Fels Mobilis ELITE Manual

Hide thumbs Also See for Mobilis ELITE:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Mobilis ELITE and is the answer not in the manual?

Questions and answers

Related Manuals for Fels Mobilis ELITE

Summary of Contents for Fels Mobilis ELITE

  • Page 2: Table Of Contents

    Sommaire Introduction Sélection du produit Calcul de ligne Mobilis Elite Présentation Données techniques Composants Standard straight element High temperature straight element Straight element without earth marking Straight element with protection lips Covering flange End-cap Sliding hanger Fixed hanger Bracket End-line feed...

  • Page 3: Présentation

    Set of 2 special screws for fixed hangers Set of 2 carrier rings Cone for short transfer element Cone for long transfer element Mobilis Movit Présentation {††††‱㔱 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 3/223...

  • Page 4: Données Techniques

    Cleaning and grindding brushes Kit for unclipping sliding hangers Ice shield Gammes historiques Composants {††††′ㄳ Mobilis Elite 200A non -reduced Earth Obsolete range MOBILIS CE www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 5 Brushes of trolleys mobilis CE for lines with transfer element Remote control brush Mobilis CE Obsolete range MOBILIS UNIT Brush for pantograph 100A Mobilis UNIT www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...

  • Page 6: Sélection Du Produit

    Issues of expansion differences in materials considered early at the design stage  Long lengths of line with no expansion joint needed  Expansion joints of innovative and compact design Product selection www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 6/223...
  • Page 7 CAD 2D/3D File Package made available to reduce design & installation costs  Long lengths of line feasible  Unlimited lengths of line due to expansion joints 1. PRESENTATION ® ® Mobilis ELITE Mobilis MOVIT Excellent safety and High mechanical resistance operator protection High currents Operating reliability Reduced voltage drop at...
  • Page 8 CLIENT SERVICE: In order to meet the increasing demand for services on the part of its clients, Fels has developed a capacity for listening and quick reaction within its organization. Each client is provided with permanent and personalized assistance and follow-up. We insist on maintaining close contact, in order to make the commercial and technical transactions, as much productive as possible, and leading to improved quality in the interest of both parties.
  • Page 9 Installation with more than 5 conductors: select Mobilis Movit or arrange 2 Elite lines in parallel  Installations with curves and a radius shorter than 15m, or transfers between different circuits: select Mobilis Elite  Installations with mobile speed greater than 180m/min: choose Mobilis Movit ...

  • Page 10: Calcul De Ligne

    LINE CALCULATION To set the product and the intensity of the MOBILIS ELITE line, two parameters must be considered simultaneously:  The voltage drop on line, which must be below the permissible value  The product current capacity, which depends on the ambient temperature and on the duty cycle factor.
  • Page 11 Mobilis line calculation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 12 One end-line feeding point Three feeding points One midway feeding point Four feeding points Two feeding points Five feeding points Mobilis line calculation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 12/223...
  • Page 13 Continuous operation under 400V at 50Hz, 35°C Start-up phase graph Starting : 2 seconds maximum under 400V at 50Hz, 35°C Mobilis line calculation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 14 Continuous operation under 400V at 50Hz, 35°C Start-up phase graph Starting : 2 seconds maximum under 400V at 50Hz, 35°C Mobilis line calculation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 15 6. DUTY CYCLE FACTOR The maximum permissible intensity in amperes depends on the maximum permissible ambient temperature for the feeding rail considered, on the ambient temperature, on the duty cycle factor (rate of equipment use over a short period), and on the Joule effect due to current carrying. The duty cycle factor depends on the rate of equipment use, defined over ten-minute time periods and expressed in %, corresponds to the ratio running time over total time.
  • Page 17 The electrical supply rail Mobilis Elite meets the requirements of the most demanding manufacturers, installers, and end-users of mobile equipment: higher safety, fast assembling, operation reliability, and easy maintenance of this electrical supply rail for travelling cranes and other mobile equipment requiring mobile power socket.
  • Page 18  Optimized cellular structures for excellent rigidity to the PVC, preventing access to dangerous inner sections, and minimal weight. Fels was the first to introduce the cellular structure of Mobilis Elite on the market.  Closed system for maximum safety, protecting against access to dangerous sections, even under rain, according to international standards.
  • Page 19 We do not accept responsibility for any defects arising from faulty supervision or maintenance. We also disclaim liability for any production stoppages that may result. Any arbitration shall be held in Strasbourg, even when several defendants are involved. Mobilis Elite presentation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 20 2. GENERAL TECHNICAL DATA: Rated operational intensity: The MOBILIS ELITE lines are available in several intensities 20 A, 40 A, 60 A, 100 A, 130 A, 160 A and 200 A. Number of poles: The MOBILIS ELITE lines are available in 4-pole or 5-pole version.
  • Page 21  (1) With protective lips for dust and special trolley for low temperatures The Mobilis Elite feeding system is exclusively designed to run with opening of the casing facing downwards. Validate suitability of the product to run in unfavorable environmental conditions (e.g. humid air flow, steam, frost…).
  • Page 22 The Mobilis Elite range is designed for both inside and external use. If a Mobilis Elite line is used in an area open to the public, additional safety measures should be installed (protection level IP4X required according to EN60204-32).
  • Page 23 1,78 1,26 0,81 0,59 0,43 0,32 Z at 40°C 36,5 12,2 1,82 1,28 0,82 0,60 0,44 0,33 Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 23/223...
  • Page 24 0,17 0,17 standard 0,347* 0,347* 0,347* 0,347* 0,347* 0,347* 0,343 H.T. 0,36* 0,36* 0,36* 0,36* 0,36* 0,36* Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 24/223...
  • Page 25 140A 35°C 100% 114A 120A 152A 184A 40°C 100% 106A 109A 145A 171A 55°C 100% 121A 126A Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 25/223...
  • Page 26 70°C 0,66 0,82 0,89 0,66 0,63 0,64 0,65 75°C 0,57 0,71 0,89 0,77 0,57 0,55 0,56 0,56 Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 26/223...
  • Page 27 For lines longer than the lengths in the below table, an expansion joint will be required: 12-20A 100A 130A 160A 200A-TR Intensity Maximum Length Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 27/223...
  • Page 28 When feeds with rigid cables are located close to the anchoring points, the standard rules apply. Otherwise, lengths without expansion joints are limited to 30m for in-line feeds between two anchoring points. Beyond this, an expansion joint is required: Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 29 These limits are etched on the body of the ELITE trolley with 4 to 6 casters: Monitoring of trolleys Replace MOBILIS Elite trolleys every 10,000 km approximately (trolleys, 4 to 6 casters, or every 3,000 km approximately for trolleys with 2 casters – these values may be reduced according to the...
  • Page 30 We do not accept responsibility for any defects arising from faulty supervision or maintenance. We also disclaim liability for any production stoppages that may result. Any arbitration shall be held in Strasbourg, even when several defendants are involved. Mobilis Elite Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 31: Composants

