DOGA GX-G Series Instruction Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

1
Instructions manual / GX-G Screwdrivers
GX-G Screwdrivers
GXA-G Screwdrivers
(40 Volts)
INSTRUCTIONS MANUAL
INSTRUCTIONS MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GX-G Series and is the answer not in the manual?

Questions and answers

Related Manuals for DOGA GX-G Series

Summary of Contents for DOGA GX-G Series

  • Page 1 Instructions manual / GX-G Screwdrivers GX-G Screwdrivers GXA-G Screwdrivers (40 Volts) INSTRUCTIONS MANUAL INSTRUCTIONS MANUAL...
  • Page 2 Instructions manual / GX-G Screwdrivers IMPORTANT The tool delivered with this manual may have been modified for specific needs. In that case, please give us the tool code number written on our shipping note or the approximate tool delivery date when you place an order for a new similar tool or for spare parts. In that way, you will be sure to get the required tool and/or spare part.

  • Page 3: Table Of Contents

    Instructions manual / GX-G Screwdrivers SUMMARY GENERAL SAFETY RULES ....................4 SPECIFIC SAFETY RULES ....................5 Electric specification ......................6 Mechanical specification of XS-40D ..................6 Input Power select ......................... 6 Screwdriver Specification ..................... 7 Torque curve (No load - Max. speed)..................8 Panel of each model ......................

  • Page 4: General Safety Rules

    Instructions manual / GX-G Screwdrivers 1. GENERAL SAFETY RULES WARNING! Read and understand all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious personal injury SAVE THESE INSTRUCTIONS 1.1 Work Area - Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. - Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust.

  • Page 5: Specific Safety Rules

    Instructions manual / GX-G Screwdrivers - Store idle tools out of reach of children and other untrained persons. Tools are dangerous in the hands of untrained users. - Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained tools, with sharp cutting edges are less likely to bind and are easier to control.

  • Page 6: Electric Specification

    Instructions manual / GX-G Screwdrivers Electric specification Items Power controller Screwdriver GX150-G, GX220-G, GX450-G, Model XS-40D GX150P-G, GX220P-G, GX450P-G Input 110 / 230VAC (selectable) DC40V Output 30/40VDC ( selectable ) Rated power 2.5A 95W Maximum output current Intermittent operation 10s On / 30s Off Safety system CE certified ( Class I ) Class III...

  • Page 7: Screwdriver Specification

    Instructions manual / GX-G Screwdrivers 6. Screwdriver Specification ■ Specification Options Rotation Torque Speed Clutch** Software* Model Start (Kgf.cm) (Rpm) Standard Soft Stop Standard ○ ○ GX 150/ESD-G 3~15 800~1700 ○ ○ GX 220/ESD-G LEVER 6~22 600~1200 ○ ○ GX 450/ESD-G 10~45 300~600 ○...

  • Page 8: Torque Curve (No Load - Max. Speed)

    Instructions manual / GX-G Screwdrivers 7. Torque curve (No load - Max. speed) GX 150 : Silver spring, dia 2,3 mm GX 220 : Gold spring, dia 2,5 mm GX 450 : Bronze spring , dia 2,2 mm Changing springs : 1 - Loosen completely the torque adjusting ring.

  • Page 9: Operation

    Instructions manual / GX-G Screwdrivers 10. Operation 10.1 Speed & Soft Start setting ( GX___ -G) ( GXA___ -G) Speed Selection: 1) Press the Speed button for 2 seconds to visit to PROGRAM mode. Then the two LED lights will display colours depending on the set speed.

