golmar Rock Series Installation Manual

golmar Rock Series Installation Manual

Video kit 3 + coax 4 + tp
Hide thumbs Also See for Rock Series:
Table of Contents

Advertisement

Quick Links

Download this manual
Cód. 50124602
Video Kit
3 + coax
4 + tp
Rock Series
Installation manual
T801EN rev.0120

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rock Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for golmar Rock Series

Summary of Contents for golmar Rock Series

  • Page 1 Cód. 50124602 Video Kit 3 + coax 4 + tp Rock Series Installation manual T801EN rev.0120...

  • Page 2: Table Of Contents

    INTRODUCTION First of all we would like to thank and congratulate you for the purchase of this product manufactured by Golmar. The commitment to reach the satisfaction of our customers is stated through the ISO-9001 certification and for the manufacturing of products like this one.

  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS O Install or modify the equipment without the power connected O The installation and handling of these equipments must be performed by authorised personnel O The entire installation must be at least 40 cm . away from any other installation O With power supply: wDo not use excessive force when tightening the connector screws.

  • Page 4: System Operation

    Plus: Description, installation, configuration and programming of the monitor (see manual TTEKNA PLUS "Code 5012 2337 ") available in: https://doc.golmar.es/search/manual/5012 2337 O Telephone T540 Uno SE: Description, installation, configuration and programming of the telephone (see manual T540 UNO SE "Cód.50122 ") disponible en:...

  • Page 5: Door Panel Installation

    DOOR PANEL INSTALLATION ositioning of the embedding 1850 1650 1450 Drill one hole in the wall so that the upper part of the doorpanel is installed at a height of 1,65m. Drill dimensions are: 131(Width) x 131(Height) x 45(Depth) mm. door panel has been designed to resist several environmental conditions.

  • Page 6: Door Panel Configuration

    DOOR PANEL INSTALLATION oor panel configuration. door panel is provided with microswitches (SW1) a jumper (JP1) in its rear part; Their functions are described below. It allows the connection of an alternative current door opener; page shows the connection diagram. It allows the connection of a direct current door opener;...

  • Page 7: Final Adjustments

    DOOR PANEL INSTALLATION inal adjustments If, when using the device, audio volume is inadequate, it is necessary to carry out some adjustments, as shown in the picture. The camera is equipped with an horizontal and vertical orientation device. If orientation is not correct, change it. Fix the doorpanel to the...

  • Page 8: Descrip Tion

    Alta tensión. No abrir la tapa. Manipular sólo por personal l ser vicio técnico. WARNING. GOLMAR S.A High Voltage. Don´t open cover C/ Silici, 13 Handle only by technical service 08940 - SPAIN 1 2 3 4 5 6 7 8 9 10 Advanced programming LED.

  • Page 9: Function Buttons

    MONITOR DESCRIPTION unction buttons. One long press for 2 seconds: with the monitor in standby and the handset on the hook, this activates ringtone volume mode, with a tone indicating the volume selected. Then each long 2- second press (before 5 seconds elapse) selects a volume level: maximum, no volume 'night mode,' minimum and medium, and so on (carousel mode).

  • Page 10: Sw1 Dip Switch (Quick Prog. Mode)

    1 2 3 4 5 6 7 8 +18V White + Blue Data Green White + Brown 1 2 3 4 5 6 7 8 Male connector Female connector Brown NOT : E For this type of installation, contact our Golmar technical support department.

  • Page 11: End Of Line Resistor

    MONITOR ADJUSTMENTS se of the end of line jumper The end of line jumper is located in CN4 connector, in the rear part of the monitor In systems with twisted pair, the end of line jumper is located in the EL562 module (see next paragraph) Do not remove jumper in those monitors where the video cable end is located.

  • Page 12: Installing In A Wall Mounting Connector

    MONITOR INSTALLATION ositioning the wall mounting connector. The top of the connector must be positioned at a height of 1.60 m. The minimum distance between the sides of the connector and the closest object must be 5 cm. Avoid dusty or smoky environments or locations near sources of heat. 1.60m ixing the monitor´s wall mounting connector to the wall.

  • Page 13: Installing In An Embedding Box

    MONITOR INSTALLATION ocation of the embedding box. Make a hole in the wall to position the top of the universal embedding box at a height of 1.60 m from the ground. The minimum distance between the sides of the embedding box and the closest object must be 5 cm.

