Technical Specifications - Cisco MERAKI MS390 Series Installation Manual

MS390-48UX2-HW

Technical Specifications

•
Each model has 1 dedicated management interface
•
Each model has two 120G stack ports
•
Each of the model has modular uplinks where you can choose from 3 different options of 10G and 40G SFP+ and QSFP+ uplink modules
•
Operating temperature for each of the model: -5°C to 45°C
•
Storage and Transportation Temperature: -20°C - 70°C
•
Humidity: 5 to 90%
Model
MS390-24-HW 24 x 1GbE RJ45
MS390-24P-HW 24 x 1GbE RJ45
MS390-24U-HW 24 x 1GbE RJ45
MS390-24UX-HW 24 x mGbE RJ45
MS390-48-HW 48 x 1GbE RJ45
MS390-48P-HW 48 x 1GbE RJ45
MS390-48U-HW 48 x 1GbE RJ45
36 x 100M/1G/2.5G +
MS390-48UX-HW
12 x 100M/1G/2.5G/5G/10G
MS390-48UX2-HW 48 x 100M/1G/2.5G/5G
Product View and Physical Features
Stackable Layer-3 48-port 5Gbe UPOE switch with 10G/40G modular uplinks, hot-swappable
power supplies and hot-swappable fans
PoE/ UPoE
Interfaces
Capabilities
n/a
PoE
UPoE
UPoE
n/a
PoE
UPoE
UPoE
UPoE
Power Load (idle/max) Available PoE
79.2 / 99 W
84.1 / 554.4 W
85.4 / 990.3 W
162.7 / 809.9 W
83.9 / 109.9 W
92.6 / 555 W
145 / 844.9 W
218.5 / 785.5 W
157.9 / 843.8 W
Hot Swap Power Supply
- Yes, Dual
445W Yes, Dual
830W Yes, Dual
560W Yes, Dual
- Yes, Dual
437W Yes, Dual
822W Yes, Dual
490W Yes, Dual
645W Yes, Dual
2
