CMOS 16-BIT SINGLE CHIP MICROCONTROLLER
S5U1C17564T1 Manual
(Software Evaluation Tool for S1C17564)
Rev.1.0

Advertisement

Table of Contents
loading

Subscribe to Our Youtube Channel

Summary of Contents for Epson S5U1C17564T1

  • Page 1 CMOS 16-BIT SINGLE CHIP MICROCONTROLLER S5U1C17564T1 Manual (Software Evaluation Tool for S1C17564) Rev.1.0...
  • Page 2 Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as, medical products.
  • Page 3 Configuration of product number Devices 17xxx 00E1 ■Packing specifications 00: Besides tape & reel 0A: TCP BL 2 directions 0B: Tape & reel BACK 0C: TCP BR 2 directions 0D: TCP BT 2 directions 0E: TCP BD 2 directions 0F: Tape & reel FRONT 0G: TCP BT 4 directions...
  • Page 4: Table Of Contents

    Power connector (CN3)..................... 14 4.2.3 EPD panel interface connector (CN2) ................15 Appendix A File organization of the sample software ..........16 Appendix B Circuit diagrams and parts list............... 17 Revision History ......................20 Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 5: Overview

    S1C17564, a single chip microcontroller from Seiko Epson. S5U1C17564T1 is a combination of two boards, a CPU board and a peripheral board. The CPU board is equipped with an IC socket for S1C17564, an extension connector, a debug connector for S1C17564, etc. The peripheral board is equipped with an EPD (Electrophoretic Display), a connector for the EPD, jumpers, through holes, tact switches, etc.
  • Page 6: Using The Board

    (1) You do not need to change the jumper switch settings on the CPU board. (2) Disconnect all the cables to the ICDminiVer.2. (3) Install a coin battery to the battery holder mounted on the peripheral board. (4) Short-circuit the jumper (SW3) on the peripheral board. Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 7 SW27 P40:Hi by SHORT OPEN SW28 P40:Lo by SHORT OPEN SHORT: Short-circuit the jumper switch OPEN: Remove the jumper switch -: Any setting is OK (Other): Set the jumper switch to the specified side. Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 8: Function And Name Of Each Component

    (J4)(Not mounted) Extension connector (J2)(Not mounted) S1C17564 (U1) 1 Pin HVDD-IN AVDD-IN LVDD-IN Extension (J7) (J9) (J8) connector (J1)(Not mounted) Figure 2.1 Names of the components on the front side of the S5U1C17564T1 CPU board. Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 9 (J6) (J5) Figure 2.2 Names of the components on the back side of the S5U1C17564T1 CPU board. Caution! The position of the pin 1 of the CN2-1 (J5) is as shown above. When you connect the ICDminiVer.2 to this board, pay attention to the direction of the connector.
  • Page 10 Do not short-circuit the two power jumper switches (SW1 and SW3) at the same Figure 2.3 Names of the components on the front side of the S5U1C17564T1 peripheral board. *) Components and circuit diagrams are subject to change without notice.
  • Page 11 Coin battery Power-supply External power supply Connector (CN1) Figure 2.4 Names of the components on the back side of the S5U1C17564T1 peripheral board. *) Components and circuit diagrams are subject to change without notice. Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 12: Function Of Each Component

    P43:Lo by SHORT OPEN SW23 P42:Hi by SHORT OPEN SW24 P42:Lo by SHORT OPEN SW25 P41:Hi by SHORT OPEN SW26 P41:Lo by SHORT OPEN SW27 P40:Hi by SHORT OPEN SW28 P40:Lo by SHORT OPEN Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 13: Function Of Each Part

    Thermistor for the measurement of the ambient Thermistor temperature. Used for control of the EPD panel MOS-FET P20-P22 port input switches Tact switch SW13 to SW15 Holder for a coin battery used for operation CR2032 holder check Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 14: Block Diagram

    3. Block diagram Block diagram The following figure shows the block diagram of S5U1C17564T1. Peripheral Board External Power Peripheral Board EPD Panel (PDI 2”) Regulater Jumper Switch x 34 FET/ SHDN/ Tact THR/ Battery Folder switch x 3 CR2032 Level-shifter...
  • Page 15: Connector

