Page 1: Indoor Unit
Split-type Packged Air Conditioner Grieta de Colmado de Aire Acondicionado Climatiseur Monobloc de Type Split E S F A DB98-04434A(1) OWNER’S INSTRUCTIONS MANUAL DE INSTRUCCIONES MANUEL D’UTILISATION Indoor Unit Outdoor Unit APC4082E UPC4082E APC4082EC UPC4082EC (Cool) (Refrigeración) (Refroidissement) -
Page 2: Safety Precautions
Safety Precautions WARNING DANGER CAUTION If the power supply cord of this air conditioner is damaged, it must be replaced by the manufacturer or its authorized service personnel only in order to avoid a safety hazard. Do not attempt to install this air conditioner by yourself. This unit contains no user-serviceable parts. -
Page 3: Table Of Contents
Contents REPARING YOUR AIR CONDITIONER Safety Precautions ........2 View of the Unit . -
Page 4: View Of The Unit
View of the Unit Indoor Unit Air flow blades (up/down orientation) Air flow blades (right/left orientation) Automatic shutter Air outlet Air filter Air inlet Control Panel You can operate the air conditioner with the control panel when you do not wish to or cannot operate the air conditioner with the remote control. - Page 5 Outdoor Unit Air inlet(Rear) Air outlet Connection valve...
-
Page 6: Remote Control-Buttons And Display
Remote Control - Buttons and Display Operating mode Temperature setting (Cool, Auto, Dry, Fan) Fan speed (Auto, Low, Medium, High) Timer settings Temperature adjustment buttons On/Off button Sleep timer button Turbo button Fan speed adjustment button Extra button Energy saving button Operating mode selection button (Cool, Auto, Dry, Fan) Air Clean button... -
Page 7: Digital Telecommunicator
Digital Telecommunicator Front Back Connection Telephone jack (Line-line) Plug in DC adaptor Operating indicator It flashes when the ARS is operating. Reset button Press if the digital telecommunicator does not operate normally. Telephone cable port Power cable port Digital telecommunicator Connect telephone line Telephone jack (Line-phone) -
Page 8: Getting Start
etting Start You have just purchased a split-type packaged air conditioner and it has been installed by your installation specialist. You Owner's Instructions contain much valuable information on using your air conditioner. Please take the time to read them as they will help you take full advantage of unit's features. -
Page 9: Inserting The Remote Control Batteries
Inserting the Remote Control Batteries You must insert or replace the remote control batteries when : You purchase the air conditioner The remote control does not work correctly Use two AAA, LR03 1.5V batteries. Do not use old batteries or different kinds of batteries together. Batteries may be completely discharged after 12 months, even if they have not actually been used. -
Page 10: Cooling Your Room
Cooling Your Room You must select the Cool mode if you wish to adjust the : Cooling temperature Fan speed when cooling If necessary, press the button. Result: The air conditioner starts up in the Cool mode. The indoor unit beeps. IMPORTANT The air conditioner is fitted with a protection mechanism to prevent the unit from being damaged when it is started... -
Page 11: Selecting The Automatic Operating Mode
Selecting the Automatic Operating Mode You can start the air conditioner in the Automatic mode from your remote control. In the Automatic mode, the temperature and the optimum fan speed is selected automatically. If necessary, press the button. Result: The air conditioner starts up in the Cool mode. The indoor unit beeps. -
Page 12: Changing The Room Temperature Quickly
Changing the Room Temperature Quickly The Turbo function is used to cool your room as quickly as possible. You have just come home and find that the room is very hot. You wish to cool it down as quickly as possible. The Turbo function operates for 30 minutes with the maximum setting before returning automatically to the mode and temperature previously selected. -
Page 13: Cooling Distant Place
Cooling Distant Place The Extra function is used to cool your room as far as possible. In the Extra mode, the up/down orientation of air flow and fan speed are selected automatically. If necessary, press the button. Result: The air conditioner starts up in the Cool mode. The indoor unit beeps. -
Page 14: Removing Excess Humidity
Removing Excess Humidity If the atmosphere in your room is very humid or damp, you can remove excess humidity without lowering the room temperature too much. If necessary, press the button. Result: The air conditioner starts up in the Cool mode. The indoor unit beeps. -
Page 15: Airing Your Room
Airing Your Room If the atmosphere in your room is stale, you can air the room using the Fan feature. If necessary, press the button. Result: The air conditioner starts up in the Cool mode. The indoor unit beeps. IMPORTANT The air conditioner is fitted with a protection mechanism to prevent the unit from being damaged when it is started immediately after being:... -