    Composants Mobilis Elite Standard straight element Straight element with built-in conductors and pre-mounted connections, usable up to 55°C ambient temperature. Description Feeds mobile trolley ensures insulation protection against accidental contact. Categorie Standard Avantage n°1 Easy and fast connection, safe assembling Avantage n°2...
  • Page 32 Température d'utilisation -30°C to +55°C Calibre 12A, 20A, 40A, 60A, 100A, 130A, 160A, 200A Matière Self-extinguishing PVC light grey Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/Gaine_2010_06.7z Fichier 2D d'implantation face http://catalogue.fels.fr/medias/produits/Gaine_face_DXF.7z Fichier 2D d'implantation profil http://catalogue.fels.fr/medias/produits/Gaine_profile_DXF.7z Fichier 2D d'implantation dessus http://catalogue.fels.fr/medias/produits/Gaine_top_DXF.7z Montage Outils nécessaires au montage...
  • Page 33 Règle de montage 2 Règle de montage 3 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 33/223...

  • Page 34: High Temperature Straight Element

    Composants Mobilis Elite High temperature straight element Straight element with built-in conductors and pre-mounted connections, usable up to 75°C ambient temperature. Description Feeds mobile trolley ensures insulation protection against accidental contact. Categorie High Temperature Avantage n°1 Can be used up to +75°C Avantage n°2...
  • Page 35 (covering flange, feed box): minimum recommended clearance of 65mm. Règle de montage 1 1. Insert the lines in the sliding hangers, 2. Connect the lines Règle de montage 2 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 36 Règle de montage 3 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 36/223...

  • Page 37: Straight Element Without Earth Marking

    Composants Mobilis Elite Straight element without earth marking Straight element without earth marking, with built-in conductors and pre-mounted connections, usable up to 55°C. Description Feeds mobile trolley ensures insulation protection against accidental contact. Categorie Without PE Avantage n°1 All conductors may be used as active conductors Avantage n°2...
  • Page 38 D.C. current poles according to the requirements for the circuit. Règle de montage 1 1. Insert the lines in the sliding hangers, 2. Connect the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 39 Règle de montage 2 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 39/223...
  • Page 40 Règle de montage 3 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 40/223...

  • Page 41: Straight Element With Protection Lips

    Composants Mobilis Elite Straight element with protection lips Straight element with built-in conductors and pre-mounted connections, dust protection lips pre-mounted in factory, usable up to 55°C ambient temperature. Description Feeds mobile trolley ensures insulation protection against accidental contact dust. Categorie With lips Avantage n°1...
  • Page 42 (covering flange, feed box): minimum recommended clearance of 65mm. Règle de montage 1 1. Insert the lines in the sliding hangers, 2. Connect the lines Règle de montage 2 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 43 Repeat the application of silicone grease between the lips if excessive adhesion is observed. The assembling of the lips can be made workshop using specific tools, please enquire. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 43/223...

  • Page 44: Covering Flange

    Composants Mobilis Elite Covering flange Accessory for electrical insulation of the junctions. Description The covering flange is used to protect the operator against direct contact with the connections. It also ensures the protection of the junctions against hard conditions of the environment. Assembling only possible if the heads of the connection screws have been correctly broken.
  • Page 45 Calibre 12A, 20A, 40A, 60A, 100A, 130A, 160A, 200A Matière Self-extinguishing thermoplastic Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/Couvre_joint_2010_06.7z Montage Outils nécessaires au montage Outils nécessaires au démontage Règle d'installation 1 Provide one element at each junction, outside feeding points. Choose the version for curves (ME2000-CO or ME2000-COLV),...
  • Page 46 Règle de montage 2 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 46/223...

  • Page 47: End-Cap

    Composants Mobilis Elite End-cap Provides the insulation of live elements at the ends of the line. Description The end-cap must be placed at each end of the line to ensure operator protection. Its use is required for CE conformance. Categorie Standard Avantage n°1...
  • Page 48 Close line making sure place grooves another. Règle de montage 2 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 48/223...

