RSA1Z*** RSA1S*** RSA1U*** RSA1D*** RSA1N*** Refrigerator user manual English imagine the possibilities Thank you for purchasing a Samsung product. To receive a more complete service, please register your product at www.samsung.com/global/register Free Standing Appliance...
KEy fEaturEs of your nEw rEfrigErator Your Samsung Side-By-Side Refrigerator comes equipped with many space-saving, innovative storage and energy-efficient features. • HiDDEn HingEs & Door s/w Slick-covered hidden hinges & door s/w helps Neat & Stylish square frontal view.
safety information safEty inforMation • Before operating the appliance, please read this manual thoroughly and retain it for your reference. WARNING • Because these following operating instructions cover various models, the characteristics of your refrigerator may differ slightly from those WARNING described in this manual.
Page 4
safety information • In order to avoid the creation of a flammable gas-air mixture if a leak in the refrigerating circuit occurs, the size of the room in which the appliance may be sited WARNING depends on the amount of refrigerant used. •...
Page 5
- You run risk of causing a fire, malfunction and/or personal injury. • If you smell pharmaceutical or smoke, pull out power plug immediately and contact your Samsung electronics service center. • Keep ventilation opening in the appliance enclosure or mounting structure clear of obstruction.
Page 6
safety information Caution signs for CLEaning • Do not insert your hands into the bottom area under the appliance. - Any sharp edges may cause personal injury. • Never put fingers or other objects into the dispenser hole and ice chute. - It may cause personal injury or material damage.
Page 7
safety information aDDitionaL tiPs for ProPEr usagE • Allow the appliance to stand for 2hours after installation. • To get best performance of product, - Do not place foods too closely in front of the vents at the rear of the appliance as it can obstruct free air circulation in the freezer compartment.
Leveling the refrigerator seTTING UP yOUR sIde-by-sIde Making minor adjustments to the doors RefRIGeRATOR Checking the water dispenser line(optional) Installing the water dispenser line OPeRATING The sAMsUNG Setting up the refrigerator sIde-by-sIde RefRIGeRATOR Operating the refrigerator Using the digital display Controlling the temperature Using the ice and cold water dispenser...
GETTING READY TO INSTALL THE REFRIGERATOR Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many state-of-the-art features and efficiencies that this new appliance has to offer. Selecting the best location for the refrigerator •...
REMOVING THE REFRIGERATOR DOORS If your entrance won’t allow the refrigerator to pass easily through it, you can remove the doors. 1. Removing the Front Leg Cover First, open both the freezer and refrigerator doors, and then take off the front leg cover by turning the three screws counter-clockwise.
setting up your side-by-side refrigerator 2. Removing the freezer door A few things to mention first. • Make sure that you lift the door straight up so the hinges are not bent or broken. • Be careful not to pinch the water tubing and wire harness on the door. • Place doors on a protected surface to prevent scratching or damage.
Removing the Fridge Door 1. With the door closed, remove the upper hinge cover using a screwdriver. . Remove hinge screws and the ground screw by turning counter-clockwise, and take off the upper hinge . Be careful that the door does not fall on you as you are removing it. . Remove the door from the lower hinge by lifting the door straight up 1_ setting up...
setting up your side-by-side refrigerator rEattaCHing tHE rEfrigErator Doors Once you have safely placed your refrigerator where you plan for it to stay, it is time to put the doors back on. Reattaching the Freezer Door 1. Insert the upper hinge shaft into the hole on the corner of the freezer door .
Reattaching the Fridge Door 1. Fit the hole in the corner of the fridge door over the lower hinge . Insert the upper hinge shaft into the hole on the hinge . Make sure the hinge is level between the upper hinge hole and the hole on the top of the cabinet .
Page 15
setting up your side-by-side refrigerator Reattaching the Water Supply Line 1. Insert the water line into the coupler 2.The Water Line must be fully Inserted to the center of transparent coupler to prevent water leakage from the dispenser. 3.Insert the clip in the install pack and check that it holds the line fi rmly. Center of transparent coupler clip A (1/4”)
LEVELing tHE rEfrigErator Now that the doors are back on the refrigerator, you will want to make sure the refrigerator is level so you can then make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even.
setting up your side-by-side refrigerator MaKing Minor aDjustMEnts to tHE Doors Remember, a leveling refrigerator is necessary for getting the doors perfectly even. If you need help, review the previous section on leveling the refrigerator. When the door of the freezer is higher than the fridge adjustment part In the case of the process to correct the imbalance is the same. Open the doors and adjust them, one at a time, as follows: 1. Unscrew the nut from the lower hinge until it reaches the upper end of the bolt...
CHECKing tHE watEr DisPEnsEr LinE (oPtionaL) A water dispenser is just one of the helpful features on your new Samsung refrigerator. To help promote better health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or destroy microorganisms.
