193111-200
INSTALLATION
LINE AMPS
0-2.5
2.6-4.5
4.6-7.5
7.6-12
12.1-16
16.1-18
18.1-22
22.1-24.5
24.6-32.5
32.6-40
40.1-45
45.1-57.5
57.6-78
78.1-102.5
102.6-135
The above table (Table 4-1) is based on 75°C (167°F) rated conductors and 40°C (104°F) ambient temperatures.
Refer to National Electrical Code (2008) Tables 310-16 corrected to 40°C (104°F).
* For 115, 208, and 230-volt lines, use 250-volt disconnect switch.
For 440-480, 575-volt lines, use 600-volt disconnect switch.
* * Two conductors and ground conductor required for single phase.
Three conductors and ground conductor required for three phase.
Recommended minimum size of grounding conductors (based on National Electrical Code 2008 – Table 250-95).

Line Connections to Battery Charger

Follow local code requirements if different than
instructions in this manual.
1. Turn charger OFF.
2. Be sure charger is connected correctly for available
line voltage as instructed above.
3. On charger nameplate, note the AC input amperes
corresponding to the line voltage to which charger
is to be connected. Use that ampere value to select
the proper disconnect switch, fuse, and power cable
sizes from Table 4-1.
4. Route AC power input cable in through knockout
provided in side panel of charger cabinet. Securely
fasten cable wires to a power input terminal inside
charger. Refer to Grounding section of this manual
for proper connection of grounding conductor.
4-2
DISCONNECT BRANCH FUSE SIZE
SWITCH * (AMPERES)
30A
30A
30A
30A
30A
30A
30A
60A
60A
60A
60A
100A
100A
200A
200A
Table 4-1 Recommended AC Input and Branch Fusing
COPPER CABLE SIZE AWG * *
POWER
5 No. 14
7 No. 14
10 No. 14
15 No. 14
20 No. 12
25 No. 10
30 No. 10
35 No. 8
40 No. 8
50 No. 8
60 No. 6
80 No. 4
100 No. 2
125 No. 2
150 No. 1/0
5. With disconnect switch (on AC input power line)
in "OPEN" or "OFF" position, connect power
cable coming from charger, to the switch. Install
fuses in switch.
WARNING
At all times, safety must be considered
an important factor in the installation,
servicing and operation of the product
and skilled, qualified technical assis-
tance should be utilized.
AC Supply Input Conditions:
Supply voltage should not exceed +/-10% of rated
input voltage value. Consistent power should
be provided with fluctuations not to exceed
1200VAC (850Vrms) for a duration longer than 25
Microseconds.
GROUND
No. 14
No. 14
No. 14
No. 14
No. 12
No. 10
No. 10
No. 10
No. 10
No. 10
No. 10
No. 8
No. 8
No. 6
No. 6
