DEH-41473

Section 8, Operating the Switchgear

Covers how to operate the circuit breaker, and contains
information concerning draw-out provisions, doors, and
various accessories.

Section 9, Energizing the Switchgear

Outlines the steps to be taken before and during the electrical
energization of the equipment.

Section 10, Maintaining the Switchgear

Provides instructions for all preventive maintenance,
servicing, and lubrication information for the switchgear
equipment. Included is service and maintenance data for the
circuit breakers, instrument compartments, instruments, bus
bar joints, and cable connections. This section also includes
paint refinishing requirements.
Section 11, Common Switchgear Accessories and
Kits
Outlines a listing of common accessory and kit items
available from the factory.

Appendices A, B, C, D, E, F, and G

Contains information concerning screw and bolt torque
values, circuit breaker rejection features, circuit breaker
information, exhaust plenum system component details, and
a open space for taking notes.
©2016 General Electric. All rights reserved.
Courtesy of NationalSwitchgear.com
AKD-20 AR / Entellisys AR Low-voltage Switchgear

Related Publications

Addendum's to this instruction manual are the available
service and maintenance publications supplied separately for
circuit breakers, relays and other devices not described in this
instruction manual.
In addition to instruction manuals, the following drawings will
be supplied as required for each order of AKD-20 AR and
Entellisys AR switchgear equipment.
These are all the documents necessary to install, operate, and
maintain the equipment. One complete set of drawings and
instruction manuals is shipped with the equipment.

General Arrangement Drawings

Drawings which Include front view and floor plan details.

Elementary and Connection Drawings

Drawings (or wiring routing tables) which indicate and identify
test and connection points including terminal blocks, device
studs, switch contact developments, and remote connections.

Summary of Switchgear Equipment

Documents which list of all the components furnished with
the switchgear, including the breakers, identified by catalog
number.
Figure 1.1 AKD-20 AR low-voltage switchgear
Section 1. Introduction
2