  • Page 14: Programming

    MONITOR PROGRAMMING rogramming the Tekna Plus monitors MEMBER Monitors must be programmed only in case of installed parallel units or if there are general door panels. Find the configuration switch located in the rear part of the door panel and set number to door panel will produce a tone, indicating that it has...

  • Page 15: Quick Programming

    MONITOR PROGRAMMING Coming from previous page To programme it as Slave without video (in call), press button the status LED will blink (green) once. If button is pressed again, the monitor will return to being programmed as Slave with video (in call) and the status LED will blink (green) twice.
  • Page 16 MONITOR PROGRAMMING dvanced programming of Tekna-S Plus monitor Advanced programming enables the monitor's default settings to be changed: Turn off the monitor to be programmed (press button for 3 seconds). Once switched off, press button to access of advanced 'Menu 1' programming and the programming LED will illuminate.
  • Page 17 MONITOR PROGRAMMING Coming from previous page Men 2: Then adjust the settings as required: Button has no function No function. Changing the function of button Intercom function default function Select the function to assign to button : Each press on button selects a different function which is indicated with blinks (1 to 4 blinks) of the programming LED and in the following order: auxiliary device 'A1' activation, call to secondary guard unit, second...
  • Page 18 MONITOR PROGRAMMING Coming from previous page Men 3: Then adjust the settings as required: - Rep eating the ringtones One repeat (default setting). To 'repeat the ringtone' on the monitor: Each press on button selects a repeat of the ringtones which is indicated with blinks (1 to 3 blinks) of the programming LED and in the following order: 1, 2 or 3 repeats.
  • Page 19 MONITOR PROGRAMMING Coming from previous page Men 4: Then adjust the settings as required: - Setting to the default setting " ", all the monitor's advanced programming options Setting to the 'default setting': Press button and the monitor will indicate with two audible tones that all of the options of the monitor's advanced programming (pp.

  • Page 20: Description

    TELEPHONE DESCRIPTION escrip tion of T- 40 Plus telephone. Telephone handset. Speaker grille Microphone hole. Subjection hole. Telephone cord connectors. Function / programming buttons. Telephone status LED: Standby: LED illuminated red. Call: LED illuminated green (master telephone). Communication: LED illuminated green. Night mode: LED blinking red.

  • Page 21: Function Push Buttons

    TELEPHONE DESCRIPTION unction buttons. One short press for 1 second, with the telephone in standby and the handset on the hook, activates ringtone volume mode, with a tone indicating the volume selected. Then each 1 second press (before 5 seconds elapse) selects a ringtone volume level and so on (in carousel mode) with the following selections (maximum, medium, minimum and no volume “night mode”.

  • Page 22: Sw1 Dip Switch

    TELEPHONE DESCRIPTION escription of the SW1 DIP switch (quick programming mode). The SW1 DIP switch is located in the central part of the circuit, accessible by opening the telephone. It enables the telephone to be configured as master/slave and an address to be assigned to it.

  • Page 23: Telephone Installation

    TELEPHONE INSTALLATION ix the telephone to the wall. In order to connect the phone and to fix it to the wall, it is necessary to open it. Put a flat screwdriver in the proper openings as shown in the picture and prise them open. Do not install the device near heat sources, in places with dust or fumes.

  • Page 24: Programming

    TELEPHONE PROGRAMMING rogramming the T- 40 Plus SE telephones. Find the configuration switch located in the rear part of the door panel and set number 2 to ON. The door panel will produce a tone, indicating that it has entered program mode. In systems with more than one door panel, this operation must be carried out only in the main door panel of each building.

  • Page 25: Quick Programming

    TELEPHONE PROGRAMMING escription of the SW1 DIP switch (quick programming mode). The SW1 DIP switch is located in the central part of the circuit, accessible by opening the telephone. It enables the telephone to be configured as master/slave and an address to be assigned to it.
  • Page 26 TELEPHONE PROGRAMMING Coming from previous page ctivating / deactivating the doctor mode function: Doctor mode not activated default setting The doctor mode function enables the door release to be activated automatically 5 seconds after “ ” making a call from the door panel without having to establish communication or press door release button .
  • Page 27 TELEPHONE PROGRAMMING Coming from previous page Men 3: Then adjust the settings as required: - Repe ating the ringtones One repeat default setting To repeat the ringtone on the telephone: Each press on button “ ” selects a repeat of the ringtones which is indicated with blinks (1 to 3 blinks) of the status LED and in the following order: 1, 2 or 3 repeats.