  • Page 10: Speed/Angle Control & Auto Reverse ( Gxt

    Instructions manual / GX-G Screwdrivers 10.2 Speed/Angle control & Auto reverse ( GXT__ -G) Model: GXT150-G, GXT220-G, GXT450-G One triggering by the lever can make 3 steps operation sequence in a cycle ■ Start, Stop and Direction in a cycle →...
  • Page 11 Instructions manual / GX-G Screwdrivers ■ Angle setting for first RUN ① Keep the first Run button pressed over 2 sec. for angle setting. Then press one by one for the desired rotating angle ② Select the R position of F/R switch for increasing set angle or F position for decreasing set angle ③...
  • Page 12 Instructions manual / GX-G Screwdrivers ■ Rotating speed setting ① Keep both first Run & stop time buttons pressed over 2 sec. to unlock. Then click one by one for the desired rotating speed. ② Select the R position of F/R switch for increasing speed or F position for decreasing speed ③...
  • Page 13 Instructions manual / GX-G Screwdrivers ■ Application Example First Stop Auto Applications with different HOLD Reverse sequence in a cycle Angle Time Angle Normal Normal screwdriver screwdriver It stops at the set torque Angle ON(1) control It stops at set angle(1) Tapper or ON(3) Insert...

  • Page 14: Change Notification Of T Option - Run And Torque Up Signals

    Instructions manual / GX-G Screwdrivers 11. Change Notification of T Option - run and torque up signals Effective from GXT, S/N: 1805060073 and GXT-G, S/N: 1805080168. Applicable to GXT 30V and GXT-G 40V Electric Screwdrivers Concerns feature of out signals : run and torque up 1) Complete Motor Run Signal Out During One Cycle If the user set 1st run-stop-reverse turn as a complete cycle, motor run signal will last for a cycle.

  • Page 15: Exploded Views And Part List

    Instructions manual / GX-G Screwdrivers 12. Exploded views and part list 12.1 GX150-G and GX220-G • Exploded view...
  • Page 16 Instructions manual / GX-G Screwdrivers • Part list CODE GX220- DESCRIPTION GX150-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070335 581-0065 SPRING [TORQUE] 1070336 581-0067 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR 1070305...
  • Page 17 Instructions manual / GX-G Screwdrivers 1070319 579-0013 SNAP RING 1070320 510-0001 BEARING HOLDER 1070321 527-0023 C-RING [STOP] 1002864 557-0032 PIN [NEEDLE] 6~12 1070230 307-0034 BIT SOCKET ASSY 16(2),22~24 1070228 304-0029 BEARING COVER + SHAFT ASSY 26~35 1070231 901-0011 GEAR BOX 26~35 1070235 901-0012...

  • Page 18: Gx450-G

    Instructions manual / GX-G Screwdrivers 12.2 GX450-G • Exploded view...
  • Page 19 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX450-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070302 581-0069 SPRING [TORQUE] 1075008 515-0009 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR 1070305 581-0025 SPRING [COLLAR] 1070306...
  • Page 20 Instructions manual / GX-G Screwdrivers 6~12 1070230 307-0034 BIT SOCKET ASSY 16 ,22,26,27 1070221 304-0031 BEARING COVER + SHAFT ASSY 29~38 1070236 901-0013 GEAR BOX 44,45 1076002 903-0048 NF HOUSING SET 59,60 1012530 903-0177 PCB SET 1~16,21~31,42 1081402 901-0063 DOUBLE BEARING UPGRADE KIT...

  • Page 21: Gx150P-G And Gx220P-G

    Instructions manual / GX-G Screwdrivers 12.3 GX150P-G and GX220P-G • Exploded view...
  • Page 22 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX150P-G GX220P-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070335 581-0065 SPRING [TORQUE] 1070336 581-0067 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1070324 316-0023 COVER ASSY [TOP] 1070325 579-0002 SNAP RING 1070326 524-0007 COLLAR [A] 1070328...
  • Page 23 Instructions manual / GX-G Screwdrivers 26~35 1070231 901-0011 GEAR BOX 26~35 1070235 901-0012 GEAR BOX 42,43 1076002 903-0048 NF HOUSING SET 51,52 1012531 903-0178 PCB SET 1~12,16,21,22,24,60,61,63 1081401 901-0062 DOUBLE BEARING UPGRADE KIT 1~12,16,21,22,24,60,61,63 1035001 901-0072 DOUBLE BEARING UPGRADE KIT...

