Loading paper

In the tray

Load the print media you use for the majority of your print jobs in the tray.
The tray can hold a maximum of 150 sheets of 75 g/m
plain paper.
Loading paper in the tray
1 Pull the tray out of the machine.
2 Open the paper cover.
3 Adjust the size of tray until it sound click.
4 Enlarge the tray by adjusting the paper width guide.
5 Flex the paper sheets back and forth to separate pages and then
fan them while holding one edge. Tap the edges of the stack on a
flat surface to even it up.
6
2
(20 lb bond)
7
5.5
<Selecting and loading print media>
Load paper with the print side up.
Make sure not to overfill the tray and that all four corners are flat in
the tray and under the brackets, as shown below. Overfilling the
tray may cause a paper jam.
Squeeze the paper length guide and slide in it until it lightly touches
the end of the paper stack.
