Introduction:

The Sky-Watcher Star Adventurer 2i Body

4
5
1
20
21
18
19
16
17
23
1:Mode Dial
2:Mode Index
3:Polar Scope Cap
4:Battery Case Cover
5:Polar Scope Cover
6:Quick Polaris Finder
7:Mini USB Port
8:RJ-12 6-pins Auto-guider Interface
9:DSLR Shutter Control Port
10:3-Position Slide Switch
11:Right Button and LED Indication
12:Left Button and LED Indication
13:Clutch Knob
3
6
2
22
13
14
15
24
14:Mounting Platform
15:Locking Knob
16:Knurled Ring of Polar Scope
17:Polar Scope
18:Date Graduation Circle
19:Time Meridian Indicator
20:AAx4 Battery Case
21:Time Graduation Circle
22:Time Meridian Indicator Calibration Screw
23:Polar Scope Calibration Screw
24:Worm Gear Meshing Adjustment Screw
25:Socket for 3/8" Thread Screw
26:1/4" to 3/8" Convert Screw Adapter
5
11
10
12
9
8
7
26
25
