PRINCIPLE OF OPERATION
The remote control allows you to:
Remotely lock or unlock the vehicle
doors.
Unlock the doors without actively using
a key or remote control (intelligent
access only).
Remotely open the power liftgate (if
equipped).
Remotely start or stop the engine and
user pre-set features (if equipped).
Arm and disarm the anti-theft system.
Activate the panic alarm.
GENERAL INFORMATION ON
RADIO FREQUENCIES
This device complies with Part 15 of the
FCC Rules and with Industry Canada
license-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) This device
must accept any interference received,
including interference that may cause
undesired operation.
Note: Changes or modifications not
expressively approved by the party
responsible for compliance could void the
user's authority to operate the equipment.
The term IC before the radio certification
number only signifies that Industry Canada
technical specifications were met.
The typical operating range for your
transmitter is approximately 33 ft (10 m).
Vehicles with the remote start feature will
have a greater range.
One of the following could cause a
decrease in operating range:
Weather conditions.
Nearby radio towers.
Keys and Remote Controls
Structures around the vehicle.
Other vehicles parked next to your
vehicle.
The radio frequency used by your remote
control can also be used by other radio
transmitters, for example amateur radios,
medical equipment, wireless headphones,
wireless remote controls, cell phones,
battery chargers and alarm systems. If the
frequencies are jammed, you will not be
able to use your remote control. You can
lock and unlock the doors with the key.
Note: Make sure to lock your vehicle before
leaving it unattended.
Note: If you are in range, the remote control
will operate if you press any button
unintentionally.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 0082R and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aptiv 0082R

  • Page 1 Keys and Remote Controls • Structures around the vehicle. PRINCIPLE OF OPERATION • Other vehicles parked next to your The remote control allows you to: vehicle. • Remotely lock or unlock the vehicle The radio frequency used by your remote doors.
  • Page 2: Keys And Remote Controls

    Keys and Remote Controls REMOTE CONTROL Integrated Keyhead Transmitters (If Equipped) Use the key blade to start your vehicle and unlock or lock the driver door from outside your vehicle. The transmitter portion functions as the remote control. E191532 Press the button to release the key. Press and hold the button to fold the key back in when not in use.
  • Page 3 Keys and Remote Controls Replacing the Battery E191533 Note: Refer to local regulations when disposing of transmitter batteries. Insert a screwdriver in the position shown and gently push the clip. Note: Do not wipe off any grease on the battery terminals or on the back surface of 2.
  • Page 4 Keys and Remote Controls Note: Do not touch the battery contacts or the printed circuit board with the screwdriver. 4. Insert a screwdriver as shown to release the battery. E151801 5. Remove the battery. 6. Install a new battery with the + facing Replace the battery cover.
  • Page 5 Keys and Remote Controls Press the unlock button on a linked remote control to recall the memory positions. If you enable the easy-entry-and-exit feature, the seat moves to the easy-entry position. The seat moves to the driver memory position when you put the key in the ignition.
  • Page 6: Wheels And Tires

    Wheels and Tires TIRE PRESSURE MONITORING SYSTEM WARNING The tire pressure monitoring system is not a substitute for manually checking tire pressure. The tire pressure should be checked periodically (at least monthly) using a tire gauge, see Inflating your tires in this chapter. Failure to properly maintain your tire pressure could increase the risk of tire failure, loss of control, vehicle rollover and personal...
  • Page 7 Wheels and Tires illuminates, you should stop and check The tire pressure monitoring system your tires as soon as possible, and inflate complies with part 15 of the FCC rules and them to the proper pressure. Driving on a with RSS-210 of Industry Canada. significantly under-inflated tire causes the Operation is subject to the following two tire to overheat and can lead to tire failure.
  • Page 8 Wheels and Tires Understanding Your Tire Pressure When Your Temporary Spare Tire is Monitoring System Installed When one of your road tires needs to be The tire pressure monitoring system replaced with the temporary spare, the measures pressure in your four road tires system will continue to identify an issue to and sends the tire pressure readings to remind you that the damaged road wheel...
  • Page 9 Wheels and Tires Low tire pressure Possible cause Customer action required warning light Solid warning light Tire(s) under-inflated Make sure tires are at the proper pres- sure. See Inflating your tires in this chapter. After inflating your tires to the manufacturer’s recommended pressure as shown on the Tire Label (located on the edge of driver’s door or the B-Pillar),...
  • Page 10 Advanced Safety and User Experience Troy, MI The device under test is manufactured by the grantee (APTIV Services US LLC) and sold as an OEM product. Per 47 CFR 2.909, 2.927, 2.931, 2.1033, etc…, the grantee must ensure the end-user has all applicable / appropriate operating instructions.