  • Page 24: Gx450P-G

    Instructions manual / GX-G Screwdrivers 12.4 GX450P-G • Exploded view...
  • Page 25 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX450PG 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070302 581-0069 SPRING [TORQUE] 1075008 515-0009 WRENCH BOLT 1070324 316-0023 COVER ASSY [TOP] 1070325 579-0002 SNAP RING 1070326 524-0007 COLLAR [A] 1070328 581-0026 SPRING [COLLAR] 1070329...

  • Page 26: Gxa150-G And Gxa220-G

    Instructions manual / GX-G Screwdrivers 12.5 GXA150-G and GXA220-G • Exploded view...
  • Page 27 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GXA150-G GXA220-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070335 581-0065 SPRING [TORQUE] 1070336 581-0067 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1075008 515-0009 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR 1070305 581-0025 SPRING [COLLAR]...
  • Page 28 Instructions manual / GX-G Screwdrivers 1070320 510-0001 BEARING HOLDER 1070321 527-0023 C-RING [STOP] 1070333 526-0036 COVER [DUST ] 1075115 571-0010 SCREW 6~12 1070230 307-0034 BIT SOCKET ASSY 22,24 1070207 304-0029 BEARING COVER + SHAFT ASSY 26~35 1070231 901-0011 GEAR BOX 26~35 1070235 901-0012 GEAR BOX...

  • Page 29: Gxa450-G

    Instructions manual / GX-G Screwdrivers 12.6 GXA450-G • Exploded view...
  • Page 30 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GXA450-G 1070300 505-0002 ADJUSTER 1073001 557-0003 PIN [ADJUST] 1070302 581-0069 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1075008 515-0009 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR...
  • Page 31 Instructions manual / GX-G Screwdrivers 1075115 571-0010 SCREW 6~12 1070230 307-0034 BIT SOCKET ASSY 16 ,22,26,27 1012524 304-0033 BEARING COVER + SHAFT ASSY 29~38 1070236 901-0013 GEAR BOX 44,45 1012534 903-0181 GX HOUSING SET 59,60 1070219 903-0099 PCB SET 1~16,21~31,42 1012527 901-0133 DOUBLE BEARING UPGRADE KIT...

  • Page 32: Exploded Views And Part List For Tools With Minimum Sn 1701080036

    Instructions manual / GX-G Screwdrivers 13. Exploded views and part list for tools with minimum SN 1701080036 13.1 GX150-G and GX220-G • Exploded view...
  • Page 33 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX150-G GX220-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070335 581-0065 SPRING [TORQUE] 1070336 581-0067 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR...
  • Page 34 Instructions manual / GX-G Screwdrivers 1070316 548-0116 LABEL [WINDOW] 582-0035 SUPPORTER [TORQUE SPRING 1070317 WASHER] 1070318 582-0044 SUPPORTER [TORQUE SPRING] 1070319 509-0022 BEARING [BALL] 1070320 579-0013 SNAP RING 1070321 510-0001 BEARING HOLDER 1070321 527-0023 C-RING [STOP] 1~16, 21~24 , 40 , 66 1081400 901-0061 DOUBLE BEARING UPGRADE KIT...

  • Page 35: Gx450-G

    Instructions manual / GX-G Screwdrivers 13.2 GX450-G • Exploded view...
  • Page 36 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX450-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070302 581-0069 SPRING [TORQUE] 1075008 515-0009 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR 1070305 581-0025 SPRING [COLLAR] 1070306...
  • Page 37 Instructions manual / GX-G Screwdrivers 1070318 509-0022 BEARING [BALL] 1070319 579-0013 SNAP RING 1070320 510-0001 BEARING HOLDER 1070321 527-0023 C-RING [STOP] 1070322 547-0003 1070323 515-0024 WRENCH BOLT * Bold letters are assembled parts for users.

