Table of Contents

Advertisement

Quick Links

Virtual Chassis Fabric Hardware
Documentation
Published
2020-11-06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QFX5110 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Juniper QFX5110 Series

Summary of Contents for Juniper QFX5110 Series

  • Page 1 Virtual Chassis Fabric Hardware Documentation Published 2020-11-06...
  • Page 2 END USER LICENSE AGREEMENT The Juniper Networks product that is the subject of this technical documentation consists of (or is intended for use with) Juniper Networks software. Use of such software is subject to the terms and conditions of the End User License Agreement (“EULA”) posted at https://support.juniper.net/support/eula/.

  • Page 3: Table Of Contents

    Table of Contents About the Documentation | xviii Documentation and Release Notes | xviii Using the Examples in This Manual | xviii Merging a Full Example | xix Merging a Snippet | xx Documentation Conventions | xx Documentation Feedback | xxiii Requesting Technical Support | xxiii Self-Help Online Tools and Resources | xxiv Creating a Service Request with JTAC | xxiv...
  • Page 4 System Software | 14 QFX5110-48S Port Panel | 15 Switch Overview | 15 Network Ports | 16 Channelizing Interfaces | 17 Virtual Chassis and Virtual Chassis Fabric | 17 QFX5110-32Q Port Panel | 18 Switch Overview | 18 Network Ports | 19 Channelizing Interfaces | 20 Virtual Chassis and Virtual Chassis Fabric | 21 QFX5100 Overview | 22...
  • Page 5 QFX3500 Overview | 51 QFX3500 Device Overview | 51 Software | 52 Hardware | 52 SFP+ Access Ports | 53 QSFP+ Uplink Ports | 54 Front Panel of a QFX3500 Device | 56 EX4300 Overview | 58 EX4300 Switches Hardware Overview | 58 Benefits of the EX4300 Switch | 59 Software | 59 EX4300 Switches First View | 59...
  • Page 6 Environmental Requirements and Specifications for EX Series Switches | 103 Rack and Cabinet Requirements | 109 QFX5110 Rack Requirements | 109 Rack Requirements for a QFX5100 Device | 111 Rack Requirements for a QFX3600 or QFX3600-I Device | 112 Rack Requirements for a QFX3500 Device | 114 Rack Requirements | 115 Cabinet Requirements for a QFX5100 Device | 117 Cabinet Requirements for a QFX3600 or QFX3600-I Device | 118...
  • Page 7 Cable Specifications for Console and Management Connections for the QFX Series | 146 Calculating the Fiber-Optic Cable Power Budget for QFX Series Switches | 147 Calculating the Fiber-Optic Cable Power Margin for QFX Series Switches | 147 Management Cable Specifications | 149 Understanding EX Series Switches Fiber-Optic Cable Signal Loss, Attenuation, and Dispersion | 150 Signal Loss in Multimode and Single-Mode Fiber-Optic Cable | 150 Attenuation and Dispersion in Fiber-Optic Cable | 150...
  • Page 8 viii N+0 Redundancy Configuration of AC Power Supplies | 174 N+N Redundancy Configuration of AC Power Supplies | 177 AC Power Cord Specifications for an EX4300 Switch | 180 DC Power Supply in EX4300 Switches | 184 Characteristics of a DC Power Supply | 185 DC Power Supply Airflow | 186 N+0 Redundancy Configuration of DC Power Supplies | 187 N+N Redundancy Configuration of DC Power Supplies | 188...
  • Page 9 Safety General Safety Information | 203 General Safety Guidelines and Warnings | 203 Definitions of Safety Warning Levels | 204 Fire Safety Requirements | 207 Fire Suppression | 207 Fire Suppression Equipment | 207 Qualified Personnel Warning | 208 Warning Statement for Norway and Sweden | 209 Radiation and Laser Warnings | 210 Radiation from Open Port Apertures Warning | 211 Laser and LED Safety Guidelines and Warnings for the QFX Series | 212...
  • Page 10 Power and Electrical Safety Information | 240 General Electrical Safety Guidelines and Warnings | 240 Prevention of Electrostatic Discharge Damage | 242 Action to Take After an Electrical Accident | 243 AC Power Electrical Safety Guidelines | 244 AC Power Disconnection Warning | 245 DC Power Electrical Safety Guidelines | 245 DC Power Disconnection Warning | 247 DC Power Grounding Requirements and Warning | 249...
  • Page 11 Connecting AC Power to a QFX5100 Device | 285 Connecting DC Power to a QFX5100 Device | 288 Connecting a QFX Series Device to a Management Console | 293 Connecting a QFX5100 Device in a Virtual Chassis Fabric | 295 Connecting a QFX5100 Device to a Network for Out-of-Band Management | 296 Installing a QFX3600 Switch | 298 Installing and Connecting a QFX3600 or QFX3600-I Device | 298...
  • Page 12 Connecting a QFX Series Device to a Management Console | 343 Connecting QFX Series and EX Series Switches in a QFX Virtual Chassis | 345 Before You Start | 345 Valid Configurations | 346 Cabling QFX3500 Switches in a QFX5100 Virtual Chassis | 347 Cabling QFX3600 Switches in a QFX Virtual Chassis | 348 Cabling a Mixed QFX Virtual Chassis | 349 Connecting a QFX3500 Device to a Network for Out-of-Band Management | 351...
  • Page 13 xiii Adding a Spine or Leaf Device to a Nonprovisioned Virtual Chassis Fabric | 402 Removing a Device From a Virtual Chassis Fabric | 405 Powering Off a QFX5110 | 406 Powering Off a QFX5100 Device | 409 Powering Off a QFX3600 Device | 412 Powering Off a QFX3500 Device | 414 Removing a QFX5110 from a Rack | 416 Removing a QFX5100 Device from a Rack or Cabinet | 418...
  • Page 14 Replacing QFX3500 Components | 452 Installing and Removing QFX3500 Device Hardware Components | 452 Installing a Power Supply in a QFX3500 Device | 453 Removing a Power Supply from a QFX3500 Device | 455 Installing a Fan Tray in a QFX3500 Device | 457 Removing a Fan Tray from a QFX3500 Device | 459 Installing a Management Board in a QFX3500 Device | 460 Removing a Management Board from a QFX3500 Device | 462...
  • Page 15 QFX5110 Fan Module LED | 500 QFX5110 AC Power Supply LEDs | 501 QFX5110 DC Power Supply LEDs | 502 Viewing QFX5100 System Information | 505 Chassis Status LEDs on a QFX5100 Device | 505 Management Port LEDs on a QFX5100 Device | 508 Access Port and Uplink Port LEDs on a QFX5100 Device | 510 Fan Module LED on a QFX5100 Device | 513 AC Power Supply LEDs on a QFX5100 Device | 514...
  • Page 16 File System Usage | 548 Chassis Viewer | 548 Chassis Status LEDs on EX4300 Switches | 564 Network Port, Built-In QSFP+ Port, Uplink Port, and Uplink Module Port LEDs on EX4300 Switches | 566 Management Port LEDs on EX4300 Switches | 573 AC Power Supply LEDs in EX4300 Switches | 575 DC Power Supply LEDs in EX4300 Switches | 576 Troubleshooting...
  • Page 17 xvii Locating the Serial Number ID Labels on FRUs in an EX4300 Switch | 601 Packing an QFX5110 Device or Component for Shipping | 605 Packing a QFX5110 Switch for Shipping | 606 Packing QFX5110 Components for Shipping | 606 Packing a QFX5100 Device or Component for Shipping | 607 Packing a QFX5100 Switch for Shipping | 608 Packing QFX5100 Switch Components for Shipping | 608...

  • Page 18: About The Documentation

    If the information in the latest release notes differs from the information in the documentation, follow the product Release Notes. Juniper Networks Books publishes books by Juniper Networks engineers and subject matter experts. These books go beyond the technical documentation to explore the nuances of network architecture, deployment, and administration.

  • Page 19: Merging A Full Example

    If the example configuration contains the top level of the hierarchy (or multiple hierarchies), the example is a full example. In this case, use the load merge command. If the example configuration does not start at the top level of the hierarchy, the example is a snippet. In this case, use the load merge relative command.

  • Page 20: Merging A Snippet

    Merging a Snippet To merge a snippet, follow these steps: 1. From the HTML or PDF version of the manual, copy a configuration snippet into a text file, save the file with a name, and copy the file to a directory on your routing platform. For example, copy the following snippet to a file and name the file ex-script-snippet.conf.
  • Page 21 Table 1: Notice Icons Icon Meaning Description Informational note Indicates important features or instructions. Caution Indicates a situation that might result in loss of data or hardware damage. Warning Alerts you to the risk of personal injury or death. Laser warning Alerts you to the risk of personal injury from a laser.
  • Page 22 xxii Table 2: Text and Syntax Conventions (continued) Convention Description Examples Italic text like this Represents variables (options for Configure the machine’s domain which you substitute a value) in name: commands or configuration [edit] statements. root@# set system domain-name domain-name Text like this Represents names of configuration To configure a stub area, include...

  • Page 23: Documentation Feedback

    URL or page number, and software version (if applicable). Requesting Technical Support Technical product support is available through the Juniper Networks Technical Assistance Center (JTAC). If you are a customer with an active Juniper Care or Partner Support Services support contract, or are...

  • Page 24: Self-Help Online Tools And Resources

    JTAC hours of operation—The JTAC centers have resources available 24 hours a day, 7 days a week, 365 days a year. Self-Help Online Tools and Resources For quick and easy problem resolution, Juniper Networks has designed an online self-service portal called the Customer Support Center (CSC) that provides you with the following features: Find CSC offerings: https://www.juniper.net/customers/support/...

  • Page 25: Overview

    PART Overview Virtual Chassis Fabric Overview | 2 QFX5110 Overview | 10 QFX5100 Overview | 22 QFX3600 Overview | 45 QFX3500 Overview | 51 EX4300 Overview | 58...

  • Page 26: Virtual Chassis Fabric Overview

    Virtual Chassis Fabric Hardware Overview | 8 Virtual Chassis Fabric Overview The Juniper Networks Virtual Chassis Fabric (VCF) provides a low-latency, high-performance fabric architecture that can be managed as a single device. VCF is an evolution of the Virtual Chassis feature, which enables you to interconnect multiple devices into a single logical device, inside of a fabric architecture.
  • Page 27 Figure 1: VCF Spine-and-Leaf Architecture A VCF is based on either QFX5100 or QFX5110 switches as the spine devices, as follows: You can configure a VCF with QFX5100 switches as the spine devices, referred to as a QFX5100 VCF. In an optimal QFX5100 VCF configuration, the leaf devices are also QFX5100 switches. You can, however, also create a mixed QFX5100 VCF by including any combination of QFX5100, QFX3600, QFX3500, and EX4300 switches as leaf devices.

  • Page 28: Understanding Virtual Chassis Fabric Configuration

    Flexibility—You can easily expand the size of your VCF by adding devices to the fabric as your networking needs grow. Investment protection—In environments that need to expand because the capabilities of a traditional QFX Series Virtual Chassis are maximized, a VCF is often a logical upgrade option because it enables the system to evolve without having to remove existing, previously purchased devices from the network.

  • Page 29: Virtual Chassis Fabric Setup

    This topic describes the configuration options available for your Virtual Chassis Fabric (VCF). This topic covers: Virtual Chassis Fabric Setup IN THIS SECTION Autoprovisioned Virtual Chassis Fabric Configuration | 5 Preprovisioned Virtual Chassis Fabric Configuration | 6 Nonprovisioned Virtual Chassis Fabric Configuration | 6 You must setup your VCF using one of the following options: Autoprovisioned Virtual Chassis Fabric Configuration Autoprovisioned configuration allows you to “plug and play”...

  • Page 30: Preprovisioned Virtual Chassis Fabric Configuration

    mixed mode to participate in the VCF. You can optionally avoid the downtime that accompanies a leaf device reboot by manually setting the leaf device into fabric mode and into or out of mixed mode, zeroizing the device at that point if necessary, and manually rebooting the device before interconnecting it into the VCF.

  • Page 31: Configuration File Management In A Vcf

    The default primary-role priority value for all devices is 128. You should always configure two spine devices with the highest primary-role priority to ensure the Routing Engine role is assigned to a spine device. In a nonprovisioned VCF, you must manually configure every VCP. Configuration File Management in a VCF You configure a VCF by logging onto the primary Routing Engine and making configuration changes.

  • Page 32: Virtual Chassis Fabric Hardware Overview

    Configuring a Nonprovisioned Virtual Chassis Fabric | 380 Virtual Chassis Fabric Hardware Overview The Juniper Networks Virtual Chassis Fabric (VCF) spine-and-leaf architecture supports two types of hardware configurations based on the switch model used as the spine in the VCF.
  • Page 33 VCF installations with a mixture of models are called mixed mode. For example, a mixed mode QFX5100 VCF might contain a EX4300 or QFX3600 as leaf devices. Mixed mode devices must be configured before joining the VCF and are not eligible for the auto-provisioned configuration (plug and play). Adding a device configured as mixed mode to a VCF can cause those devices to be marked inactive if the other devices are not also configured as mixed mode.

  • Page 34: Qfx5110 Overview

    QFX5110-32Q Hardware | 14 System Software | 14 The QFX5110 line of switches is Juniper Network’s versatile fixed-chassis solution for hybrid cloud deployments. The small form-factor data center switches are designed for either core or aggregation environments with high performance and low latency.

  • Page 35: Qfx5110 Models Overview

    A primary, backup, or line card in a QFX5110 Virtual Chassis (Junos OS Release 17.3R1 and later). A QFX5110 Series Virtual Chassis allows you to connect up to 10 QFX5110 or supported QFX5100 switches into one logical device and manage the device as a single chassis using a ring topology. The...
  • Page 36 A primary, backup, or line card in a QFX5110 Virtual Chassis (Junos OS Release 17.3R1 and later). A QFX5110 Series Virtual Chassis allows you to connect up to 10 QFX5110 or supported QFX5100 switches into one logical device and manage the device as a single chassis using a ring topology. The...

  • Page 37: Qfx5110-48S Hardware

    to a total of 20 QFX5110 devices in a QFX5110 VCF. Use QFX5110-32Q as the spine devices. You can use these models in any combination as leaf devices: QFX5100-24Q QFX5100-48S QFX5100-48T (Junos OS Release 17.3R2 and later) QFX5100-96S QFX5110-48S NOTE: If only QFX5110-48S switches are available, cable and configure the switches as a QFX5110 Virtual chassis.

  • Page 38: Qfx5110-32Q Hardware

    The same Junos OS code base that runs on QFX5110 switches also runs on all Juniper Networks EX Series switches, and M Series, MX Series, and T Series routers. The QFX5110-48S switch is supported on Junos OS Release 15.1X53-D210 and later; the QFX5110-32Q is supported on Junos OS 17.2R1 and later.

  • Page 39: Qfx5110-48S Port Panel

    QFX5110 switches employ the security feature, Secure Boot, which is based on the UEFI 2.4 standard. The BIOS has been hardened and serves as a core root of trust. The BIOS updates, the bootloader, and the kernel are cryptographically protected. No action is required to implement Secure Boot. If a premium or advanced feature is configured on the QFX5110 without a valid license, an alarm is raised and system log (syslog) messages are generated.

  • Page 40: Network Ports

    use SFP+ DAC cables and 10-Gbps active optical cables (AOC) in any access port. Starting in Junos OS Release 18.3R1, the 10-GbE ports also support 100 Mbps. The remaining 4 QSFP28 ports (48 through 51) support speeds of 40 GbE or 100 GbE. Each port can be configured as an independent 100-GbE port or as an independent 40-GbE port.

  • Page 41: Channelizing Interfaces

    SFP+ direct attach copper (DAC) cables SFP+ active optical cables (AOC) The QFX5110-48S uplink ports (48 to 51) support: 100-Gbps QSFP28 transceivers 40-Gbps QSFP+ transceivers 100-Gbps AOC 40-Gbps AOC (Junos OS 18.3R1 and later) 100-Gbps QSFP28 DAC cables 40-Gbps QSFP+ DAC cables 40-Gbps QSFP+ to SFP+ DACBO cables (40-Gbps breaks out to 10-Gbps for copper connections) 40-Gbps AOCBO cables (40-Gbps breaks out to 10-Gbps for fiber connections) Channelizing Interfaces...

  • Page 42: Qfx5110-32Q Port Panel

    QFX5110-32Q Port Panel IN THIS SECTION Switch Overview | 18 Network Ports | 19 Channelizing Interfaces | 20 Virtual Chassis and Virtual Chassis Fabric | 21 The port panel of the QFX5110-32Q primarily comprises 28 quad small form-factor pluggable plus (QSFP+) ports and 4 quad small form-factor pluggable solution (QSFP28) ports.

  • Page 43: Network Ports

    Figure 5: QFX5110-32Q Port Panel Electrostatic discharge (ESD) terminal 1 pulse per second (PPS) output connection — — RJ-45 connection to grandmaster clock 28 QSFP+ ports — — Output clock at 10 MHz 4 QSFP28 ports — — Network Ports The QFX5110-32Q device ports (0 through 27) support: 40-Gbps QSFP+ transceivers QSFP+ direct attach copper (DAC) cables...

  • Page 44: Channelizing Interfaces

    Channelizing Interfaces CAUTION: Starting with Junos OS Release 18.1R1, default behaviors changed for: System mode—Flexi-pic mode is replaced by non-oversubscribed mode. Auto-sense—The ports auto-sense the transceiver and set the port speed to match. The Packet Forwarding Engine on the switch is restarted when you issue system mode changes.

  • Page 45: Virtual Chassis And Virtual Chassis Fabric

    CAUTION: Take care when changing the channelization mode from Flexi-pic to default. If you have existing ports that are channelized in Flexi-pic mode, remove the channelization from the interface before changing the system mode. Changing the Flexi-pic mode to the default mode with channelized ports causes the ports to go down, log a system log error, and remain down.

  • Page 46: Qfx5100 Overview

    QFX5100 Hardware | 22 System Software | 31 The QFX5100 line of switches is Juniper Network’s second generation of top-of-rack switch solutions for data centers and campus distribution or aggregation environments. The QFX5100 portfolio consists of high-performance fixed-configuration switches that add higher port densities, additional scalability, and improved latency to the QFX Series.
  • Page 47 The QFX5100-24Q-AA switch has a 2.5 GHz 4-core Intel CPU with 32 GB of memory and 128 GB of SSD storage. The QFX5100 line of switches include both 10GE and 40GE fixed-configurations: QFX5100-48S As shown in Figure 2 on page 13, the QFX5100-48S is a 10-Gigabit Ethernet Enhanced Small Form-Factor Pluggable (SFP+) top-of-rack switch with 48 SFP+ ports and 6 Quad SFP+ (QSFP+) ports.
  • Page 48 Figure 7 on page 24, the QFX5100-48SH is the same form factor and port configuration as the QFX5100-48S. The QFX5100-48SH is specifically designed for Juniper Networks Cloud Data Center and comes pre-configured with Satellite Network Operational System (SNOS) instead of Juniper Networks Junos OS.
  • Page 49 Figure 9 on page 26, the QFX5100-48TH is the same form factor and port configuration as the QFX5100-48T. The QFX5100-48TH is specifically designed for Juniper Networks Cloud Data Center and comes pre-configured with Satellite Network Operational System (SNOS) instead of Juniper...
  • Page 50 Networks Junos OS. The switch may not be converted to Junos OS without an additional license. The switch can be ordered with either ports-to-FRUs or FRUs-to-ports airflow and with AC power supplies. The QFX5100-48TH can only be used as a satellite device in a Junos Fusion system. Figure 9: QFX5100-48THPort Panel QFX5100-24Q As shown in...
  • Page 51 A primary, backup, or line card in a QFX Virtual Chassis. A QFX Series Virtual Chassis allows you to interconnect up to 10 QFX3500, QFX3600, or QFX5100 switches into one logical device and manage the device as a single chassis in a ring topology. Use QFX5100-24Q switches as the primary and backup in a QFX Virtual Chassis.
  • Page 52 CAUTION: Use only the top four ports or the bottom four ports for SFP transceivers. Because SFP transceivers are larger than SFP+ transceivers, attempting to stack SFP transceivers can cause internal damage to the module. Figure 12: EX4600-EM-8F Expansion Module NOTE: The EX4600-EM-8F is not supported on the QFX5100-24Q running in QFabric systems.
  • Page 53 Figure 13: QFX5100-24Q-AA Port Panel with QFX-PFA-4Q The QFX5100-24Q-AA can be used as a standalone switch that supports high frequency statistics collection. Working with Juniper Networks Cloud Analytics Engine, this switch monitors and reports the workload and application behavior across the physical and virtual infrastructure.
  • Page 54 down. Likewise, when an EX4600-EM-8F is running on the QFX5100-24Q and is swapped with a QFX-EM-4Q, the interfaces temporarily go down, which can cause a short disruption in traffic. QFX5100-96S As shown in Figure 15 on page 30, the QFX5100-96S switch is a is a 10-Gigabit Ethernet Enhanced Small Form-Factor Pluggable (SFP+) top-of-rack switch with 96 SFP+ ports and 8 Quad SFP+ (QSFP+) ports.

  • Page 55: System Software

    Junos OS is installed on a QFX5100 switch’s 32-gigabyte (GB) internal solid state flash drive. The same Junos OS code base that runs on QFX5100 switches also runs on all Juniper Networks EX Series switches, M Series, MX Series, and T Series routers.

  • Page 56: Port Panel Of A Qfx5100-24Q Device

    Port Panel of a QFX5100-24Q Device IN THIS SECTION Switch Ports | 32 QFabric Systems | 33 Channelizing Interfaces (Non-QFabric) | 33 Virtual Chassis and Virtual Chassis Fabric | 34 Port LEDs | 35 The port panel of the QFX5100-24Q device consists of 24 quad small-form factor pluggable plus (QSFP+) ports.

  • Page 57: Qfabric Systems

    QSFP+ to QSFP+ active optical cables (AOC) QSFP+ to SFP+ active optical breakout cable (AOCBO) Access ports You can use 40-Gigabit Ethernet QSFP+ transceivers and QSFP+ direct attach copper cables in any downstream port. See “Determining Interface Support for the QFX5100 Device” on page 137.

  • Page 58: Virtual Chassis And Virtual Chassis Fabric

    Default mode All 24 QSFP+ ports on the switch (PIC 0) are channelized by default (96 ports). With QFX-EM-4Q Expansion Modules (PIC 1) and (PIC 2), the QSFP+ ports are supported for access or uplink ports, but cannot be channelized. Ports are over-subscribed In this mode and could be subject to packet-loss. You can have one of two port combinations: 32 40-Gbps QSFP+ ports, or 96 10-Gigabit Ethernet ports plus 8 40-Gbps QSFP+ ports.

  • Page 59: Port Leds

    VCP connections. See “Connecting a QFX5100 Device in a Virtual Chassis Fabric” on page 295 for a cabling diagram. BEST PRACTICE: Whenever possible use the QFX5100-24Q device as a spine device. By using the QFX5100-24Q device in a maximum configuration of 20 total devices, four QFX5100-24Q devices may be used as spine devices.

  • Page 60: Port Panel Of Qfx5100-48S And Qfx5100-48Sh Devices

    Table 3: Port LEDs on a QFX5100-24Q Switch (continued) Color State Description Green On steadily A link is established, but there is no link activity. NOTE: When configured for channelized 10-Gigabit Ethernet, the LED is lit green when at least one of the four 10-Gigabit Ethernet SFP+ breakout links is established.
  • Page 61 cables. You can use 1-Gigabit Ethernet SFP+, 10-Gigabit Ethernet SFP+ transceivers and SFP+ DAC cables in any access port. The remaining 24 logical ports are the six 40 GbE physical ports (48 through 53) that support up to 6 quad small-form factor pluggable plus (QSFP+) transceivers .
  • Page 62 BEST PRACTICE: In a mixed QFX5100 VCF environment with multiple models of QFX5100 and the EX4300, use QFX5100-24Q as spine devices. In the maximum configuration of 20 total devices, up to four QFX5100-24Q devices may be used as spine devices. All members can be connected to the spine using QSFP+ ports.

  • Page 63: Port Panel Of Qfx5100-48T And Qfx5100-48Th Devices

    The QFX5100-48T device operates as a standalone switch, a member of a QFX Virtual Chassis, a member of a QFX5110 Virtual Chassis, act as a leaf device in a Juniper Networks Virtual Chassis Fabric (VCF). QFX Virtual Chassis and QFX5100 Virtual Chassis both support up to 10 members. VCF supports 20 total devices, of which 4 QFX5100-24Q devices can be configured as spine devices.
  • Page 64 Figure 19: QFX5100-48T or QFX5100-48TH Switch Port Panel Electrostatic Discharge (ESD) terminal 40 GbE ports (6) — — 10GBASE-T ports (48) — The QFX5100-48T and QFX5100-48TH device ports, (0 through 47) support RJ45 connectors. The 40 G uplink or data ports (48 through 53) support: QSFP+ transceivers QSFP+ to QSFP+ direct attach copper (DAC) cables QSFP+ to SFP+ DAC breakout cables (DACBO)

  • Page 65: Port Panel Of A Qfx5100-96S Device

    Connecting a QFX5100 Device in a Virtual Chassis Fabric | 295 Management Port Connector Pinouts for the QFX Series | 132 Port Panel of a QFX5100-96S Device IN THIS SECTION Switch Ports | 42 Channelizing Interfaces | 42 Virtual Chassis and Virtual Chassis Fabric Support | 43 The port panel of the QFX5100-96S switch consists of 96 small form-factor pluggable plus (SFP+) and 8 quad small-form factor pluggable plus (QSFP+) ports that are normally configured as access ports.

  • Page 66: Switch Ports

    Switch Ports The QFX5100-96S switch ports, (0 through 95) support: SFP transceivers that can run at either 100 Mbps or 1 Gbps speed SFP+ transceivers at 10 Gbps speed SFP to SFP direct attach copper (DAC) cables SFP+ to SFP+ DAC cables SFP+ to SFP+ active optical cables (AOC) Ports 96 through 104 support: 40 Gbps QSFP+ transceivers...

  • Page 67: Virtual Chassis And Virtual Chassis Fabric Support

    All 96 SFP+ ports on the switch (PIC 0) are supported. In this mode, the eight QSFP+ ports are not supported and cannot be channelized. There is no packet loss for packets of any size in this mode. Default mode All 96 SFP+ ports on the switch (PIC 0) are supported.
  • Page 68 RELATED DOCUMENTATION Field-Replaceable Units in a QFX5100 Device Port Panel of a QFX5100-24Q Device | 32 Port Panel of QFX5100-48S and QFX5100-48SH Devices | 36 Access Port and Uplink Port LEDs on a QFX5100 Device | 510 Installing and Removing QFX5100 Device Hardware Components | 429 Connecting QFX Series and EX Series Switches in a QFX Virtual Chassis | 319...

  • Page 69: Qfx3600 Overview

    In a QFX3000-G QFabric system, the QFX3600 device can operate as a Node device through the 40-Gbps uplinks ports to a Juniper Networks QFX3008-I Interconnect device. On a QFX3000-M QFabric device, the QFX3600 can be configured to operate as either a Node device or as a QFX3600-I Interconnect device.

  • Page 70: Software

    Junos OS is installed on the QFX3600 device’s 8-gigabyte (GB) internal flash drive. The same Junos OS code base that runs on QFX Series devices also runs on all Juniper Networks EX Series, J Series, M Series, MX Series, and T Series devices.
  • Page 71 Figure 21: QFX3600 Chassis Front LCD panel C0S 1-Gbps SFP management port — — QSFP+ ports C0 1000BASE-T RJ-45 management port — — C1S 1-Gbps SFP management port C1 1000BASE-T RJ-45 management port — — Figure 22: QFX3600 Chassis Rear Power supplies Fan trays —...

  • Page 72: Front Panel Of A Qfx3600 Device

    and in other releases, the port is available. See the topics on channelizing interfaces or configuring the port type for your specific software release. The rear panel of the QFX3600 chassis has two redundant power supplies and three redundant fan trays that are field-replaceable and hot-swappable.
  • Page 73 QSFP+ transceivers. You can use QSFP+ transceivers to create four 10-Gigabit Ethernet ports by using a fiber breakout cable to distribute the interfaces to four 10GBASE-SR SFP+ transceivers. (Juniper Networks does not sell fiber breakout cables, they must be purchased separately.) “Determining Interface Support for the QFX3600 Device” on page 140.
  • Page 74 Figure 23: QFX3600 Device Front Panel QFX3600-16Q C0 S OK / C1 S LCD panel C0 management port — — Chassis status LEDs C0S management port — — Access and uplink ports C1S management port — — Chassis serial number label and ESD point Console (CON) port —...

