Wen 4282 Manual

8-inch bench grinder with led lights
Hide thumbs Also See for 4282:
Table of Contents

Advertisement

Quick Links

226002
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
BENCH GRINDER
WITH LED LIGHTS
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
8-INCH
Model # 4282
bit.ly/WENvideo
(M-F 8AM-5PM CST)

Advertisement

Table of Contents
loading

Related Manuals for Wen 4282

Summary of Contents for Wen 4282

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    #60 (Medium Grit, Left Wheel) Wheel Grits: #36 (Coarse Grit, Right Wheel) Net Weight: 30.5 pounds 14 x 10 x 11.75 inches Product Dimensions: Compatible with: • WEN 4288 Cast Iron Bench Grinder Pedestal Stand • WEN 858WW 8-Inch Crimped Benchtop Steel Wire Wheel...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
  • Page 4 GENERAL SAFETY RULES POWER TOOL USE AND CARE 1. Avoid accidental start-ups. Make sure the power switch is in the OFF position before connecting the plug to a power source or carrying the tool. 2. Check power tool for damaged parts. Check for misalignment of moving parts, jamming, breakage, improper mounting, or any other conditions that may affect the tool’s operation.

  • Page 5: Specific Safety Rules For Bench Grinders

    SPECIFIC RULES FOR BENCH GRINDERS WARNING: Do not plug in or operate this tool until the entire manual has been read and understood. Failure to do so may result in personal injury or machine damage. 1. Use only the correct grinding wheels that meet the following requirements: •...
  • Page 6 SPECIFIC RULES FOR THE BENCH GRINDER 16. New wheels may require dressing to make them round. Use a grinding wheel dressing tool (not included) to shape or remove glaze from grinding wheels. 17. Keep the distance between the wheel and tool rest at most a 1/8-inch (3.2 mm) space. Adjust the work rest ac- cordingly as the wheel grinds down to a smaller diameter with use over time.

  • Page 7: Electrical Information

    ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug.

  • Page 8: Unpacking

    UNPACKING Carefully remove the tool and any accessories from the box. Make sure that all items listed in the packing list are included. If any part is damaged or missing, please contact our customer service at (800) 232-1195, M-F 8-5 CST. PACKAGING LIST Fig.

  • Page 9: Know Your Bench Grinder

    KNOW YOUR BENCH GRINDER LED Light Switch Coolant Tray Eye Shield Left Work Rest (Grooved) Grinding Wheel 36 Grit Grinding Wheel 60 Grit Right Work Rest Wheel Guard ON/Off Switch Spark Deflector...

  • Page 10: Assembly

    E - Philips screw M - Lock washer F - Spark deflector with LED assembly (left) Flat washer ASSEMBLY G - Spark deflector with LED assembly (right) Batteries AAA H - Eye shield - Flat washer WARNING: Do not connect to power supply until assembly is complete. Failure to comply could Eye shield lock knob - Work rest knob result in accidental starting and personal injury.
  • Page 11 Fig. 11 tion. I - Washer Fig. 7 NOTE: This bench grinder is compatible with the WEN 4288 Cast Iron Bench Grinder Pedestal Stand. A - Coolant tray bracket 1. Prepare 1/4 in. bolts, flat washers, lock washers and hex nuts B - Coolant tray (not included).

  • Page 12: Operation

    OPERATION WARNING: Always wear eye protection with side shields marked to comply with ANSI Z87.1. Failure Fig. 10 Fig. to do so could result in objects being thrown into your eyes resulting in possible serious injury. USING THE COOLANT TRAY (Fig. 8) The coolant tray allows you to cool overheated workpieces.
  • Page 13 OPERATION Fig. 10 Fig. 13 SHARPENING LAWN MOWER BLADES (Fig. 10) g. 10 Fig. 13 Screwdriver Lawn mower blades are usually sharpened on only one edge and dressed up slightly on the other. Perform this sharpen- ing process on both cutting ends of the blade. Vise After sharpening, be sure to balance the blade by removing additional material from the heavy end.

  • Page 14: Maintenance

    MAINTENANCE WARNING: For your own safety, turn the switch OFF and remove the plug from the electrical outlet before adjusting or performing maintenance inspection work on the bench grinder. GENERAL CLEANING AND MAINTENANCE 1. Regularly check the tool and use a soft brush to remove accumulated dust. Wear safety goggles to protect your eyes while cleaning.
  • Page 15 A wire or buffing wheel can be installed onto either side of the grinder as needed. You know what is the perfect wire wheel for your WEN bench grinder? The WEN 858WW 8-Inch Crimped Benchtop Steel Wire Wheel, with 5/8-inch arbor and .011-inch wire. Purchase your wire wheel today at wenproducts.com.

  • Page 16: Exploded View & Parts List

    EXPLODED VIEW AND PARTS LIST...
  • Page 17 Coolent tray 4286-002 M5x51 Bolt 4282-051 Battery cover 4286-019 Left fixing work rest 4282-052 Lamp cover 4286-020 φ5 Big flat washer 4282-053 ST2.9X8 Screw NOTE: The part numbers have been consolidated with our existing bench grinders WEN 4276 and WEN 4286.

  • Page 18: Warranty

    LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
