Then, assemble the upper panel's rear cover. The image below shows the parts
corresponding to each phase.
Frontal plastic
cover set
Frontal stainless
steel sheet
Colector box's
socket kit
Frontal cover
Rear cover
Fiat washer M3, lock washer
M3 and hex nut M3
Rear stainless steel cover
Pictogram's acrylic
plus
plus
12