  • Page 28: Programming Backbone Code

    TELEPHONE PROGRAMMING Coming from previous page - Acce ssing "Men 1" o r exiting programming mode To access press button , and the status LED will blink once (see p. To exit programming mode, press button for 3 seconds, and the status LED will turn off. Turning on the telephone when exiting programming When exiting advanced programming mode, the telephone will be turned off: Press button...
  • Page 29 To carry out this operation, do as follows. NOT : E For this type of installation, please contact the technical trade department of Golmar. ackbone code programming. The general door panel enters programming mode after pressing the key button and inserting the installer secret code factory value 1315).

  • Page 30: Video System With Coaxial Cable

    ne or more accesses, alternative current lock release and coaxial cable. Tekna-S Plus Tekna-S Plus T540 Plus SE Tekna-S Plus Tekna-S Plus D4L-PLUS M =Master. S =Slave. PVS-295SE FA-805 230 110 0 out- out+ Main Vca. Lock release...

  • Page 31: Installation Diagrams

    INSTALLATION DIAGRAMS Tekna-S Plus Example of cascade connected devices Remove N4 connector jumper from all the monitors see page ), except from the one in which the coaxial cable end is located without using output). xample of distribution connected devices Remove the end of line jumper from all the distributors (JP1) and monitors...
  • Page 32 ne or more accesses, alternative current lock release and twisted pair. Tekna-S Plus Tekna-S Plus T540 Plus SE EL562 EL562 Tekna-S Plus Tekna-S Plus EL562 EL562 D6L-Plus/2H M =Master. P =Principal. S =Slave. S =Secundario. PVS-295SE FA-805 230 110 0 out- out+ Main...
  • Page 33 INSTALLATION DIAGRAMS Tekna-S Plus Example of cascade connected devices. Remove jumper of all EL562 circuits EL562S from monitors see page 50 except from the one in which the twisted pair end is located Example of distribution connected devices. Remove the end of line jumper from all the distribu tors (JP1)

  • Page 34: Video System With Twisted Pair

    INSTALLATION DIAGRAMS ock release connection. a.c. lock release d.c. lock release FA-805 FA-805 PVS-295SE PVS-295SE 230 110 0 Main Main In order to open the door in any moment by means of an external button, connect the button between door panel terminals 'CV1' and 'CV2’...

  • Page 35: Optional Connections

    OPTIONAL CONNECTIONS uxiliary devices activation with Tekna-S Plus monitor. To activate auxiliary devices the use of a SAR-12/24 relay unit will be required. If this device is shared for all the Tekna Plus monitors, link their A1 terminal and use just one relay unit. In case that each monitor has its own application use a SAR-12/24 relay unit for each monitor and don't link the A1 monitor terminals.

  • Page 36: 2Nd Camera Activation

    OPTIONAL CONNECTIONS ctivation of a second camera. To activate a second camera, it is necessary to use an SAR-12/24 relay unit and to change the configuration of function button on the monitor, as described on p. To activate this function, press the button configured for this function on the monitor during an auto- spy, call or communication process.

  • Page 37: Intercom

    OPTIONAL CONNECTIONS ntercom function. The Tekna S Plus monitor and T-540 Plus SE telephone features as standard an intercom function between two points in the same apartment. To enable this function, the following is necessary: - One of the monitors needs to be configured as master and the other as slave with intercom, as described on p ages .

  • Page 38: Aux. Devices Activation T 40Plus 5 Se

    OPTIONAL CONNECTIONS uxiliary devices activation with T- 40 Plus SE telephone. To activate auxiliary devices the use of a SAR-12/24 relay unit will be required. If this device is shared for all the T- 40 Plus SE telephones, link their 'A1' terminal and use just one relay unit. In case that each telephone has its own application use a SAR-12/24 relay unit for each telephone and don't link the 'A1' telephone terminals.

  • Page 39: Troubleshooting

    TROUBLESHOOTING Your device does not work Make sure that power supply output tension between terminals '–' remains between 17,5 18,5V .c. Otherwise, disconnect the power supply from the system and measure tension again If it is correct, there is a short circuit in the installation.

  • Page 40: Compliance

    Sistemas de comunicación S.A. golmar@golmar.es www.golmar.es GOLMAR S.A. C/ Silici, 13 08940- Cornellá de Llobregat SPAIN Golmar se reserva el derecho a cualquier modificación sin previo aviso. Golmar reserves the right to make any modifications without prior notice.