  • Page 75: Qfx3500 Overview

    FC frames in Ethernet to transport the FC frames over the physical Ethernet network. In a QFabric system, a QFX3500 device functions as a Node device, connected to a QFabric system through 40-Gbps uplink ports to a Juniper Networks QFX3008-I or QFX3600-I Interconnect device. Together, the...

  • Page 76: Software

    Junos OS is installed on the QFX3500 device’s 8-gigabyte (GB) internal flash drive. The same Junos OS code base that runs on QFX3500 devices also runs on all Juniper Networks EX Series switches, and J Series, M Series, MX Series, and T Series routers.

  • Page 77: Sfp+ Access Ports

    Figure 24: QFX3500 Device Front Mounting ESD point/ bracket serial number ID label FX350 0-48S Power Mounting supply bracket Management Power tray board tray supply Figure 25: QFX3500 Device Rear SFP+ QSFP+ SFP+ access uplink access ports ports ports The front panel of the QFX3500 chassis has an LCD panel that displays the device hostname and the number of active alarms.

  • Page 78: Qsfp+ Uplink Ports

    Up to 36 of the access ports can be used for SFP transceivers. Gigabit Ethernet SFP transceivers can be used in ports 6 through 41. CAUTION: Do not install 1GbE copper transceivers (such as QFX-SFP-1GE-T) directly above or below another 1GbE copper transceiver. Use only the top row or bottom row to avoid damage to the device caused by some types of copper transceivers when the transceivers are installed above or below each other.
  • Page 79 NOTE: Port Q0 is unique in that the number of 10-Gigabit Ethernet interfaces supported varies by Junos OS release. In some Junos OS releases, port 00 has a reserved port and in other releases the port is available. See the topics on Channelizing Interfaces or Configuring the Port Type, for your specific release.

  • Page 80: Front Panel Of A Qfx3500 Device

    Front Panel of a QFX3500 Device The front panel of the QFX3500 device consists of the following components: Management board Chassis serial number label and ESD point NOTE: The chassis serial number ID label is located on a sliding panel to the right of the fan tray on a QFX3500 device (see Figure 29 on page 56).
  • Page 81 USB Port Specifications for the QFX Series | 134 Management Board for a QFX3500 Device Chassis Status LEDs on a QFX3500 Device | 527 Cooling System and Airflow for a QFX3500 Device AC Power Supply for a QFX3500, QFX3600, or QFX3600-I Device Prevention of Electrostatic Discharge Damage | 242 Installing and Removing QFX3500 Device Hardware Components | 452...

  • Page 82: Ex4300 Overview

    Fan Modules | 80 EX4300 Switch Components | 81 Juniper Networks EX4300 Ethernet Switches provide connectivity for high-density environments and scalability for growing networks. These switches can be deployed wherever you need high density of Gigabit Ethernet ports or redundancy. Typically, EX4300 switches are used in large branch offices, campus wiring closets, and data centers.

  • Page 83: Benefits Of The Ex4300 Switch

    Ethernet ports. Software Juniper Networks EX Series Ethernet Switches run Junos OS, which provides Layer 2 and Layer 3 switching, routing, and security services. The same Junos OS code base that runs on EX Series switches also runs on all Juniper Networks M Series, MX Series, and T Series routers, and SRX Series Services Gateways.

  • Page 84: 24-Port Ex4300 Switches

    EX4300 switches provide connectivity for high-density Gigabit Ethernet data center top-of-rack, enterprise, and campus aggregation/core deployments. EX4300 switches can be used in large branch offices, campus wiring closets, and data centers. In data centers, these switches can be positioned as the top devices in a rack to provide connectivity for all devices in the rack and provide options for optimized airflow (hot aisle/cold aisle).
  • Page 85 Figure 31: Rear Panel of a 24-Port EX4300 Switch Table 4 on page 61 lists the 24-port EX4300 switch models and their components. Table 4: Components in 24-Port EX4300 Switches Number of Fan Modules Power Supply Switch PoE-Enabled Shipped by Shipped by Supported Models...

  • Page 86: 32-Port Ex4300 Switches

    Table 4: Components in 24-Port EX4300 Switches (continued) Number of Fan Modules Power Supply Switch PoE-Enabled Shipped by Shipped by Supported Models Built-In Ports Ports Default Default Uplink Module EX4300-24P-S Fan modules for Power supplies 4-port 10-Gigabit 10/100/1000BASE-T this model are for this model Ethernet SFP+ Ethernet ports and...
  • Page 87 Figure 33 on page 63 shows the rear panel of a 32-port EX4300 switch. Figure 33: Rear Panel of a 32-Port EX4300 Switch Table 5 on page 63 lists the 32-port EX4300 switch models and their components. Table 5: Components in 32-Port EX4300 Switches Number of Power Supply Built-In...

  • Page 88: 48-Port Ex4300 Switches

    Table 5: Components in 32-Port EX4300 Switches (continued) Number of Power Supply Built-In PoE-Enabled Shipped by Supported Uplink Switch Models Ports Ports Fan Modules Default Modules EX4300-32F-DC 32 SFP Two fan A 550 W DC 2-port 40-Gigabit ports, four modules; each power supply Ethernet QSFP+ uplink SFP+ ports,...
  • Page 89 40-Gigabit Ethernet QSFP+/100-Gigabit Ethernet QSFP28 uplink module can house two QSFP+ transceivers, two QSFP28 transceivers, or a combination of one QSFP+ transceiver and one QSFP28 transceiver. The 4-port 1-Gigabit Ethernet/10-Gigabit Ethernet SFP+ uplink module can house four SFP transceivers, four SFP+ transceivers, or a combination of SFP and SFP+ transceivers in the four ports on the uplink module.
  • Page 90 Figure 36 on page 66 shows the rear panel of 48-port EX4300 switches except EX4300-48MP and EX4300-48MP-S switches, with power supplies and fan modules installed. Figure 37 on page 66 shows the rear panel of EX4300-48MP and EX4300-48MP-S switches, with power supplies and fan modules installed.
  • Page 91 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules EX4300-48T-S Fan modules for Power supplies 4-port 10-Gigabit 10/100/1000BASE-T this model are not for this model Ethernet SFP+ Ethernet ports and...
  • Page 92 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules EX4300-48P-S Fan modules for Power supplies 4-port 10-Gigabit 10/100/1000BASE-T this model are not for this model Ethernet SFP+ Ethernet ports and...
  • Page 93 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules EX4300-48MP Two fan modules; A 1400 W AC 10/100/1000BASE-T each with an AIR power supply Ethernet network OUT (AFO) label.
  • Page 94 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules 2-port 40-Gigabit Ethernet QSFP+/100-Gigabit Ethernet QSFP28 uplink module (model number: EX-UM-2QSFP-MR) or 4-port 1-Gigabit Ethernet/ 10-Gigabit Ethernet SFP+ uplink module...
  • Page 95 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules Ethernet transceiver. If you configure both the ports on the uplink module to operate at 100-Gbps speed, the four QSFP+ ports on the switch...
  • Page 96 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules EX4300-48MP-S 24 10/100/ Fan modules for Power supplies 1000BASE-T this model are not for this model Ethernet network shipped by default;...
  • Page 97 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules 2-port 40-Gigabit Ethernet QSFP+/100-Gigabit Ethernet QSFP28 uplink module (model number: EX-UM-2QSFP-MR) or 4-port 1-Gigabit Ethernet/ 10-Gigabit Ethernet SFP+ uplink module...
  • Page 98 Table 6: Components in 48-Port EX4300 Switches (continued) Number of PoE- Power Supply enabled Shipped by Supported Uplink Switch Models Built-In Ports Ports Fan Modules Default Modules Ethernet transceiver. If you configure both the ports on the uplink module to operate at 100-Gbps speed, the four QSFP+ ports on the switch...

  • Page 99: Uplink Modules

    In EX4300-48MP and EX4300-48MP-S switches, you can use only the built-in QSFP+ ports as VCPs to connect the switch in a Virtual Chassis. You cannot configure the ports on the uplink module in EX4300-48MP and EX4300-48MP-S switches to Virtual Chassis ports (VCPs). You cannot configure the built-in QSFP+ ports as network ports.
  • Page 100 Table 7: Uplink Modules for 24-Port and 48-Port EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches First Junos OS Uplink Module Description Supported EX4300 Switch Models Release 4-port 1-Gigabit The 4-port 1-Gigabit Ethernet/ EX4300-24T 13.2X50- Ethernet/ 10-Gigabit Ethernet SFP+ uplink EX4300-24P 10-Gigabit Ethernet module can house up to four SFP EX4300-48T...
  • Page 101 Table 9: Uplink Modules for EX4300-48MP and EX4300-48MP-S Switches Supported EX4300 Switch Uplink Module Description Models First Junos OS Release 2-port 40-Gigabit Ethernet You can install two QSFP+ EX4300-48MP 18.4R1 QSFP+/100-Gigabit transceivers, two QSFP28 EX4300-48MP-S NOTE: Starting in Ethernet QSFP28 uplink transceivers, or a Junos OS Release 19.3R1, module (model number:...

  • Page 102: Virtual Chassis

    Virtual Chassis You can interconnect a maximum of 10 EX4300 switches to form a Virtual Chassis. You can operate these interconnected switches as a single, logical device with a single IP address. You can use the following ports to configure an EX4300 switch in a Virtual Chassis: For 24-port and 48-port EX4300 switches except EX4300-48MP and EX4300-48MP-S switches: QSFP+ ports configured as VCPs SFP+ uplink module ports configured as VCPs...

  • Page 103: Power Supplies

    Power Supplies EX4300 switches except EX4300-48MP and EX4300-48MP-S switches support AC or DC power supplies with different airflow directions. EX4300-48MP and EX4300-48MP-S switches support only AC power supplies with front-to-back airflow. Power supplies for the EX4300 switch are fully redundant, load-sharing, and hot-removable and hot-insertable FRUs.

  • Page 104: Fan Modules

    Table 10: Airflow Direction in Power Supplies for EX4300 Switches (continued) Power Supply Rating Label on Power Supply Direction of Airflow 715 W AC AIR OUT (AFO) Front-to-back—that is, air intake to cool the chassis is through the vents on the front panel of the chassis and hot air exhausts through the vents on the rear panel of the chassis.

  • Page 105: Ex4300 Switch Components

    All the EX4300 switch models, except EX4300-24T-S, EX4300-24P-S, EX4300-32F-S, EX4300-48T-S, EX4300-48P-S, and EX4300-48MP-S switches are shipped with two fan modules preinstalled in the rear panel of the switch. EX4300-24T-S, EX4300-24P-S, EX4300-32F-S, EX4300-48T-S, EX4300-48P-S, and EX4300-48MP-S switches are not shipped with preinstalled fan modules; you must order the fan modules separately.
  • Page 106 Figure 39: Components on the Front Panel of a 32-Port EX4300 Switch Cover panel for uplink module slot Chassis status LEDs — — SFP network ports LCD panel Enter button — — LCD panel Mini-USB console port — — LCD panel Menu button SFP+ uplink ports —...
  • Page 107 Figure 41: Components on the Front Panel of EX4300-48MP and EX4300-48MP-S Switches QR code Factory Reset/Mode button — — Mini-USB console port 4-port 1-Gigabit Ethernet SFP/10-Gigabit Ethernet — — SFP+ uplink module (optional) Chassis status LEDs 100/1000/2500/5000/10000 Ethernet Network — —...
  • Page 108 Figure 43 on page 84 shows the components on the rear panel of a 32-port EX4300 switch (with two AC power supplies and two fan modules installed). Figure 43: Components on the Rear Panel of a 32-Port EX4300 Switch AC power supplies in slot 0 and slot 1 USB port —...
  • Page 109 Figure 44: Components on the Rear Panel of EX4300-48MP and EX4300-48MP-S Switches RESET Management port Empty slot for AC power supply — — ESD point QSFP+ ports (dedicated Virtual Chassis ports) — — Fan module Console port — — Serial number label Reset button —...

  • Page 110: Planning

    PART Planning Site Preparation | 87 Rack and Cabinet Requirements | 109 Port and Interface Specifications | 130 Transceiver and Cable Specifications | 136 Planning QFX5100 Power Requirements | 153 Planning QFX5110 Power Requirements | 158 Planning QFX3600 Power Requirements | 162 Planning QFX3500 Power Requirements | 166 Planning EX4300 Power Requirements | 170 Compliance | 190...

  • Page 111: Site Preparation

    CHAPTER 7 Site Preparation IN THIS CHAPTER Plan a Virtual Chassis Fabric Deployment | 87 QFX5110 Site Preparation Checklist | 90 Site Preparation Checklist for a QFX5100 Device | 92 Site Preparation Checklist for a QFX3600 or QFX3600-I Device | 93 Site Preparation Checklist for a QFX3500 Device | 95 Site Preparation Checklist for EX4300 Switches | 97 QFX5110 Environmental Requirements and Specifications | 98...
  • Page 112 Table 11: Deployment Checklist Item or Task For More Information Performed By Date Components Determine the number of devices Understanding Virtual Chassis Fabric in the VCF and the role of each Components device. NOTE: A VCF is not constrained to a single building; the limits for the optic cable are the only consideration.
  • Page 113 Table 11: Deployment Checklist (continued) Item or Task For More Information Performed By Date Verify that your rack or cabinet “QFX5110 Rack Requirements” on page 109 meets the minimum requirements “Rack Requirements for a QFX5100 Device” for the installation of the switch. on page 111 “Cabinet Requirements for a QFX5100 Device”...

  • Page 114: Qfx5110 Site Preparation Checklist

    Table 11: Deployment Checklist (continued) Item or Task For More Information Performed By Date Cables Acquire cables and connectors: “Cable Specifications for QSFP+ and QSFP28 Transceivers” on page 144 Determine the number of cables needed based on your “Cable Specifications for Console and planned configuration.
  • Page 115 Table 12: Site Preparation Checklist (continued) Item or Task For More Information Performed By Date Power Measure the distance between external power sources and switch installation site. Calculate the power consumption and QFX5110 AC Power requirements. Specifications and QFX5110 DC Power Specifications Rack Verify that your rack meets the minimum...

  • Page 116: Site Preparation Checklist For A Qfx5100 Device

    Site Preparation Checklist for a QFX5100 Device The checklist in Table 13 on page 92 summarizes the tasks you need to perform when preparing a site for QFX5100 deviceinstallation. Table 13: Site Preparation Checklist Item or Task For More Information Performed By Date Architecture...

  • Page 117: Site Preparation Checklist For A Qfx3600 Or Qfx3600-I Device

    Table 13: Site Preparation Checklist (continued) Item or Task For More Information Performed By Date Secure the rack or cabinet to the floor and building structure. Cables Acquire cables and connectors: Port Panel of a QFX5100-24Q Device on page 32 Determine the number of cables Port Panel of a QFX5100-24Q-AA needed based on your planned...
  • Page 118 Table 14: Site Preparation Checklist Item or Task For More Information Performed By Date Environment Verify that environmental factors such “Environmental Requirements and as temperature and humidity do not Specifications for QFX3600 and exceed device tolerances. QFX3600-I Devices” on page 101 Power Measure distance between external power sources and device installation...

  • Page 119: Site Preparation Checklist For A Qfx3500 Device

    Table 14: Site Preparation Checklist (continued) Item or Task For More Information Performed By Date Acquire cables and connectors: “Determining Interface Support for the QFX3600 Device” on page 140 Determine the number of cables needed based on your planned Determining Transceiver Support for configuration.
  • Page 120 Table 15: Site Preparation Checklist (continued) Item or Task For More Information Performed By Date Calculate the power consumption and “AC Power Specifications for a requirements. QFX3500 Device” on page 166 Rack or Cabinet Verify that your rack or cabinet meets the “Rack Requirements for a QFX3500 minimum requirements for the installation Device”...

  • Page 121: Site Preparation Checklist For Ex4300 Switches

    Site Preparation Checklist for EX4300 Switches The checklist in Table 16 on page 97 summarizes the tasks you need to perform when preparing a site for EX4300 switch installation. Table 16: Site Preparation Checklist Item or Task For More Information Performed by Date Environment...

  • Page 122: Qfx5110 Environmental Requirements And Specifications

    Table 16: Site Preparation Checklist (continued) Item or Task For More Information Performed by Date Secure the rack or cabinet to the floor and building structure. Cables Acquire cables and connectors: Determine the number of cables needed based on your planned configuration. Review the maximum distance allowed for each cable.

  • Page 123: Environmental Requirements And Specifications For A Qfx5100 Device

    Table 17: QFX5110 Environmental Tolerances Description Tolerance Altitude No performance degradation to 6562 feet (2000 meters) Relative humidity Normal operation ensured in relative humidity range of 5% through 90%, noncondensing Short-term operation ensured in relative humidity range of 5% through 93%, noncondensing NOTE: As defined in NEBS GR-63-CORE, Issue 3, short-term events can...
  • Page 124 Follow these environmental guidelines: The site must be as dust-free as possible, because dust can clog air intake vents and filters, reducing the efficiency of the switch cooling system. Maintain ambient airflow for normal switch operation. If the airflow is blocked or restricted, or if the intake air is too warm, the switch might overheat, leading to the switch temperature monitor shutting down the device to protect the hardware components.

  • Page 125: Environmental Requirements And Specifications For Qfx3600 And Qfx3600-I Devices

    Clearance Requirements for Airflow and Hardware Maintenance for a QFX5100 Device | 122 QFX5100 Standalone Installation Overview | 276 Environmental Requirements and Specifications for QFX3600 and QFX3600-I Devices The QFX3600 and QFX3600-I devices must be installed in a rack or cabinet housed in a dry, clean, well-ventilated, and temperature-controlled environment.

  • Page 126: Environmental Requirements And Specifications For A Qfx3500 Device

    NOTE: Install QFX Series devices only in restricted areas, such as dedicated equipment rooms and equipment closets, in accordance with Articles 110-16, 110-17, and 110-18 of the National Electrical Code, ANSI/NFPA 70. RELATED DOCUMENTATION Clearance Requirements for Airflow and Hardware Maintenance for a QFX3600 or QFX3600-I Device | 123 Installing and Connecting a QFX3600 or QFX3600-I Device | 298 Environmental Requirements and Specifications for a QFX3500 Device...

  • Page 127: Environmental Requirements And Specifications For Ex Series Switches

    Table 20: QFX3500 Device Environmental Tolerances (continued) Description Tolerance Temperature Normal operation ensured in temperature range of 32° F through 104° F (0° C through 40° C) Short-term operation ensured in temperature range of 23° F through 131° F (–5° C through 55°...
  • Page 128 Table 21 on page 104 provides the required environmental conditions for normal switch operation. Table 21: EX Series Switch Environmental Tolerances Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX2200-C No performance Normal operation ensured Normal operation ensured Complies with Zone degradation up to in the relative humidity...
  • Page 129 Table 21: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX3300 No performance Normal operation ensured Normal operation ensured Complies with Zone degradation up to in the relative humidity in the temperature range 4 earthquake 10,000 feet range 10% through 85%...
  • Page 130 Table 21: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX4550 No performance Normal operation ensured EX4550-32F switches— Complies with Zone degradation up to in the relative humidity Normal operation 4 earthquake 10,000 feet range 10% through 85% ensured in the...
  • Page 131 Table 21: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX8208 No performance Normal operation ensured Normal operation is ensured Complies with Zone degradation up to in the relative humidity in the temperature range 4 earthquake 10,000 feet range 10% through 85%...
  • Page 132 Table 21: EX Series Switch Environmental Tolerances (continued) Environment Tolerance Switch or device Altitude Relative Humidity Temperature Seismic EX9251 No performance Normal operation ensured Normal operation ensured Complies with degradation up to in relative humidity range in temperature range of 32° Telcordia 10,000 ft (3048 m) of 5% to 90%,...

  • Page 133: Rack And Cabinet Requirements

    CHAPTER 8 Rack and Cabinet Requirements IN THIS CHAPTER QFX5110 Rack Requirements | 109 Rack Requirements for a QFX5100 Device | 111 Rack Requirements for a QFX3600 or QFX3600-I Device | 112 Rack Requirements for a QFX3500 Device | 114 Rack Requirements | 115 Cabinet Requirements for a QFX5100 Device | 117 Cabinet Requirements for a QFX3600 or QFX3600-I Device | 118...
  • Page 134 Table 22: Rack Requirements for the QFX5110 Rack Requirement Guidelines Rack type Use a four-post rack that provides bracket holes or hole patterns spaced at 1 U (1.75 in. or 4.45 cm) increments and that meets the size and strength requirements to support the weight.

  • Page 135: Rack Requirements For A Qfx5100 Device

    Rack Requirements for a QFX5100 Device All QFX5100 devices are designed to be installed on four-post racks. The QFX5100-96S device can also be installed on two-post racks. Rack requirements consist of: Rack type Mounting bracket hole spacing Rack size and strength Table 23 on page 111 provides the rack requirements and specifications for the QFX5100 device.

  • Page 136: Rack Requirements For A Qfx3600 Or Qfx3600-I Device

    Table 23: Rack Requirements for the QFX5100 Device (continued) Rack Requirement Guidelines Rack size and strength (all Ensure that the rack complies with the standards for a 19-in. or 23-in. rack as defined product SKUs) in Cabinets, Racks, Panels, and Associated Equipment (document number EIA-310–D) published by the Electronics Industry Association.
  • Page 137 Rack type Mounting bracket hole spacing Rack size and strength Rack connection to the building structure Table 24 on page 113 provides the rack requirements and specifications for a QFX3600 or QFX3600-I device. Table 24: Rack Requirements for a QFX3600 or QFX3600-I Device Rack Requirement Guidelines Rack type...

  • Page 138: Rack Requirements For A Qfx3500 Device

    One pair of fixed rail mounting brackets for front-mounting or rear-mounting the switch on four posts of a rack One pair of adjustable rail mounting brackets for front-mounting or rear-mounting the switch on four posts of a rack RELATED DOCUMENTATION Chassis Physical Specifications for QFX3600 and QFX3600-I Devices Rack-Mounting and Cabinet-Mounting Warnings | 224 Clearance Requirements for Airflow and Hardware Maintenance for a QFX3600 or QFX3600-I...

  • Page 139: Rack Requirements

    Table 25: Rack Requirements for the QFX3500 Device (continued) Rack Requirement Guidelines Mounting bracket hole The holes in the mounting brackets are spaced at 1 U (1.75 in. or 4.45 cm), so that the spacing device can be mounted in any rack that provides holes spaced at that distance. Rack size and strength Ensure that the rack complies with the standards for a 19-in.
  • Page 140 Rack size and strength Rack connection to the building structure Table 26 on page 116 provides the rack requirements and specifications. Table 26: Rack Requirements and Specifications Rack Requirement Guidelines Rack type You can mount the device on a rack that provides bracket holes or hole patterns spaced at 1 U (1.75 in.

  • Page 141: Cabinet Requirements For A Qfx5100 Device

    Cabinet Requirements for a QFX5100 Device You can mount the QFX5100 device in an enclosure or cabinet that contains a four-post 19-in. open rack as defined in Cabinets, Racks, Panels, and Associated Equipment (document number EIA-310-D) published by the Electronics Industry Association. Cabinet requirements consist of: Cabinet size and clearance Cabinet airflow requirements...

  • Page 142: Cabinet Requirements For A Qfx3600 Or Qfx3600-I Device

    Rack Requirements for a QFX5100 Device | 111 Mount a QFX5100 Device in a Rack or Cabinet | 279 Cabinet Requirements for a QFX3600 or QFX3600-I Device You can mount a QFX3600 or QFX3600-I device in a cabinet that contains a four-post 19-in. rack as defined in Cabinets, Racks, Panels, and Associated Equipment (document number EIA-310-D) published by the former Electronics Industry Association.

  • Page 143: Cabinet Requirements For A Qfx3500 Device

    RELATED DOCUMENTATION Clearance Requirements for Airflow and Hardware Maintenance for a QFX3600 or QFX3600-I Device | 123 Rack Requirements for a QFX3600 or QFX3600-I Device | 112 Mounting a QFX3600 or QFX3600-I Device on Four Posts in a Rack or Cabinet | 303 Mounting a QFX3600 or QFX3600-I Device on Two Posts in a Rack or Cabinet | 301 Cabinet Requirements for a QFX3500 Device You can mount the QFX3500 device in a cabinet that contains a four-post 19-in.

  • Page 144: Cabinet Requirements

    Table 29: Cabinet Requirements for the QFX3500 Device (continued) Cabinet Requirement Guidelines Cabinet airflow When you mount the device in a cabinet, ensure that ventilation through the cabinet is requirements sufficient to prevent overheating. Ensure that the cool air supply you provide through the cabinet adequately dissipates the thermal output of the device (or devices).

  • Page 145: Qfx5110 Clearance Requirements For Airflow And Hardware Maintenance

    Table 30: Cabinet Requirements and Specifications Cabinet Requirement Guidelines Cabinet size The minimum cabinet size is 36 in. (91.4 cm) depth. Large cabinets improve airflow and reduce chances of overheating. Cabinet clearance The outer edges of the front mounting brackets extend the width of the chassis to 19 in. (48.2 cm).

  • Page 146: Clearance Requirements For Airflow And Hardware Maintenance For A Qfx5100 Device

    Figure 45: Clearance Requirements for Airflow and Hardware Maintenance for a QFX5110 For the cooling system to function properly, the airflow around the chassis must be unrestricted. See QFX5110 Cooling System and Airflow Description for more information about the airflow through the chassis.

  • Page 147: Clearance Requirements For Airflow And Hardware Maintenance For A Qfx3600 Or Qfx3600-I Device

    Figure 46: Clearance Requirements for Airflow and Hardware Maintenance for a QFX5100 Device 24" ( 6 0 .9 cm) 24" ( 6 0 .9 cm) Clearance required Clearance required for maintenance for maintenance FRUs Ports 20.48" 17.36" 19" (52.02 cm) 44.1 cm (48.2 cm) Mounting bracket...

  • Page 148: Device

    Figure 47: Clearance Requirements for Airflow and Hardware Maintenance for a QFX3600 or QFX3600-I Device Clearance required Clearance required for maintenance for maintenance Mounting bracket 24 in. (60.9 cm) 24 in. (60.9 cm) 16.9 in. 19.2 in. FRUs Ports (42.9 cm) (48.8 cm) 19.4 in.

  • Page 149: Clearance Requirements For Airflow And Hardware Maintenance For A Qfx3500 Device

    Clearance Requirements for Airflow and Hardware Maintenance for a QFX3500 Device When planning the site for installing a QFX3500 device, you must allow sufficient clearance around the installed chassis (see Figure 48 on page 125). Figure 48: Clearance Requirements for Airflow and Hardware Maintenance for a QFX3500 Device Clearance required Clearance required for maintenance...

  • Page 150: Clearance Requirements For Airflow And Hardware Maintenance For Ex4300 Switches

    Clearance Requirements for Airflow and Hardware Maintenance for EX4300 Switches When planning the site for installing an EX4300 switch, you must ensure sufficient clearance around the switch. Follow these clearance requirements:...
  • Page 151 For the cooling system to function properly, the airflow around the chassis must be unrestricted. See Figure 49 on page 127, Figure 50 on page 127, and Figure 51 on page 127 for reference. Figure 49: Front-to-Back Airflow on 24-Port and 48-Port EX4300 Switches Front Rear Figure 50: Front-to-Back Airflow on 32-Port EX4300 Switches...
  • Page 152 If you are mounting the switch on a rack or cabinet along with other equipment, ensure that the exhaust from other equipment does not blow into the intake vents of the chassis. Leave at least 6 in. (15.2 cm) clearance in front of and behind the chassis for airflow. Leave at least 6 in.
  • Page 153 Rack-Mounting and Cabinet-Mounting Warnings | 224 General Site Guidelines Cooling System and Airflow in an EX4300 Switch...

  • Page 154: Port And Interface Specifications

    Console Port Connector Pinout Information The console port on a Juniper Networks device is an RS-232 serial interface that uses an RJ-45 connector to connect to a console management device. The default baud rate for the console port is 9600 baud.

  • Page 155: Console Port Connector Pinouts For The Qfx Series

    Table 31: Console Port Connector Pinout Information (continued) Signal Description Signal Ground Signal ground RxD Input Receive data CD Input Data carrier detect CTS Input Console Port Connector Pinouts for the QFX Series The console port (labeled CON, or CONSOLE) is an RS-232 serial interface that uses an RJ-45 connector to connect to a console management device.

  • Page 156: Management Port Connector Pinouts For The Qfx Series

    Management Port Connector Pinouts for the QFX Series The 1000BASE-T RJ-45 management ports use an RJ-45 connector to connect either to the control plane and management network in a QFabric system, or to a management device for out-of-band management. Table 33 on page 132 provides the pinout information of the RJ-45 management port connector.

  • Page 157: Mini-Usb Port Pinout Specifications

    Could be not connected (N/C), connected to ground (GND), or used as an attached device presence indicator Ground USB Port Specifications for an EX Series Switch The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port on all EX Series switches: RE-USB-1G-S RE-USB-2G-S...

