Fels Mobilis ELITE Manual page 38

Données techniques
Données techniques
PVC Line with connection system fitted with self-breaking screws, guaranteeing a tightening of the connections to the ideal torque.
All conductors of the elements without earth marking can be active conductors and supply power or signal when a protection
conductor is not required.
Encombrement L x H x Z
Poids
Tension d'emploi
Calibre
Matière
Montage
Outils nécessaires au montage
Règle d'installation 1
Elements to be clipped in sliding hangers, end to end connection of elements by tightening the connections. For lengths above 140
meters, or when curves, transfer elements, or rigid power cables are fitted, please refer to the section 'Expansion joints' to
determine if an expansion joint is required. Position the elements at a distance from the support large enough to provide access to
the connections and to position the accessories (covering flange, feed box): minimum recommended clearance of 65mm. It is the
responsibility of the fitter to precisely identify the D.C. current poles according to the requirements for the circuit.
Règle de montage 1
www.fels.fr | T +33(0)3 88 67 10 60
The element is identified
64 x 90 x
According to reference
750V
12A, 20A, 40A, 60A, 100A, 130A, 160A, 200A
Self-extinguishing PVC light grey
1. Insert the lines in the sliding hangers, 2. Connect the lines
| F +33 (0)3 88 55 01 79
by a black band
Température d'utilisation
Outils nécessaires au démontage
| Edité le 04/01/2017
over the entire length.
-30°C to +55°C
Page 38/223