  • Page 49: Sliding Hanger

    Avantage n°2 Easy assembling by screw and simple clip-on of the line Références et compatibilités Références et variantes ME1510: sliding hanger fully pre-mounted, fits brackets and line elements of Mobilis Elite line. For suspension with anchoring, refer 'Fixed hangers'. Données techniques Données techniques...
  • Page 50 Température d'utilisation -30°C to +75°C Matière zinc coated steel Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/Suspension_coulissante_2010_06.7z Montage Outils nécessaires au montage Outils nécessaires au démontage Règle de montage 1 Simply clip-on the line between the sides of the sliding hanger. Requires two wrenches No. 13 for assembling on the support.
  • Page 51 Règle de montage 3 Maintenance Preventive maintenance external dusty installations: check that lines slide freely. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 51/223...

  • Page 52: Fixed Hanger

    Composants Mobilis Elite Fixed hanger Fixes the position of the line and special curved elements and transfer elements. Description The fixed hanger is built on the basis of the sliding hanger. It is entirely pre-mounted and equipped with 2 compression screws...
  • Page 53 Règle de montage 1 Clip-on elements line, place them longitudinally: tighten fully compression screws. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 53/223...
  • Page 54 Règle de montage 2 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 54/223...

  • Page 55: Bracket

    Composants Mobilis Elite Bracket Ensures the mechanical link connection between the structure of the frame and the sliding hangers, fixes the position of the line in relation with the running rail. Description The fixing bracket allows to maintain the clearance between the line and the travel path. This clearance must be as parallel as possible.
  • Page 56 Encombrement Température d'utilisation -30°C to +75°C Matière Zinc coated steel Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/Support_a_pince_F.7z Montage Outils nécessaires au montage Outils nécessaires au démontage www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 57 Align the assembling holes of the sliding hangers in parallel to the travel path Règle de montage 2 Règle de montage 3 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 57/223...

  • Page 58: End-Line Feed

    Composants Mobilis Elite End-line feed Interface accessory for the electrical connection of the line at end of line. Description For electrical connection of the installation end of line. Feeds in line are also available. For copper and aluminum flexible cable. For use with aluminum cables, provide bi-metallic cable eye stiffeners and cables of minimum section of 16mm²...
  • Page 59 Disponible avec lèvres ? compatible Disponible en version haute température ? compatible Disponible en version sans terre ? Disponible en version courbe ? compatible www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 59/223...
  • Page 60 The cable should not impede the free expansion of the line: provide adequate free loop of flexible cable. Provide cable eye stiffeners connection Ø5mm, screws bolts included. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 60/223...
  • Page 61 Règle de montage 2 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 61/223...

  • Page 62: M25-M32 In-Line Feed

    Composants Mobilis Elite M25-M32 in-line feed Interface accessory for the electrical connection of the line on a connection in-line. Description To be inserted in replacement of a covering flange for the electrical connection of the installation in-line. End feeds are also available.
  • Page 63 Disponible avec lèvres ? Disponible en version haute température ? compatible Disponible en version sans terre ? Disponible en version courbe ? compatible www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 63/223...
  • Page 64 'Lt' section taken into account equals half the length of the line. For more than one feeding point in line, please review the following graph for the position of the points and related voltage drops. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 65 The cable should not impede the free expansion of the line: provide adequate free loop of flexible cable. Provide cable eye stiffeners connection Ø5mm, screws bolts included. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 65/223...
  • Page 66 Règle de montage 2 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 66/223...

  • Page 67: M40 In-Line Feed

    Composants Mobilis Elite M40 in-line feed Interface accessory for the electrical connection of the line at a junction in-line. Description To be inserted in replacement of a covering flange for the electrical connection of the installation in-line. End feeds are also available.
  • Page 68 Disponible avec lèvres ? Disponible en version haute température ? compatible Disponible en version sans terre ? Disponible en version courbe ? www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 68/223...
  • Page 69 With the version for curves, no limit for the radius at the curve-straight element junction, otherwise minimum radius R… at curve-curve junction. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 70 The cable should not impede the free expansion of the line: provide adequate free loop of flexible cable. If single wire aluminium cables used (multistrand prohibited), contact lubricant. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 70/223...
  • Page 71 Règle de montage 2 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 71/223...

  • Page 72: Pre -Mounted Feed Box On Straight Element

    Composants Mobilis Elite Pre -mounted feed box on straight element Interface accessory for the electrical connection of the pre-mounted line on a straight element. Description Pre-mounted on 1 or 4m of standard line element, renovation with 2m cable for standard version. Connecting box aside required. L...
  • Page 73 Calibre 100A, 130A, 160A, 200A-TR Matière Self-extinguishing thermoplastic, zinc coated steel Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/boite_d_alimentation_premontee_sur_element_droit.7z Montage Outils nécessaires au montage Outils nécessaires au démontage Règle d'installation 1 Fitted in place of a straight element. Provide a connecting box aside (not supplied). L = 4m: 3 sliding hangers. L = 1m: 2 sliding hangers.
  • Page 74 1. Clip-on the line in the sliding hangers, 2. Connect the line element at the ends, 3. Connect the cables in the box aside. The cable should impede free expansion line. Provide adequate free loop before junction box. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 74/223...
  • Page 75 Règle de montage 2 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 75/223...

  • Page 76: Introduction Gate

    Composants Mobilis Elite Introduction gate Allows trolleys to be removed or inserted in-line. Description Introduction gates are designed to facilitate access to the collector trolleys, mainly for maintenance purposes. The introduction gate has a standard length of 2m and is supported by 2 special sliding hangers for the lateral displacement of the two line sections. It replaces a standard element of 2 meters.
  • Page 77 1. Install the swivelling suspensions 2. Clip-on the straight elements of the introduction gate in the swivelling sliding hangers 3. Connect the straight elements to each other 4. Position the covering flange 5. Lock the swivelling sliding hanger. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 78 Règle de montage 2 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 78/223...

