Sealey SIEGEN S775 Quick Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instructions protection
1. SAFETY
Familiarise yourself with the application and limitations, as well as the potential hazards of the spray gun.
9
WARNING! Disconnect the spray gun from the air supply before changing accessories, servicing or performing any maintenance.
‰
Ensure spray gun is well maintained and kept in good condition (use an authorised service agent).
9
Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9
Locate the spray gun in a suitable work area, keep area clean and tidy and free from unrelated materials, and ensure that there is
9
adequate ventilation and lighting.
Keep the spray gun clean for best and safest performance.
9
Ensure that the air system has sufficient output for the spray gun air consumption (see specification).
9
Wear approved respiratory protection, safety eye goggles and skin protection.
9
Remove ill fitting clothing. Remove ties, watches, rings and other loose jewellery and tie back long hair.
9
Keep children and unauthorised persons away from the work area.
9
When gun is not in use ensure that the air supply is disconnected.
9
If spraying isocynate based finisher, wear approved respirator/clean air breathing
9
apparatus and cover exposed skin with latex gloves and an impervious hooded
coverall.
Avoid unintentional operation.
9
DO NOT paint were there is any source, or possible source, of ignition as paint
8
mist is extremely flammable.
DO NOT point spray gun at yourself or at other persons or animals.
8
DO NOT carry the gun by the air hose, or yank the hose from the air supply.
8
DO NOT use the spray gun for any purpose other than that for which it is
8
designed.
DO NOT allow untrained persons to operate the spray gun.
8
DO NOT get the spray gun wet or use in damp or wet locations or areas where
8
there is condensation.
DO NOT operate gun if any parts are missing or damaged as this may cause
8
failure and/or personal injury.
DO NOT direct air from the air hose at yourself or others.
8
When not in use switch off the air supply and disconnect the spray gun.
8
2. INTRODUCTION
Ideal for automotive refinishing. Supplied with 1.7mm set-up. Fitted with air regulator
control. Suitable for use with water based paints. Supplied with cam action suction pot.
3. SPECIFICATION
Model No: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .S775
Standard Set-up: . . . . . . . . . . . . . . . . . . . . . . . . 1.7mm
Recommended Air Pressure: . . . . . . . . . . . . . 30 - 70psi
Air Consumption: . . . . . . . . . . . . . . . . . . . . 12 - 15cfm
Pot Capacity: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 900ml
Air Connection:. . . . . . . . . . . . . . . . . . . . . . . . . 1/4"BSP
Available Set-Ups: . . . . . . . . . . . . . . . . . . 1.5, 1.8, 2mm
Nett Weight: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.12kg
© Jack Sealey Limited
SPRAY GUN SUCTION FEED SIEGEN BRAND
1.7MM SET-UP
MODEL NO:
Wear protective Wear safety
gloves footwear
Original Language Version
S775
Wear protective Wear respiratory
clothing protection when
spraying
isocynate
S775 | Issue 3 (H,F) 27/11/18