  • Page 158: Usb Port Specifications For The Qfx Series

    USB flash drive for information about how your USB flash drive is formatted. USB Port Specifications for the QFX Series The following Juniper Networks USB flash drives have been tested and are officially supported for the USB port in the QFX Series: RE-USB-1G-S—1-gigabyte (GB) USB flash drive (except QFX3100 Director device)
  • Page 159 NOTE: Executing the request system snapshot CLI command on a QFX3500 device requires an external USB flash drive with at least 4 GB of free space. We recommend using the RE-USB-4G-S flash drive. NOTE: USB flash drives used with the QFX Series device must support USB 2.0 or later.

  • Page 160: Transceiver And Cable Specifications

    These port are usually used as uplinks. In 40-Gigabit Ethernet mode, these ports can be channelized using QSP+ to SFP+ DAC breakout (DACBO) cables. You can find information about the optical transceivers supported on your Juniper device by using the Hardware Compatibility Tool. In addition to transceiver and connection type, the optical and cable characteristics–where applicable–are documented for each transceiver.

  • Page 161: Determining Interface Support For The Qfx5100 Device

    CAUTION: If you face a problem running a Juniper Networks device that uses a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
  • Page 162 Figure 53 on page 138 shows the location of SFP+ and QSFP+ ports for the QFX5100-96S, Figure 54 on page 138 shows these ports for the QFX5100-48S device, Figure 55 on page 138 shows the RJ45 and QSFP+ ports for the QFX5100-48T device, and Figure 56 on page 139 shows the location of QSFP+ ports for the QFX5100-24Q device.
  • Page 163 QSFP+ access or uplink ports (24) — You can find information about the optical transceivers supported on your Juniper device by using the Hardware Compatibility Tool. In addition to transceiver and connection type, the optical and cable characteristics–where applicable–are documented for each transceiver. The Hardware Compatibility Tool enables you to search by product, displaying all the transceivers supported on that device, or category, by interface speed or type.

  • Page 164: Determining Interface Support For The Qfx3600 Device

    Port Panel of QFX5100-48S and QFX5100-48SH Devices | 36 Port Panel of QFX5100-48T and QFX5100-48TH Devices | 39 Port Panel of a QFX5100-96S Device | 41 Determining Interface Support for the QFX3600 Device The QFX3600 device provides 16 QSFP+ ports, which support QSFP+ transceivers and QSFP+ DAC or DAC breakout cables.

  • Page 165: Determining Interface Support For The Qfx3500 Device

    QFX3600 Node device with another device, the interface is automatically configured to operate as four 10-Gigabit Ethernet interfaces over one cable. You can find information about the optical transceivers supported on your Juniper device by using the Hardware Compatibility Tool. In addition to transceiver and connection type, the optical and cable characteristics–where applicable–are documented for each transceiver.
  • Page 166 Junos OS 12.2X50-D10 or later for the QFX3500 Node device in a QFabric system You can find information about the optical transceivers supported on your Juniper device by using the Hardware Compatibility Tool. In addition to transceiver and connection type, the optical and cable characteristics–where applicable–are documented for each transceiver.

  • Page 167: Pluggable Transceivers Supported On Ex4300 Switches

    CAUTION: If you face a problem running a Juniper Networks device that uses a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.

  • Page 168: Cable Specifications For Qsfp+ And Qsfp28 Transceivers

    The 40-Gigabit Ethernet QSFP+ and 100-Gigabit Ethernet QSFP28 transceivers that are used in QFX Series switches use 12-ribbon multimode fiber crossover cables with socket MPO/UPC connectors. The fiber can be either OM3 or OM4. These cables are not sold by Juniper Networks. CAUTION: To maintain agency approvals, use only a properly constructed, shielded cable.
  • Page 169 Table 35: QSFP+ and QSFP28 Optical Module Receptacle Pinouts (continued) Fiber Signal Tx1 (Transmit) Tx2 (Transmit) Tx3 (Transmit) Unused Unused Unused Unused Rx3 (Receive) Rx2 (Receive) Rx1 (Receive) Rx0 (Receive) Table 36: QSFP+ MPO Fiber-Optic Crossover Cable Pinouts...

  • Page 170: Cable Specifications For Console And Management Connections For The Qfx Series

    Table 36: QSFP+ MPO Fiber-Optic Crossover Cable Pinouts (continued) Cable Specifications for Console and Management Connections for the QFX Series Table 37 on page 146 lists the specifications for the cables that connect the QFX Series switch to a management device. NOTE: The QFX Series can be configured with SFP management ports that support 1000BASE-SX transceivers.

  • Page 171: Calculating The Fiber-Optic Cable Power Budget For Qfx Series Switches

    Calculating the Fiber-Optic Cable Power Budget for QFX Series Switches Calculate the fiber-optic data link's power budget when planning fiber-optic cable layout and distances to ensure that fiber-optic connections have sufficient power for correct operation. The power budget is the maximum amount of power the link can transmit.
  • Page 172 Before you begin to calculate the power margin, calculate the power budget. See “Calculating the Fiber-Optic Cable Power Budget for QFX Series Switches” on page 147. To calculate the worst-case estimate for the power margin (P ) for the link: 1.

  • Page 173: Management Cable Specifications

    – LL = P 13 dBm – 0.5 dBm [HOL] – 5 x (0.5 dBm) – 2 (0.5 dBm) – 2 km (1.0 dBm/km) – 1 dB [CRM] = P 13 dB m – 0.5 dBm – 2.5 dBm – 1 dBm – 2 dBm – 1 dBm = P = 6 dBm The calculated power margin is greater than zero, indicating that the link has sufficient power for transmission.

  • Page 174: Understanding Ex Series Switches Fiber-Optic Cable Signal Loss, Attenuation, And Dispersion

    Understanding EX Series Switches Fiber-Optic Cable Signal Loss, Attenuation, and Dispersion IN THIS SECTION Signal Loss in Multimode and Single-Mode Fiber-Optic Cable | 150 Attenuation and Dispersion in Fiber-Optic Cable | 150 To determine the power budget and power margin needed for fiber-optic connections, you need to understand how signal loss, attenuation, and dispersion affect transmission.

  • Page 175: Understanding Qfx Series Fiber-Optic Cable Signal Loss, Attenuation, And Dispersion

    Dispersion is the spreading of the signal over time. The following two types of dispersion can affect signal transmission through an optical data link: Chromatic dispersion, which is the spreading of the signal over time caused by the different speeds of light rays.

  • Page 176: Attenuation And Dispersion In Fiber-Optic Cable

    the light at different angles. Light rays travel in jagged lines through a multimode fiber, causing signal dispersion. When light traveling in the fiber core radiates into the fiber cladding (layers of lower refractive index material in close contact with a core material of higher refractive index), higher-order mode loss occurs.

  • Page 177: Planning Qfx5100 Power Requirements

    CHAPTER 11 Planning QFX5100 Power Requirements IN THIS CHAPTER AC Power Specifications for a QFX5100 Device | 153 AC Power Cord Specifications for a QFX Series Device | 154 DC Power Specifications for a QFX5100 Device | 156 AC Power Specifications for a QFX5100 Device Table 40 on page 153 describes the AC power specifications for a QFX5100 device.

  • Page 178: Ac Power Cord Specifications For A Qfx Series Device

    Table 40: AC Power Specifications for a QFX5100 Device (continued) Item QFX5100-48S and QFX5100-48SH 365 W QFX5100-48T and QFX5100-48TH 395 W QFX5100-96S 470 W RELATED DOCUMENTATION AC Power Cord Specifications for a QFX Series Device | 154 AC Power Supply for a QFX5100 Device General Safety Guidelines and Warnings | 203 General Electrical Safety Guidelines and Warnings | 240 AC Power Cord Specifications for a QFX Series Device...
  • Page 179 Table 41: AC Power Cord Specifications Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic Australia 250 VAC, 10 A, AS/NZ CG_CBL-C13-06-AU CBL-EX-PWR-C13-AU 50 Hz 3109-1996 China 250 VAC, 10 A, CG_CBL-C13-06-CH CBL-EX-PWR-C13-CH 50 Hz...

  • Page 180: Dc Power Specifications For A Qfx5100 Device

    Table 41: AC Power Cord Specifications (continued) Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic 250 VAC, 10 A, 50 Hz DC Power Specifications for a QFX5100 Device Table 42 on page 156 describes the DC power specifications for DC product SKUs of the QFX5100 device.
  • Page 181 Table 42: DC Power Specifications for a QFX5100 Device (continued) Item Product SKUs Specifications Maximum power QFX5100-24Q 385 W consumption QFX5100-48S QFX5100-48T QFX5100-96S 470 W RELATED DOCUMENTATION DC Power Supply in a QFX5100 Device DC Power Supply LEDs on a QFX5100 Device | 516...

  • Page 182: Planning Qfx5110 Power Requirements

    CHAPTER 12 Planning QFX5110 Power Requirements IN THIS CHAPTER QFX5110 AC Power Specifications | 158 AC Power Cord Specifications for a QFX Series Device | 159 QFX5110 DC Power Specifications | 161 QFX5110 AC Power Specifications Table 43 on page 158 describes the AC power specifications for QFX5110 switches.

  • Page 183: Ac Power Cord Specifications For A Qfx Series Device

    AC Power Cord Specifications for a QFX Series Device Detachable AC power cords are shipped with the chassis, if you include them as part of your order. The coupler is type C13 as described by International Electrotechnical Commission (IEC) standard 60320. The plug end of the power cord fits into the power source outlet that is standard for your geographical location.
  • Page 184 Table 44: AC Power Cord Specifications Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic Australia 250 VAC, 10 A, AS/NZ CG_CBL-C13-06-AU CBL-EX-PWR-C13-AU 50 Hz 3109-1996 China 250 VAC, 10 A, CG_CBL-C13-06-CH CBL-EX-PWR-C13-CH 50 Hz...

  • Page 185: Qfx5110 Dc Power Specifications

    Table 44: AC Power Cord Specifications (continued) Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic 250 VAC, 10 A, 50 Hz QFX5110 DC Power Specifications Table 45 on page 161 describes the QFX5110 DC power specifications. The typical and maximum power consumption values are calculated using dummy transceivers on all ports.

  • Page 186: Planning Qfx3600 Power Requirements

    CHAPTER 13 Planning QFX3600 Power Requirements IN THIS CHAPTER AC Power Specifications for a QFX3600 or QFX3600-I Device | 162 AC Power Cord Specifications for a QFX Series Device | 163 DC Power Specifications for a QFX3600 or QFX3600-I Device | 165 AC Power Specifications for a QFX3600 or QFX3600-I Device Table 46 on page 162 describes the AC power specifications for a QFX3600 or QFX3600-I device.

  • Page 187: Ac Power Cord Specifications For A Qfx Series Device

    AC Power Cord Specifications for a QFX Series Device Detachable AC power cords are shipped with the chassis, if you include them as part of your order. The coupler is type C13 as described by International Electrotechnical Commission (IEC) standard 60320. The plug end of the power cord fits into the power source outlet that is standard for your geographical location.
  • Page 188 Table 47: AC Power Cord Specifications Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic Australia 250 VAC, 10 A, AS/NZ CG_CBL-C13-06-AU CBL-EX-PWR-C13-AU 50 Hz 3109-1996 China 250 VAC, 10 A, CG_CBL-C13-06-CH CBL-EX-PWR-C13-CH 50 Hz...

  • Page 189: Dc Power Specifications For A Qfx3600 Or Qfx3600-I Device

    Table 47: AC Power Cord Specifications (continued) Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic 250 VAC, 10 A, 50 Hz DC Power Specifications for a QFX3600 or QFX3600-I Device Table 48 on page 165 describes the DC power specifications for a QFX3600 or QFX3600-I device.

  • Page 190: Planning Qfx3500 Power Requirements

    CHAPTER 14 Planning QFX3500 Power Requirements IN THIS CHAPTER AC Power Specifications for a QFX3500 Device | 166 AC Power Cord Specifications for a QFX Series Device | 167 DC Power Specifications for a QFX3500 Device | 169 AC Power Specifications for a QFX3500 Device Table 49 on page 166 describes the AC power specifications for a QFX3500 device.

  • Page 191: Ac Power Cord Specifications For A Qfx Series Device

    General Electrical Safety Guidelines and Warnings | 240 AC Power Cord Specifications for a QFX Series Device Detachable AC power cords are shipped with the chassis, if you include them as part of your order. The coupler is type C13 as described by International Electrotechnical Commission (IEC) standard 60320. The plug end of the power cord fits into the power source outlet that is standard for your geographical location.
  • Page 192 Table 50: AC Power Cord Specifications Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic Australia 250 VAC, 10 A, AS/NZ CG_CBL-C13-06-AU CBL-EX-PWR-C13-AU 50 Hz 3109-1996 China 250 VAC, 10 A, CG_CBL-C13-06-CH CBL-EX-PWR-C13-CH 50 Hz...

  • Page 193: Dc Power Specifications For A Qfx3500 Device

    Table 50: AC Power Cord Specifications (continued) Electrical Plug Shipped Juniper Spare Juniper Model Country/Region Specifications Standards Model Number Number Graphic 250 VAC, 10 A, 50 Hz DC Power Specifications for a QFX3500 Device Table 51 on page 169 describes the DC power specifications for a QFX3500 device.

  • Page 194: Planning Ex4300 Power Requirements

    CHAPTER 15 Planning EX4300 Power Requirements IN THIS CHAPTER AC Power Supply in EX4300 Switches | 170 AC Power Cord Specifications for an EX4300 Switch | 180 DC Power Supply in EX4300 Switches | 184 AC Power Supply in EX4300 Switches IN THIS SECTION Characteristics of an AC Power Supply | 171 AC Power Supply Airflow | 173...

  • Page 195: Characteristics Of An Ac Power Supply

    This topic describes the AC power supplies. CAUTION: Do not mix: AC and DC power supplies in the same chassis Power supplies with different airflow labels (AIR IN (AFI) and AIR OUT (AFO)) in the same chassis. Fan modules with different airflow labels (AIR IN (AFI) and AIR OUT (AFO)) in the same chassis.
  • Page 196 Table 52: Details of the AC Power Supplies in EX4300 Switches 350 W AC Power 715 W AC Power 1100 W AC 1400 W AC Details Supply Supply Power Supply Power Supply Model number JPSU-350-AC- JPSU-715-AC- JPSU-1100-AC- JPSU-1400W-AC- AFO-A AFO-A AFO-A JPSU-350-AC- AFI-A...

  • Page 197: Ac Power Supply Airflow

    Table 52: Details of the AC Power Supplies in EX4300 Switches (continued) 350 W AC Power 715 W AC Power 1100 W AC 1400 W AC Details Supply Supply Power Supply Power Supply Airflow Front-to-back, Front-to-back, Front-to-back, Front-to-back, indicated by label indicated by label indicated by label indicated by label...

  • Page 198: N+0 Redundancy Configuration Of Ac Power Supplies

    Table 53: Airflow Direction in AC Power Supply Models for EX4300 Switches Label on Power Model Supply Direction of Airflow JPSU-350-AC-AFO-A AIR OUT (AFO) Front-to-back—that is, air intake to cool the chassis is through the vents on the front panel of the chassis and hot air exhausts through the vents on the rear panel of the chassis.
  • Page 199 Table 54: N+0 AC Power Calculations for 24-Port EX4300 Switches (continued) Power Supply Rating Total Power (in Usable Backup Available Ports watts) System Power Base Enabled (W) + Power (in Power (in Power (in watts) watts) watts) watts) PoE+ 350 W AC 715 W AC 1065 993.5...
  • Page 200 Table 56: N+0 AC Power Calculations for 48-Port EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches Power Supply Rating Total Power (in Usable Backup Available Ports watts) System Power Base Enabled (W) + Power (in Power (in Power (in watts) watts) watts) watts) PoE+...

  • Page 201: N+N Redundancy Configuration Of Ac Power Supplies

    Table 57: N+0 AC Power Calculations for EX4300-48MP and EX4300-48MP-S Switches Power Supply Rating Total Power (in watts) Usable Backup Base Available Ports Ports System Power Power Enabled Enabled Power Power (in (in watts) watts) watts) watts) PoE+ PoE++ 715 W AC –...
  • Page 202 Table 58: N+N AC Power Calculations for 24-Port EX4300 Switches (continued) Power Supply Rating Usable Backup Available Ports Total System Power Base enabled Power (in Power (in Power (in Power (in watts) watts) watts) watts) watts) PoE+ 350 W AC 350 W AC 350 W AC 715 W AC...
  • Page 203 Table 60: N+N AC Power Calculations for 48-Port EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches Power Supply Rating Usable Backup Available Ports Total System Power Base enabled Power (in Power (in Power (in Power (in watts) watts) watts) watts) watts) PoE+ 350 W AC –...

  • Page 204: Ac Power Cord Specifications For An Ex4300 Switch

    Table 61: N+N AC Power Calculations for EX4300-48MP and EX4300-48MP-S Switches (continued) Power Supply Rating Usable Backup Base Available Ports Ports Total System Power Power enabled enabled Power Power Power (in (in watts) (in watts) watts) watts) watts) PoE+ PoE++ 715 W AC 1100 W AC 1815...
  • Page 205 AC power supplies for EX4300-48MP and EX4300-48MP-S Switches Table 62: AC Power Cord Specifications for 350 W Power Supplies for EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches and 715 W AC Power Supplies for EX4300 Switches Country/ Electrical Juniper Model Region Specifications Plug Standards Number...
  • Page 206 Table 62: AC Power Cord Specifications for 350 W Power Supplies for EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches and 715 W AC Power Supplies for EX4300 Switches (continued) Country/ Electrical Juniper Model Region Specifications Plug Standards Number Graphic Israel...
  • Page 207 Table 63: AC Power Cord Specifications for 1100 W AC Power Supplies for EX4300 Switches and 1400 W AC Power Supplies for EX4300-48MP and EX4300-48MP-S Switches Country/Region Electrical Specifications Plug Standards Juniper Model Number Argentina 250 VAC, 10 A, 50 Hz IRAM 2073 Type RA/3 CBL-PWR-C15M-HITEMP-AR...

  • Page 208: Dc Power Supply In Ex4300 Switches

    Table 63: AC Power Cord Specifications for 1100 W AC Power Supplies for EX4300 Switches and 1400 W AC Power Supplies for EX4300-48MP and EX4300-48MP-S Switches (continued) Country/Region Electrical Specifications Plug Standards Juniper Model Number North America 125 VAC, 15 A, 60 Hz NEMA 5-15 Type N5/15 CBL-PWR-C15M-HITEMP-US...

  • Page 209: Characteristics Of A Dc Power Supply

    NOTE: EX4300-24T, EX4300-24P, EX4300-32F, EX4300-48T, EX4300-48T-AFI, EX4300-48P, EX4300-48MP, and EX4300-48MP-S models do not support DC power. EX4300-24T-S, EX4300-24P-S, EX4300-32F-S, EX4300-32F-DC, EX4300-48T-S, EX4300-48T-DC, EX4300-48T-DC-AFI, and EX4300-48P-S models support DC power. All the EX4300 switches that are powered by DC power supplies except EX4300-24T-S, EX4300-24P-S, EX4300-32F-S, EX4300-48T-S, and EX4300-48P-S switches are shipped with one DC power supply installed in the rear panel of the switches.

  • Page 210: Dc Power Supply Airflow

    Table 64 on page 186 lists the details of the 550 W DC power supplies used in EX4300 switches. Table 64: Details of the DC Power Supplies in EX4300 Switches Details 550 W DC Power Supply Model number JPSU-550-DC-AFO-A JPSU-550-DC-AFI-A Field-replaceable unit (FRU) type Hot-insertable and hot-removable Power supply weight...

  • Page 211: N+0 Redundancy Configuration Of Dc Power Supplies

    Table 65 on page 187 lists the DC power supply models and the direction of airflow in them. Table 65: Airflow Direction in DC Power Supply Models for EX4300 Switches Label on Power Model Supply Direction of Airflow JPSU-550-DC-AFO-A AIR OUT (AFO) Front-to-back—that is, air intake to cool the chassis is through the vents on the front panel of the chassis and hot air exhausts through the vents on the rear panel of the chassis.

  • Page 212: N+N Redundancy Configuration Of Dc Power Supplies

    Table 66: N+0 DC Power Calculations for EX4300 Switch Configurations Number of Backup Switch Power Total Power (in Usable System Power (in Base Power (in Configuration Supplies watts) Power (in watts) watts) watts) 24-port EX4300 switch 1100 1045 32-port EX4300 switch 1100 48-port EX4300...
  • Page 213 System power budget = PSU(W) – (0.05 x PSU(W)) Backup power available = (Output wattage of one power supply) – (5% of the output wattage of one power supply) System power budget = PSU(W) – (0.05 x PSU(W)) Table 67 on page 189 lists the N+N power calculation for EX4300 switches that use 550 W DC power supplies.

  • Page 214: Compliance

    CHAPTER 16 Compliance IN THIS CHAPTER Agency Approvals for EX Series Switches | 190 Agency Approvals for the QFX Series | 191 Compliance Statements for EMC Requirements for EX Series Switches | 192 Compliance Statements for EMC Requirements for the QFX Series | 197 Compliance Statements for Acoustic Noise for EX Series Switches | 200 Agency Approvals for EX Series Switches This topic applies to hardware devices in the EX Series product family, which includes EX Series switches,...

  • Page 215: Agency Approvals For The Qfx Series

    EN 55024 EN 300386 EN 61000-3-2 Power Line Harmonics EN 61000-3-3 Voltage Fluctuations and Flicker EN 61000-4-2 ESD EN 61000-4-3 Radiated Immunity EN 61000-4-4 EFT EN 61000-4-5 Surge EN 61000-4-6 Low Frequency Common Immunity EN 61000-4-11 Voltage Dips and Sags Agency Approvals for the QFX Series The QFX Series complies with the following standards: Safety...

  • Page 216: Compliance Statements For Emc Requirements For Ex Series Switches

    BSMI, Class A CNS 13438 Electromagnetic Interference (EMI) FCC 47 CFR Part 15, Class A (2009) USA Radiated Emissions EN 55022 Class A (2010) European Radiated Emissions VCCI Class A:(2010) Japanese Emissions BSMI CNS 13438 and NCC C6357 Class A Taiwan Radiated Emissions AS/NZS CISPR 22:2009: Class A, Australian/New Zealand Radiated Emissions Immunity EN 55024: 1998/A1:2001/A2:2003 Information Technology Equipment Immunity Characteristics...

  • Page 217: Canada

    FCC Part 15 Statement | 195 Nonregulatory Environmental Standards | 196 This topic applies to hardware devices in the EX Series product family, which includes EX Series switches, the EX Series Redundant Power System (RPS), and the XRE200 External Routing Engine. This topic describes the EMC requirements for these hardware devices.

  • Page 218: European Community

    The preceding translates as follows: This is a Class A device. In a domestic environment, this device might cause radio interference, in which case the user needs to take adequate measures. European Community This is a Class A device. In a domestic environment this device might cause radio interference, in which case the user needs to take adequate measures.

  • Page 219: Korea

    Korea Korean Class A Warning The preceding translates as follows: This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it, and this equipment is to be used in the places except for home United States The device has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.

  • Page 220: Nonregulatory Environmental Standards

    Nonregulatory Environmental Standards NEBS compliance—These EX Series switches are Network Equipment Building System (NEBS) compliant: EX2200-24T and EX2200-48T EX3200-24T, EX3200-48T EX3300-24T, EX3300-48T EX4200-24T, EX4200-24F, EX4200-24F-S, EX4200-48T and EX4200-48T-S EX4300-24T, EX4300-24T-S, EX4300-24P, EX4300-24P-S, EX4300-32F, EX4300-32F-S, EX4300-48T, EX4300-48T-AFI, EX4300-48T-S, EX4300-48P, and EX4300-48P-S All EX4500 switches with AC power supplies EX4550-32T-AFO, EX4550-32T-AFI, EX4550-32F-AFO, EX4550-32F-AFI, and EX4550-32F-S EX4600-40F and EX4600-40F-S...

  • Page 221: Compliance Statements For Emc Requirements For The Qfx Series

    Compliance Statements for EMC Requirements for the QFX Series IN THIS SECTION Canada | 197 European Community | 198 Israel | 198 Japan | 198 Korea | 199 Taiwan | 199 United States | 199 Nonregulatory Environmental Standards | 199 This topic describes the EMC requirements for the QFX Series.

  • Page 222: European Community

    CAUTION: Users should not attempt to make electrical ground connections by themselves, but should contact the appropriate inspection authority or an electrician, as appropriate. Users should ensure for their own protection that the electrical ground connections of the power utility, telephone lines, and internal metallic water pipe system, if present, are connected together.

  • Page 223: Korea

    Korea Korean Class A Warning The preceding translates as follows: This equipment is Industrial (Class A) electromagnetic wave suitability equipment and seller or user should take notice of it, and this equipment is to be used in the places except for home. Taiwan Chinese Class A warning The preceding translates as follows:...

  • Page 224: Compliance Statements For Acoustic Noise For Ex Series Switches

    QFX3008-I QFX3600-I QFX3600 QFX3500 QFX5100 QFX5110 QFX5200-32C QFX10002-36Q and QFX10002-72Q QFX10008 QFX10016 Those device product SKUs meet the following NEBS compliance standards: SR-3580 NEBS Criteria Levels (Level 3 Compliance) GR-1089-CORE, Issue 6: EMC and Electrical Safety—Generic Criteria for Network Telecommunications Equipment The equipment is suitable for installation in locations where the National Electrical Code (NEC) applies.
  • Page 225 Translation: The emitted sound pressure is below 70 dB(A) per EN ISO 7779.

  • Page 226: Safety

    PART Safety General Safety Information | 203 Radiation and Laser Warnings | 210 Installation and Maintenance Safety Information | 217 Power and Electrical Safety Information | 240...

  • Page 227: General Safety Information

    CHAPTER 17 General Safety Information IN THIS CHAPTER General Safety Guidelines and Warnings | 203 Definitions of Safety Warning Levels | 204 Fire Safety Requirements | 207 Qualified Personnel Warning | 208 Warning Statement for Norway and Sweden | 209 General Safety Guidelines and Warnings The following guidelines help ensure your safety and protect the device from damage.

  • Page 228: Definitions Of Safety Warning Levels

    Replace fuses only with fuses of the same type and rating. Do not open or remove chassis covers or sheet-metal parts unless instructions are provided in the hardware documentation for this device. Such an action could cause severe electrical shock. Do not push or force any objects through any opening in the chassis frame.
  • Page 230 WARNING: This symbol means danger. You are in a situation that could cause bodily injury. Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with standard practices for preventing accidents. Waarschuwing Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan veroorzaken.

  • Page 231: Fire Safety Requirements

    In addition, you should establish procedures to protect your equipment in the event of a fire emergency. Juniper Networks products should be installed in an environment suitable for electronic equipment. We recommend that fire suppression equipment be available in the event of a fire in the vicinity of the equipment and that all local fire, safety, and electrical codes and ordinances be observed when you install and operate your equipment.

  • Page 232: Qualified Personnel Warning

    To keep warranties effective, do not use a dry chemical fire extinguisher to control a fire at or near a Juniper Networks device. If a dry chemical fire extinguisher is used, the unit is no longer eligible for coverage under a service agreement.

  • Page 233: Warning Statement For Norway And Sweden

    Warning Statement for Norway and Sweden WARNING: The equipment must be connected to an earthed mains socket-outlet. Advarsel Apparatet skal kobles til en jordet stikkontakt. Varning! Apparaten skall anslutas till jordat nätuttag.

  • Page 234: Radiation And Laser Warnings

    CHAPTER 18 Radiation and Laser Warnings IN THIS CHAPTER Radiation from Open Port Apertures Warning | 211 Laser and LED Safety Guidelines and Warnings for the QFX Series | 212...

  • Page 235: Radiation From Open Port Apertures Warning

    Radiation from Open Port Apertures Warning WARNING: Because invisible radiation might be emitted from the aperture of the port when no fiber cable is connected, avoid exposure to radiation and do not stare into open apertures. Waarschuwing Aangezien onzichtbare straling vanuit de opening van de poort kan komen als er geen fiberkabel aangesloten is, dient blootstelling aan straling en het kijken in open openingen vermeden te worden.

  • Page 236: Laser And Led Safety Guidelines And Warnings For The Qfx Series

    Laser and LED Safety Guidelines and Warnings for the QFX Series IN THIS SECTION Class 1M Laser Product Warning | 212 Class 1M Laser Radiation Warning | 213 Unterminated Fiber-Optic Cable Warning | 214 In addition to the general guidelines provided in Laser and LED Safety Guidelines and Warnings, follow these warnings and guidelines that are specific to QFX Series devices.

  • Page 237: Class 1M Laser Radiation Warning

    Class 1M Laser Radiation Warning WARNING: Class 1M laser radiation when open. Do not view directly with optical instruments.

