2GIG-DW40-345
WIRELESS DOOR/WINDOW CONTACT WITH LOCAL BYPASS

INSTALLATION INSTRUCTIONS

1. The Wireless Door/Window Contact with Local Bypass
(2GIG-DW40-345) is designed for installa on on doors,
windows, and other items having an open/close feature.
It communicates with the control panel using the 2GIG
protocol.
2. Figure 1. Wireless Door Contact Components
CONTACT
PHILLIPS
SCREWS (2)

Box Contents

Verify that the package contains the following:
• 1—Wireless Door/Window Sensor with Ba ery
• 1—Adhesive Tape for Sensor
• 1—Magnet
• 1—Adhesive Tape for Magnet
• 2—Phillips Screws
Activating Contact
To ac vate the ba ery in contact, pull out the plas c ba ery
pull tab and discard it. A red LED will fl ash 5 mes to indicate
that the bypass bu on is enabled.
Figure 2. Removing the Plastic Battery Pull Tab
PLASTIC
BATTERY PULL
TAB
Mounting Orientation
Before moun ng the contact and magnet check the moun ng
orienta on (See Figure 3). There are three (3) lines on the
contact and they must face the magnet.
Figure 3. Contact/Magnet Orientation
RIGHT MOUNTED
CONTACT
CONTACT
MAGNET
5/8"
3 LINES
MAX.
MUST FACE
MAGNET
Mount the contact on the sta onary part of the window or door.
Mount the magnet on the moving part of the window or door.
PRINTER'S INSTRUCTIONS:
ADHESIVE STRIP
FOR MAGNET
MAGNET
ADHESIVE STRIP
FOR CONTACT
CONTACT
LEFT MOUNTED
CONTACT
HIDDEN
LED
5/8"
MAX.
2
A 5/8"(15.875mm) maximum distance is allowed between the
magnet and contact.
Figure 4. Contact/Magnet Location on a Window or Door
CONTACT IS ATTACHED
TO STATIONARY LOCATION
MAGNET
Contact Mounting Methods
First determine if the local bypass bu on will be used. The
local bypass bu on is enabled by default. Disabling the bu on
provides higher security if used as a door/window contact only.
Please see reverse side on instruc ons to enable or disable the
local bypass bu on.
Select the moun ng method that will be used. If the installa on
conforms to UL, open the contact base using a coin in the slots
(See Figure 5). Fasten the contact base permanently to loca on
using the Phillips screws (provided). See Figure 6.
Figure 5. Opening Contact
CONTACT BASE
Figure 6. Permanently Mounting Contact Base
CONTACT
COIN
Figure 7. Double-Stick Tape Mounting Contact & Magnet
REMOVE BACKING
DOUBLE-STICK
TAPE
MAGNET
If installa on is not for a UL installa on, the contact can be
fastened into posi on using double-s ck tape. (See Figure 7).
1. Clean and dry the surface of the moun ng loca ons.
2. Apply the adhesive strips to the contact and magnet.
3. Use fi rm pressure to adhere the contact to the desired
loca on. NOTE: For best results, avoid moun ng the
adhesive tape at temperatures below 50° F (10°C). A er
24 hours, bond will hold at lower temperatures.
PHILLIPS
SCREWS
DOUBLE-STICK TAPE
CONTACT