  • Page 79: Ventilation Element

    Composants Mobilis Elite Ventilation element Limits condensation in a line with a warm section (interior) and a cold section (exterior) of a building. Description The purpose of the ventilation element is to limit condensation in a line with a warm section (inside the factory) and a cold section (outside factory).
  • Page 80 According to reference Tension d'emploi According to reference Calibre 12A, 20A, 40A, 60A, 100A, 130A, 160A, 200A-TR Matière PVC and self-extinguishing thermoplastic, copper www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 80/223...
  • Page 81 2 sliding hangers with a centre axis distance of 500 mm for 1m elements, 1000mm for 4m elements. 1. Insert the lines sliding hangers, Connect lines. Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 81/223...

  • Page 82: Expansion Joint

    The expansion joint is a line accessory which is designed to absorb the difference in expansion between the support structure and the Mobilis Elite line within the whole temperature range of the product, thereby ensuring the continuity of the electrical supply for the conductors and also the mechanical continuity for the sliding of the brushes and the trolley guides.
  • Page 83 Données techniques Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 83/223...
  • Page 84 Calibre 20A, 40A, 60A, 100A, 130A, 160A, 200A Matière Self-extinguishing PVC and thermoplastic Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/Joint_de_dilatation_2010_06.7z Montage Outils nécessaires au montage Outils nécessaires au démontage Règle d'installation 1 General case: Refer to the following diagram and the technical data for the layout of the expansion joints. Whenever the installation includes rigid cables impeding the expansion of the line, please request from us the Instruction Sheet SPST326.
  • Page 85 The expansion joint must always be placed exactly at mid-point between two fixed hangers. Increase setting Length +5mm surrounding working temperature from -30°C +75°C. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 85/223...
  • Page 86 Règle de montage 2 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 86/223...

  • Page 87: Horizontal Curve

    Composants Mobilis Elite Horizontal curve Curved element bent in the horizontal plane with built-in conductors and pre-mounted connections. Description The curves are prepared in factory with the precise radius and angle of curve needed to maintain the feeding line at a constant distance from the travel path.
  • Page 88 JOINTS: When a straight line section is located between 2 curves, provide an expansion joint for lines with length above the values below. Image d'installation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 89 1. Insert the lines in the fixed hangers, 2. Connect the lines, 3. Tighten the screws of the fixed hangers, 4. Adjust the position carrier have trolley collector move smoothly. Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 89/223...

  • Page 90: Transfer Elements

    Composants Mobilis Elite Transfer elements Ensures the passage of the trolley between discontinuous sections. Description The purpose of the transfer elements is to ensure the trolley crosses over mechanically discontinuous line sections, for instance as in the case of switches. They can also be used for circuit interruptions (the advantage being that they actually cut the electrical circuit).
  • Page 91 Disponible avec lèvres ? Disponible en version haute température ? Disponible en version sans terre ? Disponible en version courbe ? www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 91/223...
  • Page 92 Outils nécessaires au démontage Règle d'installation 1 Support each transfer element by 2 fixed hangers in accordance with the diagrams below. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 92/223...
  • Page 93 - the mechanical condition of the transfer elements and the trolleys (rollers, brushes, signs wear cones etc.). www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 93/223...

  • Page 94: Circuit Interruption Element

    Composants Mobilis Elite Circuit interruption element Ensures the electrical insulation between 2 sections in the same feeding line. Description The purpose of the circuit interruption element is to insulate electrically one part of the line from another. Example: on a line with several travelling cranes, the circuit interruption element allows maintenance to be carried out on a crane (in a well defined area) while the other cranes continue to run.
  • Page 95 Elements to be clipped in sliding hangers, connection of the elements end to end by tightening the connections. Règle de montage 1 1. Insert the lines in the sliding hangers, 2. Connect the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 96 Regular inspection is required to check the insulation between the conductors of the same pole on both sides of the interruption, at least once year. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...

  • Page 97: Rigid Trolleys

    H07-RNF (4 X 4 mm² or 5 X 4 mm² or 6 mm²). The prewired trolley can be delivered with a cable length of 1m (standard), or more (on request). The carbon brush (or brushes) are the parts of the Mobilis Elite trolley most subject to wear.
  • Page 98 Références et variantes Disponible en version sans terre ? Disponible en version courbe ? see 'articulated trolleys Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 98/223...
  • Page 99 Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 99/223...
  • Page 100 40A, 80A, 120A Tension d'emploi 750V Température d'utilisation -20°C to +75°C Matière Self-extinguishing thermoplastic, self-lubricating carbon brushes, galvanized steel Fichier 3D à télécharger http://catalogue.fels.fr/medias/produits/Chariot_double_2010_06.7z Montage Outils nécessaires au montage Outils nécessaires au démontage Règle d'installation 1 Providing introduction gate allows...
  • Page 101 A simple screwdriver only is necessary. An indicator showing the maximum wear tolerance etched body trolley. Check play wear rollers. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 101/223...
  • Page 102 Image maintenance www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 102/223...

  • Page 103: Simplified Trolleys

    1m (standard), or more (on request). The carbon brushes (or brushes) are the parts of the Mobilis Elite trolley most subject to wear. They can be easily replaced without intervention on wiring. A simple screwdriver is all that is needed.
  • Page 104 Disponible en version haute température ? Disponible en version sans terre ? Disponible en version courbe ? Données techniques Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 104/223...
  • Page 105 Règle de montage 1 Provide adequate loop of cable so as not to impede the motion of the trolley www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 105/223...
  • Page 106 Règle de montage 2 Maintenance Check the wear of the brushes and the general state of the trolley periodically www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 106/223...