  • Page 238: Unterminated Fiber-Optic Cable Warning

    Unterminated Fiber-Optic Cable Warning...
  • Page 239 WARNING: Invisible laser radiation might be emitted from the unterminated connector of a fiber-optic cable. To avoid injury to your eye, do not view the fiber optics with a magnifying optical device, such as a loupe, within 100 mm. Waarschuwing Er kunnen onzichtbare laserstralen worden uitgezonden vanuit het uiteinde van de onafgebroken vezelkabel of connector.
  • Page 240 lupas, lentes de aumento ou microscópios) a uma distância de 100 mm pode causar riscos à visão. ¡Atención! El extremo de un cable o conector de fibra sin terminación puede emitir radiación láser invisible. No se acerque al radio de acción ni lo mire directamente con instrumentos ópticos.

  • Page 241: Installation And Maintenance Safety Information

    CHAPTER 19 Installation and Maintenance Safety Information IN THIS CHAPTER Installation Instructions Warning | 218 QFX5100 Installation Safety Guidelines | 218 Chassis Lifting Guidelines for a QFX3600 or QFX3600-I Device | 219 Chassis Lifting Guidelines for a QFX3500 Device | 220 Chassis Lifting Guidelines for EX4300 Switches | 220 Restricted Access Warning | 222 Ramp Warning | 224...

  • Page 242: Installation Instructions Warning

    Installation Instructions Warning WARNING: Read the installation instructions before you connect the device to a power source. Waarschuwing Raadpleeg de installatie-aanwijzingen voordat u het systeem met de voeding verbindt. Varoitus Lue asennusohjeet ennen järjestelmän yhdistämistä virtalähteeseen. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation.

  • Page 243: Chassis Lifting Guidelines For A Qfx3600 Or Qfx3600-I Device

    Before installing a QFX5100 switch, read the guidelines in “Site Preparation Checklist for a QFX5100 Device” on page 92 to verify that the intended site meets the specified power, environmental, and clearance requirements. Before lifting or moving the QFX5100 switch, disconnect all external cables. As when lifting any heavy object, lift most of the weight with your legs rather than your back.

  • Page 244: Chassis Lifting Guidelines For A Qfx3500 Device

    Chassis Lifting Guidelines for a QFX3500 Device The weight of a fully loaded QFX3500 device chassis is approximately 30.8 lb (14 kg). Observe the following guidelines for lifting and moving a QFX3500 device: CAUTION: If you are installing the QFX3500 device above 60 in. (152.4 cm) from the floor, you must remove the power supplies, fan trays, and management board before attempting to install the device, or ask someone to assist you during the installation.
  • Page 245 RELATED DOCUMENTATION General Safety Guidelines and Warnings | 203 Installation Instructions Warning | 218 Mounting an EX4300 Switch | 355...

  • Page 246: Restricted Access Warning

    Restricted Access Warning...
  • Page 247 WARNING: This unit is intended for installation in restricted access areas. A restricted access area is an area to which access can be gained only by service personnel through the use of a special tool, lock and key, or other means of security, and which is controlled by the authority responsible for the location.

  • Page 248: Ramp Warning

    ¡Atención! Esta unidad ha sido diseñada para instalarse en áreas de acceso restringido. Área de acceso restringido significa un área a la que solamente tiene acceso el personal de servicio mediante la utilización de una herramienta especial, cerradura con llave, o algún otro medio de seguridad, y que está...
  • Page 250 De onderstaande richtlijnen worden verstrekt om uw veiligheid te verzekeren: De Juniper Networks switch moet in een stellage worden geïnstalleerd die aan een bouwsel is verankerd. Dit toestel dient onderaan in het rek gemonteerd te worden als het toestel het enige in het rek is.
  • Page 251 Les directives ci-dessous sont destinées à assurer la protection du personnel: Le rack sur lequel est monté le Juniper Networks switch doit être fixé à la structure du bâtiment. Si cette unité constitue la seule unité montée en casier, elle doit être placée dans le bas.
  • Page 252 Il Juniper Networks switch deve essere installato in un telaio, il quale deve essere fissato alla struttura dell'edificio. Questa unità deve venire montata sul fondo del supporto, se si tratta dell'unica unità da montare nel supporto. Quando questa unità viene montata in un supporto parzialmente pieno, caricare il supporto dal basso all'alto, con il componente più...
  • Page 253 El Juniper Networks switch debe instalarse en un bastidor fijado a la estructura del edificio. Colocar el equipo en la parte inferior del bastidor, cuando sea la única unidad en el mismo. Cuando este equipo se vaya a instalar en un bastidor parcialmente ocupado, comenzar la instalación desde la parte inferior hacia la superior colocando el equipo más pesado...

  • Page 254: Grounded Equipment Warning

    Grounded Equipment Warning WARNING: This device must be properly grounded at all times. Follow the instructions in this guide to properly ground the device to earth. Waarschuwing Dit apparaat moet altijd goed geaard zijn. Volg de instructies in deze gids om het apparaat goed te aarden. Varoitus Laitteen on oltava pysyvästi maadoitettu.
  • Page 255 Lightning Activity Warning | 235 Operating Temperature Warning | 236 Product Disposal Warning | 238 While performing the maintenance activities for devices, observe the following guidelines and warnings:...

  • Page 256: Battery Handling Warning

    Battery Handling Warning WARNING: Replacing a battery incorrectly might result in an explosion. Replace a battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions. Waarschuwing Er is ontploffingsgevaar als de batterij verkeerd vervangen wordt. Vervang de batterij slechts met hetzelfde of een equivalent type dat door de fabrikant aanbevolen is.

  • Page 257: Jewelry Removal Warning

    Jewelry Removal Warning...
  • Page 258 WARNING: Before working on equipment that is connected to power lines, remove jewelry, including rings, necklaces, and watches. Metal objects heat up when connected to power and ground and can cause serious burns or can be welded to the terminals. Waarschuwing Alvorens aan apparatuur te werken die met elektrische leidingen is verbonden, sieraden (inclusief ringen, kettingen en horloges) verwijderen.

  • Page 259: Lightning Activity Warning

    se conectan a la alimentación y a tierra, lo que puede ocasionar quemaduras graves o que los objetos metálicos queden soldados a los bornes. Varning! Tag av alla smycken (inklusive ringar, halsband och armbandsur) innan du arbetar på utrustning som är kopplad till kraftledningar. Metallobjekt hettas upp när de kopplas ihop med ström och jord och kan förorsaka allvarliga brännskador;...

  • Page 260: Operating Temperature Warning

    Operating Temperature Warning...
  • Page 261 40° C. Para evitar a restrição à circulação de ar, deixe pelo menos um espaço de 15,2 cm à volta das aberturas de ventilação. ¡Atención! Para impedir que un encaminador de la serie Juniper Networks switch se recaliente, no lo haga funcionar en un área en la que se supere la temperatura ambiente máxima recomendada de 40°...

  • Page 262: Product Disposal Warning

    Varning! Förhindra att en Juniper Networks switch överhettas genom att inte använda den i ett område där den maximalt rekommenderade omgivningstemperaturen på 40° C överskrids. Förhindra att luftcirkulationen inskränks genom att se till att det finns fritt utrymme på minst 15,2 cm omkring ventilationsöppningarna.

  • Page 263: Wall-Mounting Warning For Ex4300 Switches

    Wall-Mounting Warning for EX4300 Switches WARNING: When mounting EX4300 switches except EX4300-48MP and EX4300-48MP-S switches on a wall, orient the front panel of the chassis downward to ensure proper airflow and meet safety requirements in the event of a fire. When mounting EX4300-48MP and EX4300-48MP-S switches on a wall, orient the front panel of the chassis pointing to the right side or to the left side to ensure proper airflow and meet safety requirements in the event of a fire.

  • Page 264: Power And Electrical Safety Information

    CHAPTER 20 Power and Electrical Safety Information IN THIS CHAPTER General Electrical Safety Guidelines and Warnings | 240 Prevention of Electrostatic Discharge Damage | 242 Action to Take After an Electrical Accident | 243 AC Power Electrical Safety Guidelines | 244 AC Power Disconnection Warning | 245 DC Power Electrical Safety Guidelines | 245 DC Power Disconnection Warning | 247...
  • Page 265 CAUTION: Before removing or installing components of a device, connect an electrostatic discharge (ESD) grounding strap to an ESD point and wrap and fasten the other end of the strap around your bare wrist. Failure to use an ESD grounding strap could result in damage to the device.

  • Page 266: Prevention Of Electrostatic Discharge Damage

    Prevention of Electrostatic Discharge Damage Device components that are shipped in antistatic bags are sensitive to damage from static electricity. Some components can be impaired by voltages as low as 30 V. You can easily generate potentially damaging static voltages whenever you handle plastic or foam packing material or if you move components across plastic or carpets.

  • Page 267: Action To Take After An Electrical Accident

    Figure 61: Placing a Component into an Antistatic Bag CAUTION ELECTROSTATIC SENSITIVE DEVICES DO NOT OPEN OR HANDLE EXCEPT AT A STATIC-FREE WORKSTATION CAUTION: ANSI/TIA/EIA-568 cables such as Category 5e and Category 6 can get electrostatically charged. To dissipate this charge, always ground the cables to a suitable and safe earth ground before connecting them to the system.

  • Page 268: Ac Power Electrical Safety Guidelines

    AC Power Electrical Safety Guidelines The following electrical safety guidelines apply to AC-powered devices: Note the following warnings printed on the device: “CAUTION: THIS UNIT HAS MORE THAN ONE POWER SUPPLY CORD. DISCONNECT ALL POWER SUPPLY CORDS BEFORE SERVICING TO AVOID ELECTRIC SHOCK.” “ATTENTION: CET APPAREIL COMPORTE PLUS D'UN CORDON D'ALIMENTATION.

  • Page 269: Ac Power Disconnection Warning

    AC Power Disconnection Warning WARNING: Before working on the device or near power supplies, unplug all the power cords from an AC-powered device. Waarschuwing Voordat u aan een frame of in de nabijheid van voedingen werkt, dient u bij wisselstroom toestellen de stekker van het netsnoer uit het stopcontact te halen. Varoitus Kytke irti vaihtovirtalaitteiden virtajohto, ennen kuin teet mitään asennuspohjalle tai työskentelet virtalähteiden läheisyydessä.
  • Page 270 For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible. Be sure to connect the ground wire or conduit to a solid central office earth ground. A closed loop ring is recommended for terminating the ground conductor at the ground stud. Run two wires from the circuit breaker box to a source of 48 VDC.

  • Page 271: Dc Power Disconnection Warning

    DC Power Disconnection Warning...
  • Page 272 WARNING: Before performing any of the DC power procedures, ensure that power is removed from the DC circuit. To ensure that all power is off, locate the circuit breaker on the panel board that services the DC circuit, switch the circuit breaker to the OFF position, and tape the device handle of the circuit breaker in the OFF position.

  • Page 273: Dc Power Grounding Requirements And Warning

    que toda a corrente foi DESLIGADA, localize o disjuntor no painel que serve o circuito de corrente contínua e coloque-o na posição OFF (Desligado), segurando nessa posição a manivela do interruptor do disjuntor com fita isoladora. ¡Atención! Antes de proceder con los siguientes pasos, comprobar que la alimentación del circuito de corriente continua (CC) esté...
  • Page 274 WARNING: When you install the device, the ground connection must always be made first and disconnected last. Waarschuwing Bij de installatie van het toestel moet de aardverbinding altijd het eerste worden gemaakt en het laatste worden losgemaakt. Varoitus Laitetta asennettaessa on maahan yhdistäminen aina tehtävä ensiksi ja maadoituksen irti kytkeminen viimeiseksi.

  • Page 275: Dc Power Wiring Sequence Warning

    DC Power Wiring Sequence Warning...
  • Page 276 WARNING: Wire the DC power supply using the appropriate lugs. When connecting power, the proper wiring sequence is ground to ground, +RTN to +RTN, then –48 V to –48 V. When disconnecting power, the proper wiring sequence is –48 V to –48 V, +RTN to +RTN, then ground to ground.
  • Page 277 para moler. Observe que el alambre de tierra se debe conectar siempre primero y desconectar por último. Observe que el alambre de tierra se debe conectar siempre primero y desconectar por último. ¡Atención! Wire a fonte de alimentação de DC Usando os talões apropriados nan EXtremidade da fiação.

  • Page 278: Dc Power Wiring Terminations Warning

    DC Power Wiring Terminations Warning...
  • Page 279 WARNING: When stranded wiring is required, use approved wiring terminations, such as closed-loop or spade-type with upturned lugs. These terminations must be the appropriate size for the wires and must clamp both the insulation and conductor. Waarschuwing Wanneer geslagen bedrading vereist is, dient u bedrading te gebruiken die voorzien is van goedgekeurde aansluitingspunten, zoals het gesloten-lus type of het grijperschop type waarbij de aansluitpunten omhoog wijzen.
  • Page 280 conexión vueltas hacia arriba. Estos terminales deberán ser del tamaño apropiado para los cables que se utilicen, y tendrán que sujetar tanto el aislante como el conductor. Varning! När flertrådiga ledningar krävs måste godkända ledningskontakter användas, t.ex. kabelsko av sluten eller öppen typ med uppåtvänd tapp. Storleken på dessa kontakter måste vara avpassad till ledningarna och måste kunna hålla både isoleringen och ledaren fastklämda.

  • Page 281: Multiple Power Supplies Disconnection Warning

    Multiple Power Supplies Disconnection Warning WARNING: The network device has more than one power supply connection. All connections must be removed completely to remove power from the unit completely. Waarschuwing Deze eenheid heeft meer dan één stroomtoevoerverbinding; alle verbindingen moeten volledig worden verwijderd om de stroom van deze eenheid volledig te verwijderen.

  • Page 282: Tn Power Warning

    TN Power Warning WARNING: The device is designed to work with a TN power system. Waarschuwing Het apparaat is ontworpen om te functioneren met TN energiesystemen. Varoitus Koje on suunniteltu toimimaan TN-sähkövoimajärjestelmien yhteydessä. Attention Ce dispositif a été conçu pour fonctionner avec des systèmes d'alimentation Warnung Das Gerät ist für die Verwendung mit TN-Stromsystemen ausgelegt.
  • Page 283 PART Installation Before You Begin | 260 Installing a QFX5110 Switch | 262 Installing a QFX5100 Switch | 276 Installing a QFX3600 Switch | 298 Installing a QFX3500 Switch | 326 Installing an EX4300 Switch | 353 Performing the Initial Configuration | 368 Cabling a Virtual Chassis Fabric | 385...

  • Page 284: Before You Begin

    CHAPTER 21 Before You Begin IN THIS CHAPTER Virtual Chassis Fabric Installation Overview | 260 Virtual Chassis Fabric Installation Overview For best results, ensure you review and understand the Virtual Chassis Fabric (VCF) configuration options. These configuration options are explained in “Virtual Chassis Fabric Hardware Overview”...
  • Page 285 WARNING: Only configure operational-level commands. If you commit any configuration-level commands (including assigning IP address), the Virtual Chassis Fabric cannot form and the switch must be zeroed. 4. Configure the VCF into mixed mode if it is a QFX5100 VCF and the switch models span different lines of switches.

  • Page 286: Installing A Qfx5110 Switch

    CHAPTER 22 Installing a QFX5110 Switch IN THIS CHAPTER Standalone Installation Overview | 262 Unpacking a QFX5110 | 263 Mounting a QFX5110 in a Rack | 264 Connect the QFX5110 to Earth Ground | 267 Connecting AC Power to a QFX5110 | 268 Connecting DC Power to a QFX5110 | 271 Standalone Installation Overview You can mount a QFX5110:...

  • Page 287: Unpacking A Qfx5110

    c. Register Products—Mandatory for Validating SLAs 4. Follow the instructions in Configuring a QFX5110. Unpacking a QFX5110 The QFX5110 is a rigid sheet-metal structure that houses the hardware components. A QFX5110 is shipped in a cardboard carton, secured with foam packing material. The carton also contains an accessory box and a Documentation Roadmap card.

  • Page 288: Mounting A Qfx5110 In A Rack

    Table 68: Inventory of Components Supplied with a QFX5110 Component Quantity Chassis Fan modules Power supplies (650 W) JPSU-650W-AC-AFO JPSU-650W-AC-AFI JPSU-650W-DC-AFO JPSU-650W-DC-AFI AC systems ship with 2 country-specific C13 power cables. Four-post rack mount kit Front mounting rail with attached front flange Rear mounting blade with attached rear flange Extension brackets Flat head screws, 4-40...

  • Page 289: Before You Begin Rack Installation

    You can mount a QFX5110 on a four-post 19-in. rack using the mounting kit provided with the switch. This kit contains two front-mounting rails with two matching rear-mounting blades. This configuration allows either end of the switch to be mounted flush with the rack and still be adjustable for racks with different depths.
  • Page 290 RJ-45 cable and RJ-45 to DB-9 serial port adapter (provided). Management host, such as a PC laptop, with a serial port (not provided). Optional equipment: grounding cable kit with bracket, lug, and two screws and washers. CAUTION: All QFX5110 switches require two people for installation, one person to lift the switch into place and another person to attach the switch to the rack.

  • Page 291: Connect The Qfx5110 To Earth Ground

    Connect the QFX5110 to Earth Ground You must install the QFX5110 in a restricted-access location and ensure that the chassis is always properly grounded. The QFX5110 has a two-hole protective grounding terminal provided on the chassis. See Figure 62 on page 268.

  • Page 292: Connecting Ac Power To A Qfx5110

    3. Secure the grounding lug to the protective earthing terminal with two screws and washers. See Figure 62 on page 268 Figure 62: Connecting a Grounding Cable to a QFX5110 4. Dress the grounding cable and ensure that it does not touch or block access to other device components and that it does not drape where people could trip over it.
  • Page 293 CAUTION: Before you connect power to the switch, a licensed electrician must attach a cable lug to the grounding and power cables that you supply. A cable with an incorrectly attached lug can damage the switch (for example, by causing a short circuit).
  • Page 294 4. Connect each power supply to the power sources. Insert the coupler end of the power cord into the AC power cord inlet on the AC power supply faceplate. 5. Push the power cord retainer onto the power cord (see Figure 63 on page 270).

  • Page 295: Connecting Dc Power To A Qfx5110

    Connecting DC Power to a QFX5110 The QFX5110 is shipped from the factory with two 650 W power supplies. Each power supply is a hot-removable and hot-insertable field-replaceable unit (FRU) when the second power supply is installed and running. You can install replacement power supplies in the two slots next to the fan modules without powering off the switch or disrupting the switching function.
  • Page 296 Ensure that you have the following parts and tools available: DC power source cables (14–16 AWG) with ring lug (Molex 190700069 or equivalent) (not provided) Phillips (+) screwdriver, number 2 (not provided) Multimeter (not provided) To connect DC power to a QFX5110: 1.
  • Page 297 6. Remove the screws on the terminals using the screwdriver. Save the screws. WARNING: Ensure that the power cables do not block access to device components or drape where people can trip on them. 7. Connect each power supply to the power sources. Secure power source cables to the power supplies by screwing the ring lugs attached to the cables to the appropriate terminals by using the screw from the terminals (see Figure 64 on page 274...
  • Page 298 Figure 64: DC Power Supply Faceplate for a QFX5110 Shunt negative input terminals (+RTN) Protective earthing terminal — — Shunt positive input terminals (-48V) Fault LED — — Terminal block Output LED — — Ejector lever Input LED — — CAUTION: The V+ terminals are shunted internally together, as are the V- terminals.
  • Page 299 Figure 65: Securing Ring Lugs to the Terminals on the QFX5110 DC Power Supply 8. Replace the terminal block cover. 9. Close the input circuit breaker. NOTE: The switch powers on as soon as power is provided to the power supply. There is no power switch on the device.

  • Page 300: Installing A Qfx5100 Switch

    CHAPTER 23 Installing a QFX5100 Switch IN THIS CHAPTER QFX5100 Standalone Installation Overview | 276 Unpack a QFX5100 Device | 277 Mount a QFX5100 Device in a Rack or Cabinet | 279 Connecting Earth Ground to a QFX5100 Device | 284 Connecting AC Power to a QFX5100 Device | 285 Connecting DC Power to a QFX5100 Device | 288 Connecting a QFX Series Device to a Management Console | 293...

  • Page 301: Unpack A Qfx5100 Device

    “Connecting AC Power to a QFX5100 Device” on page 285 Connecting DC Power to a QFX5100 Device on page 288 c. Register Products—Mandatory for Validating SLAs 4. Depending on how you plan to use the QFX5100 device, do one of the following: If you are using the QFX5100 device as a standalone switch, follow the instructions in Configure a QFX5100 Device.
  • Page 302 1. Move the shipping carton to a staging area as close to the installation site as possible, but where you have enough room to remove the system components. 2. Position the carton so that the arrows are pointing up. 3. Open the top flaps on the shipping carton. 4.

  • Page 303: Mount A Qfx5100 Device In A Rack Or Cabinet

    RELATED DOCUMENTATION Mount a QFX5100 Device in a Rack or Cabinet | 279 QFX5100 Standalone Installation Overview | 276 Mount a QFX5100 Device in a Rack or Cabinet IN THIS SECTION Before You Begin Rack Installation | 279 Four-Post Procedure | 281 You can mount all QFX5100 switches on a four post 19-in.
  • Page 304 5. Remove the switch from the shipping carton (see “Unpack a QFX5100 Device” on page 277). 6. Ensure that you have the following parts and tools available to mount the switch in a rack: ESD grounding strap (not provided). Blades, rails, or brackets (provided). For four-post installations: One pair of rear mounting blades.

  • Page 305: Four-Post Procedure

    CAUTION: If you are mounting multiple switches on a rack, mount the switch in the lowest position of the rack first. Proceed to mount the rest of the switches from the bottom to the top of the rack to minimize the risk of the rack toppling. Four-Post Procedure To mount the switch on four posts in a rack using the provided mounting kit: 1.
  • Page 306 Figure 68: Attaching Mounting Rails to the QFX5100-96S 4. Attach the mounting rail to the switch using the mounting screws (and cage nuts and washers if your rack requires them). Tighten the screws. 5. Repeats steps 4 and 5 on the opposite side of the switch. 6.
  • Page 307 Figure 70: Slide Mounting Rail onto the QFX5100-96S Rear Mounting Blade 8. Continue to support the switch while sliding the rear mounting-blades into the channel of the side mounting-rails and securing the blades to the rack. Use the four mounting screws (and cage nuts and washers if your rack requires them) to attach each blade to the rack.

  • Page 308: Connecting Earth Ground To A Qfx5100 Device

    Connecting Earth Ground to a QFX5100 Device To meet safety and electromagnetic interference (EMI) requirements and to ensure proper operation, you must connect the QFX5100 device to earth ground before you connect it to power. For installations that require a separate grounding conductor to the chassis, you must attach a protective earthing terminal bracket on the QFX5100 device left front mounting bracket to connect to the earth ground (see Figure 72 on page...

  • Page 309: Connecting Ac Power To A Qfx5100 Device

    3. Secure the grounding lug to the protective earthing terminal with the washers and screws. See Figure 72 on page 285 Figure 73 on page 285. Figure 72: Connecting a Grounding Cable to a 1 U QFX5100 Device Figure 73: Connecting a Grounding Cable to the 2 U QFX5100-96S Device 4.
  • Page 310 You can install replacement power supplies in the two slots next to the fan modules without powering off the switch or disrupting the switching function. Ensure that you have a power cord appropriate for your geographical location available to connect AC power to the switch.
  • Page 311 3. Locate the power cord or cords shipped with the switch; the cords have plugs appropriate for your geographical location. See “AC Power Cord Specifications for a QFX Series Device” on page 154. WARNING: Ensure that the power cord does not block access to device components or drape where people can trip on it.

  • Page 312: Connecting Dc Power To A Qfx5100 Device

    7. Insert the power cord plug into an AC power source outlet. 8. If the AC power source outlet has a power switch, set it to the ON (|) position. 9. Verify that the AC and DC LEDs on each power supply are lit green. If the amber fault LED is lit, remove power from the power supply, and replace the power supply (see “Removing a Power Supply from a QFX5100 Device”...
  • Page 313 NOTE: The battery returns of the DC power supply must be connected as an isolated DC return (DC-I). Before you begin connecting DC power to the switch: Ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage (see “Prevention of Electrostatic Discharge Damage”...
  • Page 314 The cable with very high resistance (indicating an open circuit) to chassis ground is negative (–) and will be installed on the V– (input) DC power input terminal. CAUTION: You must ensure that power connections maintain the proper polarity. The power source cables might be labeled (+) and (–) to indicate their polarity. There is no standard color coding for DC power cables.
  • Page 315 The terminal block of the power supply has four terminals labeled V+, V+, V–, and V– for connecting DC power source cables labeled positive (+) and negative (–). The V+ terminals are shunted internally together, as are the V- terminals. CAUTION: The connection between each power source and power supply must include a circuit breaker.
  • Page 316 Figure 76: DC Power Supply Faceplate for a QFX5100 Device Shunt negative input terminals (-48V) ESD grounding point — — Shunt positive input terminals (+RTN) Fault LED — — Terminal block Output LED — — Ejector lever Input LED — —...

  • Page 317: Connecting A Qfx Series Device To A Management Console

    Figure 77: Securing Ring Lugs to the Terminals on the QFX5100 DC Power Supply 8. Replace the terminal block cover. 9. Close the input circuit breaker. NOTE: The switch powers on as soon as power is provided to the power supply. There is no power switch on the device.
  • Page 318 Ensure that you have an RJ-45 to DB-9 rollover cable available. An RJ-45 cable with an RJ-45 to DB-9 adapter is provided with the device. NOTE: If your laptop or PC does not have a DB-9 plug connector pin and you want to connect your laptop or PC directly to the QFX Series, use a combination of the RJ-45 cable and RJ-45 to DB-9 adapter supplied with the device and a USB to DB-9 plug adapter.

  • Page 319: Connecting A Qfx5100 Device In A Virtual Chassis Fabric

    Connecting a QFX5100 Device in a Virtual Chassis Fabric The role of a QFX5100 device in a VCF is dependant on the other switch models used in the VCF configuration. To understand the different hardware configurations supported, see “Virtual Chassis Fabric Hardware Overview”...

  • Page 320: Connecting A Qfx5100 Device To A Network For Out-Of-Band Management

    Figure 81: QFX5100-24Q as Spine and QFX5100-48S as Leaf Devices in a QFX5100 VCF RELATED DOCUMENTATION Virtual Chassis Fabric Hardware Overview | 8 Plan a Virtual Chassis Fabric Deployment | 87 Connecting QFX5110 in a QFX5110 Virtual Chassis Fabric | 385 Connecting a QFX5100 Device to a Network for Out-of-Band Management You can monitor and manage the QFX5100 device using a dedicated management channel.
  • Page 321 CAUTION: Configuring the two management interfaces within the same subnet is not supported. NOTE: You cannot use the management ports to perform the initial configuration of the QFX5100 device. You must configure the management ports before you can successfully connect to the QFX5100 switch using these ports.

  • Page 322: Installing A Qfx3600 Switch

    CHAPTER 24 Installing a QFX3600 Switch IN THIS CHAPTER Installing and Connecting a QFX3600 or QFX3600-I Device | 298 Unpacking a QFX3600 or QFX3600-I Device | 299 Mounting a QFX3600 or QFX3600-I Device on Two Posts in a Rack or Cabinet | 301 Mounting a QFX3600 or QFX3600-I Device on Four Posts in a Rack or Cabinet | 303 Connecting Earth Ground to QFX3600 or QFX3600-I Devices | 308 Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 309...

  • Page 323: Unpacking A Qfx3600 Or Qfx3600-I Device

    If you are using the QFX3600 device as a standalone switch, follow the instructions in Configuring a QFX3600 Device as a Standalone Switch. If you are using the QFX3600 device as a Node device in a QFX3000-G QFabric system, see QFX3000-G QFabric System Installation Overview for information about the steps to install and configure your QFX3000-G QFabric system.
  • Page 324 4. Remove the accessory box and verify the contents against the inventory included in the box. Table 70 on page 300 lists the inventory of components supplied with a QFX3600 or QFX3600-I device. 5. Pull out the packing material holding the device in place. 6.

  • Page 325: Mounting A Qfx3600 Or Qfx3600-I Device On Two Posts In A Rack Or Cabinet

    Installing and Connecting a QFX3600 or QFX3600-I Device | 298 Mounting a QFX3600 or QFX3600-I Device on Two Posts in a Rack or Cabinet You can mid-mount a QFX3600 or QFX3600-I device on two posts of a 19-in. rack or cabinet by using the mounting brackets provided with the device.
  • Page 326 NOTE: One person must be available to lift the device while another secures the device to the rack. CAUTION: If you are mounting multiple device on a rack, mount a device in the bottom of the rack first and proceed to mount the rest of the devices from bottom to top. To mount the device on two posts in a rack: 1.

