Houd, wanneer u contact opneemt met de serviceafdeling, het complete typenummer bij de hand.

En cas de contact avec le service après-vente, ayez auprès de vous le numéro de type complet.

Halten Sie die vollständige Typennummer bereit,

wenn Sie mit der Kundendienstabteilung Kontakt aufnehmen.

When contacting the service department, have the complete type number to hand.

Sørg for at have hele typenummeret klar, når serviceafdelingen kontaktes.

Ha hele typenummeret for hånden når du kontakter serviceavdelingen.

Ha det kompletta typnumret till hands när du tar kontakt med serviceavdelningen.

Adressen en telefoonnummers van de serviceorganisatie vindt u op de garantiekaart.

Les adresses et les numéros de téléphone du service après-vente se trouvent sur la carte de garantie.

Adressen und Telefonnummern der Kundendienstorganisation ﬁ nden Sie auf der Garantiekarte.

You will ﬁ nd the addresses and phone numbers of the service organisation on the guarantee card.

Adressen og telefonnummeret til servicevirksomheden ﬁ ndes på garantikortet.

Du ﬁ nner adresser og telefonnumre til serviceorganisasjonen på garantikortet.

Adresser och telefonnummer till serviceorganisationen hittar du på garantikortet.

Gebruiksaanwijzing

Oven

Mode d'emploi

Four

Bedienungsanleitung

Ofen

Instructions for use

Oven

Anvendelse

Ovn

Bruksanvisning

Ovn

Bruksanvisning

Ugn

DX6411B

DX6411F/DX6492F

DX6492K/DX6411K

DX6492H/DX6411H

Need help?

Do you have a question about the DX6411B and is the answer not in the manual?

