DOGA MD Series Instruction Manual page 89

Preset #
Temporary
Virtual
parameter
Preset #1
in RAM
Temporary
Virtual
parameter
model #1
in RAM
Temporary Virtual
parameter advenced
in RAM #1
Remote
Operation
control
60342 07/20
Instructions manual
Parameter
Forward / Loosening ( F=0, L=1 )
Screw count value
Input status ( MSB=IN 8, LSB=IN 1)
Output status ( MSB=OUT 8, LSB=OUT 1)
Motor Temperature
Molde No
Current step #
Total count
Currnet step count
Currnet Preset #
Function
Model Complete
TC/AM_AC/TM
Torque
Torque min/max (%)
Target angle(degree)
Min angle(degree)
Max angle(degree)
Snug torque(%)
Speed (rpm)
Free fastenig angle(degree)
Free fastenig speed(rpm)
Soft start(1-300ms)
Seating point (%) 10-90
Torque rising rate(ms) 50-200
Torque holding time(ms) 1-20
Torque compensation (%) 90-110
Model1 - 20
advenced parameter no 1
Alarm reset
Driver Lock
0 : Unlock 1: Lock all dirction
2 : Lock Loosening 3: Lock Fastening
No use ( Factory only )
Remote start ( 0 : Stop, 1 : Start )
/ MD Series & MDC v2
3535 - 3554
3520 - 3534
Factory
Address
setting
3309
3310
3311
3312
3313
3314
3315
3316
3317
3318
3319
3320
3500
3501
3502
3503
3504
3505
3506
3507
3508
3509
3510
3511
3512
3513
3514
4000
4001
4002
4003
