DPS Telecom NetGuardian LPG D-PK-NGLPG User Manual page 41

37
Low ref and High Ref The low and high values for scaling voltage to your display units.
MjU (Major Under)
Threshold settings that, when crossed, will prompt the NetGuardian to set an alarm.
MnU (Minor Under)
Recorded values less than an under value or greater than an over value will cause alarms.
MnO (Minor Over)
MjO (Major Over)
Select the threshold alarms to post. All thresholds, Major Only, Minor Only, Major Over
Post On
Only, Major Under Only.
Enable Checking this box enables Push-to-Talk feature for this analog.
Discrete Input Assign the alarm point associated with this analog.
Length of time, in milliseconds, that an alarm point must be set before before an analog
Qual. Time (ms)
can post.
Select the type of analog gauge represented in the Monitor>User Analogs>Gauge View
Analog Gauge Type
menu