Questions and answers

Summary of Contents for Atag DX6411B

Page 1 You will ﬁ nd the addresses and phone numbers of the service organisation on the guarantee card. Adressen og telefonnummeret til servicevirksomheden ﬁ ndes på garantikortet. Du ﬁ nner adresser og telefonnumre til serviceorganisasjonen på garantikortet. Adresser och telefonnummer till serviceorganisationen hittar du på garantikortet. DX6411B DX6411F/DX6492F DX6492K/DX6411K DX6492H/DX6411H...
Page 2 Handleiding NL 3 - NL 60 Notice dútilisation FR 3 - FR 60 Anleitung DE 3 - DE 60 Manual EN 3 - EN 63 Brugsvejledning DA 3 - DA 60 Bruksanvisning NO 3 - NO 63 Bruksanvisning SV 3 - SV 63 Gebruikte pictogrammen - Pictogrammes utilisés - Benutzte Piktogramme Pictograms used - Anvendte piktogrammer - Symboler brukt Symboler som används...
Page 3 CONTENTS Control panel Oven features Accessories Using the accessories Features Using this manual Safety instructions Installation and connection Before you begin Setting the clock Initial cleaning To clean the oven Using the oven Setting the divider mode Setting the oven temperature Switching the oven off Setting the end time Setting the cook time...
Page 4 CONTENTS 6. Bottom heat + hot air 7. Twin mode 8. Auto menu programs for DX6411F/DX6492F 9. Auto menu programs for DX6411B/DX6411K/H DX6492K/H Cleaning and care Aqua cleaning Cleaning the oven door Oven door glass (only for DX6411B/DX6411F/DX6492F) Cleaning the side runners...
Page 5 CONTROL PANEL DX6411B/DX6411F/DX6492F DX6411K/H DX6492K/H Cavity select knob Window display Time / temp control knob Oven function button Lamp button Child lock button Clock button Kitchen timer button Cook time button End time button Temperature button Special features The oven comes equipped with the following special features.
Page 6 OVEN FEATURES Control panel Side runner Oven light Glass door Top heating elements Level 5 Level 4 Level 3 Level 2 Level 1 Door handle Note • Shelf levels are numbered from the bottom up. • The levels 4 and 5 are mainly used for grill mode. •...
Page 7 ACCESSORIES The following accessories are provided with your oven: Baking tray The baking tray could be used for the preparation of cakes, cookies and other pastries. Front Deep baking tray The deep baking tray should be used for roasting or collecting meat juices or fat drippings.
Page 8 USING THE ACCESSORIES Note • When using the deep baking tray or the baking tray to collect drippings from cooking foods, ensure that the tray is properly placed in the Side Runners. Allowing these accessories to contact the bottom surface of the oven can damage the enamel of the surface.
Page 9 USING THE ACCESSORIES Telescopic slide guides (only for DX6411F/DX6492F) Telescopic slide guides and other oven accessories might get very hot! Use kitchen gloves or other suitable protection! Telescopic slide guides are located inside the oven to the right and to the left in two different levels. •...
Page 10 FEATURES Safety shut off If a cooking time is not entered, the oven will shut itself off after the lengths of time indicated below. Shut off times for various temperature settings Under 105 °C 16 hours From 105 °C to 240 °C 8 hours From 245 °C to 300 °C 4 hours...
Page 11 USING THIS MANUAL Thank you for purchasing an ATAG built-in oven. First read the user instructions carefully and completely before starting to use the appliance, and keep them carefully for future reference. Stick the data card in the space provided, at the back of the manual.
Page 12 • Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. If your oven needs repair, contact the Atag Customer Service or your dealer. • If the supply cord is defective, it must be...
Page 13 SAFETY INSTRUCTIONS Warning • This appliance and the accessible parts become hot during use. Do not touch the hot components. Keep children younger than 8 away from the appliance unless you can watch them continuously. • This equipment may be used by children older than 8, as well as by people with physical, sensory or learning difficulties or with a lack of experience and knowledge,...
Page 14 SAFETY INSTRUCTIONS • Frozen foods such as pizzas should be cooked on the wire rack. If the baking tray is used, it may become deformed due to the great variation in temperatures. • Do not pour water into the oven bottom when it is hot.
Page 15 INSTALLATION AND CONNECTION Safety instructions for the installation This oven may be installed only by an approved electrician. The installer is responsible for connecting the appliance to the mains and in so doing for observing the relevant safety regulations. • Ensure protection from live parts when installing the oven. •...
