SECTION 6-lnterlocks
AKR breakers are equipped with safety interlock devices
that are requi red by I ndustry Standards and Certifyi ng Au­
thorities. I nterlock devices for special applications are also
available as options. The standard interlock devices de­
scribed below are used only on drawout breakers. Station­
ary breakers h ave no required interlocks.
Caution m ust be taken to ensure that any interlock lever is
not bent and caused to not function. All interlocks should be
operated to c onfirm that they function as required.
6 . 1 RACKING MECHANISM I NTERLOCK
The function of the racking mechanism interlock is to
prevent the breaker from moving from the CONN ECTED
position before the breaker is in the OPEN position.
The racking mechanism d rive shaft is located behind
the RACKING SCREW cover shown in Fig. 1 4A. This
cover m ust be slid to the right to gain access to the d rive
shaft as shown in Fig. 1 48 . When the RACKING SCREW
cover preventing it from being o pened . This l i n k is d riven
by the motion of the OPEN/CLOSED indicator as shown in
Fig. 1 5.
CAUTION!
Prior to m oving rack screw cover over to attach
racking wrench push the manual trip button above the cover.
This will ensure that the breaker is open. Also read breaker
position flag to confirm that breaker is open.
Compartment door should be closed and latched when
racking a breaker from the connect position.
The T R I P button also en gages with the RAC K I N G
SCREW cover in both the O P E N and CLOSED positions.
Therefore , the T R I P button must be pushed in before the
cover can be opened. This will open the breaker if it was
closed and also depress the OPEN/C LOSED lin kage
d isc ussed above.
When the RACKI N G SCR EW cover is open it holds the
TR I P button i n . Th is keeps the breaker trip-free so a
mechanism closing cycle wi ll not cause contact movement
especially when the breaker is being racked in or out.
CAUTION!
Use only the proper racking m echanism
wrench for racking the breaker in or out, otherwise the
trip-free interlock featu re may not function .
FIG. 1 4A - RACKING SCREW
FIG. 1 4B
1 5