  • Page 327: Mounting A Qfx3600 Or Qfx3600-I Device On Four Posts In A Rack Or Cabinet

    Figure 83: Mounting the Device on Two Posts in a Rack RELATED DOCUMENTATION Rack-Mounting and Cabinet-Mounting Warnings | 224 Connecting Earth Ground to QFX3600 or QFX3600-I Devices | 308 Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 309 Connecting DC Power to a QFX3500, QFX3600, or QFX3600-I Device | 312 Mounting a QFX3600 or QFX3600-I Device on Four Posts in a Rack or Cabinet...
  • Page 328 Ensure you understand how to prevent electrostatic discharge (ESD) damage. See “Prevention of Electrostatic Discharge Damage” on page 242. Verify that the site meets the requirements described in “Site Preparation Checklist for a QFX3600 or QFX3600-I Device” on page Place the rack in its permanent location, allowing adequate clearance for airflow and maintenance, and secure it to the building structure.
  • Page 329 1. Attach the ESD grounding strap to your bare wrist and to a site ESD point. 2. Decide where to position the device in the rack. 3. Install the rear installation blades. See Figure 84 on page 305. a. With two mounting screws—and cage nuts and washers if your rack requires them—attach one of the rear installation blades to the left rear of the rack at the point where you want to mount the device.
  • Page 330 a. Grasp both sides of the device, lift it, and position it in the rack so that the rear of the chassis slides onto the installation blade. See Figure 85 on page 306. TIP: If someone is assisting you, have one person stand at the rear of the rack where the installation blade is installed, to help guide the device onto the installation blade.
  • Page 331 RELATED DOCUMENTATION Rack-Mounting and Cabinet-Mounting Warnings | 224 Connecting Earth Ground to QFX3600 or QFX3600-I Devices | 308 Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 309 Connecting DC Power to a QFX3500, QFX3600, or QFX3600-I Device | 312 Configuring a QFX3600 Device as a Standalone Switch...

  • Page 332: Connecting Earth Ground To Qfx3600 Or Qfx3600-I Devices

    Connecting Earth Ground to QFX3600 or QFX3600-I Devices To meet safety and electromagnetic interference (EMI) requirements and to ensure proper operation, you must connect the QFX3600 and QFX3600-I devices to earth ground before you connect it to power. For installations that require a separate grounding conductor to the chassis, use the protective earthing terminal on the left rear of the chassis to connect to the earth ground (see Figure 86 on page 309).

  • Page 333: Connecting Ac Power To A Qfx3500, Qfx3600, Or Qfx3600-I Device

    3. Secure the grounding lug to the protective earthing terminal with screws. 4. Dress the grounding cable and ensure that it does not touch or block access to other switch components and that it does not drape where people could trip over it. Figure 86: Connecting a Grounding Cable to a QFX3600 or QFX3600-I Device RELATED DOCUMENTATION General Safety Guidelines and Warnings | 203...
  • Page 334 CAUTION: Before you connect power to the device, a licensed electrician must attach a cable lug to the grounding and power cables that you supply. A cable with an incorrectly attached lug can damage the device (for example, by causing a short circuit).
  • Page 335 4. Connect each power supply to the power sources. Insert the coupler end of the power cord into the AC power cord inlet on the AC power supply faceplate. 5. Push the power cord retainer onto the power cord (see Figure 87 on page 311 Figure 88 on page 311).

  • Page 336: Connecting Dc Power To A Qfx3500, Qfx3600, Or Qfx3600-I Device

    replacement power supply ready: the power supplies or a blank cover panel must be installed in the device to ensure proper airflow. CAUTION: Replace a failed power supply with a blank panel or new power supply within 1 minute of removal to prevent chassis overheating. RELATED DOCUMENTATION AC Power Supply for a QFX3500, QFX3600, or QFX3600-I Device AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 523...
  • Page 337 CAUTION: Before you connect power to the device, a licensed electrician must attach a cable lug to the grounding and power cables that you supply. A cable with an incorrectly attached lug can damage the device (for example, by causing a short circuit).
  • Page 338 CAUTION: You must ensure that power connections maintain the proper polarity. The power source cables might be labeled (+) and (–) to indicate their polarity. There is no standard color coding for DC power cables. The color coding used by the external DC power source at your site determines the color coding for the leads on the power cables that attach to the DC power input terminals on each power supply.
  • Page 339 CAUTION: The DC power supply has four terminals labeled V+, V+, V–, and V– for connecting DC power source cables labeled positive (+) and negative (–). The V+ terminals are shunted internally together, as are the V- terminals. The same polarity terminal can be wired together from the same source to provide an additional current path in a higher power chassis.
  • Page 340 Figure 89: DC Power Supply Faceplate for a QFX3500, QFX3600 or QFX3600-I Device Shunt positive input terminals ESD grounding point — — Shunt negative input terminals Fault LED — — Terminal block Output LED — — Ejector lever Input LED —...

  • Page 341: Connecting A Qfx Series Device To A Management Console

    Figure 90: Securing Ring Lugs to the Terminals on the QFX3500, QFX3600 or QFX3600-I DC Power Supply 8. Replace the terminal block cover. 9. Close the input circuit breaker. NOTE: The device powers on as soon as power is provided to the power supply. There is no power switch on the device.
  • Page 342 NOTE: If your laptop or PC does not have a DB-9 plug connector pin and you want to connect your laptop or PC directly to the QFX Series, use a combination of the RJ-45 cable and RJ-45 to DB-9 adapter supplied with the device and a USB to DB-9 plug adapter. You must provide the USB to DB-9 plug adapter.

  • Page 343: Connecting Qfx Series And Ex Series Switches In A Qfx Virtual Chassis

    Connecting QFX Series and EX Series Switches in a QFX Virtual Chassis IN THIS SECTION Before You Start | 319 Valid Configurations | 320 Cabling QFX3500 Switches in a QFX5100 Virtual Chassis | 321 Cabling QFX3600 Switches in a QFX Virtual Chassis | 322 Cabling a Mixed QFX Virtual Chassis | 323 In a QFX Virtual Chassis, you can connect up to 10 standalone QFX5100, QFX3600, QFX3500, and EX4300 switches except EX4300-48MP and EX4300-48MP-S switches into a QFX Series Virtual Chassis and...

  • Page 344: Valid Configurations

    In EX4300-48MP and EX4300-48MP-S switches, you can use only the built-in QSFP+ ports as VCPs. You cannot configure the ports on the uplink module in EX4300-48MP and EX4300-48MP-S switches to Virtual Chassis ports (VCPs). On QFX3500 and QFX3600, all non-channelized QSFP+ and fixed SFP+ interfaces. BEST PRACTICE: Use the 40-Gigabit QSFP+ interfaces for the VCPs.

  • Page 345: Cabling Qfx3500 Switches In A Qfx5100 Virtual Chassis

    An all EX4300 member is simply considered an EX4300 Virtual Chassis (see Understanding EX Series Virtual Chassis). If the QSFP+ interfaces are not available for VCP, 10-Gigbit interfaces can be used. All members of the Virtual Chassis are required to run the same Junos OS Release. You can check the version and release by issuing the show chassis version CLI command.

  • Page 346: Cabling Qfx3600 Switches In A Qfx Virtual Chassis

    Figure 94: QFX3500 Using the 10G Ports as the VCPs 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45...

  • Page 347: Cabling A Mixed Qfx Virtual Chassis

    Figure 95: QFX3600 Using the 40G Ports as the VCPs QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S Cabling a Mixed QFX Virtual Chassis...
  • Page 348 Figure 97: QFX3500 and QFX3600 Mixed Using Both 40G Ports and 10G Ports as the VCPs 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39...

  • Page 349: Connect A Device To A Network For Out-Of-Band Management

    Understanding QFX Series Virtual Chassis Connecting QFX5110 and QFX5100 Members in a QFX5110 Virtual Chassis Adding a New Switch to an Existing EX4650 or QFX Series Virtual Chassis Connecting a QFX5100 Device in a Virtual Chassis Fabric | 295 Connect a Device to a Network for Out-of-Band Management You can monitor and manage these devices by using a dedicated management channel.

  • Page 350: Installing A Qfx3500 Switch

    CHAPTER 25 Installing a QFX3500 Switch IN THIS CHAPTER Installing and Connecting a QFX3500 Device | 326 Unpacking a QFX3500 Device | 327 Mounting a QFX3500 Device in a Rack or Cabinet | 328 Connecting Earth Ground to a QFX3500 Device | 334 Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 336 Connecting DC Power to a QFX3500, QFX3600, or QFX3600-I Device | 338 Connecting a QFX Series Device to a Management Console | 343...

  • Page 351: Unpacking A Qfx3500 Device

    If you are using the QFX3500 device as a Node device in a QFX3000-G QFabric system, see QFX3000-G QFabric System Installation Overview for information about the steps to install and configure your QFX3000-G QFabric system. If you are using the QFX3500 device as a Node device in a QFX3000-M QFabric system, see QFX3000-M QFabric System Installation Overview for information about the steps to install and configure your QFX3000-M QFabric system.

  • Page 352: Mounting A Qfx3500 Device In A Rack Or Cabinet

    6. Verify the chassis components received: Management board Two fan trays One or two power supplies, depending on your order. If only one power supply is installed, a blank panel should be installed on the second power supply slot. 7. Save the shipping carton and packing materials in case you need to move or ship the device later. Table 71: Inventory of Components Supplied with a QFX3500 Device Component Quantity...

  • Page 353: Before You Begin Rack Installation

    Before you begin mounting a QFX3500 device in the rack or cabinet: If replacing an existing QFX3500, remove previous rack-mount hardware. The mounting bracket and mounting blade in this procedure is not compatible with other Juniper mounting kits. Ensure that you understand how to prevent electrostatic discharge (ESD) damage. See “Prevention of...

  • Page 354: Two Mounting Rails Procedure

    WARNING: The QFX3500 device must be supported at all four corners. Mounting the chassis using only the front brackets will damage the chassis and can result in serious bodily injury. CAUTION: If you are installing the QFX3500 device above 60 in. (152.4 cm) from the floor, you must remove the power supplies, fan trays, and management board before attempting to install the device, or ask someone to assist you during the installation.
  • Page 355 3. Grasp both sides of the device, lift it, and position it in the rack so that the blade receptacle at the rear of the chassis catches and slides onto the installation blade. See Figure 102 on page 331. TIP: If someone is assisting you, have one person stand at the rear of the rack where the installation blade is installed, to help guide the device onto the installation blade.

  • Page 356: Four Mounting Rails Procedure

    Four Mounting Rails Procedure To mount the device on four posts in a rack using a four -rail kit: 1. Attach the ESD grounding strap to your bare wrist and to a site ESD point. 2. Decide whether the management end of the device or the ports are to be placed at the front of the rack.
  • Page 357 Figure 104: Slide Mounting Rail onto the Rear Mounting Blade 8. Align the holes in the mounting brackets with the holes in the rack. Ensure that the chassis is level. 9. With four front mounting screws–and cage nuts and washers if your rack requires them–attach the mounting bracket to the rack.

  • Page 358: Connecting Earth Ground To A Qfx3500 Device

    Connecting Earth Ground to a QFX3500 Device To meet safety and electromagnetic interference (EMI) requirements and to ensure proper operation, you must connect the QFX3500 device to earth ground before you connect it to power. For installations that require a separate grounding conductor to the chassis, you must attach a protective earthing terminal bracket on the QFX3500 device left front mounting bracket to connect to the earth ground (see Figure 105 on page...
  • Page 359 1. Secure the provided protective earthing terminal bracket to the threaded post on the QFX3500 device left front mounting bracket with the nut provided. The posts on the protective earthing terminal bracket should point to the left. See Figure 105 on page 335.

  • Page 360: Connecting Ac Power To A Qfx3500, Qfx3600, Or Qfx3600-I Device

    Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device The QFX3500, QFX3600, and QFX3600-I devices are shipped from the factory with two 650 W power supplies pre-installed. Each power supply is a hot-removable and hot-insertable field-replaceable unit (FRU) when the second power supply is installed and running. You can install replacement power supplies without powering off the device or disrupting the switching function.
  • Page 361 1. Attach the grounding strap to your bare wrist and to a site ESD point. 2. Ensure that the power supplies are fully inserted in the chassis and the latches are secure. If only one power supply is installed, ensure a that blank cover panel is installed over the second power supply slot.

  • Page 362: Connecting Dc Power To A Qfx3500, Qfx3600, Or Qfx3600-I Device

    NOTE: The device powers on as soon as power is provided to the power supply. There is no power switch on the device. 7. Insert the power cord plug into an AC power source outlet. 8. If the AC power source outlet has a power switch, set it to the ON (|) position. 9.
  • Page 363 NOTE: The battery returns of the DC power supply should be connected as an isolated DC return (DC-I). Before you begin connecting DC power to the device: Ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage (see “Prevention of Electrostatic Discharge Damage”...
  • Page 364 plant, you can use a multimeter to verify the resistance of the –48V and RTN DC cables to chassis ground: The cable with very low resistance (indicating a closed circuit) to chassis ground is positive (+) and will be installed on the V+ (return) DC power input terminal. The cable with very high resistance (indicating an open circuit) to chassis ground is negative (–) and will be installed on the V–...
  • Page 365 CAUTION: The DC power supply has four terminals labeled V+, V+, V–, and V– for connecting DC power source cables labeled positive (+) and negative (–). The V+ terminals are shunted internally together, as are the V- terminals. The same polarity terminal can be wired together from the same source to provide an additional current path in a higher power chassis.
  • Page 366 Figure 108: DC Power Supply Faceplate for a QFX3500, QFX3600 or QFX3600-I Device Shunt positive input terminals ESD grounding point — — Shunt negative input terminals Fault LED — — Terminal block Output LED — — Ejector lever Input LED —...

  • Page 367: Connecting A Qfx Series Device To A Management Console

    Figure 109: Securing Ring Lugs to the Terminals on the QFX3500, QFX3600 or QFX3600-I DC Power Supply 8. Replace the terminal block cover. 9. Close the input circuit breaker. NOTE: The device powers on as soon as power is provided to the power supply. There is no power switch on the device.
  • Page 368 NOTE: If your laptop or PC does not have a DB-9 plug connector pin and you want to connect your laptop or PC directly to the QFX Series, use a combination of the RJ-45 cable and RJ-45 to DB-9 adapter supplied with the device and a USB to DB-9 plug adapter. You must provide the USB to DB-9 plug adapter.

  • Page 369: Connecting Qfx Series And Ex Series Switches In A Qfx Virtual Chassis

    Connecting QFX Series and EX Series Switches in a QFX Virtual Chassis IN THIS SECTION Before You Start | 345 Valid Configurations | 346 Cabling QFX3500 Switches in a QFX5100 Virtual Chassis | 347 Cabling QFX3600 Switches in a QFX Virtual Chassis | 348 Cabling a Mixed QFX Virtual Chassis | 349 In a QFX Virtual Chassis, you can connect up to 10 standalone QFX5100, QFX3600, QFX3500, and EX4300 switches except EX4300-48MP and EX4300-48MP-S switches into a QFX Series Virtual Chassis and...

  • Page 370: Valid Configurations

    In EX4300-48MP and EX4300-48MP-S switches, you can use only the built-in QSFP+ ports as VCPs. You cannot configure the ports on the uplink module in EX4300-48MP and EX4300-48MP-S switches to Virtual Chassis ports (VCPs). On QFX3500 and QFX3600, all non-channelized QSFP+ and fixed SFP+ interfaces. BEST PRACTICE: Use the 40-Gigabit QSFP+ interfaces for the VCPs.

  • Page 371: Cabling Qfx3500 Switches In A Qfx5100 Virtual Chassis

    An all EX4300 member is simply considered an EX4300 Virtual Chassis (see Understanding EX Series Virtual Chassis). If the QSFP+ interfaces are not available for VCP, 10-Gigbit interfaces can be used. All members of the Virtual Chassis are required to run the same Junos OS Release. You can check the version and release by issuing the show chassis version CLI command.

  • Page 372: Cabling Qfx3600 Switches In A Qfx Virtual Chassis

    Figure 113: QFX3500 Using the 10G Ports as the VCPs 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45...

  • Page 373: Cabling A Mixed Qfx Virtual Chassis

    Figure 114: QFX3600 Using the 40G Ports as the VCPs QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S QFX3600-16Q C0 S OK / C1 S Cabling a Mixed QFX Virtual Chassis...
  • Page 374 Figure 116: QFX3500 and QFX3600 Mixed Using Both 40G Ports and 10G Ports as the VCPs 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39...

  • Page 375: Connecting A Qfx3500 Device To A Network For Out-Of-Band Management

    Understanding QFX Series Virtual Chassis Connecting QFX5110 and QFX5100 Members in a QFX5110 Virtual Chassis Adding a New Switch to an Existing EX4650 or QFX Series Virtual Chassis Connecting a QFX5100 Device in a Virtual Chassis Fabric | 295 Connecting a QFX3500 Device to a Network for Out-of-Band Management If you are using the QFX3500 device as a standalone switch, you can monitor and manage the QFX3500 device using a dedicated management channel.
  • Page 376 Figure 118: Connecting a QFX3500 Device to a Network for Out-of-Band Management Management PC Management Network MGMT Management PC To Management Port (on Device) Management PC RELATED DOCUMENTATION Management Board for a QFX3500 Device Management Port Connector Pinouts for the QFX Series | 132 Connecting a QFX Series Device to a Management Console | 293...

  • Page 377: Installing An Ex4300 Switch

    CHAPTER 26 Installing an EX4300 Switch IN THIS CHAPTER Installing and Connecting an EX4300 Switch | 353 Unpacking an EX4300 Switch | 354 Mounting an EX4300 Switch | 355 Mounting an EX4300 Switch on Two Posts of a Rack or Cabinet | 356 Mounting an EX4300 Switch on Four Posts of a Rack or Cabinet | 359 Mounting an EX4300 Switch in a Recessed Position in a Rack or Cabinet | 363 Mounting an EX4300 Switch on a Wall | 363...

  • Page 378: Unpacking An Ex4300 Switch

    “Mounting an EX4300 Switch on Four Posts of a Rack or Cabinet” on page 359 (by using the separately orderable four-post rack-mount kit) “Mounting an EX4300 Switch on a Wall” on page 363 (by using the separately orderable wall-mount kit) 5.

  • Page 379: Mounting An Ex4300 Switch

    To unpack the switch: 1. Move the shipping carton to a staging area as close to the installation site as possible, but where you have enough room to remove the system components. 2. Position the carton so that the arrows are pointing up. 3.

  • Page 380: Mounting An Ex4300 Switch On Two Posts Of A Rack Or Cabinet

    Mounting an EX4300 Switch on Four Posts of a Rack or Cabinet | 359 Mounting an EX4300 Switch on a Wall | 363 Connect Earth Ground to an EX Series Switch Mounting an EX4300 Switch on Two Posts of a Rack or Cabinet You can mount an EX4300 switch on two posts of a 19-in.
  • Page 381 NOTE: One person must be available to lift the switch while another secures the switch to the rack. CAUTION: If you are mounting multiple switches on a rack, mount a switch in the bottom of the rack first and proceed to mount the rest of the switches from bottom to top.
  • Page 382 Figure 121: Mounting Bracket Attached to the Side Panel of EX4300-48MP and EX4300-48MP-S Switches 3. Align the bottom holes in the mounting brackets with the holes on the side panels of the switch chassis. 4. Insert mounting screws into the aligned holes. Tighten the screws by using the Phillips (+) screwdriver. 5.

  • Page 383: Mounting An Ex4300 Switch On Four Posts Of A Rack Or Cabinet

    7. Have a second person secure the switch to the rack by using the appropriate screws. Tighten the screws. 8. Ensure that the switch chassis is level by verifying that all screws on one side of the rack are aligned with the screws on the other side.
  • Page 384 NOTE: To ensure that the protective earthing terminal is accessible through the opening in the rear mounting-blade: Ensure that the rack is 27.5 in. (70 cm) through 30.5 in. (77.5 cm) deep if you are mounting the switch flush with the rack front on four posts of a rack. Ensure that the rack is 29.5 in.
  • Page 385 CAUTION: If you are mounting multiple units on a rack, mount the heaviest unit at the bottom of the rack and mount the other units from the bottom of the rack to the top in decreasing order of the weight of the units. To mount the switch on four posts of a rack: 1.
  • Page 386 Figure 124: Mounting the Switch on Front Posts of a Rack 6. Have a second person secure the front of the switch to the rack by using the appropriate screws for your rack. 7. Slide the rear mounting-blades into the side mounting-rails. See Figure 125 on page 362.

  • Page 387: Mounting An Ex4300 Switch In A Recessed Position In A Rack Or Cabinet

    Rack-Mounting and Cabinet-Mounting Warnings | 224 Mounting an EX4300 Switch in a Recessed Position in a Rack or Cabinet You can mount an EX4300 switch in a recessed position on two posts of either a two-post rack or a four-post rack such that the switch is recessed inside the rack from the rack front by 2 inches. To mount the switch in a recessed position, use the front-mounting brackets provided in the separately orderable four-post rack-mount kit.
  • Page 388 Phillips (+) screwdriver, number 2 (not provided) 2 wall-mount brackets (provided with the wall-mount kit) 12 wall-mount bracket screws (provided with the wall-mount kit) 4 mounting screws (8-32 x 1.25 in. or M4 x 30 mm) (not provided) Cover panels for uplink module and power supply slots (provided) Hollow wall anchors capable of supporting the combined weight of two fully loaded switches, up to 33 lb (15 kg) (not included)—if you are mounting the switch in sheetrock (wall board with a gypsum plaster core) or in wall board not backed by wall studs.
  • Page 389 To mount the switch on a wall: 1. Attach the wall-mount brackets to the sides of the chassis by using four of the wall-mount bracket screws on each side (see the representation in Figure 126 on page 365). Use the screwdriver to tighten the screws.
  • Page 390 Figure 127: Mounting the Switch on a Wall Rear panel Hang attached brackets on wall-mounted screws. Front panel Figure 128: Measurements for Mounting EX4300-48MP and EX4300-48MP-S Switches on a Wall with the Front Panel Pointing to the Right Side FRUs Ports 18.67 in.
  • Page 391 Figure 129: Mounting EX4300-48MP and EX4300-48MP-S Switches on a Wall with the Front Panel Pointing to the Left Side FRUs Ports 18.67 in. (47.42 cm) 1.76 in. 5.98 in. (4.47 cm) (15.2 cm) 5. Tighten the mounting screws by using the screwdriver. RELATED DOCUMENTATION Wall-Mounting Warning for EX4300 Switches | 239...

  • Page 392: Performing The Initial Configuration

    CHAPTER 27 Performing the Initial Configuration IN THIS CHAPTER Autoprovisioning a Virtual Chassis Fabric | 368 Preprovisioning a Virtual Chassis Fabric | 373 Configuring a Nonprovisioned Virtual Chassis Fabric | 380 Autoprovisioning a Virtual Chassis Fabric Autoprovisioning a Virtual Chassis Fabric (VCF) enables you to “plug and play” devices into your VCF after minimal initial configuration.
  • Page 393 Update all devices to the same version of Junos OS that supports VCF. See Installing Software Packages on QFX Series Devices or Installing Software on an EX Series Switch with a Virtual Chassis or Single Routing Engine (CLI Procedure). CAUTION: QFX5100 switches running a Junos OS image that includes “-qfx-5-”...
  • Page 394 NOTE: A spine device whose fabric and mixed mode settings are improperly set will not properly join a mixed VCF. You can check the mode settings by using the show virtual-chassis mode command. We recommend that you set the fabric and mixed mode settings before you interconnect your spine devices into the VCF to avoid the following issues: Incurring downtime during VCF formation as the devices reboot to commit the fabric or mixed mode settings.
  • Page 395 Keep in mind that any member devices you configure into the Routing Engine role participate in the primary-role election process (see Master Routing Engine Election Process). The VCF will elect one primary and one backup member from the devices configured into this role. Member devices that are not in Routing Engine role are not eligible for primary-role election.
  • Page 396 For a VCF deployment, we recommend having two license keys for redundancy—one for the device in the primary Routing Engine role and the other for the device in the backup Routing Engine role. To purchase a feature license for VCF, contact your Juniper Networks sales representative (https://www.juniper.net/us/en/contact-us/sales-offices). The Juniper sales representative will provide you with the feature license files and license keys.

  • Page 397: Preprovisioning A Virtual Chassis Fabric

    [edit virtual-chassis] user@device# set member 0 fabric-tree-root user@device# set member 1 fabric-tree-root user@device# set member 4 fabric-tree-root user@device# set member 5 fabric-tree-root NOTE: This option can also be configured anytime later during VCF operation if you observe internal VCF multicast traffic flow issues with default MDTs. RELATED DOCUMENTATION Understanding Virtual Chassis Fabric Configuration | 4 Adding a Device to a Virtual Chassis Fabric | 394...
  • Page 398 CAUTION: QFX5100 switches running a Junos OS image that includes “-qfx-5-” in the software package filename must be upgraded to a package filename that includes “-qfx-5e-” before being added to a QFX5110 Virtual Chassis or VCF. See Upgrading a QFX5100 Switch with a USB Device to Join a QFX5110 Virtual Chassis or Virtual Chassis Fabric.
  • Page 399 NOTE: A device whose fabric and mixed mode settings are improperly set will not properly join a mixed VCF. You can check the mode settings using the show virtual-chassis mode command. We recommend that you set the fabric and mixed mode before you interconnect your devices into a VCF to avoid the following issues: Incurring downtime during VCF formation as the devices reboot to commit the fabric or mixed mode settings.
  • Page 400 For instance, if you wanted to preprovision a VCF with twenty member devices that uses member 0 and 1 in the Routing Engine role, members 2 and 3 as spine devices in the line card role, and the remaining devices as leaf devices: [edit virtual-chassis] user@device# set member 0 serial-number SERIALNUMB00 role routing-engine user@device# set member 1 serial-number SERIALNUMB01 role routing-engine...
  • Page 401 8. (Optional) The VCF forwards broadcast, unknown unicast, and multicast (BUM) traffic among the members of the VCF using multicast distribution trees (MDTs). By default, the VCF creates MDTs for every member of the VCF with that member as the root node of an MDT. If this default MDT creation method is not optimal for your installation, you can control which members become MDT root nodes.
  • Page 402 NOTE: Automatic VCP conversion only works when the interfaces on both ends of a link are not already configured as VCPs. This step is needed on EX4300 switches using 40-Gbps QSFP+ interfaces as VCPs because the 40-Gbps QSFP+ interfaces on EX4300 switches are configured as VCPs by default. If you are cabling the EX4300 switch to the spine switch with a DAC cable in the 40-Gbps QSFP+ interface, you must use the request virtual-chassis vc-port set command to manually convert the 40-Gbps QSFP+ interface on the spine device into a VCP, as described in the...
  • Page 403 For a VCF deployment, two license keys are recommended for redundancy—one for the device in the primary Routing Engine role and the other for the device in the backup Routing Engine role. To purchase a feature license for VCF, contact your Juniper Networks sales representative (https://www.juniper.net/us/en/contact-us/sales-offices). The Juniper sales representative will provide you with the feature license files and license keys.

  • Page 404: Configuring A Nonprovisioned Virtual Chassis Fabric

    Configuring a Nonprovisioned Virtual Chassis Fabric CAUTION: Configure your Virtual Chassis Fabric (VCF) using autoprovisioning or preprovisioning unless you have a compelling reason to use nonprovisioned configuration. You can configure all aspects of a VCF using autoprovisioned or preprovisioned configuration. The process for autoprovisioning your VCF is described “Autoprovisioning a Virtual Chassis Fabric”...
  • Page 405 If you are configuring a non-mixed VCF: user@device> request virtual-chassis mode fabric local reboot If you are configuring a mixed mode VCF: user@device> request virtual-chassis mode fabric mixed local reboot NOTE: A device whose fabric or mixed mode setting is improperly set cannot join a mixed VCF.
  • Page 406 user@device> request virtual-chassis vc-port set pic-slot pic-slot-number port port-number user@device> request virtual-chassis vc-port set pic-slot pic-slot-number port port-number The show virtual-chassis vc-port must be issued on the ports at both ends of the link in order for that link to be configured into a VCP link. 6.
  • Page 407 For a VCF deployment, two license keys are recommended for redundancy—one for the device in the primary Routing Engine role and the other for the device in the backup Routing Engine role. To purchase a feature license for VCF, contact your Juniper Networks sales representative (https://www.juniper.net/us/en/contact-us/sales-offices). The Juniper sales representative will provide you with the feature license files and license keys.
  • Page 408 Understanding Virtual Chassis Fabric Configuration | 4 Understanding Virtual Chassis Fabric Components...