Page 16 INSTALLATION AND CONNECTION 1. Fix the oven on both sides using screws. 2. After installation, remove the vinyl protective film from the door to the appliance and the protective film from the interior surfaces of the oven. Connecting to the mains power supply •...
Page 17 INSTALLATION AND CONNECTION Note When the power is connected, the electronics of the oven are initialised; this neutralizes the lighting for a few seconds. The electric cable (H05 RR-F or H05 VV-F, Min. 1.5 m, 1.5~2.5 mm²) must be long enough for it to be connected to the built-in oven standing on the floor in front of its unit.
Page 18 BEFORE YOU BEGIN Setting the clock When the power is first supplied to the oven, the display on the control panel will light briefly. After 3 seconds, you will see ‘12:00’ in the display. Press the Clock Button. The ‘ ’...
Page 19 BEFORE YOU BEGIN Initial cleaning Clean the oven thoroughly before using for the first time. • Do not use sharp or abrasive cleaning materials. These could damage the oven surface. For ovens with enamel fronts, use commercially available cleaning products. To clean the oven 1.
Page 20 USING THE OVEN Oven functions Conventional Food is heated by top and bottom heating elements. This setting is suitable for baking and roasting. Top Heat + Hot air We recommend this mode when roasting meat. The top heating element is in operation and the fans operate to circulate the hot air coming from top and back wall heating element.
Page 21 USING THE OVEN Setting the divider mode For upper, twin and lower modes, insert the divider at the ‘OFF’ position of Divider Select Knob. For single mode, remove the divider at the ‘OFF’ position. Turn the Divider Select Knob to select the desired partition.
Page 22 USING THE OVEN Steam Clean Mode Self Clean 1. P1 Mode Remove all accessories and the 2. P2 (DX6411K/H Side Runners. 3. P3 DX6492K/H) Upper mode Only the upper heating element operates. The divider should be inserted. Hot air Top Heat + Hot air Large Grill You can choose to operate the lower mode also after some time (see Twin mode).
Page 23 USING THE OVEN Lower mode Only the lower heating element operates. The divider should be inserted. Hot air Bottom Heat + Hot air You can choose to operate the upper mode also after some time (see Twin mode). Twin mode The upper and lower modes operate at the same time.
Page 24 USING THE OVEN Top Heat + Hot air Large Grill Twin mode 2: As the upper mode starts, if the Oven Function Button is pressed or if 15 seconds elapse and there has been no further adjustment, the oven moves to the lower mode.
Page 25 USING THE OVEN Single mode Hot air Top Heat + Hot air Conventional Large Grill Grill Bottom Heat + Hot air EN 25...
Page 26 USING THE OVEN Setting the oven temperature In single, upper and lower modes Press the Temperature Button. Turn the Time / Temp Control Knob to adjust the temperature in increments of 5 °C. Single Mode 40 °C – 250 °C (Large Grill &...
Page 27 USING THE OVEN Switching the oven off To switch the oven off, turn the Divider Select Knob to the ‘Off’ position. Setting the end time You can set the end time during cooking. In single, upper and lower modes Press the End Time Button. Example: current time is 12:00.
Page 28 USING THE OVEN In twin mode End times for the upper and lower modes can be selected using the End Time Button and the Time / Temp Control Knob. Press the End Time Button twice (lower mode). Example: current time is 12:00. Turn the Time / Temp Control Knob to set the desired end time.
Page 29 USING THE OVEN Setting the cook time You can use the ‘set cook time function’ in operating status. In single, upper and lower modes Press the Cook Time Button. Turn the Time / Temp Control Knob to set the desired cook time. Press the Cook Time Button.
Page 30 USING THE OVEN In twin mode Cook times for the upper and lower modes can be selected by using the Cook Time Button and the Time / Temp Control Knob. Press the Cook Time Button twice (lower mode). Turn the Time / Temp Control Knob to set the desired cook time.
Page 31 USING THE OVEN Setting the delayed start time Case 1 - Cook time is entered first If the end time is entered after the cook time has already been set (see page 28), the cook time and the end time are calculated and if necessary the oven sets a delayed start point.
