Examples of module position coding
The incorrect insertion of electronic units can be pre-
vented if the base modules are given coding elements
KOSM BHZ5.00 (Order No.1483050000)
Three coding sockets each with four possible positions can
be plugged into every base module. This results in a maxi-
mum of 4 or 64 codes.
3
It is practical to use either functionally oriented or slot-
oriented coding. Example codes are provided for each
coding scheme in the following tables.
Base module with three coding places and coding sockets plugged (Example code 013)
0 1 0
Possible positions of the coding sockets:
3 2 3
0
A-2
1 2
1 0 1
0
2 3 2
3
1 2
Functionally-oriented coding
Coding position
Code 1
01
0
02
0
03
0
10
0
11
0
12
0
3
40
2
41
2
1
13
0
20
1
21
1
30
1
22
2
1
3
50
3
51
3
52
3
53
3
60
3
61
3
62
3
Manual u-control
2 3 Meaning
0 0 4 digital inputs (4DI)
0 1 8 digital inputs (8DI)
0 2 16 digital inputs (16DI)
2 1 4 digital outputs (4DO)
2 2 8 digital outputs (8DO)
2 3 16 digital outputs (16DO)
1 3 1-channel counter (1CNT)
2 0 2-channel counter (2CNT)
3 0 2-channel PWM module (2PWM)
0 3 4 analogue inputs (4AI)
1 0 8 analogue inputs (8AI)
3 1 4 analogue outputs (4AO)
1 1 4 temperature inputs (4AI-X-DIAG)
0 1 Power-feed module input (PF-I)
0 2 Power-feed module output (PF-O)
0 3 Power-feed module output 1DI-SIL
1 0 Power-feed module output 2DI-SIL
2 3 Potential distributor +
3 0 Potential distributor –
3 1 Potential distributor FE (16AUX-FE)
