Oriental motor SCM Series Operating Manual

O P E R AT I N G M A N UA L
AC Speed Control Motor
SCM Motor
Introduction
„ Before using the motor
„
Only qualified personnel should work with the product. Use the product correctly
after thoroughly reading the section "Safety precautions. " In addition, be sure to
observe the contents described in warning, caution, and note in this manual.
The product described in this manual has been designed and manufactured to be
incorporated in general industrial equipment. Do not use for any other purpose.
Oriental Motor Co., Ltd. is not responsible for any damage caused through failure to
observe this warning.
„ Operating manuals for the product
„
Operating manuals for this product are listed below.
• • SCM Motor Connector type OPERATING MANUAL (this document)
This manual explains the motor functions and how to install the motor, among others.
• • OPERATING MANUAL for each Series (supplied with the speed
controller)
This manual explains the function, installation and connection methods,
troubleshooting, and others for the speed controller.
Safety precautions
The precautions described below are intended to prevent danger or injury to the
user and other personnel through safe, correct use of the product.
Please read and understand these precautions thoroughly before using the product.
Handling the product without observing the instructions
WARNING
that accompany a "WARNING" symbol may result in serious
injury or death.
Handling the product without observing the instructions
CAUTION
that accompany a "CAUTION" symbol may result in injury or
property damage.
The items under this heading contain important handling
Note
instructions that the user should observe to ensure safe use
of the product.
Description of : Indicates "prohibited" actions that must not be performed.
graphic symbols
: Indicates "compulsory" actions that must be performed.
• Do not use the product in explosive or corrosive environments, in the
presence of flammable gases, locations subjected to splashing water, or
near combustibles. Doing so may result in fire, electric shock or injury.
• Do not transport, install the product, perform connections or inspections
when the power is on. Always turn the power off before carrying out these
operations. Failure to do so may result in electric shock or equipment damage.
• Do not use the electromagnetic brake of the motor as a safety brake.
Take safety measures other than the electromagnetic brake. Failure
to do so may result in injury or damage to equipment.
• Use an electromagnetic brake motor in an application of vertical drive
such as elevating equipment. If a motor without an electromagnetic
brake is used, the moving part may drop. This may result in injury or
damage to equipment.
• Do not machine or modify the connection cable. Doing so may result
in electric shock or fire.
• Do not forcibly bend, pull or pinch the cables. Doing so may result in
fire and electric shock.
• Do not touch the motor or speed controller when conducting
insulation resistance measurement or dielectric strength test.
Accidental contact may result in electric shock.
• Do not disassemble or modify the motor and gearhead. This may cause
electric shock or injury.
• Only qualified and educated personnel should be allowed to perform
installation, connection, operation and inspection/troubleshooting of the
product. Handling by unqualified and uneducated personnel may result
in fire, electric shock, injury or equipment damage.
• The motor is Class І equipment. When installing the motor, ground the
Protective Earth Terminal of the motor. Failure to do so may result in
electric shock.
• Keep the input power voltage within the specified range. Failure to do so
may result in fire or electric shock.
HM-9421-2
WARNING
Thank you for purchasing an Oriental Motor product.
This Operating Manual describes product handling procedures and safety
precautions.
• Please read it thoroughly to ensure safe operation.
• Always keep the manual where it is readily available.
• Use a motor, gearhead and speed controller only in the specified
combination. An incorrect combination may cause in fire, electric shock
or equipment damage.
• Always turn off the power before performing maintenance/inspection.
Failure to do so may result in electric shock.
• Do not use the motor, gearhead beyond its specifications. Doing so
may result in electric shock, injury or damage to equipment.
• Do not touch the motor, gearhead during operation or immediately
after stopping. The surface is hot and may cause a skin burn(s).
• Keep the area around the motor free of combustible materials. Failure
to do so may result in fire or a skin burn(s).
• Do not leave anything around the motor that would obstruct
ventilation. Doing so may result in damage to equipment.
• Do not carry the product by holding the motor, gearhead output
shaft or any of the cables. Doing so may result in injury.
• Do not touch the motor output shaft (tip or pinion) with bare hands.
Doing so may result in injury.
• When assembling the motor (pinion shaft) with the gearhead,
exercise caution not to pinch your fingers or other parts of your body
between the motor and gearhead. Injury may result.
• When installing the motor, gearhead in the equipment, exercise
caution not to pinch your fingers or other parts of your body
between the equipment and motor or gearhead. Injury may result.
• Do not touch the rotating part (output shaft) while operating the
motor. Doing so may result in injury.
• When an abnormality is noted, turn off the power immediately. Failure to
do so may result in fire, electrical shock or injury.
• Securely install the motor, gearhead to their respective mounting
plates. Inappropriate installation may cause the motor, gearhead to
detach and fall, resulting in injury or equipment damage.
• Provide a cover on the rotating part (output shaft). Failure to do so
may result in injury.
• Securely install the load on the motor and gearhead output shaft.
Inappropriate installation may result in injury.
• Be sure to ground the motor and speed controller to prevent them
from being damaged by static electricity. Failure to do so may result in
fire or damage to equipment.
• The motor surface temperature may exceed 70 °C (158 °F)
even under normal operating conditions. If the operator
is allowed to approach a running motor, attach a warning
label as shown in the figure in a conspicuous position.
Failure to do so may result in skin burn(s).
Precautions for use
This section covers limitations and requirements the user should consider when
using the product.
z Be sure to match the output power and power supply voltage
when combining a motor and speed controller
z Connecting the motor and speed controller
Use a connection cable (sold separately) when extending the wiring distance
between the motor and the speed controller.
z Use an electromagnetic brake motor in an application of vertical
drive such as elevating equipment
When the motor is used in an application of vertical drive such as elevating
equipment (lifting and lowering device), use an electromagnetic brake motor so that
the load can be held in position.
z Caution when using under low temperature environment
When an ambient temperature is low, since the load torque may increase by the
viscosity increment of the oil seal or grease, the motor starting may take a long time
or the motor rotation speed may fall. However, if the operation is continued for a
while, the oil seal or grease will be warmed up, and the motor can be driven at the
normal rotation speed.
WARNING
CAUTION
Warning
label
1