Page 19
setting up your side-by-side refrigerator LINE OUTLET select the location where the filter is to install. (Model with the filter) - If you wish to reassemble the water inlet and out- 90 degree SIDE OF let sides of the filter during filter installation, FILTER see the reference illustration.
Connect the water line to the refrigerator. WATER LINE CONNECTION NUT - Remove the compressor cover of the refrigerator. - Connect the water line to the valve, as shown in the figure. - When connected, check if there is any leakage. If any, repeat the connection.
Page 21
setting up your side-by-side refrigerator Removing any residual matter inside the water supply line after installing filter. 1. Turn ON the main water supply & turn OFF the valve to the water supply line. 2. Run water through the dispenser until the water runs Water clear (approx.
If you have any further questions, contact your Samsung Electronics service center. 1. Place the refrigerator in an appropriate location with reasonable clearance between the wall and the refrigerator.
OPERATING THE REFRIGERATOR Using the Control Panel RSA1Z/U/D RSA1S/N Speeds up the time needed to freeze products in the freezer. This can POWER FREEZE be helpful if you need to quickly freeze items that spoil easily or if the BUTTON temperature in the freezer has warmed dramatically (For example, if the door was left open).
SAMSUNG side-by-side refrigerator USING THE DIGITAL DISPLAY “88” segment on Freezer part indicates the current Freezer temperature. “88” segment on Fridge part indicates the current Fridge temperature. RSA1Z/U/D RSA1S/N Power Freeze This icon will light up when you activate the “Power Freeze” feature. “Power Freeze” is great for times when you need a lot of ice.
Filter Indicator When the filter indicator light is on, it is time to change the filter. Typically this happens about every 6 months. After removing the old water filter and installing a new one (see page 18 for instructions on how to do this), reset the indicator status light by pressing the Ice Type button for about 3 seconds.
SAMSUNG side-by-side refrigerator using tHE iCE anD CoLD watEr DisPEnsEr Press the Ice Type button to select the type of ice you want No Ice Select this if you want to turn off the icemaker Ice is made in cubes. When you select “Crushed”, the icemaker grinds the ice cubes into crushed ice.
Storing Food in the Freezer The Samsung Side-By-Side Refrigerator has been designed to provide you with maximum spacesaving features and functions. Here are some of the customized compartments we have created to keep your food fresher, longer. Remember, in order to prevent odor penetration to the ice, stored food should be wrapped securely and as airtight as possible.
Storing Food in the Freezer Do not put your fingers, hands or any other objects in the ice ICe ChUTe chute or the ice maker bucket. This may result in personal injury WARNING or material damage. Can be used to store all types of frozen shelVes food.
Page 30
SAMSUNG side-by-side refrigerator using tHE Coolselect Duo (oPtionaL) The CoolSelect Duo is designed to make your busy life just a little bit easler. Meat When MEat is selected, the temperature of the CoolSelect Duo is suitable for storing meat or ham by entering chill of freezer to it.
REMOVING THE FREEZER ACCESSORIES Cleaning and rearranging the interior of the freezer is a snap. 1. Remove the Glass Shelf by pulling the shelf out as far as it will go. Then, gently lift it up and remove it. In case it does not have hooks itself in the back Block Hook side for not being tilted,a shelf should be placed...
side-by-side refrigerator REMOVING THE FRIDGE ACCESSORIES 1. Remove the Glass Shelf by pulling the shelf out as far as it will go. Then, gently lift it up and gently remove it. In case it does not have hooks itself in the back Block Hook side for not being tilted,a shelf should be placed...
SAMSUNG side-by-side refrigerator CLEaning tHE rEfrigErator Caring for your Samsung Side-By-Side Refrigerator prolongs the life of your appliance and helps keep it odor and germ-free. Cleaning the Interior Clean the inside walls and accessories with a mild detergent and then wipe dry with a soft cloth.
SAMSUNG side-by-side refrigerator CHANGING THE INTERIOR LIGHTS Do not replace LED lamp privately and please contact the specialized repair staff if necessary. WARNING And make it sure that the new LED lamp is the same as the old one.
using tHE Doors The refrigerator doors are equipped with a door opening and closing feature that ensures that the doors close all the way and are securely sealed. After opening beyond a certain point, the door will “catch” and remain open. When the door is ajar ahead of the catch that allows it to stay open, it will close automatically.
troubleshooting PRObleM sOlUTION the refrigerator does not • Check that the power plug is properly connected. work at all or it does not • Is the temperature control on the display panel set to the correct chill sufficiently. temperature? Try setting it to a lower temperature. • Is the refrigerator in direct sunlight or located too near a heat source? • Is the back of the refrigerator too close to the wall and therefore keeping air from circulating?
Page 37
Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) English This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.
