Bristan Z2 LUX 1/2 C Installation Instructions & User Manual

Specifications

Maximum Operating Temperature
Dynamic Water Pressure
Min: 0.5 bar Max: 5.0 bar
3.0 3.0
2.0 2.0
4.0
4.0 1.0
1.0
0.2 5.0
0 5.0
Pressure
Pressure BAR
BAR
Maximum Static Pressure: 10.0 bar
If the supply pressure is above 3 bar, a
pressure reducing valve must be fitted
Tools You'll Need
Cross screwdriver

Prior to Installation

All products manufactured and supplied by Bristan are safe
provided they are installed, used correctly and recieve regular
maintenance in accordance with these instructions.
This product has been tested to the Water Regulations Advisory
Scheme (WRAS) and satisfies the requirements of the Water
Supply (Water Fittings) Regulations 1999 and current bylaws.
For full Installation Requirements & Notes (IRN)
please visit wras.co.uk/directory.
We recommend isolation valves to be fitted to the inlet water
supplies to ensure ease of future maintenance.
Before installing these taps the water supply must be thoroughly
flushed in order to remove any swarf, solder etc.
This product must not be modified in any way as this will
invalidate the guarantee.
Installation Instructions
& User Guide
Please leave these instructions
with the end user
Product code: Z2 LUX 1/2 C
Inlet Connections
65°C
60°C
60-65°C
recommended
1/2" Male BSP Tap connector
The Flow Valve is timed and will
shut off in 15 ± 5 seconds
*This will vary depending on system pressure
Adjustable spanner Pipe cutter
Flat screwdriver

Pack Contents

x1
x1
x1

Spare Parts For Your Tap

To replace any spare parts
for your tap, why not
scan the QR Code or
visit www.bristan.com
and search for your product.

Installation

1
D4
3
Secure the taps to the basin
by using the washer and metal
backnut below the basin.
5/Ltr Flow Regulator
Pre-Fitted
5
x1
6
on water
Basket Filter
supply for a
washer x1
few minutes and
Indices
x2
check all joints and
Blue
connections for any
Red
Turn on
water
supply
2
Place the plinths over the holes
in the basin ensuring that the
washers are fitted between the
plinths and the basin.
4
Important
If the supply
pressure is above
3 bar a pressure
reducing valve
must be fitted
Depending on
chosen hot or cold
water supply, fit
the correct colour
indice (supplied)

Operation

Turn
leaks.
The tap will shut off up to
Fit the taps
to the basin.
Please fit the basket
filter washer into
the tail in the order
shown
Connect the
hot or cold
water supplies
to the threaded
tails.
Push down
to get flow of
water
15 5 seconds*
±
