Smart Visu Server
Further start-up takes place via SV-Control. The progress of start-up can be seen live in SV-Home.
For more details about further start-up steps and data import, please refer to the technical documentation, which can
be found on the server (SV-Control) or on the Internet at www.jung.de.

7 Disposal of batteries

This device includes an integrated battery.At the end of its useful life, dispose of the device
together with the battery in accordance with the environmental regulations. Do not throw device
into household waste. Consult your local authorities about environmentally friendly disposal.
According to statutory provisions, the end consumer is obligated to return the device.

8 Accessories

IP interface
IP router

9 Technical data

Rated voltage:
Power consumption:
Ambient temperature:
Storage/transport temperature:
LAN:
USB:
Dimensions:
Plug-in power supply
Primary voltage:
Mains frequency:
Rated current:
Secondary voltage:
Protection class:
Length of connected cable:

10 Legal information

Philips and Hue are registered trademarks of Koninklijke Philips Electronics NV.
This product contains Open Source software components, which are subject to the conditions of Copyright and/or the
license agreements of third parties. The license information is located on the Smart Visu server.

11 Warranty

The warranty follows about the specialty store in between the legal framework as provided for by law.
0024074401
Fig. 4: SV-Control
typical 3 W, max. 7 W
RJ45-socket (10/100 Mbit/s Fast Ethernet)
124 x 72 x 31 mm (without mounting plate)
124 x 92 x 40 mm (with mounting plate)
AC 100 ... 240 V ~
4 / 4
IPS 300 SREG
IPR 300 SREG
DC 12 V SELV
–5 ... +45 °C
–25 ... +70 °C
USB 2.0 Host
50 / 60 Hz
max. 1 A
DC 12 V SELV
II
1.5 m
11.08.2020
