- Page 1 LinkIt ONE Release date： 10/27/2015 Version： Wiki: http://www.seeedstudio.com/wiki/LinkIt_ONE Bazaar: http://www.seeedstudio.com/depot/LinkIt-ONE-p-2017.html...
-
Page 2: Document Revision History
Document Revision History Revision Date Author Description Sep 21, 2015 Victor.He Create file... -
Page 3: Table Of Contents
6. Compatible Groves and Shields for LinkIt ONE · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · · ·... - Page 4 Under the supervision of Seeed Technology Inc., this manual has been compiled and published which covered the latest product description and specification. The content of this manual is subject to change without notice.
-
Page 5: Introduction
Wearables and IoT devices to create a powerful development board. Notes: LinkIt ONE board comes with a lot of features and its SDK (Software Development Kit) is quite comprehensive. Read this document thoroughly once before using the board. Being a co-design product basic level Technical Support for... -
Page 6: Features
Provides various interfaces for connecting to most sensors, peripherals, Groves, and other widgets. You are what you wear. Using LinkIt ONE together with MediaTek LinkIt SDK (for Arduino) you will be able to easily turn your ideas into practical prototypes and make them a reality with the Seeed agile manufacturing and promote... -
Page 7: Specifications
Specifications Parameter Value Chipset MT2502A (Aster, ARM7 EJ-S (TM) ) Clock Speed 260MHz Dimensions 3.3x2.1 inches Flash 16MB DC Current Per I/O Pin Analog Pins Digital Output 3.3V Analog Input UART Software based(Serial) ,also known as USB Modem Port and Hardware Serial(Serial1, D0&D1) SD Card Up to 32GB(Class 10) Positioning... -
Page 8: Hardware Overview
Hardware Overview 4.1 Configuration Switches There are 3 slide switches on LinkIt ONE which are used to configure the function/working mode: Switch No. Functionality Position 1 - Functionality Position 2 - Functionality Program Mode MS： In this position, when connected to PC, UART：This position is used to set... -
Page 9: Getting Started
Extract the downloaded files to Arduino IDE folder. Double-Click the .EXE file and install. With the installation of LinkIt ONE SDK, Arduino IDE works a LinkIt ONE IDE. 5.4 Installing Drivers Disable Driver Signature Enforcement if you are using Windows 8/8.1 OS. Read instructions. - Page 10 Install driver from ..\LinkIt_ONE_IDE\drivers\mtk folder. After installing drivers, Device Manger should display the following two ports: MTK USB Debug Port used for uploading code MTK USB Modem Port used for printing message, such as Serial.println()
-
Page 11: Updating Firmware
\LinkIt_ONE_IDE\drivers\mtk from Device Manager. This is known to work on few PCs. 5.5 Updating Firmware The firmware of LinkIt ONE board needs to be updated once in a while. Latest LinkIt ONE SDK comes with a version of firmware. -
Page 12: Uploading Code (Blinky)
The slide switches should be configured for firmware upload (i.e. Put MS/UART in UART position and Power switch in USB position). Open File -> Examples -> Basics -> Blink in LinkIt ONE IDE. Select the COM Port number corresponding to MTK USB Debug port in Tools -> Port. -
Page 13: Inserting Sim Card And Sd Card
Try to use the force perpendicular to the direction of the board, otherwise you might damage the antenna pad. 5.8 Inserting SIM Card and SD Card LinkIt ONE accepts standard size SIM Card and Micro SD Card. Insert them as per the following image:... -
Page 14: Exploring Linkit One Sdk Examples
5.9 Exploring LinkIt ONE SDK Examples LinkIt ONE SDK comes with many examples / sample code to use peripherals like GSM, GPRS, Wi-Fi, BT, Audio, GPS etc. Explore them first and read about API documentation. API documentation are available in... -
Page 15: Compatible Groves And Shields For Linkit One
We manufacture hundreds of Groves and Shields, including sensors, actuators, displays and other modules. You can implement your ideas with those Groves and Shields easily. But, LinkIt ONE does not support all of them. We prepared a list of compatible Groves and Shields: Download the list. -
Page 16: Tutorial Of Sidekick Basic Kit For Linkit One
Tutorial of Sidekick Basic Kit for LinkIt ONE The Sidekick Basic Kit for LinkIt ONE is designed to be used with your LinkIt ONE board. This kit will help you quickly get along well with the platform of LinkIt. It includes many of the most popular accessories for DIY projects : like Breadboard, Jumper wires, Color LEDs, Resistors, Buzzer, etc. -
Page 17: Related Projects
Related Projects If you want to make some awesome projects by LinkIt ONE, here's some projects for reference. 8.1 Make an Instructables Indicator Instructables is really an awesome place to share your awesome project. There’s so many makers here to share their works. -
Page 18: Linkit One Iot Demo
8.2 LinkIt ONE IoT Demo This is an IoT demo make by LinkIt ONE and Grove. With this demo, we can: Display household temperautre, humidity, luminosity, volume control data collection on OLED screen Cloud service, data uploaded to Cloud platform Xively, real-time monitoring ... -
Page 19: Resources
MediaTek_LinkIt_SDK_for_Ardunio Datasheets and User Guides: LinkIt_ONE_Hardware_Reference_Design_v1_0 LinkIt ONE_Pinout Diagram_v1.0【PDF】 MediaTek_LinkIt_Developers_Guide_v1_0【PDF】 MediaTek_MT2502A_SOC_Data_Sheet_v1_0【PDF】 MediaTek_MT5931_Wi-Fi_Data_Sheet_v1_0【PDF】 MediaTek_MT3332_GPS_Data_Sheet_v1_0【PDF】 Getting Help: Seeedstudio LinkIt ONE Forum MediaTek LinkIt ONE Forums See Also: Sidekick Base Kit for LinkIt ONE... - Page 20 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Seeed Studio 102030002...
