Heatcom atria Installation And User Manual page 12

1 Minutes 5 Program button
2 Hours 6 Number of day
3 Days 7 Program
4 Return button 8 Temperature
1 Minutter 5 Program knap
2 Timer 6 Ugedag 1-7
3 Ugedag 7 Program
4 Retur knap 8 Temperatur
1 Minuter 5 Programknapp
2 Timmar 6 Dag (1-7)
3 Dagar 7 Program
4 Återknapp 8 Temperatur
1 Minuutit 5 Ohjelmointi -painike
2 Tunnit 6 Viikonpäivän
3 Päivät numero (1-7)
4 Paluu perus- 7 Ohjelma
näyttöön 8 Huonelämpötila
1 Minutter 5 Programknapp
2 Timer 6 Nummer på dag
3 Dager 7 Program
4 Returknapp 8 Temperatur
1 Minuten 5 Programm Taste
2 Stunden 6 Anzahl Tage
3 Wochentag 7 Programm
4 Zurück zur 8 Raumtemperatur
Basisanzeige
9 Heating on indicator
10 Time (12 or 24 hours)
11 Up/Down button
12 Reset button
9 Symbol for tændt varme
10 12 eller 24 timers visning
11 Op- og nedknap
12 Reset knap
9 Syns när värmen är på
10 Tid (12 alt. 24 timmar)
11 Upp- nerknapp
12 Återställningsknapp
9 Lämmitys päällä
–näyttö
10 Kello (12 tai 24 tuntia)
11 Ylös/alas -painike
12 Reset (nollaus) -
9 Viser varmen som er på
10 Tid (12 eller 24 timer)
11 Opp- og ned-knapp
12 Returknapp
9 Wärmeanzeige
10 Uhrzeit (12/24
Stundenanzeige)
11 Auf/ab Taste
12 Rückstellung
Program Day of Week Time Temp for heat control
1 Weekday 5:00
2 (Mon-Frid) 8:30
3 15:00
4 22:00
5 Saturday 7:00
6 23:00
7 Sunday 7:30
8 22:00
Max. and min. temperature overidning all programs
9 (1-8) Mon-Sun Max
0 (1-8) Mon-Sun Min
Starting thermostat.
When power is on for the first time or
reset is used, the display will show as the
picture after a few seconds.
If the display is different from shown, use
a fine probe such as a straightened paper
clip to gently push the reset button.
22°C
14°C
22°C
14°C
22°C
14°C
22°C
14°C
30°C
25°C
Setting the clock.
Press the D(day), H(hour) or M(minute)
button to set clock. Only the day of week
and time are displayed.
Press D, H or M button for about 2
seconds to start fast advance.
