4.4.7
Step7: Eject the SD card
Eject the newly programmed SD card.
4.4.8
Step8: Boot your board off of the SD card
Insert SD card into your (powered-down) board, hold down the USER/BOOT button (if using Black)
and apply power, either by the USB cable or 5V adapter.
If using an original white BeagleBone, you are done.
If using BeagleBone Green and the image is meant to program your on-board eMMC, you'll need
to wait while the programming occurs.
When the flashing is complete, all 4 USRx LEDs will be lit solid.
Note: This can take up to 45 minutes. Power-down your board, remove the SD card and apply
power again to be complete.
13
