User Manual – Electric Vehicle Charging Equipment IC-CPD
19. Specifications
Electrical specification
Power:
Rated current:
Rated voltage:
Grid frequency:
Overvoltage category:
Rated short-time withstand current:
Residual current device:
Protection class:
IP protection class:
Variants of the power plug:
Variants of the vehicle charging
inlets and vehicle connectors:
20
max. 3.6 kW
(depending on model and version)
max. 16 A
(depending on the model variant)
1-phase: 100 - 240 V ~
(depending on the model variant)
50 Hz - 60 Hz
II
< 10 kA rms
Type A
II
IP67 (ICCB)
Page 12
Available power plugs for
industrial sockets
Available power plugs for
domestic sockets
Page 11
Available vehicle charging inlets
and vehicle connectors
Dimensions and weight
Dimensions of the IC-CPD charger:
Weight of the IC-CPD charger:
Environmental conditions
Operating temperature:
Storage temperature:
Humidity:
Altitude:
Guidelines and standards
Directives of the European Union:
Standards:
Approx. 3.74 in. x 8.66 in. x 2.32 in.
(95 mm x 220 mm x 59 mm) (wxhxd)
Approx. 5.18 lbs. (2.35 kg)
-22 °F to +122 °F (-30 °C to +50 °C)
-40 °F to +158 °F (-40 °C to +70 °C)
Up to 95%, non-condensing
max. 16,404 ft (5,000 m)
above sea level
• 2014/35/EU, 2014/30/EU
• 2011/65/EU
This IC-CPD charging equipment
meets all applicable IEC and EN
standards and regulations in the
context of national legislation, as
well as the European and inter-
national regulations. If necessary,
the respective declaration of
conformity can be made available