Page 16: Selecting Energy Saving Mode
Selecting Energy Saving Mode If your wish to save energy when using your air conditioner, select the Energy saving mode with the Energy saving button. If necessary, press the button. Result: The air conditioner starts up in the Cool mode. The indoor unit beeps. -
Page 17: Cleaning Air In Your Room
Cleaning Air in Your Room You can clean air in your room with an electric dust collector and a deodorizing filter in the indoor unit which remove minute dust particles or odors. Since it is an additional function, you can select it in any mode, even when the air conditioner is turned off. -
Page 18: Adjusting The Air Flow Direction Vertically
Adjusting the Air Flow Direction Vertically Depending on the position of the indoor unit your room, you can adjust the position of the outer air flow blade on the upper part of the unit, thus increasing the efficiency of the air conditioner. Press the button. -
Page 19: Adjusting The Air Flow Direction Horizontally
Adjusting the Air Flow Direction Horizontally There are two sets of air flow blades. Just as the outer air flow blade can be adjusted vertically, the inner blade can be adjusted horizontally. Press the button. Result: The inner blade moves right and left. To stop the blade moving right and left, press the button again. -
Page 20: Setting The On Timer
Setting the On Timer The On timer enables you to switch on the air conditioner automatically after a given period of time. You can set the period of time from 30 minutes to 24 hours. Make sure that the air conditioner is turned off. The On timer can be set only when the air conditioner is turned off. -
Page 21: Setting The Off Timer
Setting the Off Timer The Off timer enables you to switch off the air conditioner automatically after a given period of time. You can set the period of time from 30 minutes to 24 hours. Make sure that the air conditioner is turned on. The Off timer can be set only when the air conditioner is turned on. -
Page 22: Setting The Sleep Timer
Setting the Sleep Timer The Sleep timer can be used to switch the air conditioner off automatically after maximum five hours. Press the button one or more times until the required time is displayed. Possible time is between 0.5 hour and 5 hours inclusive. Result: Each time you press the - The time is adjusted by 0.5 hour or 1 hour. -
Page 23: Using Digital Telecommunicator
Using Digital Telecommunicator You can control the air conditioner by phone after entering a password. Cooling and changing the password are available, and you can also turn the air conditioner off . Call a place where the digital telecommunicator is installed. Result: The ARS is operated after 6 bells. - Page 24 Using Digital Telecommunicator (cont.) To Change the Password Call a place where the digital telecommunicator is installed. Select changing the password by pressing number 8. Enter a new password. Hang up the phone after confirmation. If you forget the password, press the RESET button on the back of the digital telecommunicator.
-
Page 25: Operating Recommendations
Operating Recommendations Here are a few recommendations that you should follow when using your air conditioner. Topic Recommendation Power failure If a power failure occurs when the air conditioner is operating, the unit is switched off. When the power returns, you must press the (ON/OFF) button to restart it. -
Page 26: Cleaning Your Air Conditioner
Cleaning Your Air Conditioner To get the best possible use out of your air conditioner, you must clean it regularly to remove the dust that accumulates on the air filter. IMPORTANT Before cleaning your air conditioner, ensure that you have switched off the breaker for the unit. - Page 27 To Clean the Deodorizing Filter You have to clean the deodorizing filter regularly and the service life of the filter is max. The cleaning cycle of the filter depends on environment of using air conditioner. Open the front grille, then pull out the deodorizing filter. Clean the filter with a vacuum cleaner.
-
Page 28: Solving Common Problems
Solving Common Problems Before contacting the after-sales service, perform the following simple checks. They may save you the time and expense of an unnecessary call. Problem The air conditioner does not operate at all The air conditioner does not operate with the remote control No beep is heard when you press button on the remote control The air conditioner does not cool... -
Page 29: Technical Specifications
Technical Specifications Model APC4082E/APC4082EC Power supply 1Ø, 220-240V~, 50Hz Capacity 40000BTU/ h Power Dissipation 3850W Current 19.5A... - Page 30 THIS AIR CONDITIONER IS MANUFACTURED BY: ESTE AIRE ACONDICIONADO HA SIDO FABRICADO POR: CE CLIMATISEUR EST FABRIQUE PAR: ELECTRONICS Printed in Korea...
