Free Standing Appliance Refrigerator user manual imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register RSA1Z*** RSA1S*** RSA1U*** RSA1D*** RSA1N*** English... -
Page 2: Key Features Of Refrigerator
KEy fEaturEs of your nEw rEfrigErator Your Samsung Side-By-Side Refrigerator comes equipped with many space-saving, innovative storage and energy-efficient features. • HiDDEn HingEs & Door s/w Slick-covered hidden hinges & door s/w helps Neat & Stylish square frontal view. -
Page 3: Safety Information
safety information safEty inforMation • Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those WARNING described in this manual. - Page 4 safety information • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited WARNING depends on the amount of refrigerant used. •...
- Page 5 - You run risk of causing a fire, malfunction and/or personal injury. • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung electronics service center. • Keep ventilation opening in the appliance enclosure or mounting structure clear of obstruction.
- Page 6 safety information Caution signs for CLEaning • Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury. • Never put fingers or other objects into the dispenser hole and ice chute. - It may cause personal injury or material damage.
- Page 7 safety information aDDitionaL tiPs for ProPEr usagE • Allow the appliance to stand for 2hours after installation. • To get best performance of product, - Do not place foods too closely in front of the vents at the rear of the appliance as it can obstruct free air circulation in the freezer compartment.
-
Page 8: Table Of Contents
RefRIGeRATOR seTTING UP yOUR sIde-by-sIde RefRIGeRATOR OPeRATING The sAMsUNG sIde-by-sIde RefRIGeRATOR TROUbleshOOTING _ contents Getting ready to install the refrigerator Removing the refrigerator doors Reattaching the refrigerator doors Leveling the refrigerator Making minor adjustments to the doors Checking the water dispenser line(optional) Installing the water dispenser line... -
Page 9: Setting Up Your Side-By-Side Refrigerator
GETTING READY TO INSTALL THE REFRIGERATOR Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many state-of-the-art features and efficiencies that this new appliance has to offer. Selecting the best location for the refrigerator •... -
Page 10: Removing The Refrigerator Doors
REMOVING THE REFRIGERATOR DOORS If your entrance won’t allow the refrigerator to pass easily through it, you can remove the doors. 1. Removing the Front Leg Cover First, open both the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise. -
Page 11: Setting Up Your Side-By-Side Refrigerator
setting up your side-by-side refrigerator 2. Removing the freezer door A few things to mention first. • Make sure that you lift the door straight up so the hinges are not bent or broken. • Be careful not to pinch the water tubing and wire harness on the door. • Place doors on a protected surface to prevent scratching or damage. -
Page 12: Removing The Fridge Door
Removing the Fridge Door 1. With the door closed, remove the upper hinge cover . Remove hinge screws off the upper hinge . Be careful that the door does not fall on you as you are removing it. . Remove the door from the lower hinge 1_ setting up using a screwdriver. -
Page 13: Reattaching The Refrigerator Doors
setting up your side-by-side refrigerator rEattaCHing tHE rEfrigErator Doors Once you have safely placed your refrigerator where you plan for it to stay, it is time to put the doors back on. Reattaching the Freezer Door 1. Insert the upper hinge shaft of the freezer door . -
Page 14: Reattaching The Fridge Door
Reattaching the Fridge Door 1. Fit the hole in the corner of the fridge door hinge . Insert the upper hinge shaft . Make sure the hinge is level between the upper hinge hole and the hole on the top of the cabinet reattach hinge screws turning it in a clock wise direction. - Page 15 setting up your side-by-side refrigerator Reattaching the Water Supply Line 1. Insert the water line into the coupler Reattaching the Front Leg Cover Before attaching the cover, check water connector for leakage. Replace the front leg cover by turning the three screws clockwise, as shown in the figure. front Leg Cover screw setting up _1...
-
Page 16: Leveling The Refrigerator
LEVELing tHE rEfrigErator Now that the doors are back on the refrigerator, you will want to make sure the refrigerator is level so you can then make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even. -
Page 17: Making Minor Adjustments To The Doors
setting up your side-by-side refrigerator MaKing Minor aDjustMEnts to tHE Doors Remember, a leveling refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the refrigerator. In the case of the process to correct the imbalance is the same. Open the doors and adjust them, one at a time, as follows: 1. Unscrew the nut from the lower hinge until it reaches the upper end of the bolt... -
Page 18: Installing The Water Dispenser Line
CHECKing tHE watEr DisPEnsEr LinE (oPtionaL) A water dispenser is just one of the helpful features on your new Samsung refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms. - Page 19 setting up your side-by-side refrigerator select the location where the filter is to install. (Model with the filter) - If you wish to reassemble the water inlet and out- let sides of the filter during filter installation, see the reference illustration. - Cut the water line attached to the filter to the appropriate place after measuring the distance between the filter and the cold water tap.
-
Page 20: Connect The Water Line To The Refrigerator
Connect the water line to the refrigerator. - Remove the compressor cover of the refrigerator. - Connect the water line to the valve, as shown in the figure. - When connected, check if there is any leakage. If any, repeat the connection. - Reattach the compressor cover of the refrigerator. - Page 21 setting up your side-by-side refrigerator Removing any residual matter inside the water supply line after installing filter. 1. Turn ON the main water supply & turn OFF the valve to the water supply line. 2. Run water through the dispenser until the water runs clear (approx.
