Wen 94475 Manual

4-1/2" angle grinder
Hide thumbs Also See for 94475:
Table of Contents

Advertisement

Quick Links

Download this manual
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability, ease
of operation, and operator safety. When properly cared for, this product will supply you years of rugged,
trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If
you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.
NOTICE: Please refer to wenproducts.com for the most up-to-date instruction manual.
ANGLE GRINDER
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
4-1/2"
Model # 94475
bit.ly/wenvideo
(M-F 8AM-5PM CST)

Advertisement

Table of Contents
loading

Related Manuals for Wen 94475

Summary of Contents for Wen 94475

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions. If you use your tool properly and for its intended purpose, you will enjoy years of safe, reliable service.

  • Page 2: Table Of Contents

    Know Your Angle Grinder Assembly & Adjustments Operation Maintenance Exploded View & Parts List Warranty Statement PRODUCT SPECIFICATIONS Model Number: 94475 Motor: AC 120V, 60 Hz, 7.5A Rated Speed: 11,000 RPM Grinding Wheel Diameter: 4-1/2 in. (115 mm) Grinding Wheel Arbor Size: 7/8 in.

  • Page 3: Safety Introduction

    SAFETY INTRODUCTION Thanks for purchasing the WEN Angle Grinder. We know you are excited to put your tool to work, but first, please take a moment to read through the manual. This manual provides information regarding potential safety concerns, as well as helpful assembly and operating instructions. Safe operation of this tool requires that you read and understand this operator’s manual and all labels affixed to the tool.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES WARNING! Read all safety warnings and instructions. Failure to follow all instructions may result in electric shock, fire and serious injury. The term “power tool” in the warnings refers to your mains- operated (corded) power tool. Save all warnings and instructions for future reference. WORK AREA SAFETY 1.
  • Page 5 GENERAL SAFETY RULES 6. Dress properly. Do not wear loose clothing or jewelry. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewelry or long hair can be caught in moving parts. 7. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.

  • Page 6: Safety Rules For The Angle Grinder

    SAFETY RULES FOR THE ANGLE GRINDER WARNING: Do not let comfort or familiarity with the product replace strict adherence to product safety rules. Failure to follow the safety instructions may result in serious personal injury. 1. TOOL PURPOSE. This power tool is intended to function as a grinder and sander. Using the tool for opera- tions for which the it was not designed may create a hazard and cause personal injury.
  • Page 7 SAFETY RULES FOR THE ANGLE GRINDER REDUCING KICKBACK Kickback is a sudden reaction to a pinched or snagged rotating grinding wheel or any other accessory. Pinching or snagging causes rapid stalling of the rotating accessory which in turn causes the uncontrolled power tool to be jump toward or away from the operator, depending on direction of the wheel’s movement at the point of pinch- ing.

  • Page 8: Electrical Information

    ELECTRICAL INFORMATION DOUBLE-INSULATED TOOLS The tool’s electrical system is double insulated where two systems of insulation are provided. This eliminates the need for the usual three-wire grounded power cord. Double insulated tools do not need to be grounded, nor should a means for grounding be added to the product. All exposed metal parts are isolated from the internal metal motor components with protecting insulation.

  • Page 9: Know Your Angle Grinder

    KNOW YOUR ANGLE GRINDER Carefully unpack the tool from the packaging. Check all components and compare against the diagram below. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST or email us at techsupport@wenproducts.com.

  • Page 10: Assembly & Adjustments

    ASSEMBLY & ADJUSTMENTS WARNING: To prevent injury from accidental operation, turn OFF and unplug the tool from the power source before assembling or making any adjustments to the tool. INSTALLING THE SIDE HANDLE (Fig. 1) Install the side handle to guide and balance the tool for safe operation.
  • Page 11 (Fig. 4 - 1) to keep the spindle from rotat- ing. NOTE: Always use the supplied outer and inner flange with the same thread size as that of the spindle. Replacement outer flanges (94475-001) and inner flanges (94475-0013) can be purchased from wenproducts.com Fig. 5...

  • Page 12: Operation

    OPERATION WARNING: To prevent serious injury, make sure all the warnings and instructions have been read and understood before operating this tool. ON/OFF SWITCH (Fig. 6) WARNING: DO NOT turn the angle grinder ON or OFF while the tool is under load/contacting the workpiece;...

  • Page 13: Maintenance

    Have your carbon brushes inspected and replaced by a qualified service technician. Replacement carbon brushes (Part No. 94475-032) can be ordered at wenproducts.com. Only genuine WEN replacement brushes designed specifically for your tool should be used.

  • Page 14: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST...
  • Page 15 Bearing Sleeve Wheel Guard 94475-004 (with Lock Screw) 94475-028 Motor Baffle 94475-029 Screw, ST4.2×50 94475-005 Key, 3X10x3.7 Stator, 94475-006 Output Shaft, Φ20.5x67 94475-030 Φ53x40mm(1-9/16 Inch) Screw With Washer, 94475-007 94475-031 Front Housing M4x14 94475-032 Carbon Brush 94475-008 Gear Box Cover...
  • Page 16 LIMITED TWO YEAR WARRANTY WEN Products is committed to build tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