  • Page 38: Gx150P-G And Gx220P-G

    Instructions manual / GX-G Screwdrivers 13.3 GX150P-G and GX220P-G • Exploded view...
  • Page 39 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX150P-G GX220P-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070335 581-0065 SPRING [TORQUE] 1070336 581-0067 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1070324 316-0023 COVER ASSY [TOP] 1070325 579-0002 SNAP RING 1070326 524-0007 COLLAR [A]...
  • Page 40 Instructions manual / GX-G Screwdrivers 1070317 582-0044 SUPPORTER [TORQUE SPRING] 1002864 557-0032 PIN [NEEDLE] 1070321 527-0023 C-RING [STOP] 1~12,16,21,22,24,60,61,63 1081401 901-0062 DOUBLE BEARING UPGRADE KIT 1~12,16,21,22,24,60,61,63 1035001 901-0072 DOUBLE BEARING UPGRADE KIT 1077695 330-0038 MOTOR ASSY * Bold letters are assembled parts for users.

  • Page 41: Gx450P-G

    Instructions manual / GX-G Screwdrivers 13.4 GX450P-G • Exploded view...
  • Page 42 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GX450P-G 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070302 581-0069 SPRING [TORQUE] 1075008 515-0009 WRENCH BOLT 1070324 316-0023 COVER ASSY [TOP] 1070325 579-0002 SNAP RING 1070326 524-0007 COLLAR [A] 1070328 581-0026 SPRING [COLLAR] 1070329...

  • Page 43: Gxa150-G And Gxa220-G

    Instructions manual / GX-G Screwdrivers 13.5 GXA150-G and GXA220-G • Exploded views...
  • Page 44 Instructions manual / GX-G Screwdrivers Part list CODE DESCRIPTION GXA150A GXA220A 1070300 505-0002 ADJUSTER 1070301 557-0003 PIN [ADJUST] 1070335 581-0065 SPRING [TORQUE] 1070336 581-0067 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1075008 515-0009 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304...
  • Page 45 Instructions manual / GX-G Screwdrivers 582-0035 SUPPORTER [TORQUE SPRING 1070316 WASHER] 1070317 582-0044 SUPPORTER [TORQUE SPRING] 1070318 509-0022 BEARING [BALL] 1070319 579-0013 SNAP RING 1070320 510-0001 BEARING HOLDER 1070321 527-0023 C-RING [STOP] 1~17,22~26,62~67 1070238 901-0130 DOUBLE BEARING UPGRADE KIT 1~17,22~26,62~67 1070239 901-0131 DOUBLE BEARING UPGRADE KIT...

  • Page 46: Gxa450-G

    Instructions manual / GX-G Screwdrivers 13.6 GXA450-G • Exploded view...
  • Page 47 Instructions manual / GX-G Screwdrivers • Part list CODE DESCRIPTION GXA450A 1070300 505-0002 ADJUSTER 1073001 557-0003 PIN [ADJUST] 1070302 581-0069 SPRING [TORQUE] 1075080 515-0008 WRENCH BOLT 1075008 515-0009 WRENCH BOLT 1070303 316-0024 COVER ASSY [TOP] 1075005 527-0017 C-RING [BIT SOCKET] 1070304 524-0003 COLLAR...
  • Page 48 Instructions manual / GX-G Screwdrivers 1070321 527-0023 C-RING [STOP] 1~17,22~29,65~70 1012527 901-0133 DOUBLE BEARING UPGRADE KIT 1070333 526-0036 COVER [DUST ] 1075115 571-0010 SCREW 31~37,39,40,73,74 1070236 901-0013 GEAR BOX 1077695 330-0038 MOTOR ASSY * Bold letters are assembled parts for users.
  • Page 49 Instructions manual / GX-G Screwdrivers...
  • Page 50 Instructions manual / GX-G Screwdrivers...
  • Page 51 Instructions manual / GX-G Screwdrivers...
