Appendix A: Touch Keypad Operation Table

Function Enter Key
Enter PIN code +
ARM Mode
Partial Arm Enter PIN code +
Mode
DISARM Mode Enter PIN code +
Note: The following operations are available only in DISARM Mode
Record Alarm Enter PIN code +
Message
Alarm Type 1
Enter PIN code + 01 +
(Siren and
Dialer)
Alarm Type 2
Enter PIN code + 02 +
(No siren,
Dialer only)
Enter PIN code + 03 +
Test Mode
Explanation
Exit Delay: Arm Key LED flashes and beeps
(faster beeps at last 5 second countdown)
ARM Mode: Arm Key LED turns on
Exit Delay: Arm Key LED flashes and beeps
(faster beeps at last 5 second countdown)
Partial Arm Mode: Partial Arm Key LED turns on
Disarm Mode: Disarm Key LED turns on
1. Start recording alarm message (about 10
seconds) Playback will start automatically after
the recording is complete
2. Press to stop recording if message is
shorter than 10 seconds
Record: REC Key LED will flash
Playback: Record Key LED turns on
Siren will sound during alarm
(This is the default type)
Siren will not sound during alarm
Test Mode: Disarm Key flashes
A chime tone will sound when a device signal is
received
Hold key 7 for 3 or more seconds: Test GSM
receiving signal strength
Hold key 8 for 3 or more seconds: Turn on / off the
Wireless Siren
Hold key 9 for 3 or more seconds: Test telephone
SMS
Press Disarm key to exit Test Mode
Wireless Siren Enter PIN code + 04 +
Setting
Enter PIN code + 05 + 1 +
RF
Anti-Jamming
Enter PIN code + 05 + 2 +
Detection
Enter old PIN code + 06 + new
Change PIN
PIN code +
code
Enter PIN code + 07 + 1 +
Key Tone
Enter PIN code + 07 + 2 +
Enter PIN code + 08 + 1 +
Open Door /
Window Alert
Enter PIN code + 08 + 2 +
For HA70F outdoor solar siren
Keys 1 – 8 LEDs will display siren DIP Switch
positions.
- ON position (1) = Key LED on
- OFF position (0) = Key LED off
(Default Dip Switch position: 1111000)
Press Keys 1 – 8 to toggle new House Code DIP
Switch positions.
Press Partial Arm Key to save settings.
For SE822 indoor siren
Key 0 indicates siren is enabled or disabled
- When Enabled: Key 0 LED turns on
- When Disabled: Key 0 LED turns off
(Default: Wireless Siren Disabled)
Press Key 0 to toggle enable/disable.
Press Partial Arm Key to save settings.
Turn On
Turn Off (Default)
Default PIN code: 1234
Turn On (Default)
Turn Off
Turn on
Turn Off (Default)