Page 32 USING THE OVEN Case 2 - End time is entered first If the cook time is entered after the end time has already been set, the cook time and the end time are calculated and if necessary the oven sets a delayed start point. Press the Cook Time Button.
Page 33 USING THE OVEN Kitchen timer Press the Kitchen Timer Button once. The alarm symbol ﬂ ashes. Turn the Time / Temp Control Knob to set the desired time. Example: 5 minutes Press the Kitchen Timer Button to start the kitchen timer. When the set time has elapsed, an audible signal sounds.
Page 34 USING THE OVEN Child safety function Press the Child Lock Button. Hold for 3 seconds. The lock symbol will appear in the display ﬁ eld. Press the Child Lock Button. Hold for 3 seconds again to unlock. • When locked, all buttons and knobs except the Divider Select Knob and the Child Lock Button fail to operate.
Page 35 USING THE OVEN Auto cook Turn the Divider Select Knob to Auto Cook. Press the Oven Button. Select the desired recipe by turning the Time / Temp control knob to the right and left. Wait to select weight 5 seconds after selecting a recipe. For a recipe with weight ﬁ...
Page 36 OVEN FUNCTIONS 1. Conventional The conventional function is ideal for baking and roasting foods arranged on one rack. Both the top and bottom heating elements operate to maintain the oven temperature. We recommend to preheat the oven in conventional mode. Temperature Food Item Shelf Level...
Page 37 OVEN FUNCTIONS 2. Top Heat + Hot air The top heating element is in operation and the fan operates to constantly circulate the hot air.We recommend to preheat the oven with Top Heat + Hot air mode. Temperature Time Food Item Shelf Level Accessory (°C)
Page 38 OVEN FUNCTIONS 3. Hot air This function bakes foods placed on up to three shelves and is also appropriate for roasting. Cooking is achieved by the heating element on the rear wall and the fan distributes the heat. We recommend to preheat the oven in Hot air mode.
Page 39 OVEN FUNCTIONS 4. Large grill The large grill function grills large quantities of flat foods, such as steaks, schnitzels and fish. It is also suitable for toasting. Both the top heating element and the grill are on in this mode. We recommend to preheat the oven using Large Grill mode.
Page 40 OVEN FUNCTIONS 5. Small grill This setting is for grilling smaller amounts of flat foods, such as steaks, schnitzels, fish and toast, placed in the middle of the tray. Only the top element is in operation. Put food in the centre of accessory.
Page 41 OVEN FUNCTIONS 6. Bottom heat + hot air The Bottom Heat + Hot air mode is for recipes calling for a moist topping and a crisp base, as with foods like pizzas, quiches lorraine, German-style open fruitcakes and cheesecakes. We recommend to preheat the oven in Bottom Heat + Hot air mode.
Page 42 OVEN FUNCTIONS 7. Twin mode Using twin mode you can cook two different food items in your oven. When cooking in upper and lower cavity you can use different temperatures, cooking modes and cooking times. For example, you can grill steaks and bake gratin simultaneously. Using the divider, you can cook gratin in the lower and steaks in the upper part of the oven.
Page 43 OVEN FUNCTIONS 8. Auto menu programs for DX6411F/DX6492F The following table presents 27 Auto Programs for Cooking, Roasting and Baking. Those can be used in the single cavity of your oven. Always remove the divider. It contains its quantities, weight ranges and appropriate recommendations.
Page 44 OVEN FUNCTIONS Food Item Weight/kg Accessory Shelf Level 1. 1.0 - 1.1 Roast wire rack Whole Chicken 2. 1.2 - 1.3 Deep baking tray Brush whole chicken with oil and spices and put on roast wire rack. Turn over, as soon as the oven beeps.
Page 45 OVEN FUNCTIONS Food Item Weight/kg Accessory Shelf Level Apple Pie 1. 1.2 - 1.4 Wire rack Prepare apple pie (Dutch style) in a round black metal dish with a diameter 24 cm. 1. 0.5 - 0.6 Bundt Cake 2. 0.7 - 0.8 Wire rack 3.
Page 46 OVEN FUNCTIONS 9. Auto menu programs for DX6411B/DX6411K/H DX6492K/H The following table presents 16 Auto Programs for Cooking, Roasting and Baking. Those can be used in the single cavity of your oven. Always remove the divider. It contains its quantities, weight ranges and appropriate recommendations.
Page 47 OVEN FUNCTIONS Food Item Weight/kg Accessory Shelf Level Loaf Cake 1. 0.7 - 0.8 Wire rack Put dough into a rectangular, buttered, black metal baking dish, with a length of 30 cm. Apple Pie 1. 1.2 - 1.4 Wire rack Prepare apple pie (Dutch style) in a round black metal dish with a diameter 24 cm.
