Inscape Data AirGoggle NVC210 Quick Reference Manual

Hide thumbs Also See for AirGoggle NVC210:

Advertisement

Quick Links

Quick Reference Guide
N
N
N
V
C
2
N
V
C
2
N
V
C
2
1
N
V
C
2
1
V
C
2
1
V
C
2
1
1
0
1
0
0
R
2
0
R
2
0
W
D
0
W
D
Rev.1.2 (Augustl, 2009)

Advertisement

loading
Need help?

Need help?

Do you have a question about the AirGoggle NVC210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Inscape Data AirGoggle NVC210

  • Page 1 Quick Reference Guide Rev.1.2 (Augustl, 2009)
  • Page 2 Please check to make sure the following items are in the box. Content Content Content Content Description Description Description Description Remark Remark Remark Remark NVC210 / NVC210R2 / NVC210WD Main Product Body IP Camera with Auto-Iris Varifocal Lens Input: 100~250V 50-60Hz Power Adapter Output: +12V, 1.5A AC Power Cable...
  • Page 3 Product IP-Installer Viewer Program NVR100 Full featured 16 channel network surveillance recorder software. Network Camera IP installation software NVM1000 enterprise surveillance software is also available in the CDROM. Lens Auto Iris Control CS Lens Mount ring Lens : NVC210 / NVC210R2 / NVC210WD includes an auto-iris varifocal lens. If customized view is required, standard C or CS DC Iris or Non-DC Iris lens can be used.
  • Page 4 Interface Description Interface Description Auto-Iris For use with DC based Auto-Iris Lens Connector Lens Mount Lens Mount Interface For CS Type Lens. To Use C Type Lens, a CS to C Ring Type Lens Adapter is Needed. Audio Line Out conductor mini-jack external...
  • Page 5 Section 6.1 for more detailed description on the Alarm In/Out connections. RS-485 Connector Output PTZ control to PTZ modules. Inscape Data cameras support over 30 PTZ protocol drivers. Drivers maybe found on the product CD- ROM and upload able to the IP camera via the web management interface.
  • Page 6 Composite Video Analog video output signal with 1 V p-p. Available on the NVC210R2 Out (CVBS +/-) and NVC210WD Only. Not Used Not Used Factory Use Factory Use Only Network Link/ -Link LED: Continuous yellow light means that network cable is plugged Activity Indicator in.
  • Page 7 Figure 2-1 Connecting NVC and PC by cross type LAN Cable ① Apply power to the installation PC and start Windows Operating System. ② Apply power to the NVC product and connect it to the installation PC with the crossover LAN cable as shown in Figure 2-1.
  • Page 8 Fig 2-2 Initial mode of IP-Installer ② Network Adapter Selection on Window 2000 or XP If using Windows 2000 or XP, the PC will ask you to select the proper network adaptor as in Figure 2-3. It is important to select the right packet driver for the network adaptor. If the PC is configured to support more than one network (e.g., various MODEM, IEEE1394, etc), the PC can crash if one selects the wrong packet driver.
  • Page 9 “LAN Automatic”, “ADSL Static”, “ADSL Automatic”, “Cable Modem Static”, “Cable Modem Automatic”, which you can choose from. Settings can vary depending on this “Network Mode”. This “Quick Installation Guide” will explain only about “LAN Static” mode in which the PC and the product is directly connected by cross type LAN cable.
  • Page 10 ① Start the software by double-clicking the icon, , on your windows desktop. The NVR100 software is shown in Fig 3-1. ②The NVR100 is designed to display 16 channels simultaneously. user customize the display mode accordingly to fit their needs. (Refer to NVR100 user’s Guide for more detail.) Fig 3-1 NVR100 Initial Mode Camera assignment Button...
  • Page 11 Fig 3-3 Showing Live Images via NVR100 The NVC is designed to be accessed via your favorite web browser in addition to the NVR100 software. In order to access the unit, you must type in the appropriate IP address in the browser. Fig 3-4 is an example of the web interface.
  • Page 12 For NVM1000 Installation, Please refer to the NVM1000 User Manual located on the product CDROM. Become an Inscape Data premiere partner and enjoy the premiere partner’s web portal access where you may download the latest firmware, software, user manual, and product tutorials.
