Ethernet - DPS Telecom NetGuardian LPG D-PK-NGLPG User Manual

10.3

Ethernet

The Edit > Ethernet menu allows you to define and configure Ethernet settings.
MAC Address
Host Name
Enable DHCP
Unit IP
Subnet Mask
Gateway
DNS Server 1
DNS Server 2
Force Max TCP
Window Size
Maximum TCP
Window Size
Note: DNS Server settings are required if a hostname is being used for ping targets.
The Provisioning > Ethernet menu
Ethernet Settings
Hardware address of the NetGuardian LPG Controller. (Not editable - For reference only.)
Used only for web browsing. Example: If you don't want to remember this NetGuardian
LPG Controller's IP address, you can type in a name is this field, such as
"MyNetGuardian LPG Controller". Once you save and reboot the unit, you can now
browse to it locally by simply typing in "MyNetGuardian LPG Controller" in the address
bar. (no "http://" needed).
Used to turn on Dynamic Host Connection Protocol. NOT recommended, because the
unit is assigned an IP address from your DHCP server. The IP you've already assigned to
the unit becomes inactive. Using DHCP means the unit will NOT operate in a T/Mon
environment.
IP address of the NetGuardian LPG Controller.
A road sign to the NetGuardian LPG Controller, telling it whether your packets should
stay on your local network or be forwarded somewhere else on a wide-area network.
An important parameter if you are connected to a wide-area network. It tells the
NetGuardian LPG Controller which machine is the gateway out of your local network. Set
to 255.255.255.255 if not using. Contact your network administrator for this info.
Primary IP address of the domain name server. Set to 255.255.255.255 if not using.
Secondary IP address of the domain name server. Set to 255.255.255.255 is not using.
Advanced TCP Settings
The defined TCP window size is used for low-bandwidth networks.
Sets the TCP receive window size.
27