  • Page 107: Articulated Trolley

    1m (standard), or more (on request). The carbon brush (or brushes) are the parts of the Mobilis Elite trolley most subject to wear. They can be easily replaced without intervention on wiring. A simple screwdriver is all that is needed.
  • Page 108 Références et variantes Disponible en version sans terre ? Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 108/223...
  • Page 109 According to reference Calibre du chariot 40A, 80A, 120A Tension d'emploi 750V Température d'utilisation -20°C to +75°C Matière Self-extinguishing thermoplastic, self-lubricating carbon brushes www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 109/223...
  • Page 110 50mm. Règle de montage 1 Adjust the position of the trainer to cross over junctions smoothly. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 110/223...
  • Page 111 A simple screwdriver only is necessary. An indicator showing the maximum wear tolerance etched body trolley. Check play wear rollers. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 111/223...

  • Page 112: Special Trolley For Transfer Element

    The self-lubricating carbon brushes, are mounted on springs, thereby guaranteeing a permanent contact with the conductor. The carbon brush (or brushes) are the parts of the Mobilis Elite trolley most subject to wear.
  • Page 113 Tension d'emploi 750V Température d'utilisation -30°C to +75°C Matière Self-extinguishing thermoplastic, self-lubricating carbon brushes, galvanized steel Montage Outils nécessaires au montage www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 113/223...
  • Page 114 Outils nécessaires au démontage www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 114/223...
  • Page 115 A simple screwdriver only is necessary. An indicator showing the maximum wear tolerance etched body trolley. Check play wear rollers. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 115/223...

  • Page 116: High Speed Trolley

    Composants Mobilis Elite High speed trolley The high speed trolley shunts the electrical current in the Mobilis line to the mobile device requiring power for speeds > 100m/min. Description High speed trolleys have extra rollers to cross over junctions smoothly, even when travelling at high speeds or in very cold weather conditions.
  • Page 117 Références et variantes Disponible en version sans terre ? Disponible en version courbe ? Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 117/223...
  • Page 118 Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 118/223...
  • Page 119 Règle de montage 1 Provide adequate loop of cable so as not to impede the motion of the trolley www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 119/223...
  • Page 120 A simple screwdriver only is necessary. An indicator showing the maximum wear tolerance etched body trolley. Check play wear rollers. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 120/223...

  • Page 121: Cleaning Trolley

    Composants Mobilis Elite Cleaning trolley The cleaning trolley is designed to clean the conductors. Description Maintenance accessory used for the renovation of the conductors operating in a dusty environment, very humid environment, slight surface roughness of the conductors, projection of particles towards the line… The frequency of use of the cleaning trolley depends on the application.
  • Page 122 Fit into the line in either direction of assembling. Move by hand, using a cord, or coupled with the mobile device via a simple carrier ME1600. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 123 Maintenance Checking and replacing the scrubbing brushes regularly guarantees their effectiveness. Reference of the sets of replacement brushes: ME1356. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 123/223...

  • Page 124: Standard Carrier

    Standard carrier Element of mechanical link connection between the collector trolley and the mobile device requiring power. Description The standard carriers ensure the mechanical link between the collector trolley which travels inside the Mobilis Elite line and the mobile device requiring current.
  • Page 125 Données techniques Données techniques see References Encombrement Poids According to reference Température d'utilisation -30°C to +75°C Matière Zinc coated steel www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 125/223...
  • Page 126 +/- 50mm. Correct adjustment increases the operating life of trolley collector. Règle de montage 2 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 126/223...

  • Page 127: Carrier With Box

    Description The carriers with box ensure the mechanical link between the collector trolley which travels inside the Mobilis Elite line and the mobile device requiring current. They also provide an intermediary connection point between the collector(s) carried and the supply...
  • Page 128 Simple carrier compatible Disponible en version sans terre ? compatible Disponible en version courbe ? compatible Données techniques Données techniques see References www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 128/223...
  • Page 129 +/- 50mm. Correct adjustment increases the operating life of trolley collector. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 130 Règle de montage 2 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 130/223...

  • Page 131: Special Carrier For Long Transfer Element

    Composants Mobilis Elite Special carrier for long transfer element Maintains the trolley in the air during the interval between long transfer elements. Description Whenever space between the transfer elements is greater than 30mm, the use of long transfer elements and this special carrier is required: it maintains the trolley in the air (simple, double or triple) in the clearance between the long transfer elements.
  • Page 132 Adjust the carrier so that the trolley enters the transfer elements smoothly. Position the cables of the trolleys to limit the parasitic efforts. Limit traction springs much possible maximum operating life trolleys. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 132/223...
  • Page 133 Règle de montage 2 Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 133/223...

