Nortek 2GIG Series Installation Instructions

2GIG-TILT1-345
F/G TILT SENSOR, 345MHZ
INSTALLATION INSTRUCTIONS
The Tilt sensor (2GIG-TILT1-345) is designed for use where the lt status needs to
be monitored. A typical applica on would be on a garage door. Other uses might
include, mailbox lid, pet doors, and hinged crawl space doors. This lt sensor
communicates with the control panel using the 345 MHz frequency. Once the
sensor is lted to 45 degrees, the sensor will transmit to the panel. The sensor
will also send a restore signal when sensor is returned to less than 45 degrees.
The 2GIG-TILT1-345 is equipped with a cover tamper switch and low ba ery
monitoring. If the case of the 2GIG-TILT1-345 is removed for any reason, the
radio transmi er will send a tamper alert. Should the ba ery voltage drop below
a prescribed level, the sensor will send a low ba ery report indica ng that the
ba ery requires replacing. The 2GIG-TILT-345 is compa ble with GC2 fi rmware
1.14 and higher.
Contents
Verify that the package includes the following:
• 1—2GIG Garage Door Sensor
• 1—Sensor Backing Plate
• 1—Battery (Installed in Sensor)
• 2—5/8" Phillips Screws
• 1— Double Stick Tape Strip
Installation Tools Required
• Phillips Screw Driver
• Variable Speed Drill with 1/16" Drill Bit
Figure 1.Garage Door Sensor Contents
Figure 2. Garage Door Sensor Descrip on
A
B
C
A Tilt Sensor Top Housing
B Tilt Sensor Base
C Tamper Tab
D Side Slots (for screwdriver)
E Screw Moun ng Holes
Activating Tilt Sensor
Figure 3. Remove Ba ery Tab Insulator
Pull out the ba ery tab insulator. Sensor is now ac vated.
E
D
Locating the Tilt Sensor
For Sec onal Garage Door Installa on: The sensor should be mounted near the
top of the top panel of a garage door as shown in Figure 4.
Typical Garage Door Tilt Sensor Location
Figure 4 Sensor Loca on /Garage Door
If the sensor is being used to monitor something other than a garage door opening,
mount where convenient and in a ver cal posi on.
Mounting Tilt Sensor Base
Figure 5 Moun ng Methods for Sensor Base
TAMPER TAB
Choose op on to mount the sensor base. Both screws and double-s ck tape are
provided with the sensor.
NOTE: Be sure that Tamper Tab on Base faces down towards the fl oor.
Mounting Tilt Sensor
1. To mount the Sensor do the following:
2. Use the Base of the Sensor as a template and mark the moun ng holes for
drilling or the area where Base will be Double S ck taped.
3. Drill holes and install screws OR remove backing from double-s ck tape
and install Base in place. Snap the sensor cover on to the base making sure
that the Tamper Tab on the base aligns with the Tamper bu on as shown in
Figure 5.
Figure 6 Snap Sensor/Cover onto Sensor Base
TAMPER
TAB
TAMPER
BUTTON
BATTERY
If Sensor Base and Sensor/Cover are correctly assembled, the arrow on the side of
the Sensor Cover should be poin ng UP toward the ceiling (See Figure 8).
Figure 7 Sensor Alarm Ac va on
SENSOR SIDE VIEW
RESTORE
ATTACH MOUNTING PLATE
TO TOP PANEL OF THE
SNAP SENSOR ONTO
DOOR
THE MOUNTING PLATE
"UP"
ARROW
TAMPER
TAB ON
BOTTOM
TAMPER
TAB
SENSOR
BASE
SENSOR/
COVER
TILT
ALARM
