Bristan Z2 1/2 C Installation Instructions & User Manual

Specifications Maximum Operating Temperature
Dynamic Water Pressure
Min: 0.5 bar Max: 5.0 bar
3.0
2.0 3.0
2.0
4.0 4.0
1.0 1.0
0.2 5.0
0 5.0
Pressure
Pressure
BAR
BAR
Maximum Static Pressure: 10.0 bar
If the supply pressure is above 3 bar, a
*This will vary depending on system pressure
pressure reducing valve must be fitted
Tools You'll Need
Cross screwdriver
Prior to Installation
All products manufactured and supplied by Bristan are safe
provided they are installed, used correctly and recieve regular
maintenance in accordance with these instructions.
This product has been tested to the Water Regulations Advisory
Scheme (WRAS) and satisfies the requirements of the Water
Supply (Water Fittings) Regulations 1999 and current bylaws.
For full Installation Requirements & Notes (IRN)
please visit wras.co.uk/directory.
We recommend isolation valves to be fitted to the inlet water
supplies to ensure ease of future maintenance.
Before installing these taps the water supply must be thoroughly
flushed in order to remove any swarf, solder etc.
This product must not be modified in any way as this will
invalidate the guarantee.
Installation Instructions
& User Guide
Please leave these instructions
with the end user
Product code: Z2 1/2 C
Inlet Connections
65°C
60°C
60-65°C
recommended
1/2" Male BSP Tap connector
The Flow Valve is timed and
5/Ltr Flow Regulator
will shut off in 15 ± 5 seconds
Adjustable spanner Pipe cutter
Pack Contents
x1
x1
x1
Basket Filter
washer x1
Spare Parts For Your Tap
To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your product.
Installation
1
D4
Fit the tap to the
basin.
3
Pre-Fitted
x1
Connect
the hot and
cold water
supplies
to the
threaded
tails.
Turn
5 6
on water
5
supply for a
few minutes and
check all joints and
Indices
connections for
x2
any leaks.
Blue
Red
Turn on
supply
2
Important
4
If the supply
pressure is above
3 bar a pressure
reducing valve
must be fitted
Please fit the basket
filter washer into
the tail in the order
shown
Operation
7
The tap will shut off up to
15 ±
water
Secure the taps to the basin by using the
washer and metal backnut below the basin
Important
Please ensure
that the correct
colour indice is
fitted
Depending on
chosen hot
or cold water
supply, fit indice
(supplied)
Push down
to get flow of
water
5 seconds*