  • Page 134: Switching Finger

    Composants Mobilis Elite Switching finger End of travel electromechanical link stop. Description Located on one element of the line, it allows the overhead travelling crane provided with a cross-type sensor limit switch to detect a position line with other elements...
  • Page 135 To be positioned normally at each end of the line. Provide suitable space to allow the travelling crane to stop at full speed. Maintenance This element does not require any special maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 136: Set Of 5 Screws + Nuts 20A - 100A

    Composants Mobilis Elite Set of 5 screws + nuts 20A - 100A Replacement connection screws and nuts for 1 element, intensity 20A to 100A. Categorie Accessories Références et compatibilités Références et variantes ME1345 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 137: Set Of Feed Connection For 5Th Pole

    Composants Mobilis Elite Set of feed connection for 5th pole Screws and spacers for feeding connection 5th pole intensity 20 to 100A. Categorie Accessories Références et compatibilités Références et variantes ME1360 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 138: Set Of 10 Screws + 5 Nuts 130A

    Composants Mobilis Elite Set of 10 screws + 5 nuts 130A Replacement connection screws and nuts for 1 element 130A 5 poles. Categorie Accessories Références et compatibilités Références et variantes ME1357 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 139: Set Of Connection Screws 160A

    Composants Mobilis Elite Set of connection screws 160A Replacement connection part for 1 element 160A 5 poles. Categorie Accessories Références et compatibilités Références et variantes ME1353 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 140: Set Of Connections For 200A 5 Poles

    Composants Mobilis Elite Set of connections for 200A 5 poles Replacement connection part for 1 element 200A 5 poles. Categorie Accessories Références et compatibilités Références et variantes For elements 200A: ME1358, For 200A-TR elements: ME1358-TR www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 141: Set Of Connection Screws 200A

    Composants Mobilis Elite Set of connection screws 200A Replacement connection screws for phase and earth conductors on element 200A 5 poles. Categorie Accessories Références et compatibilités Références et variantes For elements 200A: ME1352, For 200A-TR elements: ME1352-TR www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 142: Set Of 4 Collector Brushes

    Composants Mobilis Elite Set of 4 collector brushes Replacement brushes for single 4-pole trolley type ME3043 and derivatives. Categorie Accessories Références et compatibilités Références et variantes ME1354 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 143: Set Of 5 Collector Brushes

    Composants Mobilis Elite Set of 5 collector brushes Replacement brushes for single 5-pole trolley type ME3051 and derivatives. Categorie Accessories Références et compatibilités Références et variantes ME1355 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 144: Brush For Simplified Trolley

    Composants Mobilis Elite Brush for simplified trolley Replacement brush for simplified trolley type ME2034. Categorie Accessories Références et compatibilités Références et variantes ME0306 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...

  • Page 145: Set Of 5 Cleaning Brushes

    Composants Mobilis Elite Set of 5 cleaning brushes Replacement brushes for single 5-pole cleaning trolley type ME4525 and derivative. Categorie Accessories Références et compatibilités Références et variantes ME1356 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 146: Set Of 2 Special Screws For Fixed Hangers

    Composants Mobilis Elite Set of 2 special screws for fixed hangers Converts a sliding hanger into a fixed hanger. Categorie Accessories Références et compatibilités Références et variantes ME1501 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 147: Set Of 2 Carrier Rings

    Composants Mobilis Elite Set of 2 carrier rings Replacement rings linking the chains of the trolley to the carrier. Categorie Accessories Références et compatibilités Références et variantes ME1359 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 148: Cone For Short Transfer Element

    Composants Mobilis Elite Cone for short transfer element Replacement cone for short transfer element. Categorie Accessories Références et compatibilités Références et variantes ME0188 Montage Règle de montage 1 Cut off mains voltage to the line. Remove the covering flange of transfer element using a flat screwdriver. Replace the cone making sure to insert all guiding studs of and the cone fully, remove the bridge maintaining the wings of the cone.

  • Page 149: Cone For Long Transfer Element

    Composants Mobilis Elite Cone for long transfer element Replacement cone for long transfer element. Categorie Accessories Références et compatibilités Références et variantes ME0189 Montage Règle de montage 1 Cut off mains voltage to the line. Remove the covering flange of transfer element using a flat screwdriver. Replace the cone making sure to insert all guiding studs of and the cone fully, remove the bridge maintaining the wings of the cone.
  • Page 151 Easy and quick clipped-on mounting of line into its SUSPENSIONS  Protection level IP23  Modular and interchangeable Mobilis Movit Presentation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 151/223...
  • Page 152 Reliability and mechanical resistance for exceptional service life while maintaining optimum characteristics  Simple logistics, maintenance, and dismounting. Mobilis Movit Presentation www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 152/223...
  • Page 153 See related section (Straight elements, feed boxes, hangers, accessories …) 7.DOWNLOADS Visit the website: http://catalogue.fels.fr/en/mobilis-movit/downloads (Consultation Sheet, Assembly Instructions, CAD File Package) 8.GUARANTEE Our equipment is guaranteed one year against any material or manufacturing defect recognized by ourselves. As we are not responsible for its installation and operation, our guarantee covers only replacement or repair (at our own choosing) of the part recognized to be defective.
  • Page 154 Validate suitability of the product to run in unfavorable environmental conditions (e.g. humid air flow, steam, frost…). A version with 600h resistance under saline mist is available. Please inquire. Mobilis Movit Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 155 If a Mobilis Movit line is used in an area open to the public, additional safety measures should be installed (protection level IP4X required according to EN60204-32). Mobilis Movit Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 156 Collector: with the safety pin system, it is not possible to insert a ground collector trolley incorrectly (on phase), leading to a phase-earth connection. 9. SPACE REQUIREMENTS : Mobilis Movit Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 157 Z at 40°C (Ω/m at 50Hz) 0, 000231 0, 000173 0, 000151 Under Fault condition: Icw 8,5kA/0,2s Ipk 17kA Mobilis Movit Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 157/223...
  • Page 158 100% LINE CALCULATION See related section (Data required for calculation, calculation method, charts...) ONLINE CALCULATION TOOL See http://www.fels.fr/extranet/ (Online calculation with intensity suggested based on data submitted) 14.COMPONENTS See related section (Straight elements, trolleys, feeding boxes...) Horizontal curves: Curvature radius<15m, please inquire 15.ASSEMBLY INSTRUCTIONS...
  • Page 159 Double collectors: replace a collector brush by a maintenance brush; fasten the cable to one of the maintenance collector. Mobilis Movit Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 160 Any arbitration shall be held in Strasbourg, even when several defendants are involved. Mobilis Movit Technical Data www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 161: Rail