    Non connected Non connected SIN1/SDI1/P14 Non connected Non connected Non connected SDA1/REMI/P43 Non connected Non connected Non connected SCL1/REMO/P44 Non connected #BFR/SPISS2/P25 Non connected AVDD AVDD US_SDO0/P51 TOUT4/CAP4/FOUTA/P32 SOUT1/SDO1/P15 AIN3/US_SSI1/P03 SCLK1/SPICLK1/P16 Non connected SDO2/P24(EXCL3) AIN2/US_SSI0/P02 Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 16 Non connected Non connected Non connected P22(EXCL1)/FOUTB P53/US_SDI1 Non connected Non connected Non connected P33/REMI/SPICLK2 Non connected Non connected P23(EXCL2)/SDI2 P34/REMO/#SPISS Non connected Non connected Non connected P54/US_SDO1 Non connected Non connected Non connected P55/US_SCK1 Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 17: Debug Interface Connector (J5 - J6)

    Power(+) Power(GND) Table 4.8 Pin assignment of CPU board power connector (J8) Pin name Function LVDD Power(+) Power(GND) Table 4.9 Pin assignment of CPU board power connector (J9) Pin name Function AVDD Power(+) Power(GND) Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 18: Peripheral Board Connector

    Table 4.10 Pin assignment of peripheral board power connector (CN3) Pin name Function Power(+) Power(GND) *) If you need to supply power for the EPD panel on the peripheral board, connect the power to CN3. (Normally, this connector is not used.) Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 19: Epd Panel Interface Connector (Cn2)

    4. Connector 4.2.3 EPD panel interface connector (CN2) Table 4.11 Pin assignment of EPD interface connector (CN2) Pin name Function BUSY Panel-BUSY SCLK DATA OUT(MCU) DATA IN(MCU) RESET RESET OUT(MCU) Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 20: Appendix A File Organization Of The Sample Software

    ├◆ Application-related source files ├ main.c ├ datatbl.h │ │ ├◆ Driver-related libraries, header files ├ epd.a ├ epd.h ├ osc.c ├ osc.h ├ osc1_wait.s ├ init.h │ │ ├◆ Application-related header files └ datatbl.h Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 21: Appendix B Circuit Diagrams And Parts List

    Appendix B Circuit diagrams and parts list Appendix B Circuit diagrams and parts list Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 22 Resistor 220kΩ/1%,1608 RK73H1JTTD2203F Resistor 330kΩ/1%,1608 RK73H1JTTD3303F Resistor 820kΩ/1%,1608 RK73H1JTTD8203F Thermistor 204-AP2 SEMITEC Resistor 0Ω,1608 RK73Z1JTTD Resistor Not mounted RK73Z1JTTD Resistor Not mounted RK73H1JTTD1004F *1 Components and circuit diagrams are subject to change without notice Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 23 ELECTRIC WIRE AWG#24, length=30cm, SHINAGAWA Wire AWM1007/TR-64 black black ELECTRIC WIRE Coin battery CR2032EC CR2032 TOSHIBA Spacer HIROSUGI-KEIKI M=3, L=9.5mm, Female ASB-309.5E Screw Wilco M=3,L=5 FB-0305N *1 Components are subject to change without notice. Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 24: Revision History

    Revision History Revision History Attachment-1 Rev. No. Date Page Category Contents Rev 0.1 2011/2/2 Newly established Seiko Epson Corporation S5U1C17564T Manual (Rev.1.0)
  • Page 25 EPSON HONG KONG LTD. Unit 715-723, 7/F Trade Square, 681 Cheung Sha Wan Road, Kowloon, Hong Kong. Phone: +852-2585-4600 FAX: +852-2827-4346 EPSON TAIWAN TECHNOLOGY & TRADING LTD. 14F, No. 7, Song Ren Road, Taipei 110, TAIWAN Phone: +886-2-8786-6688 FAX: +886-2-8786-6660 EPSON SINGAPORE PTE., LTD.