  • Page 409: Cabling A Virtual Chassis Fabric

    Connecting EX Series Switches in a QFX5100 Virtual Chassis Fabric | 391 Connecting QFX5110 in a QFX5110 Virtual Chassis Fabric A Juniper Networks QFX5110 Virtual Chassis Fabric (VCF) is constructed using a spine-and-leaf architecture and topology. In the spine-and-leaf architecture, each spine device is interconnected to each leaf device.
  • Page 410 Figure 130: All QFX5110 VCF Figure 131: QFX5110 VCF with QFX5100-24Q Leaf Devices...

  • Page 411: Connecting A Qfx5100 Device In A Virtual Chassis Fabric

    RELATED DOCUMENTATION Virtual Chassis Fabric Hardware Overview | 8 Plan a Virtual Chassis Fabric Deployment | 87 Connecting a QFX5100 Device in a Virtual Chassis Fabric The role of a QFX5100 device in a VCF is dependant on the other switch models used in the VCF configuration.
  • Page 412 Figure 132: QFX5100-24Q as a Leaf Device in a QFX5110 VCF...

  • Page 413: Connecting A Qfx3500 Or Qfx3600 Switch In A Qfx5100 Virtual Chassis Fabric

    Connecting a QFX3500 or QFX3600 Switch in a QFX5100 Virtual Chassis Fabric A Juniper Networks QFX5100 Virtual Chassis Fabric (VCF) is constructed using a spine-and-leaf architecture and topology. In the spine-and-leaf architecture, each spine device is interconnected to each leaf device.
  • Page 414 or QFX3600 devices are supported in the leaf role in a QFX5100 VCF. To understand the different hardware configurations supported, see “Virtual Chassis Fabric Hardware Overview” on page Although the best practice is to use all QFX5100 switches in a QFX5100 VCF, you can use QFX3500 or QFX3600 switches as leaf devices.

  • Page 415: Connecting Ex Series Switches In A Qfx5100 Virtual Chassis Fabric

    Site Preparation Checklist for EX4300 Switches | 97 Connecting EX Series Switches in a QFX5100 Virtual Chassis Fabric A Juniper Networks QFX5100 Virtual Chassis Fabric (VCF) is constructed using a spine-and-leaf architecture and topology. In the spine-and-leaf architecture, each spine device is interconnected to each leaf device.
  • Page 416 Figure 135: Mixed Mode QFX5100 VCF with an EX4300 Leaf RELATED DOCUMENTATION Virtual Chassis Fabric Overview | 2 Understanding Virtual Chassis Fabric Components Understanding EX Series Virtual Chassis...

  • Page 417: Maintenance

    PART Maintenance Removing or Replacing a Device | 394 Replacing QFX5110 Components | 422 Replacing QFX5100 Components | 429 Replacing QFX3600 Components | 444 Replacing QFX3500 Components | 452 Replacing EX4300 Components | 464 Replacing Transceivers and Fiber-Optic Cables | 476 Routine Maintenance | 491 Viewing QFX5110 System Information | 493 Viewing QFX5100 System Information | 505...

  • Page 418: Removing Or Replacing A Device

    CHAPTER 29 Removing or Replacing a Device IN THIS CHAPTER Adding a Device to a Virtual Chassis Fabric | 394 Removing a Device From a Virtual Chassis Fabric | 405 Powering Off a QFX5110 | 406 Powering Off a QFX5100 Device | 409 Powering Off a QFX3600 Device | 412 Powering Off a QFX3500 Device | 414 Removing a QFX5110 from a Rack | 416...

  • Page 419: Adding A Leaf Device To An Autoprovisioned Virtual Chassis Fabric

    devices in the VCF. See Installing Software Packages on QFX Series Devices or Installing Software on an EX Series Switch with a Virtual Chassis or Single Routing Engine (CLI Procedure). Then follow the applicable procedure to add the device based on how your VCF is configured. CAUTION: QFX5100 switches running a Junos OS image that includes “-qfx-5-”...
  • Page 420 If your device has been configured previously, zeroize your device and reboot: user@device> request system zeroize warning: System will be rebooted and may not boot without configuration Erase all data, including configuration and log files? [yes,no] (yes) yes NOTE: You must zeroize your device if you have previously entered one or more configuration commands, including basic configuration commands.

  • Page 421: Adding A Spine Device To An Autoprovisioned Virtual Chassis Fabric

    BEST PRACTICE: When adding a leaf device to an existing VCF, interconnect the new device to the spine member that is in the primary Routing Engine role first, which is the most efficient way to synchronize the new member with the current VCF configuration and state. Interconnecting a new member only to the backup or another spine member can cause flooding of messages within the VCF as the primary tries to synchronize the new member through other leaf and spine member VCP links.
  • Page 422 [edit virtual-chassis] user@device# set member 3 serial-number OU81234567890 role line-card The set virtual-chassis member member-id fabric-tree-root configuration statement specifies that only certain devices will be root nodes in the multicast distribution trees (MDTs) created for directing traffic within the VCF. This configuration item preempts the default VCF behavior to create one MDT for every device in the VCF with that device as a root node.

  • Page 423: Adding A Spine Or Leaf Device To A Preprovisioned Virtual Chassis Fabric

    NOTE: We recommend setting the fabric and mixed mode settings before interconnecting your devices into a VCF to avoid the following issues: Incurring downtime as the devices reboot to commit the mixed mode or fabric settings. Manually correcting potential issues related to VCF formation because the device did not immediately join the VCF.
  • Page 424 user@device# delete member member-id where member-id is the member ID of the device that is removed in this procedure. Add the new device to the VCF configuration: [edit virtual-chassis] user@device# set member member-id serial-number serial-number role [line-card | routing-engine] For instance, to configure a device with the serial number OU81234567890 into the Routine Engine role as member 3: [edit virtual-chassis] user@device# set member 3 serial-number OU81234567890 role routing-engine...
  • Page 425 user@device> request virtual-chassis mode fabric mixed local reboot NOTE: If you are adding a device that turns a non-mixed VCF into a mixed VCF, as the next step, you must also log in to the VCF and set all of the devices in the VCF into mixed mode. This step requires a VCF reboot, which incurs some downtime.

  • Page 426: Adding A Spine Or Leaf Device To A Nonprovisioned Virtual Chassis Fabric

    BEST PRACTICE: When adding a leaf device to an existing VCF, interconnect the new device to the spine member that is in the primary Routing Engine role first, which is the most efficient way to synchronize the new member with the current VCF configuration and state. Interconnecting a new member only to the backup or another spine member can cause flooding of messages within the VCF as the primary tries to synchronize the new member through other leaf and spine member VCP links.
  • Page 427 Reboot the device to complete this configuration step. If you are configuring a non-mixed VCF: user@device> request virtual-chassis mode fabric local reboot If you are configuring a mixed mode VCF: user@device> request virtual-chassis mode fabric mixed local reboot NOTE: If you are adding a device that turns a non-mixed VCF into a mixed VCF, you must also log in to the VCF and set all of the devices in the VCF into mixed mode.
  • Page 428 user@device> request virtual-chassis vc-port set pic-slot pic-slot-number port port-number The request virtual-chassis vc-port must be configured on the ports at both ends of the link in order for that link to be configured into a VCP. BEST PRACTICE: When adding a leaf device to an existing VCF, interconnect the new device to the spine member that is in the primary Routing Engine role first, which is the most efficient way to synchronize the new member with the current VCF configuration and state.

  • Page 429: Removing A Device From A Virtual Chassis Fabric

    Removing a Device From a Virtual Chassis Fabric This topic describes how to remove a device from a Virtual Chassis Fabric (VCF): To remove a device from a VCF: 1. Power off the device that you are removing from the VCF. 2.

  • Page 430: Powering Off A Qfx5110

    8. (Optional, but recommended) Delete the VCP or VCPs on the device that was removed: user@device> request virtual-chassis vc-port delete pic-slot pic-slot port port-number member member-id 9. (Optional, but recommended) Reset the fabric and mixed mode settings. If you are removing a device that was part of a VCF composed entirely of the same device: user@device>...
  • Page 431 An RJ-45 to DB-9 rollover cable to connect the external management device to the console port To power off a QFX5110 switch: 1. Connect to the switch using one of the following methods: Connect a management device to the console (CON) port on a QFX5110. For instructions about connecting a management device to the console (CON) port, see Connect a Device to a Management Console Using an RJ-45 Connector.
  • Page 432 Consoles: serial port BIOS drive C: is disk0 BIOS drive D: is disk1 BIOS drive E: is disk2 BIOS drive F: is disk3 BIOS 639kB/3144576kB available memory CAUTION: The final output of any version of the request system halt command is “The operating system has halted.”...

  • Page 433: Powering Off A Qfx5100 Device

    Powering Off a QFX5100 Device NOTE: Use the following procedure to turn off power on a QFX5100 device that is in standalone mode, a member in a QFX Virtual Chassis, or either a spine device or a leaf device in a Virtual Chassis Fabric.
  • Page 434 Terminated Poweroff for hypervisor to respawn Aug 26 16:49:04 init: event-processing (PID 1325) exited with status=1 Aug 26 16:49:04 init: packet-forwarding-engine (PID 1809) exited with status=8 Waiting (max 60 seconds) for system process `vnlru_mem' to stop...done Waiting (max 60 seconds) for system process `vnlru' to stop...done Waiting (max 60 seconds) for system process `bufdaemon' to stop...done Waiting (max 60 seconds) for system process `syncer' to stop...
  • Page 435 CAUTION: The final output of any version of the request system halt command is “Power down.” Wait at least 60 seconds after first seeing this message before following the instructions in Step and Step to power off the switch. 3. Attach the grounding strap to your bare wrist and to a site ESD point. 4.

  • Page 436: Powering Off A Qfx3600 Device

    Powering Off a QFX3600 Device NOTE: Use the following procedure to turn off power on a QFX3600 device that is in standalone mode, a member in a QFX Virtual Chassis, or a leaf device in a Virtual Chassis Fabric. QFX3600 devices that are Node devices in a QFabric system running OS Junos release 14.1 or later must use a different procedure and CLI to ensure there is no traffic loss.
  • Page 437 Shutdown NOW! [pid 1764] user@device> *** FINAL System shutdown message from user@device *** System going down IMMEDIATELY JWaiting (max 300 seconds) for system process `vnlru_mem' to stop...done Waiting (max 300 seconds) for system process `vnlru' to stop...done Waiting (max 300 seconds) for system process `bufdaemon' to stop...done Waiting (max 300 seconds) for system process `syncer' to stop...

  • Page 438: Powering Off A Qfx3500 Device

    DC power supply—Remove the screws securing the ring lugs attached to the power source cables to the power supply using the screwdriver, and remove the power source cables from the power supply. Replace the screws on the terminals and tighten them. RELATED DOCUMENTATION Adding or Replacing an Interconnect Device in a QFX3000-M QFabric System Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 309...
  • Page 439 1. Connect to the device using one of the following methods: Connect a management device to the console (CON) port on a QFX3500 device. For instructions about connecting a management device to the console (CON) port, see “Connecting a QFX Series Device to a Management Console”...

  • Page 440: Removing A Qfx5110 From A Rack

    CAUTION: The final output of any version of the request system halt command is the “The operating system has halted. Please press any key to reboot” message. Wait at least 60 seconds after first seeing this message before following the instructions in Step and Step to remove power from device.
  • Page 441 NOTE: When you remove multiple switches from a rack, remove the switch in the top of the rack first, then proceed to remove the rest of the switches from top to bottom. Before removing a QFX5110 from a rack: Ensure that the rack is stable and secured to the building. Ensure that there is enough space to place the removed QFX5110 in its new location and along the path to the new location.

  • Page 442: Removing A Qfx5100 Device From A Rack Or Cabinet

    Removing a QFX5100 Device from a Rack or Cabinet If you need to relocate an installed QFX5100 device, use the procedure described in this topic. (The remainder of this topic uses “rack” to mean “rack or cabinet.” ) NOTE: When you remove multiple devices from a rack, remove the device in the top of the rack first and proceed to remove the rest of the devices from top to bottom.

  • Page 443: Removing A Qfx3600 Or Qfx3600-I Device From A Rack Or Cabinet

    4. Place the removed screws and mounting blades in a labeled bag. You will need them when you reinstall the chassis. 5. Transport the QFX5100 device to your desired new location. RELATED DOCUMENTATION Mount a QFX5100 Device in a Rack or Cabinet | 279 Removing a QFX3600 or QFX3600-I Device from a Rack or Cabinet If you need to relocate an installed QFX3600 or QFX3600-I device, use the procedure described in this topic.

  • Page 444: Removing A Qfx3500 Device From A Rack Or Cabinet

    1. Have one person support the weight of the device while another person uses the screwdriver to remove the mounting screws that attach the chassis front-mounting or mid-mounting brackets to the rack or cabinet. 2. Remove the QFX3600 or QFX3600-I device from the rack or cabinet. 3.
  • Page 445 Ensure that you have the following parts and tools available: A Phillips (+) screwdriver, number 2 or number 3, depending on the size of your rack mounting screws, for mounting the QFX3500 device on the rack. To remove a QFX3500 device from a rack or cabinet: 1.

  • Page 446: Replacing Qfx5110 Components

    CHAPTER 30 Replacing QFX5110 Components IN THIS CHAPTER Installing a Fan Module in a QFX5110 | 422 Removing a Fan Module from a QFX5110 | 423 Installing a Power Supply in a QFX5110 | 425 Removing a Power Supply from a QFX5110 | 427 Installing a Fan Module in a QFX5110 The fan modules in a QFX5110 are hot-removable and hot-insertable field-replaceable units (FRUs): you can remove and replace them without powering off the switch or disrupting switch functions.

  • Page 447: Removing A Fan Module From A Qfx5110

    To install a fan module in a QFX5110 (see Figure 136 on page 423): 1. Attach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis. 2. Taking care not to touch the connectors, remove the fan module from its bag. 3.
  • Page 448 CAUTION: Replace a failed fan module with a new fan module within 1 minute of removal to prevent chassis overheating. Before removing the fan module, ensure you have a replacement fan module at hand. Before you remove a fan module from a QFX5110, ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage (see “Prevention of Electrostatic Discharge Damage”...

  • Page 449: Installing A Power Supply In A Qfx5110

    Figure 137: Removing a Fan Module from a QFX5110 NOTE: When a fan module is removed, the CLI message “Fan/Blower is Absent” is logged in the system log, and the system raises a minor alarm. Installing a Power Supply in a QFX5110 All QFX5110 switches, except the QFX5110-32Q-CHAS are shipped from the factory with two power supplies.
  • Page 450 CAUTION: Verify that the direction of the arrow on the power supply handle matches the direction of airflow in the chassis. Ensure that each power supply you install in the chassis has the same airflow direction. If you install power supplies with two different airflow directions, Junos OS raises an alarm, and the status (ALM) LED blinks amber.

  • Page 451: Removing A Power Supply From A Qfx5110

    Each power supply must be connected to a dedicated power source outlet. NOTE: If you have a Juniper Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/. Failure to do so can result in significant delays if you need replacement parts. This note does not apply if you replace existing components with the same type of component.
  • Page 452 NOTE: If only one power supply is installed in your QFX5110, you need to power off the switch before removing the power supply. See “Powering Off a QFX5110” on page 406. 3. Disconnect power to the switch: AC power supply—If the AC power source outlet has a power switch, set it to the off (O) position. If the AC power source outlet does not have a power switch, gently pull out the plug end of the power cord connected to the power source outlet.

  • Page 453: Replacing Qfx5100 Components

    CHAPTER 31 Replacing QFX5100 Components IN THIS CHAPTER Installing and Removing QFX5100 Device Hardware Components | 429 Installing a Power Supply in a QFX5100 Device | 430 Removing a Power Supply from a QFX5100 Device | 432 Installing an Expansion Module in a QFX5100 Device | 434 Removing an Expansion Module from a QFX5100 Device | 438 Installing a Fan Module in a QFX5100 Device | 440 Removing a Fan Module from a QFX5100 Device | 442...

  • Page 454: Installing A Power Supply In A Qfx5100 Device

    To install a power supply in a QFX5100 device, follow the instructions in “Installing a Power Supply in a QFX5100 Device” on page 430. To remove a power supply from a QFX5100 device, follow the instructions “Removing a Power Supply from a QFX5100 Device” on page 432.
  • Page 455 1. Attach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis. 2. Taking care not to touch power supply components, pins, leads, or solder connections, remove the power supply from its bag. CAUTION: Verify that the direction of the arrow on the power supply handle matches the direction of airflow in the chassis.

  • Page 456: Removing A Power Supply From A Qfx5100 Device

    NOTE: If you have a Juniper Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can result in significant delays if you need replacement parts. This note does not apply if you replace existing components with the same type of component.
  • Page 457 CAUTION: Replace the power supply with a new power supply within 1 minute of removal to prevent chassis overheating. To remove a power supply from a QFX5100 device (see Figure 143 on page 434 Figure 144 on page 434): 1. Place the antistatic bag or the antistatic mat on a flat, stable surface. 2.

  • Page 458: Installing An Expansion Module In A Qfx5100 Device

    Figure 143: Removing a Power Supply from a 1 U QFX5100 Device Figure 144: Removing a Power Supply from a QFX5100-96S Device RELATED DOCUMENTATION AC Power Supply for a QFX5100 Device Connecting AC Power to a QFX5100 Device | 285 Connecting DC Power to a QFX5100 Device | 288 Installing a Power Supply in a QFX5100 Device | 430 Installing an Expansion Module in a QFX5100 Device...
  • Page 459 Figure 145: QFX-EM-4Q Expansion Module EX4600-EM-8F–Each module adds eight 10 Gigabit SFP+ ports. See Figure 146 on page 435. Figure 146: EX4600-EM-8F Expansion Module The QFX5100-24Q device is configured for the QFX-EM-4Q by default, but any combination of the two modules is supported.
  • Page 460 Before you begin installing an expansion module in the switch, ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage (see “Prevention of Electrostatic Discharge Damage” on page 242). Ensure that you have the following parts and tools available: ESD grounding strap.
  • Page 461 For an EX4600-EM-8F installed in slot 2 (QIC1), the NIC interfaces are displayed as xe-0/0/24 and xe-0/0/25. NOTE: If you have a Juniper Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can result in significant delays if you need replacement parts. This note applies if you change the type of power supply or add a new type of expansion module.

  • Page 462: Removing An Expansion Module From A Qfx5100 Device

    RELATED DOCUMENTATION QFX5100 Device Hardware Overview | 22 Installing and Removing QFX5100 Device Hardware Components | 429 Removing an Expansion Module from a QFX5100 Device The expansion modules used in QFX5100-24Q and QFX5100-24Q-AA devices are hot-removable and hot-insertable field-replaceable units (FRUs): You can remove and replace them without powering off the switch or disrupting switch functions.
  • Page 463 To remove an expansion module from the switch (see Figure 150 on page 439 Figure 151 on page 440): 1. Attach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis. 2.

  • Page 464: Installing A Fan Module In A Qfx5100 Device

    Figure 151: Removing a QFX-PFA-4Q Expansion Module from a QFX5100-24Q-AA Device RELATED DOCUMENTATION Installing an Expansion Module in a QFX5100 Device | 434 Installing and Removing QFX5100 Device Hardware Components | 429 Field-Replaceable Units in a QFX5100 Device QFX5100 Device Hardware Overview | 22 Installing a Fan Module in a QFX5100 Device The fan modules in a QFX5100 device are hot-removable and hot-insertable field-replaceable units (FRUs): you can remove and replace them without powering off the switch or disrupting switch functions.
  • Page 465 To install a fan module in a QFX5100 device (see Figure 152 on page 441 Figure 153 on page 441): 1. Attach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis.

  • Page 466: Removing A Fan Module From A Qfx5100 Device

    Removing a Fan Module from a QFX5100 Device | 442 Cooling System and Airflow in a QFX5100 Device Field-Replaceable Units in a QFX5100 Device Management Panel of a QFX5100 Device Removing a Fan Module from a QFX5100 Device The fan modules in QFX5100 devices are hot-removable and hot-insertable field-replaceable units (FRUs): you can remove and replace them without powering off the switch or disrupting switch functions.
  • Page 467 5. Pull firmly to slide the fan module halfway out of the chassis. 6. When the fan stop spinning, slide the fan module completely out of the chassis. 7. Place the fan module in the antistatic bag or on the antistatic mat placed on a flat, stable surface. Figure 154: Removing a Fan Module from a 1 U QFX5100 Device Figure 155: Removing a Fan Module from a 2 U QFX5100-96S Device NOTE:...

  • Page 468: Replacing Qfx3600 Components

    CHAPTER 32 Replacing QFX3600 Components IN THIS CHAPTER Installing and Removing QFX3600 or QFX3600-I Device Hardware Components | 444 Removing a Power Supply from a QFX3600 or QFX3600-I Device | 445 Installing a Power Supply in a QFX3600 or QFX3600-I Device | 447 Removing a Fan Tray from a QFX3600 or QFX3600-I Device | 449 Installing a Fan Tray in a QFX3600 or QFX3600-I Device | 450 Installing and Removing QFX3600 or QFX3600-I Device Hardware...

  • Page 469: Removing A Power Supply From A Qfx3600 Or Qfx3600-I Device

    To install a fan tray in a QFX3600 or QFX3600-I device, follow the instructions in “Installing a Fan Tray in a QFX3600 or QFX3600-I Device” on page 450. To remove a fan tray from a QFX3600 or QFX3600-I device, follow the instructions in “Removing a Fan Tray from a QFX3600 or QFX3600-I Device”...
  • Page 470 CAUTION: Replace a failed power supply with a blank panel or new power supply within 1 minute of removal to prevent chassis overheating. To remove a power supply from a QFX3600 or QFX3600-I device (see Figure 156 on page 447): 1.

  • Page 471: Installing A Power Supply In A Qfx3600 Or Qfx3600-I Device

    Figure 156: Removing a Power Supply from a QFX3600 or QFX3600-I Device NOTE: If you have a Juniper Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can result in significant delays if you need replacement parts. This note does not apply if you replace existing components with the same type of component.
  • Page 472 NOTE: Each power supply must be connected to a dedicated power source outlet. NOTE: If you have a Juniper Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can result in significant delays if you need replacement parts. This note does not apply if you replace existing components with the same type of component.

  • Page 473: Removing A Fan Tray From A Qfx3600 Or Qfx3600-I Device

    Rear Panel of QFX3600 and QFX3600-I Devices AC Power Cord Specifications for a QFX Series Device | 154 Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 309 Connecting DC Power to a QFX3500, QFX3600, or QFX3600-I Device | 312 Removing a Power Supply from a QFX3600 or QFX3600-I Device | 445 Removing a Fan Tray from a QFX3600 or QFX3600-I Device The fan trays in QFX3600 and QFX3600-I devices are hot-removable and hot-insertable field-replaceable...

  • Page 474: Installing A Fan Tray In A Qfx3600 Or Qfx3600-I Device

    4. When the fans stop spinning, slide the fan tray completely out of the chassis. 5. Place the fan tray in the antistatic bag or on the antistatic mat placed on a flat, stable surface. Figure 158: Removing a Fan Tray from a QFX3600 or QFX3600-I Device NOTE: When a fan tray is removed, the CLI message Fan/Blower is Absent is logged in the system log, and the system raises a minor alarm.
  • Page 475 ESD grounding strap To install a fan tray in a QFX3600 or QFX3600-I device (see Figure 159 on page 451): 1. Attach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis.

  • Page 476: Replacing Qfx3500 Components

    CHAPTER 33 Replacing QFX3500 Components IN THIS CHAPTER Installing and Removing QFX3500 Device Hardware Components | 452 Installing a Power Supply in a QFX3500 Device | 453 Removing a Power Supply from a QFX3500 Device | 455 Installing a Fan Tray in a QFX3500 Device | 457 Removing a Fan Tray from a QFX3500 Device | 459 Installing a Management Board in a QFX3500 Device | 460 Removing a Management Board from a QFX3500 Device | 462...

  • Page 477: Installing A Power Supply In A Qfx3500 Device

    To install a power supply in a QFX3500 device, follow the instructions in “Installing a Power Supply in a QFX3500 Device” on page 453. To remove a power supply from a QFX3500 device, follow the instructions “Removing a Power Supply from a QFX3500 Device” on page 455.
  • Page 478 Ensure that the airflow direction of the power supply is the same as the chassis. Labels on the power supply handle indicate the direction of airflow. See Cooling System and Airflow for a QFX3500 Device for more information. Ensure that you have the following parts and tools available to install a power supply in a QFX3500 device: ESD grounding strap To install a power supply in a QFX3500 device (see...

  • Page 479: Removing A Power Supply From A Qfx3500 Device

    NOTE: If you have a Juniper Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can result in significant delays if you need replacement parts. This note does not apply if you replace existing components with the same type of component.
  • Page 480 CAUTION: Replace the power supply with a blank panel or new power supply within 1 minute of removal to prevent chassis overheating. To remove a power supply from a QFX3500 device (see Figure 161 on page 457): 1. Place the antistatic bag or the antistatic mat on a flat, stable surface. 2.

  • Page 481: Installing A Fan Tray In A Qfx3500 Device

    Figure 161: Removing a Power Supply from a QFX3500 Device RELATED DOCUMENTATION AC Power Supply for a QFX3500, QFX3600, or QFX3600-I Device Connecting AC Power to a QFX3500, QFX3600, or QFX3600-I Device | 309 Installing a Power Supply in a QFX3500 Device | 453 Installing a Fan Tray in a QFX3500 Device The fan trays in a QFX3500 device are hot-removable and hot-insertable field-replaceable units (FRUs): you can remove and replace them without powering off the device or disrupting device functions.
  • Page 482 Ensure that you have the following parts and tools available to install a fan tray in a QFX3500 device: ESD grounding strap To install a fan tray in a QFX3500 device (see Figure 162 on page 458): 1. Attach the ESD grounding strap to your bare wrist, and connect the strap to the ESD point on the chassis.

  • Page 483: Removing A Fan Tray From A Qfx3500 Device

    Removing a Fan Tray from a QFX3500 Device The fan trays in QFX3500 devices are hot-removable and hot-insertable field-replaceable units (FRUs): you can remove and replace them without powering off the device or disrupting device functions. CAUTION: Replace a failed fan tray with a new fan tray within 1 minute of removal to prevent chassis overheating.

  • Page 484: Installing A Management Board In A Qfx3500 Device

    Figure 163: Removing a Fan Tray from a QFX3500 Device NOTE: When a fan tray is removed, the CLI message Fan/Blower is Absent is logged in the system log, and the system raises a minor alarm. RELATED DOCUMENTATION Cooling System and Airflow for a QFX3500 Device Field-Replaceable Units in a QFX3500 Device Front Panel of a QFX3500 Device | 56 Installing a Fan Tray in a QFX3500 Device | 457...
  • Page 485 Before you install a management board in a QFX3500 device, ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage (see “Prevention of Electrostatic Discharge Damage” on page 242). Ensure that you have the following parts and tools available to install a management board in a QFX3500 device: ESD grounding strap To install a management board in a QFX3500 device (see...

  • Page 486: Removing A Management Board From A Qfx3500 Device

    RELATED DOCUMENTATION Management Board for a QFX3500 Device Field-Replaceable Units in a QFX3500 Device Connecting a QFX Series Device to a Management Console | 293 Connecting a QFX3500 Node Device to a Copper-Based QFX3000-G QFabric System Control Plane Network Connecting a QFX3500 Device to a Network for Out-of-Band Management | 351 Removing a Management Board from a QFX3500 Device | 462 Removing a Management Board from a QFX3500 Device QFX3500 devices have a single field-replaceable unit (FRU) management board on the front panel.
  • Page 487 WARNING: To avoid injury, do not touch the fan with your hands or any tools as you slide the management board out of the chassis—the fan might still be running. 5. Grasp the management board handle and pull firmly to slide the management board halfway out of the chassis.

  • Page 488: Replacing Ex4300 Components

    CHAPTER 34 Replacing EX4300 Components IN THIS CHAPTER Installing and Removing EX4300 Switch Hardware Components | 464 Installing an AC Power Supply in an EX4300 Switch | 465 Installing a DC Power Supply in an EX4300 Switch | 467 Installing a Fan Module in an EX4300 Switch | 469 Installing an Uplink Module in an EX4300 Switch | 471 Install a Transceiver | 473 Installing and Removing EX4300 Switch Hardware Components...

  • Page 489: Installing An Ac Power Supply In An Ex4300 Switch

    Removing an AC Power Supply from an EX4300 Switch Installing a Fan Module in an EX4300 Switch on page 469 Removing a Fan Module from an EX4300 Switch Installing an Uplink Module in an EX4300 Switch on page 471 Removing an Uplink Module from an EX4300 Switch Install a Transceiver on page 473 Remove a Transceiver on page 478 Install a QSFP28 Transceiver...
  • Page 490 Figure 166: Installing an AC Power Supply in an EX4300 Switch NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ .

  • Page 491: Installing A Dc Power Supply In An Ex4300 Switch

    RELATED DOCUMENTATION Removing an AC Power Supply from an EX4300 Switch Connecting AC Power to an EX4300 Switch AC Power Supply in EX4300 Switches | 170 AC Power Cord Specifications for an EX4300 Switch | 180 EX4300 Switches Hardware Overview | 58 Installing a DC Power Supply in an EX4300 Switch The DC power supply in EX4300 switches is a hot-removable and hot-insertable field-replaceable unit (FRU) installed in the rear panel of the switch: You can remove and replace it without powering off the...
  • Page 492 Figure 167: Installing a DC Power Supply in an EX4300 Switch NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ .

  • Page 493: Installing A Fan Module In An Ex4300 Switch

    RELATED DOCUMENTATION Removing a DC Power Supply from an EX4300 Switch Connecting DC Power to an EX4300 Switch DC Power Supply in EX4300 Switches | 184 EX4300 Switches Hardware Overview | 58 Installing a Fan Module in an EX4300 Switch Each fan module is a hot-removable and hot-insertable field-replaceable unit (FRU) installed in the rear panel of the switch: You can remove and replace it without powering off the switch or disrupting switch functions.
  • Page 494 Figure 168: Installing a Fan Module in a 24-Port EX4300 Switch NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ .

  • Page 495: Installing An Uplink Module In An Ex4300 Switch

    Installing an Uplink Module in an EX4300 Switch You can install an uplink module in the front panel of an EX4300 switch. The uplink module in EX4300 switches is a hot-removable and hot-insertable unit (FRU): You can remove and replace it without powering off the switch.
  • Page 496 3. Taking care not to touch module components, pins, leads, or solder connections, remove the uplink module from its bag. CAUTION: Before you slide the uplink module into the slot on the switch chassis, ensure the uplink module is aligned correctly. Misalignment might cause the pins to bend, making the uplink module unusable.

  • Page 497: Install A Transceiver

    Figure 171: Installing an 8-Port 10-Gigabit Ethernet SFP+ Uplink Module in a 32-Port EX4300 Switch NOTE: If you have a Juniper J-Care service contract, register any addition, change, or upgrade of hardware components at https://www.juniper.net/customers/support/tools/updateinstallbase/ . Failure to do so can result in significant delays if you need replacement parts.
  • Page 498 CAUTION: If you face a problem running a Juniper Networks device that uses a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
  • Page 499 CAUTION: Before you slide the transceiver into the port, ensure that the transceiver is aligned correctly. Misalignment might cause the pins to bend, making the transceiver unusable. 6. Slide the transceiver in gently until it is fully seated. If you are installing a CFP transceiver, tighten the captive screws on the transceiver by using your fingers.

  • Page 500: Replacing Transceivers And Fiber-Optic Cables

    CHAPTER 35 Replacing Transceivers and Fiber-Optic Cables IN THIS CHAPTER Removing a Transceiver from a QFX Series Device | 476 Remove a Transceiver | 478 Installing a Transceiver in a QFX Series Device | 481 Install a Transceiver | 484 Disconnecting a Fiber-Optic Cable from a QFX Series Device | 486 Disconnect a Fiber-Optic Cable | 487 Connecting a Fiber-Optic Cable to a QFX Series Device | 488...
  • Page 501 WARNING: Do not look directly into a fiber-optic transceiver or into the ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected to transceivers emit laser light that can damage your eyes. WARNING: Do not leave a fiber-optic transceiver uncovered except when inserting or removing a cable.

  • Page 502: Remove A Transceiver

    Installing a Transceiver in a QFX Series Device | 481 Remove a Transceiver The transceivers for Juniper Networks devices are hot-removable and hot-insertable field-replaceable units (FRUs): You can remove and replace them without powering off the device or disrupting device functions.
  • Page 503 WARNING: Do not leave a fiber-optic transceiver uncovered except when inserting or removing a cable. The rubber safety cap keeps the port clean and prevents accidental exposure to laser light. CAUTION: Do not bend fiber-optic cables beyond their minimum bend radius. An arc smaller than a few inches in diameter can damage the cables and cause problems that are difficult to diagnose.
  • Page 504 6. To remove an SFP, SFP+, XFP, or a QSFP+ transceiver: a. By using your fingers, pull open the ejector lever on the transceiver to unlock the transceiver. CAUTION: Before removing the transceiver, make sure that you open the ejector lever completely until you hear it click. This prevents damage to the transceiver.

  • Page 505: Installing A Transceiver In A Qfx Series Device

    8. Place the transceiver in the antistatic bag or on the antistatic mat placed on a flat, stable surface. 9. Place the dust cover over the empty port or install the replacement transceiver. Installing a Transceiver in a QFX Series Device The transceivers for the QFX Series are hot-removable and hot-insertable field-replaceable units (FRUs).
  • Page 506 CAUTION: Before you slide the transceiver into the port, ensure that the transceiver is aligned correctly. Misalignment might cause the pins to bend, making the transceiver unusable. Note that on QFX5100-48T devices, the QSFP+ top and bottom ports have the same orientation for inserting and removing transceivers. On all other QFX Series devices, the ports are designed belly-to-belly, which requires you to turn the transceiver over on the bottom port row.
  • Page 507 Figure 175: Installing a QSFP+ Transceiver in the QFX Series—Vertical Orientation QSFP transceiver Figure 176: Installing a QSFP+ Transceiver in the QFX Series—Horizontal Orientation Figure 177: Installing a QSFP+ Transceiver in a QFX5100-48T...

  • Page 508: Install A Transceiver

    Juniper Networks with your Juniper Networks device. CAUTION: If you face a problem running a Juniper Networks device that uses a third-party optic or cable, the Juniper Networks Technical Assistance Center (JTAC) can help you diagnose the source of the problem. Your JTAC engineer might recommend that you check the third-party optic or cable and potentially replace it with an equivalent Juniper Networks optic or cable that is qualified for the device.
  • Page 509 Before you begin to install a transceiver in a device, ensure that you have taken the necessary precautions for safe handling of lasers (see Laser and LED Safety Guidelines and Warnings). Ensure that you have a rubber safety cap available to cover the transceiver. Figure 172 on page 475 shows how to install a QSFP+ transceiver.

  • Page 510: Disconnecting A Fiber-Optic Cable From A Qfx Series Device

    6. Slide the transceiver in gently until it is fully seated. If you are installing a CFP transceiver, tighten the captive screws on the transceiver by using your fingers. 7. Remove the rubber safety cap when you are ready to connect the cable to the transceiver. WARNING: Do not look directly into a fiber-optic transceiver or into the ends of fiber-optic cables.

  • Page 511: Disconnect A Fiber-Optic Cable

    Maintaining Fiber-Optic Cables in a QFX Series Device | 491 Disconnect a Fiber-Optic Cable Juniper Networks devices have optical transceivers to which you can connect fiber-optic cables. Before you begin to disconnect a fiber-optic cable from an optical transceiver, ensure that you have taken...

  • Page 512: Connecting A Fiber-Optic Cable To A Qfx Series Device

    Ensure that you have the following parts and tools available: A rubber safety cap to cover the transceiver A rubber safety cap to cover the fiber-optic cable connector To disconnect a fiber-optic cable from an optical transceiver installed in the device: 1.
  • Page 513 To connect a fiber-optic cable to an optical transceiver installed in the QFX Series: WARNING: Do not look directly into a fiber-optic transceiver or into the ends of fiber-optic cables. Fiber-optic transceivers and fiber-optic cables connected to transceivers emit laser light that can damage your eyes. WARNING: Do not stare into the laser beam or view it directly with optical instruments even if the interface has been disabled.

  • Page 514: Connect A Fiber-Optic Cable

    Connect a Fiber-Optic Cable Before you begin to connect a fiber-optic cable to an optical transceiver installed in a device, ensure that you have taken the necessary precautions for safe handling of lasers (see Laser and LED Safety Guidelines and Warnings). To connect a fiber-optic cable to an optical transceiver installed in a device: WARNING: Do not look directly into a fiber-optic transceiver or into the ends of...

  • Page 515: Routine Maintenance

    CHAPTER 36 Routine Maintenance IN THIS CHAPTER Maintaining Fiber-Optic Cables in a QFX Series Device | 491 How to Handle Fiber-Optic Cables | 492 Maintaining Fiber-Optic Cables in a QFX Series Device To maintain fiber-optic cables in the QFX Series: When you unplug a fiber-optic cable from a transceiver, place rubber safety caps over the transceiver and on the end of the cable.

  • Page 516: How To Handle Fiber-Optic Cables

    Disconnecting a Fiber-Optic Cable from a QFX Series Device | 486 How to Handle Fiber-Optic Cables Fiber-optic cables connect to optical transceivers that are installed in Juniper Networks devices. To maintain fiber-optic cables: When you unplug a fiber-optic cable from a transceiver, place rubber safety caps over the transceiver and on the end of the cable.

  • Page 517: Viewing Qfx5110 System Information

    CHAPTER 37 Viewing QFX5110 System Information IN THIS CHAPTER QFX5110 Chassis Status LEDs | 493 QFX5110 Management Port LEDs | 496 QFX5110 Network Port LEDs | 498 QFX5110 Fan Module LED | 500 QFX5110 AC Power Supply LEDs | 501 QFX5110 DC Power Supply LEDs | 502 QFX5110 Chassis Status LEDs The QFX5110 switch series has four status LEDs on the FRU side of the chassis, next to the management...
  • Page 518 Figure 181: Chassis Status LEDs on a QFX5110 Switch Status LEDs USB port — — em0–RJ-45 (10/100/1000 BASE-T) management em1–SFP management Ethernet port (C1) — — Ethernet port (C0) cage (socket for either 10/100/1000 BASE-T RJ-45 SFP or 1-GbE fiber SFP) RJ-45 console port (CON) —...
  • Page 519 Table 72: Chassis Status LEDs on a QFX5110 Switch Name Color State Description ALM–Alarm or beacon Unlit The switch is halted or there is no alarm. On steadily A major hardware fault has occurred, such as a temperature alarm or power failure, and the switch has halted.

  • Page 520: Qfx5110 Management Port Leds

    Table 72: Chassis Status LEDs on a QFX5110 Switch (continued) Name Color State Description MST–Primary in a QFX Unlit The switch is a line card member in a Virtual Chassis or Routing QFX Virtual Chassis. Engine Primary in a VCF Green On steadily The switch is one of the following:...
  • Page 521 Figure 182: Management Port LEDs on a QFX5110 Status LEDs USB port — — em0–RJ-45 (10/100/1000BASE-T) management em1–SFP management Ethernet port (C1) — — Ethernet port (C0) cage (socket for either 10/100/1000BASE-T RJ-45 SFP or 1-GbE fiber SFP) RJ-45 console port (CON)) —...

  • Page 522: Qfx5110 Network Port Leds

    QFX5110 Network Port LEDs The Link/Activity LED configuration for QFX5110-48S uses bi-colored LEDs. The link LED indicates link activity or a fault. See Table 74 on page 498. Table 74: QFX5110-48S Access Port and Uplink LED Locations Model Port Type Indicators Location QFX5110-48S...
  • Page 523 Table 75: Network Port LEDs on QSFP28 Ports on a QFX5110 (continued) Position Color State Description Green On steadily A 40-Gigabit link is established in channelized mode, but there is no link activity. Blinking A 40-Gigabit link is established in channelized mode, and there is link activity.

  • Page 524: Qfx5110 Fan Module Led

    Table 77: QFX5110-32Q Access Port and Uplink LED Locations QFX5110-32Q QSFP28 and Link and Bi-colored LEDs QSFP+ Activity Status RELATED DOCUMENTATION QFX5110 Management Panel Install a Transceiver Connect a Fiber-Optic Cable QFX5110 Fan Module LED Figure 183 on page 500 shows the location of the LED next to the fan module.

  • Page 525: Qfx5110 Ac Power Supply Leds

    Table 78: Fan Tray LED in a QFX5110 Switch Name Color State Description Green On steadily The fan module is operating normally. The system has verified that the module is engaged, that the airflow is in the correct direction, and that the fan is operating correctly.

  • Page 526: Qfx5110 Dc Power Supply Leds

    Table 79: AC Power Supply LEDs on a QFX5110 Switch Color State Description AC OK Unlit The power supply is disconnected from power, or power is not coming into the power supply. Green On steadily Power is coming into the power supply. DC OK Unlit The power supply is disconnected from power, or the power supply...
  • Page 527 Figure 185: DC Power Supply Faceplate on a QFX5110 Switch Input LED Fault LED — — Output LED — CAUTION: The V+ terminals are shunted internally together, as are the V- terminals. The same polarity terminal can be wired together from the same source to provide an additional current path in a higher power chassis.
  • Page 528 Table 80: DC Power Supply LEDs on a QFX5110 Switch (continued) Name Color State Description Fault Amber On steadily An error has been detected in the power supply. Replace the power supply as soon as possible. To maintain proper airflow through the chassis, leave the power supply installed in the chassis until you are ready to replace...

  • Page 529: Viewing Qfx5100 System Information

    CHAPTER 38 Viewing QFX5100 System Information IN THIS CHAPTER Chassis Status LEDs on a QFX5100 Device | 505 Management Port LEDs on a QFX5100 Device | 508 Access Port and Uplink Port LEDs on a QFX5100 Device | 510 Fan Module LED on a QFX5100 Device | 513 AC Power Supply LEDs on a QFX5100 Device | 514 DC Power Supply LEDs on a QFX5100 Device | 516 Chassis Status LEDs on a QFX5100 Device...
  • Page 530 CAUTION: Do not use the Reset button to restart the power sequence unless under the direction of Juniper Networks Technical Assistance Center (JTAC). Table 81 on page 506 describes the chassis status LEDs on a QFX5100 switch, their colors and states, and the status they indicate.
  • Page 531 Table 81: Chassis Status LEDs on a QFX5100 Switch (continued) Name Color State Description SYS–System Unlit The switch is powered off or halted. Green On steadily Junos OS for QFX Series is loaded on the switch. Green Blinking The switch is participating as: A member in a QFX Virtual Chassis A leaf device in a Virtual Chassis Fabric (VCF)

  • Page 532: Management Port Leds On A Qfx5100 Device

    Management Panel of a QFX5100 Device show chassis alarms request chassis beacon Management Port LEDs on a QFX5100 Device The management ports (labeled C0 for 10/100/1000 Base-T and C1 for 10/100/1000 Base-T and SFP 1000 Base-X connections) on a QFX5100 switch have two LEDs that indicate link status and link activity (see Figure 187 on page 509).
  • Page 533 Reset button, see caution statement below USB port — — CAUTION: Do not use the Reset button to restart the power sequence unless under the direction of Juniper Networks Technical Assistance Center (JTAC). Table 82 on page 510 describes the management port LEDs.

  • Page 534: Access Port And Uplink Port Leds On A Qfx5100 Device

    Table 82: Management Port LEDs on a QFX5100 Switch Color State Description Link/Activity Unlit No link is established, there is a fault, or the link is down. Green On steadily A link is established, but there is no link activity. Blinking or flickering A link is established, and there is link activity.
  • Page 535 Table 83: QFX5100 Access Port and Uplink LED Locations Model Port Type Indicators Location QFX5100-24Q QSFP+ Link Bi-colored LEDs Status QFX5100-48S SFP+ Link Status QFX5100-48SH QFX5100-48T 10GBASE-T Link QFX5100-48TH QFX5100-96S SFP+ Link Status...
  • Page 536 Table 83: QFX5100 Access Port and Uplink LED Locations (continued) Model Port Type Indicators Location Table 84 on page 512 describes how to interpret the SFP+ port LEDs. Table 84: Network Port LEDs on SFP+ Ports on a QFX5100 Switch Color State Description...

  • Page 537: Fan Module Led On A Qfx5100 Device

    As shown in Table 83 on page 511, there are four bi-color LEDs for each QSFP+ port. The first LED is used and the remaining LEDs are not used when the interface is configured for 40-Gigabit Ethernet and connected to a QSFP+ transceiver. All four LEDs are used when the interface is configured for 10-Gigabit Ethernet and the port is connected using an optical split cable or a copper DACBO cable.

  • Page 538: Ac Power Supply Leds On A Qfx5100 Device

    Figure 188: Fan Module LED in a QFX5100 Switch Fan LED — Table 86 on page 514 describes the function of the fan tray LED. Table 86: Fan Tray LED in a QFX5100 Switch Name Color State Description Green On steadily The fan module is operating normally.
  • Page 539 Figure 189: AC Power Supply LEDs on a QFX5100 Switch AC OK DC OK Fault Table 87 on page 515 describes the LEDs on the AC power supplies. Table 87: AC Power Supply LEDs on a QFX5100 Switch Color State Description AC OK Unlit...

  • Page 540: Dc Power Supply Leds On A Qfx5100 Device

    DC Power Supply LEDs on a QFX5100 Device Figure 190 on page 516 shows the location of the LEDs on the DC power supply. Figure 190: DC Power Supply Faceplate on a QFX5100 Switch Input LED Fault LED — — Output LED —...
  • Page 541 Table 88: DC Power Supply LEDs on a QFX5100 Switch (continued) Name Color State Description Fault Amber On steadily An error has been detected in the power supply. Replace the power supply as soon as possible. To maintain proper airflow through the chassis, leave the power supply installed in the chassis until you are ready to replace RELATED DOCUMENTATION...

  • Page 542: Viewing Qfx3600 System Information

    CHAPTER 39 Viewing QFX3600 System Information IN THIS CHAPTER Chassis Status LEDs in the QFX3600 and QFX3600-I Device | 518 Management Port LEDs in the QFX3600 and QFX3600-I Device | 520 Access Port and Uplink Port LEDs on a QFX3600 or QFX3600-I Device | 521 Fan Tray LED on a QFX3600 or QFX3600-I Device | 522 AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 523 DC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 525...
  • Page 543 Table 89: Chassis Status LEDs in the QFX3600 and QFX3600-I Device Name Color State Description Power Green On steadily The device is powered on. Amber Blinking A temperature or voltage error has been detected, and the device has shut down. Power off the QFX3600 or QFX3600-I device following the instructions in “Powering Off a QFX3600 Device”...

  • Page 544: Management Port Leds In The Qfx3600 And Qfx3600-I Device

    Management Port LEDs in the QFX3600 and QFX3600-I Device The RJ-45 management ports labeled C0 and C1 and SFP management ports labeled C0S and C1S in a QFX3600 or QFX3600-I device have two LEDs that indicate link speed and activity. NOTE: On the SFP management ports, LA denotes activity, and ST denotes speed.

  • Page 545: Access Port And Uplink Port Leds On A Qfx3600 Or Qfx3600-I Device

    RELATED DOCUMENTATION Front Panel of a QFX3600 Device | 48 Front Panel of a QFX3600-I Interconnect Device Connecting a QFX3600 Device to a Network for Out-of-Band Management Access Port and Uplink Port LEDs on a QFX3600 or QFX3600-I Device Each access port and uplink port in a QFX3600 device has two LEDs (see Figure 193 on page 521).

  • Page 546: Fan Tray Led On A Qfx3600 Or Qfx3600-I Device

    Table 91: Access Port LEDs on QSFP+ Ports on a QFX3600 Device (continued) Color State Description Status Unlit No transceiver is installed in the port, or the transceiver is not supported. Green On steadily A transceiver is installed in the port. Table 92 on page 522 describes the QSFP+ uplink port LEDs.

  • Page 547: Ac Power Supply Leds On A Qfx3500, Qfx3600, Or Qfx3600-I Device

    Figure 194: Fan Tray Handle — — Table 93 on page 523 describes the function of the fan tray LED. Table 93: Fan Tray LED Name Color State Description Green On steadily The fan tray is operating normally. Amber Blinking An error has been detected in the fan tray.
  • Page 548 Figure 195: AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device AC OK DC OK Fault Table 94 on page 524 describes the LEDs on the AC power supplies. Table 94: AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device Color State Description...

  • Page 549: Dc Power Supply Leds On A Qfx3500, Qfx3600, Or Qfx3600-I Device

    DC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device Figure 196 on page 525 shows the location of the LEDs on the DC power supply. Figure 196: DC Power Supply Faceplate on a QFX3500, QFX3600, or QFX3600-I Device Shunt positive input terminals ESD grounding point —...
  • Page 550 Table 95: DC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device Name Color State Description Input Unlit The power supply is disconnected from power, or power is not coming into the power supply. Green On steadily Power is coming into the power supply. Output Unlit The power supply is disconnected from...

  • Page 551: Viewing Qfx3500 System Information

    CHAPTER 40 Viewing QFX3500 System Information IN THIS CHAPTER Chassis Status LEDs on a QFX3500 Device | 527 Management Port LEDs on a QFX3500 Device | 529 Access Port and Uplink Port LEDs on a QFX3500 Device | 530 Fan Tray LED on a QFX3500 Device | 532 AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 533 DC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device | 534 Chassis Status LEDs on a QFX3500 Device...
  • Page 552 Table 96: Chassis Status LEDs on a QFX3500 Device Name Color State Description Power Green On steadily The device is powered on. Amber Blinking A temperature or voltage error has been detected, and the device has shut down. Power off the QFX3500 device by setting the AC power source outlet to the OFF (O) position, or unplugging the AC power cords.

  • Page 553: Management Port Leds On A Qfx3500 Device

    Management Port LEDs on a QFX3500 Device The management ports (labeled C0 and C1) on a QFX3500 device have two LEDs that indicate link speed and activity (see Figure 198 on page 529). NOTE: Figure 198 on page 529 depicts the 1000BASE-T management ports. The LEDs on the SFP management ports are identical.

  • Page 554: Access Port And Uplink Port Leds On A Qfx3500 Device

    RELATED DOCUMENTATION Front Panel of a QFX3500 Device | 56 Connect a Device to a Network for Out-of-Band Management | 325 Access Port and Uplink Port LEDs on a QFX3500 Device Each access port and uplink port on a QFX3500 device has two LEDs. The two figures in this topic show the location of those LEDs: Figure 199 on page 530 shows the location of the LEDs on the SFP+ access ports.
  • Page 555 TIP: By default, all access ports are configured as Ethernet interfaces. If you insert a Fibre Channel transceiver, the LEDs do not light until you configure the port as a Fibre Channel interface in Junos OS. Likewise, the LEDs do not light if you insert an Ethernet transceiver in a port configured as a Fibre Channel interface.

  • Page 556: Fan Tray Led On A Qfx3500 Device

    Table 99: Uplink Port LEDs on QSFP+ Uplink Ports on a QFX3500 Device (continued) Color State Description Status Unlit No transceiver is installed in the port, or the transceiver is not supported. Green On steadily A transceiver is installed in the port. RELATED DOCUMENTATION Rear Panel of a QFX3500 Device Installing a Transceiver in a QFX Series Device | 481...

  • Page 557: Ac Power Supply Leds On A Qfx3500, Qfx3600, Or Qfx3600-I Device

    Table 100: Fan Tray LED in a QFX3500 Device Name Color State Description Green On steadily The fan tray is operating normally. Amber Blinking An error has been detected in the fan tray. Replace the fan tray as soon as possible. To maintain proper airflow through the chassis, leave the fan tray installed in the chassis until you are ready to replace it.

  • Page 558: Dc Power Supply Leds On A Qfx3500, Qfx3600, Or Qfx3600-I Device

    Table 101: AC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device Color State Description AC OK Unlit The power supply is disconnected from power, or power is not coming into the power supply. Green On steadily Power is coming into the power supply. DC OK Unlit The power supply is disconnected from power, or the power supply...
  • Page 559 Figure 203: DC Power Supply Faceplate on a QFX3500, QFX3600, or QFX3600-I Device Shunt positive input terminals ESD grounding point — — Shunt negative input terminals Fault LED — — Terminal block Output LED — — Ejector lever Input LED —...
  • Page 560 Table 102: DC Power Supply LEDs on a QFX3500, QFX3600, or QFX3600-I Device (continued) Name Color State Description Output Unlit The power supply is disconnected from power, or the power supply is not sending out power correctly. Green On steadily The power supply is sending out power correctly.

  • Page 561: Viewing Ex4300 System Information

    Chassis Viewer | 548 NOTE: This topic applies only to the J-Web Application package. When you log in to the J-Web user interface, the dashboard for the Juniper Networks EX Series Ethernet Switches appears. Use the dashboard to view system information.

  • Page 562: Graphical Chassis Viewer

    The Update Available window appears if there is a latest update of the J-Web Application package available on the Juniper Networks server. This window is enabled by the auto update feature of J-Web. NOTE: The Update Available window will not appear when you log in, if you have not selected the Check for updates automatically on every login in the Update Preference section in the Maintain >...
  • Page 563 Table 103: Details of a Virtual Chassis Member Switch Details Example Model number of the member switch EX3300 Assigned ID that applies to the entire Virtual Chassis ID 2 configuration NOTE: If the member switch is not provisioned, the serial number of the switch is displayed instead of its ID.

  • Page 564: System Information Panel

    Click Preferences to choose which panels must be displayed and set the refresh interval for chassis viewer information. Click OK to save your changes and return to the dashboard or click Cancel to return to the dashboard without saving changes. NOTE: You can drag the various panels to different locations in the J-Web window.
  • Page 565 Table 105: System Information (continued) Field Description Inventory details...
  • Page 566 Chassis, the value displayed in Inventory details field is always 1 FPC. FPC is a legacy term for a slot in a large Juniper Networks chassis; which simply refers to the standalone switch. For EX2200 and EX2200-C switches configured as a Virtual Chassis, the value displayed in the Inventory details field is 1–4 FPC, with the number corresponding...

  • Page 567: Health Status Panel

    Table 105: System Information (continued) Field Description External Routing Engines configured as a Virtual Chassis, the values displayed in Inventory details are 1–2 XRE and 0–4 LCC, where LCC refers to the EX8200 line card chassis. Junos image Indicates the version of the Junos OS image. In a Virtual Chassis configuration, the Junos OS image of the primary switch is displayed by default.
  • Page 568 Table 106: Health Status (continued) Field Description Memory util. Indicates the memory used in the Routing Engine. In a Virtual Chassis configuration, the memory utilization value of the primary Routing Engine is displayed. NOTE: In EX4300 and EX4600 Virtual Chassis, to display the Routing Engine memory utilization of the primary or backup, click the respective image.
  • Page 569 Table 106: Health Status (continued) Field Description Fan status Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent. In a Virtual Chassis configuration, the fan status of the primary switch is displayed by default. To display the fan status for any switch , click the image of that switch.
  • Page 570 Table 106: Health Status (continued) Field Description Memory util. Indicates the memory used in the primary Routing Engine. Click the backup Routing Engine to view the memory used in the backup Routing Engine. CPU load Indicates the average CPU usage over 15 minutes. Flash Indicates the usage and capacity of internal flash memory and any external USB flash drive.

  • Page 571: Capacity Utilization Panel

    Table 106: Health Status (continued) Field Description Fan Status Indicates the status of the fans in the fan tray. The possible values are OK, Failed, and Absent. Capacity Utilization Panel Table 107: Capacity Utilization Field Description Number of active ports Indicates the number of active ports in the switch.

  • Page 572: File System Usage

    then details of the 4 major alarms and 1 minor alarm are displayed. Major alarms are displayed in red and minor alarms are displayed in yellow. In an EX8200 Virtual Chassis, the top 5 alarms for the primary external Routing Engine are displayed by default.
  • Page 573 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icon to display name, status, and description information.
  • Page 574 (You might do this for initial switch configuration.) USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View Power supply Mouse over the power outlet icon to display name, status, and description information.
  • Page 575 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icon to display name, status, and description information.
  • Page 576 The Console port (RJ-45) is used to connect the switch to a management console or to a console server. USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch.
  • Page 577 Table 111: Chassis Viewer for EX4300 Switches (continued) Field Description Fan tray Mouse over the fan tray icons to display name, status, and description information. Power supplies Mouse over the power supply icons to display name, status, and description information. PIC 1 slot The rear panel of a 24-port and a 48-port EX4300 switch has four (built-in) 40-Gigabit QSFP+ ports, and the rear panel of an EX4300-32F switch has two (built-in) 40-Gigabit...
  • Page 578 Use this port for initial switch configuration. USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View of the EX4500 Switch Fan tray Mouse over the fan tray icon to display status of the fans and airflow direction information.
  • Page 579 Table 112: Chassis Viewer for EX4500 Switches (continued) Field Description Intraconnect module Mouse over the module to display details of the intraconnect module. The intraconnect module helps the switch achieve line rate on all its ports. Virtual Chassis module Mouse over to display details of the switches in the Virtual Chassis configuration. Table 113: Chassis Viewer for EX4550 Switches Field Description...
  • Page 580 Description USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Rear View of the EX4550 Switch Fan tray Mouse over the fan tray icon to display the status of the fans and airflow direction information.
  • Page 581 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan tray Mouse over the fan tray icons to display name, status, and description information.
  • Page 582 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Fan Tray Mouse over the fan tray icons to display name, status, and description information.
  • Page 583 You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Management (me0) port—The management port is used to connect the switch to a management device for out-of-band management.
  • Page 584 You can view status for the following ports on the SRE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is unavailable.
  • Page 585 You can view status for the following ports on the RE module: USB port—Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. Auxiliary port—This port is unavailable.
  • Page 586 USB port Indicates the USB port for the switch. NOTE: We recommend that you use USB flash drives purchased from Juniper Networks for your EX Series switch. PIC1 slot You can install a Virtual Chassis module in the PIC1 slot. Mouse over the Virtual Chassis ports to display the port status details.
  • Page 587 Table 119: Chassis Viewer for XRE200 External Routing Engines (continued) Field Description Rear View of the XRE200 External Routing Engine Fan modules Mouse over the fan modules to display status of the fans and airflow direction information. For a Virtual Chassis, the status of the fans of the selected member switch is displayed.