-
Page 22: Operating The Samsung
If you have any further questions, contact your Samsung Electronics service center. 1. Place the refrigerator in an appropriate location with reasonable clearance between the wall and the refrigerator. -
Page 23: Operating The Refrigerator
OPERATING THE REFRIGERATOR Using the Control Panel RSA1Z/U/D RSA1S/N Speeds up the time needed to freeze products in the freezer. This can POWER FREEZE be helpful if you need to quickly freeze items that spoil easily or if the BUTTON temperature in the freezer has warmed dramatically (For example, if the door was left open). -
Page 24: Side-By-Side Refrigerator
SAMSUNG side-by-side refrigerator USING THE DIGITAL DISPLAY “88” segment on Freezer part indicates the current Freezer temperature. “88” segment on Fridge part indicates the current Fridge temperature. RSA1Z/U/D RSA1S/N Power Freeze This icon will light up when you activate the “Power Freeze” feature. “Power Freeze” is great for times when you need a lot of ice. -
Page 25: Controlling The Temperature
Filter Indicator When the filter indicator light is on, it is time to change the filter. Typically this happens about every 6 months. After removing the old water filter and installing a new one (see page 18 for instructions on how to do this), reset the indicator status light by pressing the Ice Type button for about 3 seconds. -
Page 26: Using The Ice And Cold Water Dispenser
SAMSUNG side-by-side refrigerator using tHE iCE anD CoLD watEr DisPEnsEr Press the Ice Type button to select the type of ice you want Ice is made in cubes. When you select “Crushed”, the icemaker grinds the ice cubes into crushed ice. -
Page 27: Shelves And Bins
sHELVEs anD Bins Freezer Ice Chute (Optional) Door Bins Fridge Lamp Cover Glass Shelf Vegetable &Fruit Drawers (Optional) CoolSelect Duo (Optional) Ice Maker Bucket (Optional) Lamp Cover Glass Shelves Drawers (Optional) Front Leg Cover Dairy Bin Tray Utility Beverage Station (Optional) Door Bins operating _... -
Page 28: Storing Food
Storing Food in the Freezer The Samsung Side-By-Side Refrigerator has been designed to provide you with maximum spacesaving features and functions. Here are some of the customized compartments we have created to keep your food fresher, longer. Remember, in order to prevent odor penetration to the ice, stored food should be wrapped securely and as airtight as possible. -
Page 29: Coolselect Duo (Optional)
Storing Food in the Freezer ICe ChUTe WARNING shelVes dOOR bINs dRAWeRs Storing Food in the Fridge shelVes TRAy UTIlITy COOlseleCT dUO (OPTIONAl) fRUIT & VeGeTAble dRAWeR dAIRy bIN dOOR bINs beVeRAGe sTATION (OPTIONAl) Bottles should be stored tightly together so that they do not tip and fall out when the refrigerator door is opened. - Page 30 SAMSUNG side-by-side refrigerator using tHE Coolselect Duo (oPtionaL) The CoolSelect Duo is designed to make your busy life just a little bit easler. Meat When MEat is selected, the temperature of the CoolSelect Duo is suitable for storing meat or ham by entering chill of freezer to it.
-
Page 31: Removing The Freezer Accessories
REMOVING THE FREEZER ACCESSORIES Cleaning and rearranging the interior of the freezer is a snap. 1. Remove the Glass Shelf by pulling the shelf out as far as it will go. Then, gently lift it up and remove it. In case it does not have hooks itself in the back side for not being tilted,a shelf should be placed CAUTION deeply in a proper position where there are blocks... -
Page 32: Removing The Fridge Accessories
side-by-side refrigerator REMOVING THE FRIDGE ACCESSORIES 1. Remove the Glass Shelf by pulling the shelf out as far as it will go. Then, gently lift it up and gently remove it. In case it does not have hooks itself in the back side for not being tilted,a shelf should be placed CAUTION deeply in a proper position where there are blocks... -
Page 33: Cleaning The Refrigerator
SAMSUNG side-by-side refrigerator CLEaning tHE rEfrigErator Caring for your Samsung Side-By-Side Refrigerator prolongs the life of your appliance and helps keep it odor and germ-free. Cleaning the Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth. -
Page 34: Changing The Interior Lights
SAMSUNG side-by-side refrigerator CHANGING THE INTERIOR LIGHTS Do not replace LED lamp privately and please contact the specialized repair staff if necessary. WARNING And make it sure that the new LED lamp is the same as the old one. -
Page 35: Using The Doors
using tHE Doors The refrigerator doors are equipped with a door opening and closing feature that ensures that the doors close all the way and are securely sealed. After opening beyond a certain point, the door will “catch” and remain open. When the door is ajar ahead of the catch that allows it to stay open, it will close automatically. -
Page 36: Troubleshooting
troubleshooting PRObleM sOlUTION the refrigerator does not • Check that the power plug is properly connected. work at all or it does not • Is the temperature control on the display panel set to the correct chill sufficiently. temperature? Try setting it to a lower temperature. • Is the refrigerator in direct sunlight or located too near a heat source? • Is the back of the refrigerator too close to the wall and therefore keeping air from circulating? - Page 37 Correct Disposal of this Product (waste Electrical & Electronic Equipment) English (applicable in the European union and other European countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
