Sunx SF1-F Series Instruction Manual

INSTRUCTION MANUAL
20mm Beam Pitch Individual Beam Output Area Sensor
SF1-F Series
If this product is used as a sensing device for personnel protection, serious body injury or death could result.
Never use this product as a sensing device with any press machine, shearing machine, roll grinding machine, forming machine, vulcanizer, or robot etc. for
protection of a hand or a part of the body.
This product does not include a self-checking circuit for safety functions necessary to allow its use as a sefety device. Thus, a system failure or malfunction
can result in either an energized or a de-energized output condition.
When this product is used as a sensing device in the following applications and if a problem relating to 'law' or 'product liability' occurs, SUNX shall not be
liable for the failure and for the damage or less.
1) Use of this product installed to a machinery or a device as a sensing device to detect a hand or a part of the operator's body entering a dangerous area
and stop the machinery or the device.
WARNING
2) Installation of this product to a protection device for preventing to enter a dangerous area and use of this as a sensing device which detectes a hand or
a part of the operator's body and open/close the door or window.
3) Use of this product as a sensing device for personnel protection (including interlock).
For sensing devices to be used as safety devices for press machines or for personnel protection, use products which meet standards, such as OSHA,
ANSI or IEC etc., for personnel protection applicable in each region or country.
In case of using as a safety device for press machines, use a product approved by the Ministry of Labor in Japan.
1

OUTLINE

This product is 20mm beam pitch area sensor which outputs the beam received/beam interrupted condition of each beam as a serial data.
By using along with the control board (SF1-F64CB), the data output from the sensor can be output separately for each individual beam.
2

SPECIFICATIONS

Sensors
Number of beam channels 8
Item Model No. SF1-F8
Applicable control board
Sensing height 140mm
Sensing range
Beam pitch
Sensing object
Supply voltage
Current consumption Emitter: 55mA or less, Receiver: 60mA or less
Data output
Response time
Emitter
Receiver (Note 1)
Channel-Check Function
Interference prevention function
Protection
Ambient temperature
Ambient humidity
Emitting element
Material
Cable
Weight (total of the emitter and the receiver) 520g approx.
Accessory
Notes: 1) The receiver is not equipped with an incident beam indicator. In case of beam alignment, please confirm the operation from the output indicator of the control board (SF1-F64CB).
2) Mating cable is not supplied with the sensor. Please use it separately. SF1-CC3A (cable length 3m), SF1-CC7A (cable length 7m)
Control board
Model No.
Item
Applicable sensors
Supply voltage
Current consumption
Individual beam outputs
Number of channels
Output operation
Connector
Response time
Input (External, Interference
prevention/Channel-check)
Indicators
Ambient temperature
Ambient humidity
Weight
Notes: 1) Individual outputs not assigned to any beam channel stay at 'OFF'.
2) Please procure the connector and the connector attached cable for connection to the individual beam outputs.
Recommended connector: AXM140415A [manufactured by Matsushita Electric Works Ltd.], HIF3BA-40D-2.54R [manufactured by Hirose Electric CO., LTD.] or other equivalents
Recommended connector attached cable: AYT5140
16 24
SF1-F16 SF1-F24
300mm 460mm
30mm or more opaque object ( 35mm or more opaque object if the setting distance is 0.5m or less.)
Emitter: 70mA or less, Receiver: 75mA or less
Complementary voltage-driver output
Output format: Serial
Output voltage: High...(Supply voltage-2.5V) or more, Low...1.5V or less
Maximum load current: 100mA
Emitting indicator: Green LED (lights up under normal emission, blinks under emitting circuit failure)
Power indicator: Green LED (lights up when the sensor works normally)
Error indicator: Yellow LED/Red LED (blink alternately when the synchronization wire breaks ot the emitting circuit fails)
* The three color indicators blink in rotation when the receiving circuit fails.
Incorporated (Two units of sensors can be mounted closely.)
-10 to +55 (No dew condensation or icing allowed), Storage: -10 to +70
Protection enclosure: Aluminum, Unit case: ABS, Front cover: Acrylic, Lens: Acrylic
2
0.5mm 4-core cabtyre cable, 0.5m long with a round connector at the end
* Use together with the optional mating cable (Note 2)
840g approx. 1,180g approx.
MS-SF1-1 (Sensor mounting bracket):1 set for emitter and receiver
24V DC 10% Ripple P-P 10% or less, Warm-up tome: 500ms or less
NPN open-collector transistor
Maximum sink current: 50mA
Applied voltage: 30V DC or less (between individual beam output and 0V)
Residual voltage: 1.1V or less (at 50mA sink current)
Two 40-pin head connectors for a 2.54mm pitch flat cable, Conforming to MIL-C-83503 (Note 2)
20ms or less (including the sensor's response time)
Power indicator: Red LED (lights up when the power is ON)
Sensor operation indicator: Green LED (lights up when the sensor works normally)
Output indicators: Red LED 64 (each lights up when the output is ON)
-10 to +55 (No dew condensation or icing allowed), Storage: -10 to +70
(40-pin connector-40-pin connector) [manufactured by Matsushita Electric Works Ltd.]
AYT5840 (40-pin connector-40 wires) [manufactured by Matsushita Electric Works Ltd.] or equivalent
Thank you very much for using SUNX products. Please read this Instruction
Manual carefully and thoroughly for the correct and optimum use of this product.
Kindly keep this manual in a convenient place for quick reference.
32 40
SF1-F32 SF1-F40
SF1-F64CB
620mm 780mm
7m
20mm
24V DC 10% Ripple P-P10% or less
Emitter: 85mA or less, Receiver: 90mA or less
10ms or less
Incorporated
IP65 (IEC)
35 to 85% RH, Storage: 35 to 85% RH
Infrared LED (modulated)
1,520g approx. 1,840g approx.
SF1-F64CB
SF1-F
300mA or less (including the sensor)
64 channels
Light-ON (Note 1)
Input voltage: 30V DC or less
Input impedance: 5k approx.
35 to 85% RH, Storage: 35 to 85% RH
200g approx.
48 56
SF1-F48 SF1-F56
940mm 1,100mm
Emitter: 100mA or less, Receiver: 105mA or less
2,180g approx. 2,520g approx.
64
SF1-F64
1,260mm
2,860g approx.