  • Page 588: Chassis Status Leds On Ex4300 Switches

    EX8216 Switch Hardware Overview Check Active Alarms with the J-Web Interface | 639 XRE200 External Routing Engine Hardware Guide Chassis Status LEDs on EX4300 Switches EX4300 switches except EX4300-48MP and EX4300-48MP-S switches have three chassis status LEDs (labeled ALM, SYS, and MST) on the right of the LCD panel, next to the Menu and Enter buttons (see Figure 204 on page 564).
  • Page 589 Table 120: Chassis Status LEDs on an EX4300 Switch LED Label Color State and Description ALM (Alarm) Unlit There is no alarm or the switch is halted. There is a major alarm. A major alarm indicates a critical error condition that requires immediate attention.

  • Page 590: Network Port, Built-In Qsfp+ Port, Uplink Port, And Uplink Module Port Leds On Ex4300 Switches

    Table 120: Chassis Status LEDs on an EX4300 Switch (continued) LED Label Color State and Description MST (Primary) Green In a standalone EX4300 switch: On steadily—The switch is functioning normally. Off—The switch is powered off or is halted. In a Virtual Chassis configuration: On steadily—The switch is the primary in the Virtual Chassis configuration.
  • Page 591 Figure 208 on page 567 shows the LEDs on the built-in QSFP+ ports. Figure 209 on page 568 shows the LEDs on the SFP+ uplink ports and on the uplink module ports on the 4-port 1-Gigabit Ethernet/10-Gigabit Ethernet SFP+ uplink module for EX4300 switches except EX4300-48MP and EX4300-48MP-S switches.
  • Page 592 Figure 209: LEDs on the SFP+ Uplink Ports and on the 4-Port 1-Gigabit Ethernet/10-Gigabit Ethernet SFP+ Uplink Module for EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches Link activity LED Status LED — — Figure 210: LEDs on the on the Ports on the 2-Port 40-Gigabit Ethernet QSFP+ Uplink Module for EX4300-32F Switches Status LED of the uplink module Status LED of the uplink module port...
  • Page 593 Figure 212: LEDs on the Ports on the 2-Port 40-Gigabit Ethernet QSFP+/100-Gigabit Ethernet QSFP28 Uplink Module for EX4300-48MP and EX4300-48MP-S Switches Captive screws of the uplink module Link activity LED of the uplink module port — — Link activity LED of the uplink module port Link activity LED of the uplink module port —...
  • Page 594 Table 121: Link/Activity LED Color State and Description Link activity Green Blinking—The port and the link are active, and there is link activity. On steadily—The port and the link are active, but there is no link activity. Off—The port is not active. On EX4300 switches except EX4300-48MP and EX4300-48MP-S switches, from the Idle menu of the LCD panel, use the Enter button on the LCD panel to toggle between the ADM, DPX, SPD, and PoE+ indicators.
  • Page 595 Table 122: Status LED on 10/100/1000BASE-T Ethernet Network Ports and SFP Network Ports on EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches Indicator/ Status Mode State and Description Status LED: ADM/EN Indicates the administrative status (enabled or disabled). The status indicators are: Green—Port is administratively enabled.
  • Page 596 Table 124: Status LED on QSFP+ Ports and QSFP+ Uplink Module Ports LCD Indicator State and Description Status Green Indicates the status. The status indicators are: Unlit—40-Gigabit port is down. Steadily green—40-Gigabit port is up. Table 125 on page 572 describes the Status LED on 100/1000/2500/5000/10000BASE-T Ethernet network ports on EX4300-48MP and EX4300-48MP-S switches.

  • Page 597: Management Port Leds On Ex4300 Switches

    Starting in Junos OS Release 20.1R1, you can use the request chassis beacon command on EX4300-48MP switches to identify the switch or a port on the switch. When you execute the command, the status LEDs on the RJ-45 network ports blink two times per second irrespective of the mode the ports are operating in (see How to Locate a Device or Port Using the Chassis Beacon).
  • Page 598 Figure 215: LEDs on the Management Port on EX4300-48MP and EX4300-48MP-S Switches RESET Link/Activity LED Status LED — — Table 127 on page 574 describes the Link/Activity LED. Table 127: Link/Activity LED on the Management Port on an EX4300 Switch Color State and Description Link/Activity...

  • Page 599: Ac Power Supply Leds In Ex4300 Switches

    AC Power Supply LEDs in EX4300 Switches Figure 216 on page 575 shows the location of the LEDs on an AC power supply for EX4300 switches except EX4300-48MP and EX4300-48MP-S switches. Figure 216: LEDs on AC Power Supply for EX4300 Switches IN OK LED OUT OK LED —...

  • Page 600: Dc Power Supply Leds In Ex4300 Switches

    NOTE: If the IN OK LED and the OUT OK LED are not lit green, either the AC power cord is not installed properly or the power input voltage is not within normal operating range. If the IN OK LED is lit green and the OUT OK LED is unlit or lit red, the AC power supply is installed properly, but the power supply has an internal failure.
  • Page 601 Table 130: DC Power Supply LEDs on an EX4300 Switch (continued) Name Color Description OUT OK Unlit Indicates one of the following: IN OK LED is unlit. The power supply is not delivering power correctly. Green The power supply is functioning correctly. The power supply has failed and must be replaced.

  • Page 602: Troubleshooting

    PART Troubleshooting Restoring Junos OS | 579 Returning Hardware | 586 Alarms and System Log Messages | 623...

  • Page 603: Restoring Junos Os

    Before you begin, you need to the installation media image for your device and Junos OS release from https://www.juniper.net/customers/support/ NOTE: You can create the emergency boot device on another Juniper Networks switch or router, or any PC or laptop that supports Linux. The steps you take to create the emergency boot device vary, depending on the device.
  • Page 604 5. Switch to the root account using the su command: % su Password: password NOTE: The password is the root password for the device. If you logged in to the device as root, you do not need to perform this step. 6.

  • Page 605: Performing A Recovery Installation

    2. Copy the existing configuration in the file /config/juniper.conf.gz from the device to a remote system, such as a server, or to an emergency boot device. For extra safety, you can also copy the backup configurations (the files named /config/juniper.conf.n, where n is a number from 0 through 9) to a...
  • Page 606 NOTE: Do not power off the device if it is already on. [edit system] user@device> request system reboot If you do not have access to the CLI, power cycle the QFX Series device. The emergency boot device (external USB install media) is detected. At this time, you can load the Junos OS from the emergency boot device onto the internal flash storage.
  • Page 607 When the device is finished copying the software, you are presented with the following prompt: *** Fri September 4 01:19:00 UTC 2012*** Installation successful.. Please select one of the following options: Reboot to installed Junos after removing install media (default) ... 1 Reboot to installed Junos by disabling install media ....

  • Page 608: Recovering The Installation Using An Emergency Boot Device

    2. Copy the existing configuration in the file /config/juniper.conf.gz from the device to a remote system, such as a server, or to an emergency boot device. For extra safety, you can also copy the backup configurations (the files named /config/juniper.conf.n, where n is a number from 0 through 9) to a...
  • Page 609 Install Juniper Linux Platform Boot to host shell [debug] Select Install Juniper Linux Platform to install the Junos OS software from the emergency boot device. 4. The device copies the software from the emergency boot device, occasionally displaying status messages.

  • Page 610: Returning Hardware

    CHAPTER 43 Returning Hardware IN THIS CHAPTER Locating the Serial Number on a QFX5110 Device or Component | 586 Locating the Serial Number on a QFX5100 Device or Component | 590 Locating the Serial Number on a QFX3600 or QFX3600-I Device or Component | 593 Locating the Serial Number on a QFX3500 Device or Component | 596 Locating the Serial Number on an EX4300 Switch or Component | 598 Packing an QFX5110 Device or Component for Shipping | 605...

  • Page 611: Listing The Chassis And Component Details Using The Cli

    If you are returning a switch or component to Juniper Networks for repair or replacement, you must locate the serial number of the switch or component. You must provide the serial number to the Juniper Networks Technical Assistance Center (JTAC) when you contact them to obtain a Return Materials Authorization (RMA).

  • Page 612: Locating The Chassis Serial Number Id Label On A Qfx5110

    Back Airflow - AFO Fan Tray 2 fan-ctrl-2 2, Front to Back Airflow - AFO Fan Tray 3 fan-ctrl-2 3, Front to Back Airflow - AFO Fan Tray 4 fan-ctrl-2 4, Front to Back Airflow - AFO {master:0} root> NOTE: You must remove the fan module to read the fan serial number from the serial number ID label.
  • Page 613 AC power supply—The serial number ID label is on the top of the AC power supply. See Figure 219 on page 589 for an example of where to find the serial number ID. Figure 219: Location of the AC Power Supply Serial Number ID Label on a QFX5110 AC power supply serial number —...

  • Page 614: Locating The Serial Number On A Qfx5100 Device Or Component

    Locating the Serial Number ID Labels on FRU Components | 593 If you are returning a switch or component to Juniper Networks for repair or replacement, you must locate the serial number of the switch or component. You must provide the serial number to the Juniper Networks Technical Assistance Center (JTAC) when you contact them to obtain a Return Materials Authorization (RMA).

  • Page 615: Locating The Chassis Serial Number Id Label On A Qfx5100 Switch

    Routing Engine 0 BUILTIN BUILTIN QFX Routing Engine FPC 0 REV 17 750-036931 P5331-C QFX5100-24Q-2P BUILTIN BUILTIN FPC CPU PIC 0 BUILTIN BUILTIN 24x 40G-QSFP Power Supply 0 Rev 04 740-032091 VB02420 QFX3500-48S4Q Power Supply 1 Fan Tray 1 QFX5100 Fan Tray 1, Bac k to Front Airflow - AFI Fan Tray 2 QFX5100 Fan Tray 2, Bac...
  • Page 616 Figure 221: Location of the Serial Number ID Label on a QFX5100-96S Switch SN:TA3113280064 Figure 222: Location of the Serial Number ID Label on QFX5100-48S and QFX5100-48SH Switches SN:TA3113280064 Figure 223: Location of the Serial Number ID Label on QFX5100-48T and QFX5100-48TH Switches...

  • Page 617: Locating The Serial Number Id Labels On Fru Components

    Figure 224: Location of the Serial Number ID Label on a QFX5100-24Q Switch SN:TA3113280064 Locating the Serial Number ID Labels on FRU Components The power supplies, fan module, and expansion modules installed in QFX5100 switches are field-replaceable units (FRUs). For each FRU, you must remove the FRU from the switch chassis to see the FRU serial number ID label.

  • Page 618: Listing The Chassis And Component Details Using The Cli

    If you are returning a switch or component to Juniper Networks for repair or replacement, you must locate the serial number of the switch or component. You must provide the serial number to the Juniper Networks Technical Assistance Center (JTAC) when you contact them to obtain a Return Materials Authorization (RMA).

  • Page 619: Locating The Chassis Serial Number Id Label On A Qfx3600 Or Qfx3600-I Device

    NOTE: You must remove the fan tray to read the fan tray serial number from the serial number ID label. The fan tray serial number cannot be viewed through the CLI. Locating the Chassis Serial Number ID Label on a QFX3600 or QFX3600-I Device The chassis serial number ID label is located on a sliding panel to the right of the QSFP+ ports on the front panel of a QFX3600 or QFX3600-I device.

  • Page 620: Locating The Serial Number On A Qfx3500 Device Or Component

    Locating the Serial Number ID Labels on FRU Components | 597 If you are returning a device or component to Juniper Networks for repair or replacement, you must locate the serial number of the device or component. You must provide the serial number to the Juniper Networks Technical Assistance Center (JTAC) when you contact them to obtain a Return Materials Authorization (RMA).

  • Page 621: Locating The Chassis Serial Number Id Label On A Qfx3500 Device

    BUILTIN BUILTIN FPC CPU PIC 0 BUILTIN BUILTIN 48x 10G-SFP+ MGMT BRD REV 08 750-036946 EE0731 QFX3500-MB Power Supply 0 Rev 04 740-032091 UI00690 QFX PS 650W AC Power Supply 1 Rev 04 740-032091 UI00679 QFX PS 650W AC Fan Tray 0 QFX Fan Tray Fan Tray 1 QFX Fan Tray...

  • Page 622: Locating The Serial Number On An Ex4300 Switch Or Component

    Locating the Serial Number ID Labels on FRUs in an EX4300 Switch | 601 If you are returning a switch or hardware component to Juniper Networks for repair or replacement, you must locate the serial number of the switch or component. You must provide the serial number to the Juniper Networks Technical Assistance Center (JTAC) when you contact them to obtain Return Materials Authorization (RMA).
  • Page 623 Hardware inventory: Item Version Part number Serial number Description Chassis PD3113060008 EX4300 48P Routing Engine 0 REV D 650-044930 PD3113060008 EX4300-48P FPC 0 REV D 650-044930 PD3113060008 EX4300-48P BUILTIN BUILTIN FPC CPU PIC 0 REV D BUILTIN BUILTIN 48x 10/100/1000 Base-T PIC 1 REV D BUILTIN...

  • Page 624: Locating The Chassis Serial Number Id Label On An Ex4300 Switch

    For information about the show chassis hardware command, see show chassis hardware. Locating the Chassis Serial Number ID Label on an EX4300 Switch The serial number ID label is located on the rear panel of the chassis on EX4300 switches. Figure 227 on page 600 shows the location of the serial number ID label on 24-port and 48-port EX4300 switches except EX4300-48MP and EX4300-48MP-S switches.

  • Page 625: Locating The Serial Number Id Labels On Frus In An Ex4300 Switch

    Locating the Serial Number ID Labels on FRUs in an EX4300 Switch The power supplies, fan modules, and uplink modules, installed in EX4300 switches are field-replaceable units (FRUs). For each of these FRUs, you must remove the FRU from the switch chassis to see the FRU’s serial number ID label.
  • Page 626 Figure 231: Location of the Serial Number ID Label on an AC Power Supply Used in EX4300-48MP and EX4300-48MP-S Switches Serial number ID label Figure 232: Location of the Serial Number ID Label on a DC Power Supply Used in EX4300 Switches module—Figure 233 on page 602 shows the location of the serial number ID label on the fan module for EX4300 switches except EX4300-48MP and EX4300-48MP-S switches.
  • Page 627 Figure 234: Location of the Serial Number ID Label on the Fan Module Used in an EX4300-48MP and EX4300-48MP-S Switches Serial number ID label Uplink modules EX4300 switches except EX4300-48MP and EX4300-48MP-S switches—Figure 235 on page 603 shows the location of the serial number ID label on the QSFP+ uplink module, Figure 237 on page 604 shows the location of the serial number ID label on the 4-port SFP+ uplink module, and...
  • Page 628 Figure 236: Location of the Serial Number ID Label on the 2-Port 40-Gigabit Ethernet QSFP+/100-Gigabit Ethernet QSFP28 Uplink Module for EX4300-48MP Switches Serial number ID label Figure 237: Location of the Serial Number ID Label on the 4-Port SFP+ Uplink Module for EX4300 Switches Except EX4300-48MP and EX4300-48MP-S Switches Figure 238: Location of the Serial Number ID Label on the 8-Port SFP+ Uplink Module S/N: RX3114020039...

  • Page 629: Packing An Qfx5110 Device Or Component For Shipping

    Packing a QFX5110 Switch for Shipping | 606 Packing QFX5110 Components for Shipping | 606 If you are returning a QFX5110 or component to Juniper Networks for repair or replacement, pack the item as described in this topic. Before you pack a QFX5110 or component: Ensure that you have taken the necessary precautions to prevent electrostatic discharge (ESD) damage.

  • Page 630: Packing A Qfx5110 Switch For Shipping

    If you are returning the chassis, an appropriate screwdriver for the mounting screws used on your rack or cabinet. This topic describes: Packing a QFX5110 Switch for Shipping To pack a QFX5110 for shipping: 1. Power down the switch and remove the power cables. See “Powering Off a QFX5110”...

  • Page 631: Packing A Qfx5100 Device Or Component For Shipping

    Packing a QFX5100 Switch for Shipping | 608 Packing QFX5100 Switch Components for Shipping | 608 If you are returning a QFX5100 switch or component to Juniper Networks for repair or replacement, pack the item as described in this topic.

  • Page 632: Packing A Qfx5100 Switch For Shipping

    Antistatic bag, one for each component. If you are returning the chassis, an appropriate screwdriver for the mounting screws used on your rack or cabinet. Packing a QFX5100 Switch for Shipping To pack a QFX5100 switch for shipping: 1. Power down the switch and remove the power cables. See “Powering Off a QFX5100 Device”...

  • Page 633: Packing A Qfx3600 Or Qfx3600-I Device Or Component For Shipping

    Packing a QFX3600 or QFX3600-I Device for Shipping | 610 Packing QFX3600 or QFX3600-I Device Components for Shipping | 610 If you are returning a QFX3600 or QFX3600-I device or component to Juniper Networks for repair or replacement, pack the item as described in this topic.

  • Page 634: Packing A Qfx3600 Or Qfx3600-I Device For Shipping

    If you are returning the chassis, an appropriate screwdriver for the mounting screws used on your rack or cabinet. Packing a QFX3600 or QFX3600-I Device for Shipping To pack a QFX3600 or QFX3600-I device for shipping: 1. Power down the device and remove the power cables. See “Powering Off a QFX3600 Device”...

  • Page 635: Packing A Qfx3500 Device Or Component For Shipping

    Packing a QFX3500 Device for Shipping | 612 Packing QFX3500 Device Components for Shipping | 612 If you are returning a QFX3500 device or component to Juniper Networks for repair or replacement, pack the item as described in this topic.

  • Page 636: Packing A Qfx3500 Device For Shipping

    Packing a QFX3500 Device for Shipping To pack a QFX3500 device for shipping: 1. Power down the device and remove the power cables. See “Powering Off a QFX3500 Device” on page 414. 2. Remove the cables that connect the QFX3500 device to all external devices. 3.

  • Page 637: Packing An Ex4300 Switch Or Component For Shipping

    Packing EX4300 Switch Components for Shipping | 615 Packing an EX4300 Switch for Shipping If you need to transport the switch to another location or return the switch to Juniper Networks, you need to pack the switch securely in its original packaging to prevent damage during transportation.
  • Page 638 1. On the console or other management device connected to the switch, enter the CLI operational mode and issue the following command to shut down the switch software: user@switch> request system halt Wait until a message appears on the console confirming that the operating system has halted. 2.

  • Page 639: Packing Ex4300 Switch Components For Shipping

    6. Place the switch inside the cavity in the bottom packaging foam. 7. Place the top portion of the packaging foam on top of the switch. 8. If you are returning accessories or field-replaceable units (FRUs) with the switch, pack them as instructed “Packing EX4300 Switch Components for Shipping”...

  • Page 640: Returning A Qfx5110 Or Component

    For more information about return and repair policies, see the customer support page at https://www.juniper.net/support/guidelines.html. RELATED DOCUMENTATION QFX5110 Hardware Overview | 10 Returning a QFX5100 Device or Component for Repair or Replacement If you need to return a QFX5100 switch or component to Juniper Networks for repair or replacement, follow this procedure:...

  • Page 641: Returning A Qfx3600 Or Qfx3600-I Device Or Component For Repair Or Replacement

    Returning a QFX3600 or QFX3600-I Device or Component for Repair or Replacement If you need to return a QFX3600 or QFX3600-I device or component to Juniper Networks for repair or replacement, follow this procedure: 1. Determine the serial number of the component. For instructions, see “Locating the Serial Number on...

  • Page 642: Returning A Qfx3500 Device Or Component For Repair Or Replacement

    QFX3600 Device Overview | 45 Returning a QFX3500 Device or Component for Repair or Replacement If you need to return a QFX3500 device or component to Juniper Networks for repair or replacement, follow this procedure: 1. Determine the serial number of the component. For instructions, see “Locating the Serial Number on...

  • Page 643: Returning An Ex4300 Switch Or Component For Repair Or Replacement

    QFX3500 Device Overview | 51 Returning an EX4300 Switch or Component for Repair or Replacement If you need to return an EX4300 switch or hardware component to Juniper Networks for repair or replacement, follow this procedure: 1. Determine the serial number of the component. For instructions, see “Locating the Serial Number on...
  • Page 644 After locating the serial number of the device or component you want to return, open a service request with Juniper Networks Technical Assistance Center (JTAC) on the Web or by telephone. For instructions on locating the serial number of the device or component you want to return, see the...

  • Page 645: Contact Customer Support To Obtain Return Material Authorization

    Returning a QFX10000 Switch or Component for Repair or Replacement Contact Customer Support to Obtain Return Material Authorization If you are returning a device or hardware component to Juniper Networks for repair or replacement, obtain a Return Material Authorization (RMA) number from Juniper Networks Technical Assistance Center (JTAC).
  • Page 646 If you are contacting JTAC by telephone, enter your 12-digit service request number followed by the pound (#) key for an existing case, or press the star (*) key to be routed to the next available support engineer. The support representative validates your request and issues an RMA number for return of the component.

  • Page 647: Alarms And System Log Messages

    CHAPTER 44 Alarms and System Log Messages IN THIS CHAPTER Understand Alarms | 623 Chassis Alarm Messages | 624 Chassis Alarm Messages on a QFX3600 or QFX3600-I Device | 629 Chassis Alarm Messages on a QFX3500 Device | 632 Interface Alarm Messages | 636 Understand Alarm Types and Severity Levels on EX Series Switches | 637 Check Active Alarms with the J-Web Interface | 639 Monitor System Log Messages | 640...

  • Page 648: Chassis Alarm Messages

    Table 131: Alarm Terms and Definitions (continued) Term Definition Alarm severity Seriousness of the alarm. The level of severity can be either major (red) or minor (yellow). levels Major (red)—Indicates a critical situation on the device that has resulted from one of the following conditions.
  • Page 649 Table 132: Chassis Alarm Messages Component Alarm Type CLI Message Recommended Action Fans Major (red) Fan Failure Replace the fan module and report the failure to customer support. Fan I2C Failure Check the system log for one of the following error messages and report the message to customer support: CM ENV Monitor: Get fan speed failed.
  • Page 650 Table 132: Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action Power supplies Major (red) PEM pem-number Airflow not Replace the power supply with a matching Chassis Airflow power supply that supports the same airflow direction as supported by the chassis.
  • Page 651 Table 132: Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action Replace the removed power supply or reboot the switch. The switch can continue to operate with a single power supply. Temperature Major (red) sensor-location Temp Sensor Fail Check the system log for the following sensors error message and report the message...
  • Page 652 However, the alarm has no service impact. If you are unable to resolve the problem, open a support case by using the Case Manager link at https://www.juniper.net/support/ call 1-888-314-5822 (tollfree, US or 1-408-745-9500 (from outside the United States).

  • Page 653: Chassis Alarm Messages On A Qfx3600 Or Qfx3600-I Device

    Chassis Alarm Messages on a QFX3600 or QFX3600-I Device Chassis alarms indicate a failure on the device or one of its components. Chassis alarms are preset and cannot be modified. The chassis alarm message count is displayed on the LCD panel on the front of the device. To view the chassis alarm message text remotely, use the show chassis lcd CLI command.
  • Page 654 Table 133: QFX3600 and QFX3600-I Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action Power supplies Major (red) PEM pem-number Airflow not The power supply airflow direction is matching Chassis Airflow the opposite of the chassis airflow direction. Replace the power supply with a power supply that supports the same airflow direction as the chassis.
  • Page 655 Table 133: QFX3600 and QFX3600-I Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action For information only. Indicates that an AC power supply and DC power supply have been installed in the same chassis. If you wish to remove this alarm message, reboot the device with two AC power supplies or two DC power supplies.

  • Page 656: Chassis Alarm Messages On A Qfx3500 Device

    RELATED DOCUMENTATION Chassis Status LEDs in the QFX3600 and QFX3600-I Device | 518 Configuring Junos OS to Determine Conditions That Trigger Alarms on Different Interface Types alarm Chassis Alarm Messages on a QFX3500 Device Chassis alarms indicate a failure on the device or one of its components. Chassis alarms are preset and cannot be modified.
  • Page 657 Table 134: QFX3500 Chassis Alarm Messages Component Alarm Type CLI Message Recommended Action Fans Major (red) Fan/Blower Absent The fan is missing. Install a fan. Fan Failure Replace the fan and report the failure to customer support. Fan I2C Failure Check the system log for one of the following messages and report the error message to customer support:...
  • Page 658 Table 134: QFX3500 Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action Power Supplies Major (red) PEM pem-number Airflow not The power supply airflow direction is matching Chassis Airflow the opposite of the chassis airflow direction. Replace the power supply with a power supply that supports the same airflow direction as the chassis.
  • Page 659 Table 134: QFX3500 Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action Minor (yellow) PEM pem-number Absent For information only. Indicates the device was powered on with two power supplies installed, but now one is missing. The device can continue to operate with a single power supply.

  • Page 660: Interface Alarm Messages

    Table 134: QFX3500 Chassis Alarm Messages (continued) Component Alarm Type CLI Message Recommended Action Temperature Major (red) sensor-location Temp Sensor Fail Check the system log for the following Sensors message and report it to customer support: Temp sensor sensor-number failed, where sensor-number may range from 1 through 10.

  • Page 661: Understand Alarm Types And Severity Levels On Ex Series Switches

    This topic applies only to the J-Web Application package. Alarms alert you to conditions that might prevent normal operation of the switch. Before monitoring alarms on a Juniper Networks EX Series Ethernet switch, become familiar with the terms defined in Table 135 on page 637.
  • Page 662 Table 135: Alarm Terms (continued) Term Definition chassis alarm Preset alarm triggered by a physical condition on the switch such as a power supply failure, excessive component temperature, or media failure. system alarm Preset alarm triggered by a missing rescue configuration or failure to install a license for a licensed software feature.

  • Page 663: Check Active Alarms With The J-Web Interface

    Check Active Alarms with the J-Web Interface Purpose NOTE: This topic applies only to the J-Web Application package. Use the monitoring functionality to view alarm information for the EX Series switches including alarm type, alarm severity, and a brief description for each active alarm on the switching platform. Action To view the active alarms: 1.

  • Page 664: Monitor System Log Messages

    RELATED DOCUMENTATION Monitor System Log Messages | 640 Dashboard for EX Series Switches | 537 Understand Alarm Types and Severity Levels on EX Series Switches | 637 Monitor System Log Messages Purpose NOTE: This topic applies only to the J-Web Application package. Use the monitoring functionality to filter and view system log messages for EX Series switches.
  • Page 665 Table 137: Filtering System Log Messages (continued) Field Function Your Action Process Specifies the name of the process To specify events generated by a process, generating the events you want to display. type the name of the process. To view all the processes running on your For example, type mgd to list all messages system, enter the CLI command show generated by the management process.
  • Page 666 Table 137: Filtering System Log Messages (continued) Field Function Your Action Reset Resets all the fields in the Events Filter box. To reset the field values that are listed in the Events Filter box, click Reset. Generate Raw Report Generates a list of event log messages in To generate a raw report: nontabular format.
  • Page 667 Meaning Table 138 on page 643 describes the Event Summary fields. NOTE: By default, the View Events page in the J-Web interface displays the most recent 25 events, with severity levels highlighted in different colors. After you specify the filters, Event Summary displays the events matching the specified filters.
  • Page 668 Table 138: Viewing System Log Messages (continued) Field Function Additional Information Severity Severity level of a message is indicated by different A severity level indicates how seriously the colors. triggering event affects switch functions. When you configure a location for logging a facility, you Unknown—Gray—Indicates no severity level is also specify a severity level for the facility.
  • Page 669 Release History Table Release Description 14.1X53 Starting in Junos OS Release 14.1X53, a Raw Report can be generated from the log messages being loaded in the Events Detail table. 14.1X53 Starting in Junos OS Release 14.1X53, a Formatted Report can be generated from event log messages being loaded in an Events Detail table.

This manual is also suitable for:

Qfx5100-24qQfx5100-48sQfx5100-32qQfx5100-96sQfx3500Qfx3600 ... Show all

Table of Contents
