing), refer to section CARTRIDGE FILTER for details on removing and re-installing the lid. -
Page 27: Glossary Of Water Maintenance Terms
GLOSSARY OF COMMON WATER MAINTENANCE TERMS 1. CHLORINE – in granular, liquid or puck/tablet form, is an oxidant and biocidal agent. It is very effective and fast acting. Recommended chlorine residual level is 3.0 to 5.0 ppm. 2. CHLORAMINES – a compound formed when chlorine combines with nitrogen or ammonia present in the water. -
Page 28: Water Balance Summary Chart
WATER BALANCE SUMMARY FOR YOUR HOT TUB* SANITIZER (ppm) IDEAL Chlorine 3.0 – 5.0 Bromine 3.0 – 5.0 CHEMICAL 7.4 – 7.6 Total Alkalinity (TA) 80 – 120 Calcium Hardness 200 – 400 500 – 1000 *National Spa and Pool Institute recommended levels for residential spas / hot tubs. WATER BALANCE TROUBLESHOOTING PROBLEM POSSIBLE CAUSES... - Page 29 Test total alkalinity levels and if necessary increase with sodium bicarbonate* pH resistant to changing High Total Alkalinity levels Test total alkalinity levels and if necessary decrease with sodium bisulfate* or muriatic acid* * Contact your local Hydropool retailer for specific product recommendation...
-
Page 30: Routine Hot Tub Maintenance
Soak your filter cartridge in a filter cartridge cleaning solution. Rinse thoroughly and, if possible, allow to dry before re-installing. Hydropool recommends purchasing a second filter so that while the first is cleaning, the other is clean and ready to install. -
Page 31: Cartridge Filter - Removal / Cleaning
7. A cleaning cylinder may be purchased from your HYDROPOOL Hot tub Retailer. 8. Rinse thoroughly and dry before replacing. 9. Hydropool recommends purchasing a spare filter cartridge so that you always have a clean substitute ready to rotate. 10. After the element has dried - if necessary, lightly brush between pleats with a fine paint-brush to remove remaining dirt particles. -
Page 32: Serenity Filter Grill And Leaf Bag
SERENITY FILTER GRILL AND LEAF BAG On the back of each Serenity filter grill is a leaf bag that is utilized to catch any surface debris and to extend the life of the filter cartridge. The leaf bag is attached the back of the grill with clips that are screwed into the grill and the loop holes on the leaf bag slip onto each hook on the clips. -
Page 33: Water Softeners
Days Formula (_______ ÷ 13.5 ) ÷ (________) = (_______) between water Volume of Average changes water in daily liters bathers EXAMPLE: 1000 liters divided by 13.5 divided by 2 = 37 days. The hot tub water must be changed when the amount of dissolved solids become excessive, and is usually indicated by “gray”... -
Page 34: Cleaning The Acrylic Surface
When a hot tub is uncovered, over 90% of heat is lost from the water surface. This evaporation also affects the chemical balance and could create humidity problems indoors. HYDROPOOL Safety Hard Covers are engineered for maximum thermal efficiency and appearance. They are hinged in the middle for easier handling, and the zip fastener allows the tapered foam inserts to be changed if damaged. -
Page 35: Protecting Your Cabinet Finish
The exclusive Soft Stride Floor System is available as a standard feature on the 4300, 4500, 5900, 6600, 6800 and 6900 Serenity models to provide a better grip, traction and comfort on both the steps and floor of the spa. -
Page 36: Winterizing Your Hydropool Hot Tub
In the event that you do not wish to use your hot tub year-round, it is very important that you properly winterize to protect against damage from freezing. Your HYDROPOOL retailer can perform this service for a nominal fee. If you choose to winterize your hot tub yourself, please follow the directions outlined below: Drain the hot tub entirely see section - DRAINING YOUR HOT TUB ... -
Page 37: What To Do In The Event Of
Should this occur or if the display shows partial messages, try resetting the system by turning power to the hot tub off, waiting a few minutes, then turning power on again. If this does not reset the system, contact your local Hydropool retailer or service organization. …POWER FAILURE OR SYSTEM FAULT DURING COLD WEATHER CONDITIONS If your control system will not reset, (ie. -
Page 38: Wiring Diagrams
IN.YE-3 NA WIRING DIAGRAM... - Page 39 IN.YE-3 EU WIRING DIAGRAM...
