CTEK CS FREE 2005 User Manual page 17

Technical specifications
Model number
Input
Output
USB-A Output
USB-C Output
Ambient operating temperature
Battery types
Battery capacity
Ingress protection
Net weight (unit with cables)
Dimensions (L x W x H)
Warranty
INTERNAL BATTERY
Battery capacity
Cell chemistry
Cell type
Discharge temperature
Charge temperature
Shelf Life
Life Span
MAINS ADAPTER
Input
Output
Plug
Cable length
Cable type
Limited warranty
CTEK issues a limited warranty to the original purchaser of the product. Depending on the product,
the limited warranty period will vary. The limited warranty is not transferable. The warranty applies
to manufacturing faults and material defects. The warranty is void if the product has been handled
carelessly or repaired by anyone other than CTEK or its authorized representatives. CTEK makes
no warranty other than this limited warranty and is not liable for any other costs other than those
mentioned above, i.e. no consequential damages. Moreover, CTEK is not obligated to any other
warranty other than this warranty.
Revisions
Changes to the product can cause changes to the maintenance work. The descriptions and
specifications contained in this manual were in effect at printing. To make sure that the
maintenance instructions are complete and up to date, always read the manual published on our
website.
CTEK SWEDEN AB
2005
USB-C, 5VDC–25VDC, 3ADC/60W Max
12VDC, minimum 3.0VDC, 20A/240W Max
5VDC, 2.4ADC/12W Max
5VDC, 9VDC, 12VDC, 15VDC, 20VDC, 3ADC/60W Max
-20°C to +50°C, -4°F to 122°F
12V: WET, MF, Ca/Ca, AGM, EFB, GEL, LiFePO
10Ah–130Ah
IP54
1.4kg, 3lbs
248 x 98 x 78mm, 9.8 x 3.9 x 3.1in
2 Year
66Wh
Polymer Lithium-ion
Pouch Cell
-20°C to +50°C, -4°F to 122°F
0°C to +45°C, 32°F to 113°F
1 Year
300 Cycles, 80%
100–240VAC, 50–60Hz
USB-C, 5VDC-20VDC, 3ADC, 60W Max
AC plugs that fit different regions around the world
1.0m, 39in
USB-C
