S ECTION ONE | DE SCR IP TION

TERMINOLOGY

12
16
1 CONTROL PENDANT
2 EMERGENCY STOP BUTTON & KEY
3 TRAINING CARD
4 GUARD RAIL
5 GATE
6 HANDBOOK
7 PLATFORM
8 100V AND 240V CHARGER LEADS
9 SCISSOR PACK
POP-UP PUSH 6 ECO OPERATOR'S SAFETY AND MAINTENANCE HANDBOOK (v.0.4.0409)
5
4
6
8
9
10
11
14
13
10 MAIN LIFT CYLINDER
11 MAINTENANCE PROPS
12 WINCH POINT
13 FORKLIFT POCKET (1 OF 4)
14 CHASSIS
15 BUBBLE SPIRIT LEVEL
16 BRAKE (1 OF 2)
17 BATTERY
18 HYDRAULIC TANK
1
2
3
7
15
18
17
20
24
26
25
19 HYDRAULIC PACK
20 BATTERY CHARGER
21 CHASSIS PLATE
22 BATTERY CHARGER SOCKET
23 BATTERY CHARGING INDICATOR
24 BATTERY CONDITION METER AND BUTTON
25 MAINTENANCE ISOLATOR SWITCH
26 WARNING BUZZER
27 EMERGENCY LOWERING VALVE
19
21
22
23
27