    Standard Avantage n°1 Aluminum structure Avantage n°2 Stainless steel friction track Références et compatibilités Références et variantes References of the rails: www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 161/223...
  • Page 162 Tension d'emploi 750V Température d'utilisation -30°C to +55°C Calibre 315A, 450A, 630A Matière Aluminium, Stainless steel track, self-extinguishing PVC Envelope light grey www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 162/223...
  • Page 163 Position always the earth rail in the location the furthest away from the running beam. Always prepare the ends of the rails according instructions before making connections. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 163/223...
  • Page 164 T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 164/223...

  • Page 165: Connection

    Références et variantes MC1000 Données techniques Données techniques Length 80mm Poids 0,3 kg Calibre 315A, 450A, 630A Matière Aluminium and zinc coated steel www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 165/223...
  • Page 166 A connection requires preparation of the rail ends before it can be installed, to eliminate oxides present on the aluminium surface preserve quality contact over time. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 166/223...
  • Page 167 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 167/223...

  • Page 168: Covering Flange

    42 x 90 x 250 Poids 0,17 kg Tension d'emploi 750V Température d'utilisation -30°C to +55°C Calibre 315A, 450A, 630A Matière Self-extinguishing thermoplastic www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 168/223...
  • Page 169 Règle de montage 1 To be installed/dismounted on the line with mains voltage cut off. 1. Hang the base by its clips 2. Clip on the lid to lock. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 170 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 170/223...

  • Page 171: Feeding Box

    50 x 120 x 290 Poids 0,36 kg Tension d'emploi 750V Température d'utilisation -30°C to +55°C Calibre 315A, 450A, 630A Matière Self-extinguishing thermoplastic www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 171/223...
  • Page 172 'Lt' section taken into account equals half the length of the line. For more than one feeding point in line, please review the following graph for the required position of the points and related voltage drops. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 173 1. Fit on the connection 2.Open the feeding and position it on the connection 3. Pass the cables through the cable glands 3. Crimp cable stiffeners connect them connection Close feeding tighten cable glands. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 173/223...
  • Page 174 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 174/223...

  • Page 175: End-Cap

    Poids 0,14 kg Tension d'emploi 750V Température d'utilisation -30°C to +55°C Calibre 315A, 450A, 630A Matière Self-extinguishing thermoplastic, stainless steel Montage www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 175/223...
  • Page 176 To be positioned end of line. Provide enough space so as not to impede line expansion (minimum of 6cm for 50metres, minimum of 2.5cm 100metres). Règle de montage 1 To be installed/dismounted on the line with mains voltage cut off. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 176/223...
  • Page 177 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 177/223...

  • Page 178: Sliding Hanger

    Categorie Standard Avantage n°1 Self-alignment system Avantage n°2 Centre to centre clearance of 50mm between conductors Références et compatibilités www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 178/223...
  • Page 179 Références et variantes Données techniques Données techniques Centre axis distance of the poles: 50mm Encombrement Poids see table www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 179/223...
  • Page 180 Position the first sliding hanger at 0.5m of the line end, then every 2 metres. Extra sliding hanger on the last element of the line if line length >3m. Règle de montage 1 Simple clip-on of the rails between the sides of the sliding hanger. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 180/223...
  • Page 181 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 181/223...

  • Page 182: Fixing Clamp

    Categorie Standard Avantage n°1 Easily removable Avantage n°2 Visible from far away Références et compatibilités Références et variantes MC2600 Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 182/223...
  • Page 183 (see related section needed). Règle de montage 1 Stick pair clamps both sides profile supporting sliding hanger provide fixed hanger. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 183/223...
  • Page 184 Règle de montage 2 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 184/223...
  • Page 185 Règle de montage 3 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 185/223...

  • Page 186: Collector

    Références et variantes The ordering references are as follows. Please note that the earth collector shall be doubled as required by Standard EN60204-32 §13.8.2. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 187 Horizontal position not feasible with rail slot sideways. Average operating life: 10.000 km depending on alignment quality. Operating life brushes until replacement: 2000 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 187/223...
  • Page 188 To be positioned ideally horizontally. See positioning tolerances in the section 'collector bracket'. The position of the cable should lower quality contact. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 188/223...
  • Page 189 Collector 60A: Loosen and take the connection screw out of the brush, Remove the worn brush, fit the new one proceed reverse order. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 190 Image maintenance www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 190/223...

  • Page 191: Collector Bracket

    Avantage n°2 Same fixing for all models Références et compatibilités Références et variantes The following references are available. Références et variantes www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 191/223...
  • Page 192 Règle de montage 1 Use M8 bolts. Install in accordance with the following instructions. Adjust the height position taking into account the future wear of brushes. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...
  • Page 193 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 193/223...

  • Page 194: Bracket

    Available for beam wings of thickness 6 to 32mm Avantage n°2 2 lengths available Références et compatibilités Références et variantes The following references are available. Références et variantes www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 194/223...
  • Page 195 Number and position according to the placement rules for sliding hangers. Règle de montage 1 Align the assembling holes of the sliding hangers in parallel to the travel path. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 196 Règle de montage 2 Maintenance This element does not require any particular maintenance. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 196/223...