Page 48 CLEANING AND CARE Pyrolitic Self Cleaning (only for DX6411K/H DX6492K/H) This mode is for cleaning the oven automatically. It burns the leftover grease in the oven so that it can be wiped out when the oven cools down. During the Pyrolitic Self Cleaning the oven door is locked automatically. When the oven temperature heats up to 300 °C, Door locking ( ) the door will be locked automatically for safety.
Page 49 CLEANING AND CARE Aqua cleaning Remove all accessories from the oven, including the Side Runners (see page 57). Pour approximately 400 ml (3 / 4 pint) of water onto the bottom of the empty oven. Use normal water only, no distilled water. Close the oven door.
Page 50 CLEANING AND CARE Turn the Divider Select Knob to ‘Off’ to end the operation and clean the interior. Aqua cleaning notes • Take care when opening the door before the end of the aqua cleaning procedure; the water on the bottom is hot. •...
Page 51 CLEANING AND CARE Warning • Make sure the oven and accessory is cool before cleaning. • Do not use high - pressure water cleaners or steam jet cleaners to clean the oven. Rapid drying 1. Leave the oven door ajar at an angle of approximately 30°. 2.
Page 52 CLEANING AND CARE Cleaning the oven door For normal use, the oven door must not be removed but if removal is necessary, for example, for cleaning purposes, follow these instructions. Caution: The oven door is heavy. Door removal 1. Open the door and flip open the clips at both hinges completely. 2.
Page 53 CLEANING AND CARE Attaching the door 1. With the clips still flipped open, align the door hinges into the hinge holes. 2. Rotate the door toward the horizontal line and flip the clips closed. The hinge is normally inserted. Hinge Hinge hole EN 53...
Page 54 CLEANING AND CARE Oven door glass (only for DX6411B/DX6411F/DX6492F) The oven door is equipped with three sheets of glass placed against each other. These sheets can be removed for cleaning. Door glass removal The oven door is equipped with three sheets of glass placed against each other.
Page 55 CLEANING AND CARE Oven door glass (only for DX6411K/H DX6492K/H) The oven door is equipped with four sheets of glass placed against each other. The inner & middle sheets can be removed for cleaning. Warning • Whenever the door is separated from the oven, the clips should be flipped open.
Page 56 CLEANING AND CARE Detach the glass #3 from the door Glass #3 Door bracket Spring bracket (Right and Left) Glass #1 Glass #2 Glass #3 Glass #4 • Clean the sheets with warm water or washing-up liquid and polish dry with a soft clean cloth. Assembling the door 1.
Page 57 CLEANING AND CARE Cleaning the side runners To clean the interior of the oven, the Side Runners can be removed. Detaching the Side Runners Press the central part of the side runner top portion. Rotate the side runner by approximately 45°. Pull the side runner out of the two holes in the bottom and remove the side runner.
Page 58 CLEANING AND CARE Cleaning the Top Heater (only for DX6411B/ DX6411F/DX6492F) Remove the upper nut circular by turning it anti-clockwise while holding the top of the heater. The front of the Top Heater inclines down- wards. When the cleaning has been done, lift the top of the heater back to its original level and turn the nut circular clockwise.
Page 59 • Protect the oven light bulb and the glass cap by laying a cloth on the bottom of the oven compartment. Bulbs can be purchased from the ATAG Customer Service. Replacing the rear oven lamp and cleaning the glass cap 1.
Page 60 TROUBLESHOOTING If you have problems with your oven, try the solutions suggested below. They may save you the time and inconvenience of an unnecessary service call. What should I do if the oven doesn’t heat up? Check to see if one of the following actions resolves the issue: •...
Page 61 ‘Setting the divider mode’ (see page 21). For upper, twin and lower mode, the divider should be inserted, and for single mode, the divider should be eliminated. If any of these errors occur, please contact ATAG Customer Service. EN 61...
Page 62 TECHNICAL SPECIFICATIONS Model DX6411B/DX6411F/DX6492F DX6411K/H DX6492K/H Power Source 230 V ~ 50 Hz 230 V ~ 50 Hz Output Rating max. 3650 W max. 3650 W Dimensions (W x H x D) 598 x 595 x 566 mm 598 x 595 x 566 mm...
Page 63 DISPOSAL OF APPLIANCE AND PACKAGING The packaging of this appliance is recyclable and may have been made of: • cardboard • paper • polythene foil (PE) • CFC-free polystyrene (PS hard foam) • polypropylene tape (PP). Dispose of these materials in a responsible manner and in accordance with government regulations.
Page 64 NOTE EN 64...
