4.

Connection Terminals (Through Holes)

Table 4.1 List of Debug Interface Group 1 Connection Terminals
No. Terminal name
1 Vdd
2 #RESET
3 GND
4 Vpp
Table 4.2 List of Debug Interface Group 2 Connection Terminals
No. Terminal name
1 DCLK
2 GND
3 DSIO
4 DST2
Table 4.3 List of Serial Communication Signal Connection Terminals
No. Terminal name
1 P00/SIN0
2 P01/SOUT0
3 GND
S5U1C17656T Manual
(Rev. 1.0)
4. Connection Terminals (Through Holes)
I/O
I/O Target operating voltage input/output
I Target reset signal input
– Power supply (GND)
I Flash programming voltage input
I/O
O Clock signal output for debugging
– Power supply (GND)
I/O Serial communication signal input/output for debugging
O Debug status signal output
I/O
I Serial communication (UART) signal input
O Serial communication (UART) signal output
– Power supply (GND)