  • Page 197: Expansion Joint

    315A and 450A. The number and the positions of the expansion joints depend on the installation's features and can be determined using our on-line calculator at www.fels.fr. It is mounted like a rail element, compact item with height lower than that of the feed box, nominal length of 4 m to be adjusted according to the assembling temperature.
  • Page 198 Règle de montage 1 To be adjusted imperatively according to the calculation specific to the installation. Always place at mid-point between two fixed hangers. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...
  • Page 199 This element does not require any particular maintenance. Check periodically the continuity of the earth on the expansion joint: once every years. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 199/223...

  • Page 200: Circuit Interruption Element

    Can be fitted as easily as a straight element Avantage n°2 Visual location of the interruption position from the outside Références et compatibilités Références et variantes www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 200/223...
  • Page 201 Données techniques Données techniques www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 201/223...
  • Page 202 Regular inspection is required to check the insulation between the conductors of the same pole on both sides of the interruption, at least once year. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...

  • Page 203: Cable Eye Stiffeners For Feed

    MC8095 cables 95mm², Ref. MC8070 cables 70mm², Ref. MC8050 cables 50mm². Données techniques Données techniques Cable eye stiffeners for copper cable. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 203/223...

  • Page 204: Brush For Preparation Of Rail Ends

    Narrow to facilitate passage between 2 rails Avantage n°2 Contributes to connection quality optimization Références et compatibilités Références et variantes Ref. MC8010 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 204/223...

  • Page 205: Contact Lubricant

    Règle de montage 1 To be coated on aluminium surfaces for protection after brushing and wiping. Do not put on the stainless track of the rails. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

  • Page 206: Replacement Brush For Collector

    Collector 60A: Loosen and remove the connection screw of the brush. Remove the brush, replace it, and proceed to the reverse operation. Maintenance Replacement of the brush: the limit of wear is the base of the chamfer. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017...

  • Page 207: Single Cleaning Collector

    50 x 330 x 580 Poids 3,8 kg Montage Règle d'installation 1 simple collector 200A installed, symmetrical positioning relation with collector bracket. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 207/223...
  • Page 208 (abrasive grit No. 120) to improve the surface condition of the tracks. Once the lines have been cleaned up, the cleaning collector must removed this system designed over long distances. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 208/223...

  • Page 209: Cleaning And Grindding Brushes

    (abrasive grit No. 120) to improve the surface condition of the tracks. Once the lines have been cleaned up, the collector brush must back this system designed over long distances. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 209/223...

  • Page 210: Kit For Unclipping Sliding Hangers

    Avantage n°1 Allows easy disassembling Avantage n°2 Saves time Références et compatibilités Références et variantes Ref. MC8025 Données techniques Matière Self-extinguishing thermoplastic www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 210/223...

  • Page 211: Ice Shield

    Composants Mobilis Movit Ice shield Prevents formation of white frost on the track. Description Increases the temperature of the rail by means of a heating cable, thereby preventing the formation of white frost on the surface of track. Categorie Accessories Avantage n°1 Prevents formation of white frost Avantage n°2...

  • Page 213: Mobilis Elite 200A Non -Reduced Earth

    Description Mobilis Elite 200A elements with the same copper section for the phase conductors and the protection conductor (Earth) have been no longer supplied as standard version since 2008: they have been replaced by the 200A-TR version with a reduced earthing section, as authorized by standards.
  • Page 214 Règle de montage 1 1. Insert the lines in the sliding hangers, 2. Connect the lines Règle de montage 2 www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 214/223...
  • Page 215 Règle de montage 3 Maintenance See the rules of maintenance of the lines www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 215/223...

  • Page 216: Obsolete Range Mobilis Ce

    Historical range Avantage n°1 Intensities 40A, 60A, 100A, 130A, 200A, color gray anthracite white (High temperature range). Avantage n°2 High impact resistance www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 216/223...

  • Page 217: Trolley With Cable Mobilis Ce

    Encombrement L x H x Z 46 x 103 x 220 Calibre du chariot Tension d'emploi 500V Température d'utilisation -20°C to +75°C www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 217/223...

  • Page 218: Standard Brushes For Carriage Mobilis Ce

    Température d'utilisation -20°C to +55°C Calibre Matière self-lubricating carbon brushes Montage Règle d'installation 1 S'assurer état pistes frottement conducteurs avant remplacer balais. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 218/223...

  • Page 219: Brushes Of Trolleys Mobilis Ce For Lines With Transfer Element

    Température d'utilisation -20°C to +55°C Calibre Matière self-lubricating carbon brushes Montage Règle d'installation 1 S'assurer état pistes frottement conducteurs avant remplacer balais. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 219/223...

  • Page 220: Remote Control Brush Mobilis Ce

    Encombrement L x H x Z 28 x 20 x 5 Tension d'emploi Température d'utilisation -20°C to +55°C Calibre Matière self-lubricating carbon brushes www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 220/223...

  • Page 221: Obsolete Range Mobilis Unit

    Categorie Historical range Avantage n°1 Intensities 250A and 320A Avantage n°2 Aluminium rails with stainless track and single-arm collectors www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 221/223...

  • Page 222: Brush For Pantograph 100A Mobilis Unit

    50 x 45 x 5 Calibre du pantographe 100A Tension d'emploi 500V Température d'utilisation -20°C to +55°C Matière self-lubricating carbon brushes www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité le 04/01/2017 Page 222/223...
  • Page 223 être imputés. En cas de litige, les tribunaux de Strasbourg sont seuls compétents, même en cas de pluralité des défendeurs. www.fels.fr T +33(0)3 88 67 10 60 F +33 (0)3 88 55 01 79 Edité...

This manual is also suitable for:

Mobilis movit

Table of Contents
